Kramer 640T User manual

KRAMER ELECTRONICS LTD.
USER MANUAL
MODELS:
640T
HDMI–Coax Transmitter
640R
Coax–HDMI Receiver
P/N: 2900-000354 Rev 9

640T/640R – Contents
i
Contents
1Introduction 1
2Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 3
2.3 Recycling Kramer Products 3
3Overview 4
3.1 640T HDMI-Coax Transmitter 4
3.2 640R Coax-HDMI Receiver 5
4Your 640T/640R HDMI/Coax Transmitter/Receiver 6
4.1 Your 640T HDMI-Coax Transmitter 6
4.2 Your 640R Coax-HDMI Receiver 7
5Connecting the 640T/640R 8
6Technical Specifications 10
Figures
Figure 1: 640T/640R HDMI/Coax Transmitter/Receiver 6
Figure 2: 640R Coax-HDMI Receiver 7
Figure 3: HDMI-to-Coax Transmitter and Receiver System 9

640T/640R - Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront the video, audio, presentation, and broadcasting
professional on a daily basis. In recent years, we have redesigned and upgraded
most of our line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix
Switchers; GROUP 3: Control Systems; GROUP 4: Format/Standards Converters;
GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;
GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors;
GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters and
GROUP 11: Sierra Products.
Thank you for purchasing the Kramer DigiTOOLS®640T HDMI-Coax Transmitter
and/or Kramer DigiTOOLS® 640R Coax-HDMI Receiver, which are ideal for:
Boardroom and projection applications
Long-range multimedia extension for schools, hospitals, security, and stores
Upgrading a legacy analog installation to a digital installation

2
640T/640R - Getting Started
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Go to http://www.kramerelectronics.com/support/product_downloads.asp
to check for up-to-date user manuals, application programs, and to check
if firmware upgrades are available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight coils
Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
Position your Kramer 640T/640R away from moisture, excessive sunlight
and dust
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
i
!

640T/640R - Getting Started
3
2.2 Safety Instructions
Caution:
There are no operator serviceable parts inside the unit
Warning:
Use only the Kramer Electronics input power wall
adapter that is provided with the unit
Warning:
Disconnect the power and unplug the unit from the wall
before installing
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country
go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.
!

4
640T/640R - Overview
3 Overview
This section describes the:
640T HDMI-Coax Transmitter, see Section 3.1
640R Coax-HDMI Receiver, see Section 3.2
3.1 640T HDMI-Coax Transmitter
The Kramer DigiTOOLS®640T is an HDMI-coax transmitter that receives an HDMI
signal, codes it, and transmits red, green, blue, clock and data signals, as well as
power and infrared signals over coax cable to the 640R receiver.
Compatible with a Kramer transmitter and via a Kramer external remote IR receiver:
C-A35M/IRR or C-A35M/IRE or C-A35M/2IRE.
The 640T features:
Full support for HDMI up to 6.75Gbps (2.25Gbps per graphic channel) and
up to 720P with HDCP
EDID pass-through that passes the EDID between the source and display
Digital signal transmission without compression or conversion
Power feeding to the 640R
Power feeding and IR signals are available only when using a 5-plug coax cable and
the power coax line is connected.
Plug and Play installation with no adjustments

640T/640R - Overview
5
3.2 640R Coax-HDMI Receiver
The Kramer DigiTOOLS®640R is a coax-HDMI receiver that receives a coded coax
signal and infrared signals transmitted by the640T. It decodes the
R-G-B, clock and data components and converts them to an HDMI output.
Compatible with a Kramer transmitter and via a Kramer external remote IR receiver:
C-A35M/IRR or C-A35M/IRE or C-A35M/2IRE.
The 640R features:
Full support for HDMI up to 6.75Gbps (2.25Gbps per graphic channel) and
up to 720p with HDCP
EDID pass-through that passes the EDID between the source and display
Power feeding to the 640T
Power feeding and IR signals are available only when using a 5-plug coax cable and
the power coax line is connected.
Plug and Play installation with no adjustments

6
640T/640R - Your 640T/640R HDMI/Coax Transmitter/Receiver
4 Your 640T/640R HDMI/Coax
Transmitter/Receiver
This section defines the 640T HDMI-Coax Transmitter (see Section 4.1) and 640R
Coax-HDMI Receiver (see Section 4.2).
4.1 Your 640T HDMI-Coax Transmitter
Figure 1 defines the 640T:
Figure 1: 640T/640R HDMI/Coax Transmitter/Receiver
#
Feature
Function
1
IR Connector
Connects to an IR sensor or transmitter
Compatible with a Kramer transmitter and via a Kramer
external remote IR receiver: C-A35M/IRR or C-A35M/IRE or
C-A35M/2IRE
2
IN / OUT LED
The IN LED Illuminates when an input source is
connected. The OUT LED illuminates when an output
acceptor is connected
3
HDMI IN Connector
Connects to an HDMI source
4
ON LED
Illuminates when receiving power
5
RED Output BNC Connector
Transmits the red signal to the 640R
6
GREEN Output BNC Connector
Transmits the green signal to the 640R
7
BLUE Output BNC Connector
Transmits the blue signal to the 640R
8
CLK Output BNC Connector
Transmits the clock signal to the 640R
9
PWR Output BNC Connector
Transmits power and the IR signal to the 640R
10
12V DC
+12V DC connector for powering the unit

