USER MANUAL
Models:
TP-141 XGA/Audio Line Transmitter
TP-142 XGA/Audio Line Receiver

Contents
i
Contents
1Introduction 1
2Getting Started 1
2.1Quick Start 2
3Overview 3
3.1About the Power Connect Feature 3
3.2Shielded Twisted Pair (STP) / Unshielded Twisted Pair (UTP) 4
3.3Recommendations for Achieving the Best Performance 4
4Your TP-141 / TP-142 5
4.1Your TP-141 XGA/Audio Line Transmitter 5
4.1.1Your TP-141 XGA/Audio Line Transmitter (Topside) 5
4.2Your TP-142 XGA/Audio Line Receiver 6
4.2.1Your TP-142 XGA/Audio Line Receiver (Topside) 6
4.2.2Your TP-142 XGA/Audio Line Receiver (Underside) 7
5Connecting the XGA/Audio Line Transmitter/Receiver 7
5.1Wiring the CAT 5 LINE IN / LINE OUT RJ-45 Connectors 10
6Technical Specifications 11
Figures
Figure 1: TP-141 XGA/Audio Line Transmitter 5
Figure 2: TP-142 XGA/Audio Line Receiver (Topside) 6
Figure 3: TP-142 XGA/Audio Line Receiver (Underside) 7
Figure 4: Connecting the XGA/Audio Line Transmitter/Receiver System 9
Figure 5: CAT 5 PINOUT 10
Tables
Table 1: TP-141 XGA/Audio Line Transmitter Features 5
Table 2: TP-142 XGA/Audio Line Receiver (Topside) Features 6
Table 3: TP-142 XGA/Audio Line Receiver (Underside) Features 7
Table 4: CAT 5 PINOUT 10
Table 5: TP-141/TP-142 Technical Specifications 11

Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
1,000-plus different models now appear in 11 groups1that are clearly
defined by function.
Congratulations on purchasing your Kramer TOOLS: TP-141 XGA/Audio
Line Transmitter, and TP-142 XGA/Audio Line Receiver which are ideal
for:
•Presentation and multimedia applications
•Long-range graphics distribution for schools, hospitals, security, and
stores
The package includes the following items:
•The TP-141, TP-142
•Power adapter (12V DC input)
•This user manual2
2 Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
•Review the contents of this user manual
•Use Kramer high-performance high-resolution cables3
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
2
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.

Overview
3
3 Overview
The TP-141 and TP-142 are a high-immunity, extended-range twisted pair
transmitter and receiver for computer graphics video and unbalanced stereo
audio signals.
The TP-141 converts computer graphics video and audio inputs to twisted
pair signals, and the TP-142 converts the twisted pair signals back into
computer graphics video, unbalanced stereo and S/PDIF digital audio
signals. Together the TP-141 and TP-142 form a computer graphics
video/audio line transmitter/receiver system.
More specifically, the products feature:
•Highest immunity from any kind of interference
•Resolution exceeding UXGA
•HDTV compatibility
•Simultaneous unbalanced stereo and S/PDIF (24-bit 48kHz) audio
outputs (TP-142)
•Level (gain) and EQ (peaking) controls (TP-142)
•System range up to 250m (750ft)
•Power Connect™ System - Only one unit in a system, the transmitter or
the receiver, needs to be connected to a power source when the devices
are within 50m (150ft) of each other
Note: The TP-141 and TP-142 are not compatible with existing Kramer TP
units such as the TP-121, TP-122, and so on.
3.1 About the Power Connect Feature
The Power Connect feature applies as long as the cable can carry power.
This feature is available when using STP cable and the distance does not
exceed 50m on standard CAT 5 cable. For longer distances, heavy gauge
cable should be used1.For units which are connected via RJ-45 connectors,
make sure that the shield of the STP cable is connected to the metal casing
of the connectors on both ends of the cable. For units which are connected
via terminal block connectors, the shield of the STP cable must be
connected to a ground terminal on the units at both ends (use the ground
terminal of the power supply connection if necessary).
For a CAT 5 cable exceeding a distance of 50m, separate power supplies
should be connected to the transmitter and to the receiver simultaneously.
1 CAT 5 cable is still suitable for the video/audio transmission, but not for feeding the power at these distances

