Oncam EVO-05-LRD User manual

Evolution 05 Mini Recessed
QUICK START GUIDE
Important
• Read these instructions carefully before
installing or operating this camera.
• This camera should be installed by a qualied
service person and the installation should
conform to local and national regulations.
• This camera conforms to UL2043, which
certies it as suitable for installation in a wall
or ceiling used also as an air handling space.
• Certied as FCC Class A, In a domestic
environment this camera may cause radio
interference in which case the user should
take adequate measures.
DANGER: RISK OF EXPLOSION IF
REPLACING A BATTERY WITH AN
INCORRECT BATTERY TYPE.
Welcome
The Oncam Evolution Mini Recessed 360° camera is
designed to be connected to an IP network. Congure
and operate the camera using a standard internet
browser.
Described are the installation and conguration
procedures for a standard surface mount camera
application.
Power Input Power over Ethernet (PoE),
IEEE standard 802.3af
Operating
Temperature 0 to +40°C (-32 to +104°F)
Enclosure Polymer
Weight 0.30 kg (.66 lbs)
Mounting & Installation
The Evolution Mini Recessed camera allows for easy
and fast internal installation from below the ceiling
line. The camera is IP40-rated and UL2043 certied
for installation in air handling spaces. The camera
provides recessed mounting in drop ceilings or walls
with a maximum cross section of 25.4 mm (1-inch).
1. Cut a 108 mm (4¼-inch) hole in the mounting
location. A template is supplied if required.
2. Connect the Ethernet coupler to the network
infrastructure cable. Pass any spare cable length
through the hole into the ceiling before tting the
camera.
3. Connect the camera and conrm the LED lights
illuminate when powered.
4. Push both retaining springs to an upright position
and insert the camera into the hole.
5. Release the springs and gently push the camera
into position.
6. Carefully remove the lens protection lm.
Reference the Installation and User Manual for more
information.
EVO-05-LRD
MAC Address
Document the camera’s installation location and unique
MAC address. Find the MAC address printed on the
camera label. This information may be needed during the
camera conguration.
Supplied Parts
• EVO-05 Mini Camera • Quick Start Guide
• RJ45 Coupler • Drilling Template
Technical Support
For the A&E, Specication, Installation and User Manual, Software
and Firmware visit:
https://www.oncamgrandeye.com/resources/product-downloads/
Tel: UK [phone]
US [phone]
Email: [email protected]

© Copyright 2020 ONVU Technologies AG. All rights reserved. Oncam is a trading name of ONVU Technologies AG. Specications and congurations subject to change without
notice.
EVO-05-L#D-04 |Recessed Mini |11.2020 |Rev F
Conguring Network Settings
Powering the Camera
Supply power to the camera with PoE IEEE802.3af through
the integrated cable.
IP Settings
In order to use the camera you need the IP address.
There are two IP Settings.
• DHCP server or router to automatically assign unique
valid IP addresses to each camera.
• A manually congured network using static IP
addresses.
If your network has a DHCP server, go to First Time Camera
Access.
Should a DHCP server not be available, the camera adopts the
default static IP address 192.168.0.200. You will then need to
manually assign each camera with a new unique IP address.
Note: See the camera’s User Manual and Camera
Conguration Tool User Manual for IP Setting.
First Time Camera Access
Web Browser
1. If you know the IP address of the camera, enter this
into the address bar of your web browser (Internet Explorer, Edge,
Firefox or Chrome). The camera should be on the same network.
2. Create an Admin username and password.
Notes:
Internet Explorer 11 is required to view live camera images in the browser.
All other browsers can be used for conguration purposes only.
Ensure you have the latest VLC Media Player (http://www.videolan.org/vlc/
index.html) for viewing camera images on the web interface.
Camera Conguration Tool
1. Select a camera from the camera list
2. Select your browser to open the web interface.
3. Click OK on the authentication pop up. You will then be prompted
to create and set an Admin username and password to access the
camera.
Download our FREE ONVU360 Pro mobile application and
put the 360-degree experience right at your ngertips.
Scan the QR Code to get it now!
Android iOS
Using the Camera Conguration Tool
Go to the Oncam website (https://www.oncamgrandeye.com/
resources/camera-cong-tool/) to download the latest version of
the Camera Conguration tool and corresponding User Manual.
The Camera Conguration tool quickly nds the IP and MAC
addresses of all Oncam Evolution cameras connected to
the network. It also allows you to change network settings,
congure the system and perform software updates on multiple
cameras. Initiate a new scan by clicking the Full Discover button
Start the application by clicking the CameraCongurationTool
icon found on your desktop or from the program list (under
Oncam Grandeye). The software scans the network and provides
a list of all connected Oncam Evolution cameras.
Note: Some functions in this tool require a username and
password. If accessing the camera for the rst time, an
administrator username and password will need to be set.