640T/640R - Your 640T/640R HDMI/Coax Transmitter/Receiver
7
4.2 Your 640R Coax-HDMI Receiver
Figure 2 defines the 640R:
Figure 2: 640R Coax-HDMI Receiver
#
Feature
Function
1
IR Connector
Connects to an IR sensor or transmitter
Compatible with a Kramer transmitter and via a Kramer
external remote IR receiver: C-A35M/IRR or C-A35M/IRE
or C-A35M/2IRE
2
IN / OUT LED
The IN LED Illuminates when an input source is
connected. The OUT LED illuminates when an
output acceptor is connected
3
HDMI OUT Connector
Connects to the HDMI acceptor
4
ON LED
Illuminates when receiving power
5
RED Input BNC Connector
Receives the red signal from the 640T
6
GREEN Input BNC Connector
Receives the green signal from the 640T
7
BLUE Input BNC Connector
Receives the blue signal from the 640T
8
CLK Input BNC Connector
Receives the clock signal from the 640T
9
PWR Input BNC Connector
Receives power and the IR signal from the 640T
10
12V DC
+12V DC connector for powering the unit

8
640T/640R - Connecting the 640T/640R
5 Connecting the 640T/640R
You can use the 640T HDMI-Coax Transmitter and the 640R Coax-HDMI Receiver to
configure an HDMI-to-Coax Transmitter and Receiver system (see Figure 3).
Always switch off the power to each device before connecting it to your
640T/640R. After connecting your 640T/640R, connect its power and
then switch on the power to each device.
To connect the HDMI-to-Coax Transmitter and Receiver system as shown in the
example in Figure 3, do the following:
1. Connect an HDMI source, for example, the HDMI output from a Blu-ray DVD
player, to the 640T HDMI IN connector.
2. Connect the 640R HDMI OUT connector to the HDMI acceptor, for example,
a projector.
3. If using a 4-plug coax cable or 4 coax cables:
Connect the 640T red, green, blue, and clock BNC connectors to the
640R red, green, blue and, clock BNC connectors
Connect 12V DC power supplies to both the 640T and the 640R (not
shown in Figure 3). The remote power and IR remote control functions
are not available
4. If using a 5-plug coax cable or 5 coax cables:
Connect the 640T red, green, blue, clock, and power BNC connectors
to the 640R red, green, blue, clock, and power BNC connectors
Connect one 12V DC power supply to either the 640T or the 640R (not
shown in Figure 3). Power and the IR remote control function are
transmitted over the power coax connection to the second device
Note: All coax cables must be the same length. There can be no more than 6
inches (15cm) difference in length between any of the cables.
5. Connect the power supply(s) to the mains electricity.
After all connections are made and the units are powered ON, the system
operates.
i

640T/640R - Connecting the 640T/640R
9
Figure 3: HDMI-to-Coax Transmitter and Receiver System

10
640T/640R - Technical Specifications
6 Technical Specifications
640T
640R
INPUTS:
1 HDMI connector
5 BNC connectors
OUTPUTS:
5 BNC connectors
1 HDMI connector
PORT:
1 IR on a 3.5mm mini connector
MAX. DATA RATE:
Supports up to 6.75Gbps (2.25Gbps per graphic channel)
up to 720p with HDCP
STANDARDS COMPLIANCE:
HDMI and HDCP
POWER SOURCE:
12V DC, 650mA
12V DC, 540mA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12.1cm x 7.2cm x 2.4cm (4.7" x 2.8" x 1.0"), W, D, H
WEIGHT:
0.3kg (0.7lbs) approx.
ACCESSORIES:
Power supply
OPTIONS:
Kramer external remote IR receiver
C-A35M/IRR or C-A35M/IRE or C-A35M/2IRE
Specifications are subject to change without notice at http://www.kramerelectronics.com
640T/640R Range Chart
Cable Type
Max Range
BC-5 (28 AWG)
50m
BC-5 (26 AWG)
60m
RG-59
115m
RG-6
150m

For the latest information on our products and a list of Kramer distributors,
visit our Web site where updates to this user manual may be found.
We welcome your questions, comments, and feedback.
Web site: www.kramerelectronics.com
E-mail: [e-mail]
P/N:
2900-000354
Rev:
9
!
