Kramer 670T User manual

Kramer Electronics, Ltd.
USER MANUAL



Models:
670T , HDMI Optical Transmitter
670R , HDMI Optical Receiver

Contents
i
Contents
1 Introduction 1
2 Getting Started 1
2.1 Quick Start 2
3 Overview 3
3.1 About HDMI 3
3.2 Recommendations for Achieving the Best Performance 4
4 Your HDMI Optical Transmitter and Receiver 5
4.1 Your 670T HDMI Optical Transmitter 5
4.2 Your670RHDMIOpticalReceiver6
5 Connecting the 670T and 670R Transmitter/Receiver System 6
6 Technical Specifications 8
Figures
Figure 1: 670T HDMI Optical Transmitter 5
Figure 2: 670R HDMI Optical Receiver 6
Figure 3: Connecting the 670T/670R Transmitter/Receiver System 7
Tables
Table 1: 670T HDMI Optical Transmitter Features 5
Table 2: 670R HDMI Optical Receiver Features 6
Table 3: Technical Specifications of the 670T and the 670R 8

Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range
of problems that confront the video, audio, presentation, and broadcasting
professional on a daily basis. In recent years, we have redesigned and upgraded
most of our line, making the best even better! Our 1,000-plus different models
now appear in 11 groups
1
that are clearly defined by function.
Congratulations on purchasing your Kramer DigiTOOLS
®
670T HDMI
Optical Transmitter and/or 670R HDMI Optical Receiver which are ideal for:
Home theater, presentation and multimedia applications
Long range multimedia distribution for cinemas, stores, and
entertainment centers
Video production and broadcast facilities
Retail stores and other point-of-sale systems
The package includes the following:
670T and/or 670R
Power adapter (5V DC Input)
This user manual
2
The multimode (OM3) fiber cable with SC connectors is not supplied with the
unit
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
Review the contents of this user manual
Use Kramer high performance high resolution cables
3
1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:
Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories
and Rack Adapters; GROUP 11: Sierra Products
2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
2
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.

Overview
3
3 Overview
The 670T converts the HDMI signal to an optical signal, and the 670R
converts the optical signal back into an HDMI signal. Together, the 670T and
670R form an HDMI transmitter/receiver over multimode fiber system.
The 670T and 670R pair:
Features a transmission range of 1700 meters (more than 5570ft)
over an optical cable
Is strictly regulated in accordance with Class 3R Laser Eye Safety in
compliance with ANSI Z136 and IEC 60825-1:2007
Includes HDMI connectors
Transmits four TMDS video channels as well as one low-speed
channel for passing HDCP, EDID, 5V source and a Hot Plug Detect
(HPD) signal over one multimode fiber
Supports up to 2.25Gbps bandwidth per graphic channel
1
Is HDCP compliant
Has 5V DC power adapters and is housed in Kramer DigiTOOLS
®
enclosures
3.1 About HDMI
High-Definition Multimedia Interface (HDMI) is an uncompressed all-digital
2
audio/video interface, widely supported in the entertainment and home cinema
industry. It delivers the highest high-definition image and sound quality.
In particular, HDMI
3
:
Provides a simple
4
interface between any audio/video source, such as a
set-top box, DVD player, or A/V receiver and video monitor, such as a
digital flat LCD / plasma television (DTV), over a single lengthy
5
cable
Supports standard, enhanced, high-definition video, and multi-channel
digital audio
6
on a single cable
1 Suitable for resolutions up to UXGA at 60Hz, and for all HD resolutions
2 Ensuring an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-
to-analog conversions
3 HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
licensing LLC
4 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables
currently used in A/V systems is reduced
5 HDMI technology has been designed to use standard copper cable construction at up to 15m
6 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to
support Dolby 5.1 audio and high-resolution audio formats

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Overview
4
Transmits all ATSC HDTV standards and supports 8-channel digital
audio, with bandwidth to spare to accommodate future enhancements and
requirements
Benefits consumers by providing superior, uncompressed digital video
quality via a single cable
1
, and user-friendly connector
Is backward-compatible with DVI (Digital Visual Interface)
Supports two-way communication between the video source (such as a
DVD player) and the digital television, enabling new functionality such as
automatic configuration and one-button play
HDMI has the capacity to support:
Existing high-definition video formats (720p, 1080i, and 1080p/60), as
well as standard definition formats such as NTSC or PAL
3.2 Recommendations for Achieving the Best Performance
To achieve the best performance:
Connect only good quality connection cables, thus avoiding
interference, deterioration in signal quality due to poor matching,
and elevated noise-levels (often associated with low quality cables)
Avoid interference from neighboring electrical appliances and position
your 670T and 670R away from moisture, excessive sunlight and dust
Caution – No operator-serviceable parts inside unit.
Warning – Use only the Kramer Electronics input power
wall adapter that is provided with this unit
2
.
Warning – Disconnect power and unplug unit from wall
before installing or removing device or servicing unit.
1 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a
simple, cost-effective manner
2 For example, part number 2535-052002

