Kraus Bolden KPF-1610 User manual

www.kraususa.com I Toll Free: 1.800.775.0703 I © 2022 Kraus USA Plumbing LLC I REV. April 7, 2022
BoldenTM Single Handle
Commercial Kitchen Faucet
KPF-1610
R
INSTALLATION MANUAL

2
Congratulations on the purchase of your new
Kraus plumbing fixture!
Please keep the box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance or have any problems with your product:
Please contact our Customer Service Team
1-800-775-0703 / [email protected]
Have the model number available and retain a copy of your
receipt with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.
DO NOT RETURN TO STORE
STOP
R

3
Prior to Installation:
·Make sure you have all necessary parts by checking the diagram and parts list. If any
part is missing or damaged, please contact Kraus Customer Service at 800-775-0703
for a replacement.
·Read all instructions and safety warnings and ensure you have all tools, parts, and
equipment necessary for a safe installation.
·Turn off the hot and cold water supply at the angle stops and turn on the old faucet
to release any built up pressure. Remove existing faucet. Clean sink or countertop to
remove any debris, plumber’s putty, or silicone.
·Flush angle stops to release any debris prior to installation.
·Pre-drilled hole size requirement: 1 3/8" (min)
·Max countertop thickness: 2 1/2”
·1, 2 or 3 hole installation with optional deck plate (sold separately)
Tools Required
Adjustable Wrench Phillips Screwdriver Safety Goggles Pipe Tape Silicone Sealant
STOP
R
Care & Maintenance
To keep the product clean & shining, follow the steps below:
1. Rinse with clean water & dry with a soft cloth
2. Do not clean with soaps, acid, polish, abrasives or harsh cleaners
3. Do not use cloth with a coarse surface
4. Unscrew the aerator and clean when necessary
This installation manual is subject to change without further notice.
ACID

44
Diagram and Parts List
A. Spray Head
B. Faucet Body
C. Mounting Hardware
C1. Rubber & Metal
Washer
C2. Mounting Nut
C3. Mounting Screws
D. Supply Hose
E. Hot & Cold Waterlines
E1. Hot
E2. Cold
F. Hose
G. Weight
H. Hex Wrench
I. Quick Connector
Assembly
A
B
C1
C2
C3
D
E1 E2
F
H
G
I
For technical assistance or replacement parts, please contact Kraus
Customer Service and one of our representatives will be happy to help:
Toll-Free: 800-775-0703 or [email protected]
R

55
Installer Tip:
Shut off main water supply before installing new faucet.
4 1/2"
(116mm)
18"
(456mm)
2 1/4"
(56mm)
6 3/8"
(162mm)
8 3/4"
(221mm)
3 1/2"
(88mm)
Ø1 7/8"
(48mm)
Ø2 1/8"
(54mm)
10 3/4"
(274mm)
22 3/4"
(578mm)
17"
(432mm)
90°
25°
3/8" Compression
Faucet Dimension

66
Step 1. Remove mounting hardware
Step 2. Install the faucet and mounting hardware
Remove mounting hardware (C1, C2 & C3)
from faucet body (B).
Insert faucet body through the hole in the
sink or countertop.
Install the rubber washer and metal washer
(C1), mounting nut (C2) and mounting
screws (C3) onto the threaded mounting
shank.
Step 3. Secure mounting hardware
Thread the nut (C2) onto the mounting
shank. Lock the nut (C2) into position by
tightening the screws (C3). Do not
overtighten.
B
C1
C2
C3
C1
C2
C3
C2
C3

7
Step 4. Connect the quick connector
Connect the quick connector (I) to the
supply hose (D) by twisting clockwise. Push
the spray hose (F) firmly upward into quick
connector. Pull down moderately to ensure
the connection has been made.
I
F
Step 5. Attach the weight
Install the weight (G) on the indicated mark
on the spray hose (F).
G
F
D

