Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative and affordable solutions to the vast range of
problems that confront the video, audio, presentation, and broadcasting
professional on a daily basis. In recent years, we have redesigned and upgraded
most of our line, making the best even better! Our 1,000-plus different models now
appear in 11 groups1
Congratulations on purchasing your Kramer 713 Video-Audio Line Transmitter and
714 Video-Audio Line Receiver which are ideal for:
that are clearly defined by function.
•Remote monitoring for CCTV, medical and schools
•Existing facilities with TP cable already installed
•Teleconferencing in offices and hospitals using existing intercom or
telephone wiring
•Security systems
There are three models of the 714 available that support different distances:
•714-05 up to 600m (2000ft)
•714-10 up to 1000m (3000ft)
•714-15 up to 1600m (5300ft)
All references to the 714 in this manual apply to all three models.
The package includes:
•713 Video-Audio Line Transmitter and 714-05/714-10/714-15 Video-Audio
Line Receiver
•Two power adapters (12V DC output)
•This user manual2
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:
Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7: Scan
Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack
Adapters; GROUP 11: Sierra Products
2 Download up-to-date Kramer user manuals from http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
2
2 Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
•Review the contents of this user manual
•Use Kramer high performance, high resolution cables1
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.
1 The complete list of Kramer cables is available from http://www.kramerelectronics.com

Overview
3
3 Overview
The 713 and 714 are a TP (Twisted Pair) transmitter and receiver for composite
video and unbalanced stereo audio signals. The 713 transmitter converts composite
video and stereo audio into a Twisted Pair (TP) signal and the 714 receiver
converts the TP signal back to composite video, stereo audio and also provides an
S/PDIF digital audio output.
The 713/714 feature:
•A system range of up to 1600m (5300ft), depending on the model
•Audio transmission in broadcast quality digital audio format (48kHz/24bit)
•Automatic audio and video equalization (EQ) control (714)
The 713 and 714 are part of the Kramer TOOLS™ family of compact high-quality
and cost effective solutions which are fed from an external 12V DC source, making
them suitable for field operation.
To achieve the best performance:
•Connect only good quality connection cables, thus avoiding interference,
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low quality cables)
•Avoid interference from neighboring electrical appliances and position your
Kramer TOOLS™ away from moisture, excessive sunlight and dust
3.1 Shielded Twisted Pair/Unshielded Twisted Pair
We recommend that you use Shielded Twisted Pair (STP) cable. There are
different levels of STP cable available, and we advise you to use the best quality
STP cable that you can afford. Bear in mind, though, that we advise using STP
cables where possible, since the compliance to electromagnetic interference has
been tested using STP cables.
Although Unshielded Twisted Pair (UTP) cable might be preferred for extended
distance applications, the UTP cable should be installed as far as possible from
electric cables, motors, and so on, which tend to create electrical interference.
However, since the use of UTP cable might not conform to electromagnetic
standards, Kramer does not commit to meeting the standard with UTP cable.
Note: There is no requirement and we do not recommend the use of skew-free
cable.
3.2 Power Connect
The Power Connect™ feature does not apply to the 713 and 714.

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Defining the 713/714 Video-Audio Line Transmitter/Receiver
4
4 Defining the 713/714 Video-Audio Line Transmitter/Receiver
This section defines the:
•713 Video-Audio Line Transmitter (see Section 4.1)
•714 Video-Audio Line Receiver (see Section 4.2)
4.1 Defining the 713 Video-Audio Line Transmitter
Figure 1 and Table 1 define the front and rear panels of the 713 Video-Audio Line
Transmitter.
Figure 1: 713 Video-Audio Line Transmitter Front and Rear Panels
Table 1: 713 Video-Audio Line Transmitter Front and Rear Panel Features
# Feature Function
1 ON LED Lights green when the unit is powered on
2 VIDEO IN BNC Connector Connect to the composite video source
3 LINE OUT RJ-45 Connector Connect to the LINE IN RJ-45 connector on the 714 using
CAT 5 cable (see Figure 2)
4
AUDIO IN
LEFT RCA
Connector
Connect to the left channel of the unbalanced stereo audio
source
5 RIGHT RCA
Connector
Connect to the right channel of the unbalanced stereo
audio source
6 12V DC Connector Connect to the supplied power adapter, center pin positive

Defining the 713/714 Video-Audio Line Transmitter/Receiver
5
4.2 Defining the 714 Video-Audio Line Receiver
Figure 2 and Table 2 define the front and rear panels of the 714 Video-Audio Line
Receiver.
Figure 2: 714-05 Front and Rear Panels
Table 2: 714-05/714-10/714-15 Front and Rear Panel Features
#
Feature
Function
1 LINK LED V LED Lights green when video link from the 713 is established
2 A LED Lights green when audio link from the 713 is established
3 MANUAL EQ. Buttons + Press to increase the signal equalization
4 – Press to decrease the signal equalization
5 AUTO EQ. Button Press to reboot the device and set the equalization
automatically
6 ON LED Lights green when the unit is powered on
7 VIDEO OUT BNC Connector Connect to the composite video acceptor
8 LINE IN RJ-45 Connector Connect to the LINE OUT RJ-45 connector on the 713
using CAT 5 cable (see Figure 1)
9
AUDIO
OUT
LEFT RCA Connector Connect to the left channel of the unbalanced stereo audio
acceptor
10 RIGHT RCA Connector Connect to the right channel of the unbalanced stereo
audio acceptor
11 S/PDIF OUT RCA Connector Connect to the digital audio S/PDIF acceptor
12 12V DC Connector Connect to the supplied power adapter, center pin positive
Note: Table 2 also applies to the models shown in Figure 3 and Figure 4.