Your HDMI Optical Transmitter and Receiver
5
4 Your HDMI Optical Transmitter and Receiver
This section describes the:
670T HDMI Optical Transmitter, see section 4.1
670R HDMI Optical Receiver, see section 4.2
4.1 Your 670T HDMI Optical Transmitter
Figure 1 and Table 1 define the 670T HDMI Optical Transmitter:
Figure 1: 670T HDMI Optical Transmitter
Table 1: 670T HDMI Optical Transmitter Features
# Feature Function
1 5V DC +5V DC connector for powering the unit
2 OPTIC CABLE Connector
1
Connect to the optical connector on the 670R
3 HDMI IN Connector Connects to the HDMI source
4 FIBER Illuminates when the fiber optic cable is connected
5
CONNECTED
LEDs SOURCE
Illuminates when a source is connected
6 HOT PLUG LED Indicates a connected display on the receiver side
7 VIDEO DETECT LED Indicates a valid video signal on the transmitter side
8 ON LED Illuminates when receiving power
1 With a dust cap cover

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting the 670T and 670R Transmitter/Receiver System
6
4.2Your670RHDMI Optical Receiver
Figure 2 and Table 2 define the 670R HDMI Optical Receiver:
Figure 2: 670R HDMI Optical Receiver
Table 2: 670R HDMI Optical Receiver Features
# Feature Function
1 5V DC +5V DC connector for powering the unit
2 OPTIC CABLE Connector1Connect to the optical connector on the 670T
3 HDMI OUT Connector Connects to the HDMI acceptor
4 FIBER Lights when the fiber optic cable is connected
5
CONNECTED
LEDs SOURCE
Lights when a source is connected
6 HOT PLUG LED Indicates a connected display on the receiver side
7 VIDEO DETECT LED Indicates a valid video signal on the transmitter side
8 ON LED Illuminates when receiving power
5 Connecting the 670T and 670R Transmitter/Receiver System
To connect the 670T and 670R, as illustrated in the example in Figure 3, do
the following:
1. Connect an HDMI source (for example a DVD player) to the HDMI IN
connector.
2. Connect the HDMI OUT connector to an HDMI acceptor (for example, an
LCD display).
3. Remove the dust caps and connect the OPTIC CABLE connector of the 670T
to the OPTIC CABLE connector of the 670R, via optic OM3 cabling
2
(maximum range of 1700 meters (over 5570ft)).
1Coveredwithadustcap
2 With SC connectors

Connecting the 670T and 670R Transmitter/Receiver System
7
4. Connect the 5V DC power adapter to the power socket on each unit and
connect the adapter to the mains electricity (not shown in Figure 3).
Avoid direct eye exposure into the optic connectors when powered, although
this product is regulated strictly enough to operate under the Laser Class 3R
for eye safety
Figure 3: Connecting the 670T/670R Transmitter/Receiver System

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
8
6 Technical Specifications
Table 3 includes the technical specifications
1
.
Table 3: Technical Specifications of the 670T and the 670R
670T 670R
INPUTS: HDMI Connector 1 optical connector
OUTPUTS: 1 optical connector HDMI Connector
BANDWIDTH: Supports up to 2.25Gbps bandwidth per graphic channel
COMPLIANCE WITH
HDMI STANDARD:
SupportsHDMI 1.3,usingfiberopticcommunicationlinksandDDC2B
EXTENSION LIMIT: 1700m (>5570 feet) for 1080p/60Hz
FIBER-OPTIC
CONNECTION:
SC connectors for multimode (OM3) fiber cable (not supplied with the unit)
INDICATOR LEDs: Video, source, acceptor fiber and on LEDs
POWER SOURCE: 5V DC, 250mA 5V DC, 230mA
DIMENSIONS: 12cm x 7.95cm x 2.76cm (4.7" x 3.1" x 1.08", W, D, H)
WEIGHT: 0.3kg (0.67lbs) approx. each
ACCESSORIES: 2 power supplies (5V/2A), 2 bracket installation kits
OPTIONS: HDMI/HDMI male-to-male cable 2
1 Specifications are subject to change without notice
2 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