8
Step 6. Making the waterline connections
Step 7. Flushing and checking for leaks
Thread the nut (1) on the supply line onto
the outlet of the water supply valve and
tighten with a wrench. Do not overtighten.
Pull the hose assembly out of the spout
and remove the spray head by unscrewing
it from the hose in a counterclockwise
direction. Be sure to hold the end of the
hose down into the sink and turn the
faucet on to the warm position where it
mixes hot and cold water. Flush the water
lines for one minute. This flushes away any
debris that could cause damage to internal
parts. Check for leaks. Re-tighten any
connections if necessary, but do not
overtighten. Reinstall the spray head by
hand tightening it back onto the spray
hose. After installation is completed, turn
on the hot and cold water supplies. Check
for leaks.
1

9
Replacement Parts
Replacement Finish/Color Part #
Parts List
KP12202
*Denotes spray hose assembly color options:
Spray hose assembly color options: Black hose
with Matte Black connector (BLMB), Black hose
with Stainless Steel connector (BLSS),
Gray hose with Chrome connector (GRCH),
Gray hose with Stainless Steel connector
(GRSS), Black hose with Spot Free Stainless
Steel connector (BLSFS), Gray hose with Spot
Free Stainless Steel connector (GRSFS)
**Denotes faucet component color options:
CH - Chrome
SS - Stainless Steel
MB - Matte Black
SSCH - Stainless Steel/Chrome
SSMB - Stainless Steel/Matte Black
SFS - Spot Free Stainless Steel
SFSCH - Spot Free Stainless Steel/Chrome
SFSMB - Spot Free Stainless Steel/Matte Black
1. Spray Head
2. Check Valve
3. Washer
4. Hose
5. Spring Assembly
6. Sprayer Support Assembly
7. Hose Guide
8. Sleeve
9. Cap
10. Set Screw
11. Cartridge
12. Locking Nut
13. Cartridge Cover
14. Handle
15. Handle Set Screw
16. Cap
17. Base
18. Base O-ring
19. Rubber Washer
20. Metal Washer
21. Mounting Nut & Screws
22. Protective Sleeve
23. Filter Washers
CH,SS,MB,SFS**
1
24. Weight
25. Hex Wrench
GRCH, GRSS,
GRSFS, BLSFS
KP12003
KP12205
KP12204
KP12189
KP12206
KP12203
KP12008
KP12009
KP12010
KP12015
KP12014
KP12013
KP12011
KP12012
KP12009
KP12016
KP12122
KP12018
KP12019
KP12020
KP12021
KP12026
KP12024
KP12028
CH,SS,SFS,MB,
SFSCH, SFSMB
2
3
4
7
5
6
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
CH,SS,MB,SFS**
CH,SS,MB,SFS**
CH,SS,MB,SFS**
CH,SS,MB,SFS**
CH,SS,MB,SFS**
CH,SS,MB,SFS**
BLSS, BLMB*
SSCH, SSMB**
26
26. Quick Connector KP12201
Assembly

Troubleshooting
If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps:
Leakage under faucet handle Locking nut has come loose or
cartridge needs to be reseated
Loosen the set screw located at the base of
the handle with a hex wrench. Remove the
handle and unscrew cartridge holder by
hand. Tighten locking nut with an
adjustable wrench.
The water pressure
is low.
The connector underneath
the deck is clogged with debris
The aerator is clogged
Turn off the water supply and disconnect
the connector / aerator. Unscrew the
connector / aerator and clean under
running water. Screw the connector /
aerator back.
Test water flow. If water pressure is still low
then replace the connector / aerator.
The aerator has an
irregular or reduced
water flow
The aerator is dirty or
mis-fitted
Remove the aerator and check for debris.
Ensure that the rubber washer is properly
installed.
There is a low flow of
water.
The screen filter in the hose
connectors is dirty.
Turn off the water supply at water valve
and unscrew the hose connectors from
water supply lines. Clean the screen in the
water lines with hot water, removing any
debris or calcium build up.
PROBLEM CAUSE ACTION
10