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Defining the 713/714 Video-Audio Line Transmitter/Receiver
6
Figure 3: 714-10 Video-Audio Line Receiver Front Panel
Figure 4: 714-15 Video-Audio Line Receiver Front Panel

Connecting the 713 and 714
7
5 Connecting the 713 and 714
You can use the 713 and 714 to configure a long distance audio-video transmitter
and receiver system.
To connect the 713 and the 714 as illustrated in the example in Figure 5:
Figure 5: Connecting the Video-Audio Line Transmitter/Receiver System
1. On the 713, connect a composite video source (for example, a composite
video player) to the VIDEO IN BNC connector, and connect the unbalanced
stereo audio to the AUDIO IN LEFT and RIGHT AUDIO IN RCA
connectors.
2. Using CAT 5 cabling, connect the LINE OUT RJ-45 connector on the 713 to
the RJ-45 LINE IN connector on the 714.

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting the 713 and 714
8
3. On the 714, connect the VIDEO OUT BNC connector to a composite video
acceptor (for example, a display), and connect the AUDIO OUT RIGHT and
LEFT RCA connectors to an unbalanced audio acceptor (for example, an
amplifier).
4. On the 714, connect the S/PDIF connector to a digital audio acceptor (for
example, an amplifier).
5. Connect the 12V DC power adapters first to the 713 then to the 714.
Note: This order of connection is mandatory.
6. Connect both power adapters to the mains electricity.
7. If required, adjust the equalization level either automatically or manually on
the 714 (see Section 5.1).
5.1 Automatic and Manual Equalization
You can set the equalization on the 714 either manually or automatically.
To set the equalization automatically, press the Auto button. To set the equalization
manually, press either the Manual + or – button to increase or decrease the
equalization respectively.
On power up, the 714 is set to Auto mode and adjusts the video and audio for the
best quality possible. For most situations it is recommended that you leave the
device in Auto mode.
When the signal or the link between the 713 and the 714 is lost, pressing the Auto
button once is sufficient to set the Auto mode.
When using the Manual mode, the first press of either the + or – button sets the
equalization to the 760m (2500ft) setting. Pressing the Auto button returns the
device to the Auto mode.

Connecting the 713 and 714
9
5.2 Wiring the CAT 5 LINE IN/LINE OUT RJ-45 Connectors
Table 3 and Figure 6 define the CAT 5 pinout, using a straight pin-to-pin cable
with RJ-45 connectors. When using STP cable, connect/solder the cable shield to
the connector shield.
Table 3: CAT 5 PINOUT
Figure 6: CAT 5 PINOUT
EIA /TIA 568A EIA /TIA 568B
PIN
Wire Color
PIN
Wire Color
1 Green / White 1 Orange / White
2 Green 2 Orange
3 Orange / White 3 Green / White
4 Blue 4 Blue
5 Blue / White 5 Blue / White
6 Orange 6 Green
7 Brown / White 7 Brown / White
8 Brown 8 Brown
Pair 1 4 and 5 Pair 1 4 and 5
Pair 2 3 and 6 Pair 2 1 and 2
Pair 3 1 and 2 Pair 3 3 and 6
Pair 4 7 and 8 Pair 4 7 and 8

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
10
6 Technical Specifications
Table 4 lists the technical specifications1
Table 4: Technical Specifications
of the 713 and the 714-05/714-10/714-15.
2
of the 713 and the 714-05/714-10/714-15
713 714-05/714-10/714-15
INPUT: Video 1 composite 1Vpp/75Ω
on a BNC connector
1 RJ-45 CAT 5 connector (LINE IN)
Audio
1 stereo unbalanced
audio 4dBm/50kΩon
two RCA connectors
OUTPUT: 1 RJ-45 CAT 5 connector (LINE
OUT) Video
1 composite on a BNC connector
1Vpp/75Ω
Audio
1 stereo unbalanced audio
4dBm/50kΩon two RCA
connectors
1 S/PDIF digital audio on an RCA
connector
VIDEO MAX. SIGNAL LEVEL: 1.4Vpp (terminated 75 Ω)
AUDIO MAX. SIGNAL LEVEL: 2.3Vpp
VIDEO BANDWIDTH (–3dB): 9MHz
AUDIO BANDWIDTH (–3dB): 20-20kHz
VIDEO S/N RATIO (unweighted): >55dB RMS
AUDIO S/N RATIO: >85db @1kHz
AUDIO CONVERSION: 48kHz/24bit
S/PDIF out >0.5V/75 Ω terminated
CONTROLS: Equalization; automatic and manual (+/–)
VIDEO COUPLING: Input: AC Output: DC
AUDIO COUPLING: Input: AC Output: DC
POWER SOURCE: 12 VDC 120mA 12 VDC 130mA
DIMENSIONS: 12cm x 6.9cm x 2.4cm (4.7" x 2.7" x 0.96") W, D, H
WEIGHT: 0.3kg (0.67lbs) approx. (each)
ACCESSORIES: Power supplies, mounting brackets
OPTIONS: RK-T1, RK-T3, 19 inch rack adapters
1 Specifications are subject to change without notice
2 Specifications are for 100m of CAT 5 UTP cable, unless otherwise specified