9
LIMITED WARRANTY
WHO IS PROTECTED?
WHAT IS COVERED AND WHAT IS NOT COVERED
WHAT WE WILL PAY FOR AND WHAT WE WILL NOT PAY FOR
HOW YOU CAN GET WARRANTY SERVICE
LIMITATION OF IMPLIED WARRANTIES
EXCLUSION OF DAMAGES
CAUTION!
Kramer Electronics (hereafter ) warrants this product free from defects in material and workmanship under the
following terms.
Kramer
HOW LONG IS THE WARRANTY
Labor and parts are warranted for seven years from the date of the first customer purchase.
Only the first purchase customer may enforce this warranty.
We will pay labor and material expensesforcovered items.We will notpayfor thefollowing:
Theliability of Kramer for any effective products is limited to the repair or replacement of the product at our option. Kramer shall
not be liable for:
Thiswarranty gives you specificlegal rights, and you may also have otherrights, which vary from place to place.
All products returned to Kramer for service must have priorapproval.Thismay be obtained from your dealer.
Thisequipment has been testedtodetermine compliance with the requirements of:
EN-50081: "Electromagneticcompatibility(EMC);
generic emissionstandard.
Residential, commercial and lightindustry"
EN-50082: "Electromagneticcompatibility(EMC)genericimmunitystandard.
Part 1: Residential, commercial and light industryenvironment".
CFR-47: FCC* Rules and Regulations:
Part 15: “Radio frequency devices
Subpart B Unintentional radiators”
Except as below, this warranty covers all defects in material or workmanship in this product. The following are not covered
by the warranty:
1. Any product which is not distributed by Kramer, or which is not purchased from an authorized Kramer dealer. If you are
uncertain as to whether a dealer is authorized, please contact Kramer at one of the agents listed in the Web site
www.kramerelectronics.com.
2. Any product, on which the serial number has been defaced, modified or removed, or on which the WARRANTY VOID
TAMPERED sticker has been torn,
3. Damage, deterioration or malfunctionresulting from:
i) Accident, misuse, abuse, neglect, fire, water, lightning or other acts of nature
ii) Product modification, or failure to followinstructions supplied with the product
iii) Repair or attempted repair by anyone not authorized by Kramer
iv) Anyshipment of the product (claims must be presentedtothe carrier)
v) Removalorinstallationof theproduct
vi) Anyother cause, whichdoes not relate to a product defect
vii) Cartons,equipment enclosures,cablesor accessoriesusedinconjunctionwiththe product
1. Removal orinstallationscharges.
2. Costs of
initial technical adjustments (set-up), including adjustment of user controls or programming. These costs are the
responsibility of the Kramerdealer from whom the product was purchased.
3. Shipping charges.
1. To obtain service on you product, you must take or ship it prepaid to any authorized Kramer service center.
2. Whenever warranty service is required, the original dated invoice (or a copy) must be presented as proof of warranty
coverage, and should be included in any shipment of the product. Please also include in any mailing a contact name,
company, address, and a description of the problem(s).
3. For the name of the nearest Kramer authorized service center, consult your authorized dealer.
All implied warranties, including warranties of merchantability and fitness for a particular purpose, are limited in duration to
the length of this warranty.
1. Damage to other property caused by defectsin this product, damages basedupon inconvenience, loss of use of the product, loss
of time, commercialloss; or:
2. Any other damages, whether incidental, consequential or otherwise. Some countries may not allow limitations on how long an
implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitationsandexclusions maynotapplytoyou.
Servicing the machines can only be done by an authorized Kramer technician. Any user who makes changes or
modifications to the unit without the expressed approval of the manufacturer will void user authority to operate the
equipment.
Usethe suppliedDC power supply to feed power to the machine.
Please use recommended interconnection cablesto connect the machine to other components.
IF reattached, removed or otherwise interfered with.
* FCC and CE approved using STPcable (for twisted pair products)
NOTE:
Part1:

Kramer Electronics, Ltd.
Web site: www.kramerelectronics.com
E-mail: [email protected]
P/N: 2900-000483 REV 1
For the latest information on our products and a list of Kramer
distributors, visit our Web site: www.kramerelectronics.com,
where updates to this user manual may be found.
We welcome your questions, comments and feedback.
Caution
Safety Warning:
Disconnect the unit from the power supply before
opening/servicing.
Class 3R Laser Compliance
CLASS 3R LASER PRODUCT
This product complies with “ANSI Z136” and
“IEC 60825-1:2007”.