11
Codes/Standards Applicable:
ASME A112.18.1
1.8GPM 6.8L/min maximum
UPC
CR
UPC
CR
NSF/ANSI 372 NSF/ANSI/CAN 61: Q ≤ 1
Faucet
Kraus USA Plumbing, LLC (“Kraus”) extends this warranty to the original purchaser for personal household use of the
Faucet when purchased from an authorized Kraus dealer and in the location of original installation. This warranty is
non-transferable.
Kraus warrants the structure and finish of the Faucet to be free from defects in material and workmanship under normal
usage for as long as the original purchaser resides in the residence in which the Faucet was first installed.
Kraus warrants the Faucet's sprayhead assembly (including the engine, aerators, structure, restrictors, back flow
preventers, sprayer hoses, braided supply line hoses which encompasses nylon, silicon and stainless steel) of the product
to be free from defects in material and workmanship under normal usage for a period of one (1) year from the date of
purchase.
Kraus warrants the Faucet's cartridge to be free from defects in material and workmanship under normal usage for a
period of five (5) years from the date of purchase.
Any product reported to the authorized dealer or to Kraus as being defective within the warranty period will be repaired
or replaced with a product of equal value at the option of Kraus.
Commercial Warranty
Kraus USA Plumbing, LLC (“Kraus”) warrants its Products for a period of one (1) year to commercial purchasers of
Products used in industrial, commercial and business applications.
Care and Cleaning Instructions
Certain cleaning products may cause damage to a Product's finish and use of the following on the Product will void this
warranty:
·Abrasive cleaners such as powders, bleach, ammonia, alcohol or chorine
·Abrasive pads, steel wool or wire brushes
What is Not Covered
This warranty does not cover Products that were discontinued when purchased or display Products, whether such
Products were purchased at discount outlets, unauthorized dealers, and/or sold on clearance. This warranty does not
cover any free gifts included with purchase.
This warranty does not cover damage resulting from neglect, misuse (including use for an unintended application),
abuse, carelessness, accident, hard water or mineral deposits, exposure to corrosive materials, improper maintenance,
alteration of the Product, or failure to follow care, cleaning or installation instructions enclosed with your Product. Kraus
recommends that all Kraus Products be installed by a fully licensed and insured trade professional with experience in the
installation of bathroom and/or kitchen manufactured goods.

Download the Kraus Care & Maintenance Guide at:
http://www.kraususa.com/maintenance
12
How to Make a Warranty Claim
If you are a consumer purchaser, please contact a Kraus Customer Service Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
Toll-free 800-775-0703
[email protected]
If you are a plumbing contractor or trade professional, please contact a Kraus Pro Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8955
[email protected]
If you are an authorized partner, please contact a Partner Support Representative at:
Kraus USA Plumbing, LLC
12 Harbor Park Drive
Port Washington, NY 11050
516-801-8954
[email protected]
In requesting warranty service, please be ready to provide your proof of purchase and a description of the problem.
Shipping charges will be covered for the first (1) year of the warranted replacement part or product (HI, AK, and Puerto
Rico shipping charges may apply). International shipping fees are not included.
Limitation on Duration of Implied Warranties
Please note that some states/provinces (including Quebec) do not allow limitations on how long an implied
warranty lasts, so the below limitations may not apply to you. TO THE MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW, ANY IMPLIED WARRANTY, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
OF FITNESS FOR A PARTICULAR PURPOSE, IS LIMITED TO THE STATUTORY PERIOD OR THE DURATION OF THIS
WARRANTY, WHICHEVER IS SHORTER.
Limitation of Special, Incidental or Consequential Damages
Please note that some states/provinces (including Quebec) do not allow the exclusion or limitation of special,
incidental or consequential damages, so the below limitations and exclusions may not apply to you. TO THE
MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND KRAUS USA
PLUMBING, LLC SHALL NOT BE LIABLE FOR, ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES
(INCLUDING LABOR CHARGES TO REPAIR, REPLACE, INSTALL OR REMOVE THIS PRODUCT), WHETHER ARISING
OUT OF BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, BREACH OF CONTRACT, TORT, OR OTHERWISE.
This warranty gives you specific legal rights, and you may also have other rights which vary from state/province to
state/province.

Register Your Kraus Product
Activate Your Warranty
Access Premium Customer Support
Get Product Information
REGISTER TODAY
http://www.kraususa.com/registration
R
www.kraususa.com
IMPORTANT