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Overview
4
3.2 Shielded Twisted Pair (STP) / Unshielded Twisted Pair (UTP)
We recommend that you use Shielded Twisted Pair (STP) cable. There are
different levels of STP cable available, and we advise you to use the best
quality STP cable that you can afford. Our non-skew-free cable, Kramer
BC-STP is intended for analog signals where skewing is not an issue. For
cases where there is skewing, our UTP skew-free cable, Kramer BC-XTP,
may be used. Bear in mind, though, that we advise using STP cables where
possible, since the compliance to electromagnetic interference was tested
using those cables.
Although Unshielded Twisted Pair (UTP) cable might be preferred for long
range applications, the UTP cable should be installed far away from electric
cables, motors and so on, which are prone to create electrical interference.
However, since the use of UTP cable might cause inconformity to
electromagnetic standards, Kramer does not commit to meeting the standard
with UTP cable.
3.3 Recommendations for Achieving the Best Performance
To achieve the best performance:
•Use only good quality connection cables1to avoid interference,
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low-quality cables)
•Avoid interference from neighboring electrical appliances that may
adversely influence signal quality and position your Kramer
TP-141/TP-142 away from moisture, excessive sunlight and dust
1 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com

Your TP-141 / TP-142
5
4 Your TP-141 / TP-142
This section defines the TP-141 XGA/Audio Line Transmitter (see section
4.1), and the TP-142 XGA/Audio Line Receiver (see section 4.2).
4.1 Your TP-141 XGA/Audio Line Transmitter
This section describes the topside (see section 4.1.1) of the TP-141
XGA/Audio Line Receiver.
4.1.1 Your TP-141 XGA/Audio Line Transmitter (Topside)
The TP-141 is an XGA/stereo audio line transmitter that receives an XGA
signal and an unbalanced stereo analog audio signal, codes them, and
transmits them over CAT 5 cable to a TP-142 receiver.
Figure 1 and Table 1 define the TP-141:
Figure 1: TP-141 XGA/Audio Line Transmitter
Table 1: TP-141 XGA/Audio Line Transmitter Features
# Feature Function
1 12V DC +12V DC connector for powering the unit
2 AUDIO IN 3.5mmMiniJack Connects to the audio source
3 LINE OUT RJ-45 Connector Connects to1the LINE IN RJ-45 connector on the TP-142 XGA/Audio
Line Receiver
4 XGA IN 15-pin HD F Connector Connect to the XGA source
5 ON LED Illuminates when receiving power
1 Using a CAT 5 cable with RJ-45 connectors at both ends (the PINOUT is defined in Figure 5 and Table 4)

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your TP-141 / TP-142
6
4.2 Your TP-142 XGA/Audio Line Receiver
This section describes the topside (see section 4.2.1), and the underside (see
section 4.2.2) of the TP-142 XGA/Audio Line Receiver.
4.2.1 Your TP-142 XGA/Audio Line Receiver (Topside)
The TP-142 is an XGA/audio line receiver that receives the coded CAT 5
signal transmitted by a TP-141, decodes it and converts it to XGA, stereo
analog and S/PDIF digital audio outputs.
Figure 2 and Table 2 define the topside of the TP-142 XGA/Audio Line
Receiver:
Figure 2: TP-142 XGA/Audio Line Receiver (Topside)
Table 2: TP-142 XGA/Audio Line Receiver (Topside) Features
# Feature Function
1 12V DC +12V DC connector for powering the unit
2 AUDIO
OUT S/PDIF RCA connector Connects to the digital audio acceptor
3 ANALOG 3.5mmMiniJack Connects to the analog audio acceptor
4 LINE IN RJ-45 Connector Connects to1the TP-141
5 XGA OUT 15-pinHDF Connector Connects to the XGA acceptor
6 LINK LED Illuminates when receiving the correct input signal
7 LEVEL Trimmer Adjusts the output signal level
8 EQ.2Trimmer Adjusts3the cable compensation equalization level
9 ON LED Illuminates when receiving power
1 Using a CAT 5 cable with RJ-45 connectors at both ends (the PINOUT is defined in Figure 5 and Table 4)
2 Degradation and VGA/XGA signal loss can result from using long cables (due to stray capacitance), sometimes leading to a
total loss of sharpness in high-resolution signals
3 Use a screwdriver to carefully rotate the trimmer, adjusting the appropriate level

