Kraus Exquisite Series User manual

6.14’’
45
4.2’’
5.4’’
45
3.11’’
25
G 1/2
Max 1.2’’
O 35
Exquisite Collection
Installation Manual
Single-lever bathroom faucet
Before Your Installation
Check to make sure you have the following parts indicated below:
Tools You Will Need
Adjustable wrench
Spanner for body
(supplied)
Plpe tape
(supplied)
Phillips screwdriver
Adjustable wrench
KEF-14601
AB1953
Contact Us Toll-Free at 1-800-775-0703; or visit our website at www.kraususa.com 2008-2011 Kraus USA Inc.Contact Us Toll-Free at 1-800-775-0703; or visit our website at www.kraususa.com 2008-2011 Kraus USA Inc.
KRAUS Brand Bathroom Faucets Limited Lifetime Warranty
KRAUS is proud to offer its customers the strongest, most durable ceramic cartridges in all solid
brass Bathroom Faucets it manufactures. KRAUS guarantees all products to be free of defect in
materials and craftsmanship. All KRAUS BRAND Bathroom Faucets carry a limited lifetime warranty
from the original date of purchase.
If a product fails due to defect in material or craftsmanship during the warranty period, KRAUS will
repair or replace the items at its sole discretion. Warranty does not apply when the item has been
tampered with, misused, improperly installed, altered, or damaged due to abuse or accident.
Proof of purchase (original sales receipt) must be provided to KRAUS for all warranty claims.
Please contact one of our representatives if you need any additional details.
All KRAUS products must be installed by a licensed professional plumber or contractor to avoid any
improper use or installation.
IN NO EVENT SHALL KRAUS BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL OR
SPECIAL DAMAGES, INSTALLATION COST, LABOR, TRAVEL TIME, FREIGHT COSTS
INCURRED, LOST PROFITS, OR CONTINGENT LIABILITIES.
KRAUS USA Inc. makes no representation that its products comply with any or all local building or
plumbing codes. It is the consumer’s responsibility to determine local code compliance.
This warranty extends to the original purchaser and first
consumer.

1 3/8’’
O
4
3
1
2
3
4
5
6
7
2
1
Faucet body
Waterlines
Fixing bolt
O-ring
Rubber washer
Brass washer
Fixing nut
1.
2.
3.
4.
5.
6.
7.
Replacement Parts
Keep this manual for ordering replacement parts.
Trouble - Shooting
Problem Cause Action
Leaks underneath handle
Aerator leaks or has an inconsistent
water flow pattern.
Water will not shut off completely.
Adjusting ring or cap has come loose.
Aerator is dirty or misfitted.
Dirty or worn out plastic washer in the
cartridge.
Tighten the adjusting ring or cap.
Unscrew the aerator to check rubber packing
or replace the aerator.
Remove handle and cartridge to check if ceramic
disk is damage permanently or dirty.
Re-install cartridge.
Contact Us Toll-Free at 1-800-775-0703; or visit our website at www.kraususa.com 2008-2011 Kraus USA Inc.
Installation
Contact Us Toll-Free at 1-800-775-0703; or visit our website at www.kraususa.com 2008-2011 Kraus USA Inc.
Screw waterlines 2 into the inlet pipe of faucet body 1.
Fit O-ring 4 into the bottom groove of faucet body 1.
After, screw the fixing bolt 3 into the corresponding
screw-hole of faucet body 1.
Insert waterlines 2 and fixing bolt 3 through the drilled hole
1 3/8’’ of the countertop. Put rubber washer 5 and brass
washer 6 onto the fixing bolt, screwing in the nut 7. Then
place faucet body 1 correctly and securely tighten nut 7.