11
LIMITED WARRANTY
WHO IS PROTECTED?
WHAT IS COVERED AND WHAT IS NOT COVERED
WHAT WE WILL PAYFOR AND WHAT WE WILLNOT PAYFOR
HOW YOU CAN GET WARRANTY SERVICE
LIMITATION OFIMPLIED WARRANTIES
EXCLUSION OF DAMAGES
CAUTION!
Kramer Electronics (hereafter ) warrants this product free from defects in material and workmanship under the
following terms.
Kramer
HOW LONG IS THE WARRANTY
Labor and parts are warranted for seven years from the date of the first customer purchase.
Only the first purchase customer may enforce this warranty.
We will pay labor and material expenses for covered items.We will notpay for the following:
The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall
not be liable for:
This warranty gives you specific legal rights, and you may also have other rights, which vary from place to place.
All products returned to Kramer for service must have prior approval.Thismay be obtained from your dealer.
This equipment has been testedto determine compliance with the requirements of:
EN-50081: "Electromagnetic compatibility (EMC);
generic emission standard.
Residential, commercial and light industry"
EN-50082: "Electromagnetic compatibility (EMC) generic immunitystandard.
Part 1: Residential, commercialand lightindustryenvironment".
CFR-47: FCC* Rules and Regulations:
Part 15: “Radio frequency devices
Subpart B Unintentional radiators”
Except as below, this warranty covers all defects in material or workmanship in this product. The following are not covered
by the warranty:
1. Any product which is not distributed by Kramer, or which is not purchased from an authorized Kramer dealer. If you are
uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the Web site
www.kramerelectronics.com.
2. Any product, on which the serial number has been defaced, modified or removed, or on which the WARRANTY VOID
TAMPERED sticker has been torn,
3. Damage, deterioration or malfunction resulting from:
i) Accident, misuse, abuse, neglect, fire, water, lightning or other acts of nature
ii) Product modification, orfailureto followinstructions supplied with the product
iii) Repair or attempted repair by anyone not authorized by Kramer
iv) Any shipment of the product(claims must be presented tothe carrier)
v) Removal or installation of the product
vi) Any other cause, which does not relate to a product defect
vii) Cartons, equipment enclosures, cables or accessories used in conjunction with the product
1. Removal or installations charges.
2. Costs of initial technical adjustments (set-up), including adjustment of user controls or programming. These costs are the
responsibility of the Kramer dealer from whom the product was purchased.
3. Shipping charges.
1. To obtain service on you product, you must take or ship it prepaid to any authorized Kramer service center.
2. Whenever warranty service is required, the original dated invoice (or a copy) must be presented as proof of warranty
coverage, and should be included in any shipment of the product. Please also include in any mailing a contact name,
company, address, and a description of the problem(s).
3. For the name of the nearest Kramer authorized service center, consult your authorized dealer.
All implied warranties, including warranties of merchantability and fitness for a particular purpose, are limited in duration to
the length of this warranty.
1. Damage to other property caused by defects inthis product,damages based upon inconvenience, loss of use of theproduct, loss
of time, commercialloss; or:
2. Any other damages, whether incidental, consequential or otherwise. Some countries may not allow limitations on how long an
implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitations andexclusions maynot applyto you.
Servicing the machines can only be done by an authorized Kramer technician. Any user who makes changes or
modifications to the unit without the expressed approval of the manufacturer will void user authority to operate the
equipment.
Use the supplied DC power supply to feed power to the machine.
Please use recommended interconnection cables to connect the machine to other components.
IF reattached, removed or otherwise interfered with.
* FCC and CEapproved using STPcable (for twisted pairproducts)
NOTE:
Part 1:

Kramer Electronics, Ltd.
Web site: www.kramerelectronics.com
E-mail: [e-mail]
P/N: 2900-000608 REV 1
For the latest information on our products and a list of
Kramer distributors visit www.kramerelectronics.com
where updates to this user manual may be found.
We welcome your questions, comments, and feedback.
Safety Warning:
Disconnect the unit from the power supply before
opening/servicing.
Caution