Connecting the XGA/Audio Line Transmitter/Receiver
7
4.2.2 Your TP-142 XGA/Audio Line Receiver (Underside)
Figure 3 and Table 3 define the underside of the TP-142 XGA/Audio Line
Receiver:
Figure 3: TP-142 XGA/Audio Line Receiver (Underside)
Table 3: TP-142 XGA/Audio Line Receiver (Underside) Features
# Feature Function
10 HS Switch To set H SYNC to positive polarity, slide the switch to the right1;
to set the H SYNC to negative polarity, slide the switch to the left
11 VS Switch To set V SYNC to positive polarity, slide the switch to the right1;
to set the V SYNC to negative polarity, slide the switch to the left
12 XGA/VIDEO
Switch To set for any video signal, such as HDTV, slide the switch to VIDEO; to set for a computer graphics signal, slide the switch to XGA
5 Connecting the XGA/Audio Line Transmitter/Receiver
You can use the TP-141 and TP-142 to configure an XGA / Audio
Line-to-Twisted Pair Transmitter and Receiver system.
To connect the TP-141 XGA/Audio Line Transmitter with the TP-142
XGA/Audio Line Receiver, as illustrated in Figure 4, do the following:
1. On the TP-141, connect the XGA source (for example, the graphics card of a
laptop) to the XGA INPUT 15-pin HD (F) connector.
2. Connect an audio source to the AUDIO IN 3.5mm mini jack, for example,
using a Kramer C-GMA/GMA cable (VGA 15-pin HD (M) +audio jack to
VGA 15-pin HD (M) +audio jack)2.
Alternatively, you can connect an XGA source to the XGA INPUT 15-pin
HD (F) connector, and a separate audio source to the AUDIO IN 3.5mm mini
jack.
1 By default, both switches are set to the left (for a negative V SYNC and H SYNC polarity)
2 Not supplied. The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting the XGA/Audio Line Transmitter/Receiver
8
3. On the TP-142, connect the XGA OUT 15-pin HD (F) connector to the XGA
acceptor (for example, a display).
4. Connect the AUDIO OUT S/PDIF RCA connector to the digital audio
acceptor (for example, an AV receiver).
5. Connect the ANALOG 3.5mm mini jack to the analog audio acceptor (for
example, a stereo audio recorder).
6. Connect the LINE OUTPUT RJ-45 connector on the TP-141 to the LINE IN
RJ-45 connector on the TP-142, via CAT 5 (UTP or STP) cabling, (see
connector pinouts in section 5.1).
7. Connect the 12V DC power adapter to the power socket of either the TP-141
or the TP-142 and connect the adapter to the mains electricity. The Power
Connect feature feeds power to the second device. If the second device does
not power on due to a long line, connect a 12V DC power adapter to the
second device as well.
8. If required, On the TP-142:
Set the XGA/VIDEO switch to XGA
Adjust1the video output signal level and/or cable compensation
equalization level
Set the H SYNC and V SYNC switches2, on the underside
1 Use a screwdriver to carefully rotate the trimmer, adjusting the appropriate level
2 By default, both switches are set to the left (for negative V SYNC and H SYNC polarity)

Connecting the XGA/Audio Line Transmitter/Receiver
9
Figure 4: Connecting the XGA/Audio Line Transmitter/Receiver System

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting the XGA/Audio Line Transmitter/Receiver
10
5.1 Wiring the CAT 5 LINE IN / LINE OUT RJ-45 Connectors
Table 4 and Figure 5 define the CAT 5 PINOUT, using a straight pin to pin
cable with RJ-45 connectors:
Table 4: CAT 5 PINOUT Figure 5: CAT 5 PINOUT
EIA /TIA 568A EIA /TIA 568B
PIN Wire Color PIN Wire Color
1 Green / White 1 Orange / White
2 Green 2 Orange
3 Orange / White 3 Green / White
4 Blue 4 Blue
5 Blue / White 5 Blue / White
6 Orange 6 Green
7 Brown / White 7 Brown / White
8 Brown 8 Brown
Pair 1 4 and 5 Pair 1 4 and 5
Pair 2 3 and 6 Pair 2 1 and 2
Pair 3 1 and 2 Pair 3 3 and 6
Pair 4 7 and 8 Pair 4 7 and 8

Technical Specifications
11
6 Technical Specifications
The technical specifications are shown in Table 5:
Table 5: TP-141/TP-142 Technical Specifications1
TP-141 TP-142
INPUTS: Video: 1 computer graphics video on a
15-pin HD connector
Audio: 1 audio analog 3.5mm mini jack
1 RJ-45 LINE IN connector
OUTPUTS: 1 RJ-45 OUT connector Video: 1 computer graphics video on a
15-pin HD connector
Audio: 1 audio S/PDIF RCA connector,
1 audio analog 3.5mm mini jack
MAX. OUTPUT
LEVEL: Video: 1V, Audio: 2.5V
CONTROLS: Level: –7.5dB to +4.4dB
EQ: 0dB to +33dBm, (130m) @50MHz
BANDWIDTH (-
3dB)2: Audio: 20Hz–20kHz @0.5dB
RESOLUTION: Exceeding UXGA
S/N RATIO: Audio: <–80dB
TOTAL GAIN: Audio: Analog/analog: 0dB, Analog/SPDIF: –12dBFS
COUPLING: AC
TND+N: Audio: <0.01%
POWER SOURCE: 12V DC, 60mA
DIMENSIONS: 12.1cm x 7.18cm x 2.42cm (4.76" x 2.83" x 0.95"), W, D, H
WEIGHT: 0.3kg (0.67lbs) approx.
ACCESSORIES: Power supply
1 Specifications are subject to change without notice
2 For the transmitter/receiver pair

