Kramer K-CamHD User manual

www.kramerAV.com
[e-mail]
Quick Start Guide
MODEL:
K-CamHD
PTZ Camera
P/N:
2900- 301529QS
Rev:
1
SAFETY WARNING
Disconnect the unit from the power supply before opening and servicing
For the latest information on our products and a list of Kramer distributors, visit our
Web site where updates to these installation instructions may befound.
We welcome your questions, comments, andfeedback.

2
K-CamHD PTZ Camera
K-CamHD PTZ Camera
Congratulations on purchasing your Kramer K-CamHD PTZ Camera (Pan Tilt Zoom camera). K-CamHD provides
great image quality, even in low-light conditions, and easy access to medium and large size conferencing. K-CamHD
combines 1080p image quality, 12x optical zoom, intelligent color optimization technology, ultra-low CMOS image
sensors as well as 2D and 3D DNR technology.
Control K-CamHD via the IR remote controller, or the RS-232. Go to www.kramerav.com/downloads/K-CamHD to
download the latest user manual and check if firmware upgrades are available.
Get to know your K-CamHD
#
Feature
Function
1
Camera
High quality Camera.
2
Tilting Mechanism
Can be set to any of 255 preset positions.
3
STANDBY LED
Lights green when the camera is in standby mode.
4
POWER LED
Lights green when the power is on.
5
USB 3 Type B Port
Connect to a PC.
6
LINE IN
Connect to a microphone.
7
RS-232 8-pin
DIN Connectors
IN
Connect to a device with an RS-232 port (for example, a system controller).
8
OUT
Connect to a device with an RS-232 port (for example, a camera).
9
12V DC Power Connector
Connect to the 12V power adapter.

Installation Instructions
3
Mounting K-CamHD
You can mount K-CamHD on the wall, the ceiling or place it on a tabletop. The built-in gravity sensor automatically
corrects the image orientation.
•Ensure that the environment (e.g., maximum ambient temperature, humidity & air flow) is compatible for the device.
•Avoid exposing the product to direct sunlight or any other heat source.
•Keep away from children –product includes small accessories and components.
•Avoid uneven mechanical loading.
•Do not insert any sharp objects into the product.
•Avoid dropping or hitting the product to avoid damaging the product.
•For maintenance, call tech support.
To attach K-CamHD onto a wall:
1. Find the correct location on the wall.
2. In the desired location, mark the hole
locations, then drill 4 holes 82mm and
60mm apart (using a 6mm drill-bit) to fit
the 4 holes of the wall-mounting bracket.
3. Insert the four expansion-plugs into the
holes.
4. Attach the wall bracket to
the wall, using the four wall-
bracket screws.
5. Attach the device to the wall bracket
by fitting the mortise (on the bracket)
into the tenon (on the camera).
6. Fix the camera by screwing (A)
Nickel screw to the center and (B)
then tighten with 3 black screws.
Note that you can also
attach the device upside
down, from under the
bracket.
Connecting K-CamHD
Always switch OFF the power on each device before connecting it to your K-CamHD.
Connect the power cord to K-CamHD and plug it into the mains electricity.
Safety Instructions (See www.kramerav.com for updated safety information)
Caution:
•There are no operator serviceable parts inside the unit.
Warning:
•Use only the power cord that is supplied with the unit.
•Disconnect the power and unplug the unit from the wall before installing.
•Do not open the unit. High voltages can cause electrical shock! Servicing by qualified personnel only.
•To ensure continuous risk protection, replace fuses only according to the rating specified on the product label
which located on the bottom of the unit.

4
K-CamHD PTZ Camera
Controlling and configuring K-CamHD via the IR remote controller
K-CamHD IR Remote Controller
#
Key
Function
Shortcut Keys
*+＃+1: OSD default (English)
*+＃+3: OSD default (Chinese)
*+＃+6: Quickly recover the
default
*+＃+8: View the camera version
*+＃+9: Quickly set up inversion
*+＃+MANUAL: Restore default
IP address
1
Power
Press once to enter standby mode. Press again to
enter normal operation mode.
2
Number (0 to 9)
Configure or edit a preset
3
*
Use together with other keys for various functions.
4
PRESET
Press PRESET + a numerical key (0 to 9) to save the
current configuration to that preset number.
5
HOME
Press to return K-CamHD to its default position.
When in the OSD, press to enter a submenu or
confirm menu.
6
Return
Return to previous item on the menu.
7
ZOOM
SLOW
Press for slow zoom in (+) or out (-).
FAST
Press for quick zoom in (+) or out (-).
8
L/R
Set
STD (1)
Press L/R +STD (1) keys to set Pan-Tilt to same
direction as L/R setting.
REV (2)
Press L/R +REV (2) keys to set Pan-Tilt to the
direction opposite to the L/R setting.
9
FOCUS
AUTO
Press to automatically set the focus to
the center of the image.
MANUAL
Press to enter manual focus mode.
Then press FAR or NEAR.
FAR
When in MANUAL mode, press to
focus on a far object
NEAR
When in MANUAL mode, press to
focus on a near object.
10
CAMERA SELECT
Select the camera to configure and control (1 to 4).
11
#
Use together with other keys for various functions.
12
IR RC
Press * + # + (F1 to F4) to assign a camera address
to the remote. For example, point the remote to a
camera, press *+#+F1. The remote assigns CAMERA
SELECT 1 key to this camera. To use the remote to
control camera 1 press the CAMERA SELECT 1 key.
Press F4 to freeze the image.
13
RESET
Press RESET+ a key number (0 to 9) to delete a
preset configuration. Press *+#+RESET to delete all
preset configurations.
14
PTZ Control
Control camera panning and tilting using arrow keys
(left, right, up, and down).
15
MENU
Enter/exit OSD menu.
16
BACKLIGHT
Press to turn backlight compensation on or off.
Available when exposure mode is set to Auto (via the
OSD menu).
17
P/T RST
Press to self-check preset Pan/Tilt on camera.