12
LIMITED WARRANTY
WHOIS PROTECTED?
WHATISCOVEREDANDWHATISNOTCOVERED
WHATWE WILLPAYFORANDWHATWE WILLNOTPAYFOR
HOW YOU CAN GET WARRANTY SERVICE
LIMITATIONOFIMPLIEDWARRANTIES
EXCLUSIONOFDAMAGES
CAUTION!
Kramer Electronics (hereafter )warrants this product free from defects in material and workmanship under the
followingterms.
Kramer
HOWLONGIS THE WARRANTY
Labor and parts are warranted for seven years from the date of the first customer purchase.
Only the first purchase customer may enforce this warranty.
Wewill paylaborandmaterialexpensesforcovereditems.Wewill notpayforthefollowing:
Theliability of Kramer for any effective productsis limited to the repair or replacement of the product at our option. Kramer shall
notbeliablefor:
Thiswarrantygives youspecificlegalrights,andyoumay alsohaveotherrights,whichvaryfromplacetoplace.
AllproductsreturnedtoKramerforservicemusthavepriorapproval.Thismaybe obtainedfromyourdealer.
Thisequipmenthasbeentestedtodeterminecompliancewiththe requirements of:
EN-50081: "Electromagneticcompatibility(EMC);
genericemissionstandard.
Residential, commercial andlightindustry"
EN-50082: "Electromagneticcompatibility(EMC)generic immunitystandard.
Part 1: Residential, commercial and lightindustry environment".
CFR-47: FCC* Rules and Regulations:
Part 15: “Radio frequency devices
Subpart B Unintentional radiators”
Except as below, this warranty covers all defects in material or workmanship in this product.The following are not covered
bythewarranty:
1. Any product which is not distributed by Kramer, or which is not purchased from an authorized Kramer dealer. If you are
uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the Web site
www.kramerelectronics.com.
2. Any product, on which the serial number has been defaced, modified or removed, or on which the WARRANTYVOID
TAMPERED sticker has been torn,
3. Damage,deteriorationormalfunctionresultingfrom:
i) Accident,misuse,abuse, neglect, fire, water, lightningorotheractsofnature
ii) Product modification, or failure to follow instructions supplied with the product
iii) RepairorattemptedrepairbyanyonenotauthorizedbyKramer
iv) Anyshipmentoftheproduct(claimsmust bepresentedtothecarrier)
v) Removalorinstallationoftheproduct
vi) Any other cause, which does not relate to a product defect
vii) Cartons, equipment enclosures, cablesor accessories usedinconjunctionwiththeproduct
1. Removalorinstallationscharges.
2. Costs of initial technical adjustments (set-up), including adjustment of user controls or programming. These costs are the
responsibilityoftheKramerdealerfromwhomtheproductwaspurchased.
3. Shipping charges.
1. To obtain service on you product, you must take or ship it prepaid to any authorized Kramerservice center.
2. Whenever warranty service is required, the original dated invoice (or a copy) must be presented as proof of warranty
coverage, and should be included in any shipment of the product. Please also include in any mailing a contact name,
company, address, and a description of the problem(s).
3. For the name of the nearest Kramer authorized service center, consult your authorized dealer.
All implied warranties, including warranties of merchantability and fitness for a particular purpose, are limited in duration to
the length of this warranty.
1. Damagetootherpropertycausedbydefectsinthisproduct,damagesbaseduponinconvenience,lossofuseoftheproduct,loss
oftime,commercialloss; or:
2. Any other damages, whether incidental, consequential or otherwise. Some countries may not allow limitations on how long an
implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitationsandexclusionsmaynotapplytoyou.
Servicing the machines can only be done by an authorized Kramer technician. Any user who makes changes or
modifications to the unit without the expressed approval of the manufacturer will void user authority to operate the
equipment.
Use the supplied DC power supply to feed power to the machine.
Pleaseuserecommendedinterconnection cablestoconnectthemachineto other components.
IF reattached, removed or otherwise interfered with.
*FCCandCEapprovedusingSTPcable(fortwistedpairproducts)
NOTE:
Part1:

Kramer Electronics, Ltd.
Web site: www.kramerelectronics.com
E-mail: [email protected]
P/N: 2900-000419 REV 4
For the latest information on our products and a list of Kramer
distributors, visit our Web site: www.kramerelectronics.com
where updates to this user manual may be found.
We welcome your questions, comments and feedback.
Caution
Safety Warning:
Disconnect the unit from the power supply before
opening/servicing.
