Kraus KCA-1102 User manual

KCA-1102
All-In-One
Kitchen Set
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2018 Kraus USA Inc. I REV. December 10, 2018

Congratulations on the purchase of your new
Kraus plumbing fixture!
Please keep the box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance or have any problems with your product:
2
Please contact our Customer Service Team
1-800-775-0703 / [email protected]
Have the model number available and retain a copy of your receipt
with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.

3
Make sure to check off that you have all of the following items
Prior to Installation:
·Make sure you have all necessary parts by checking the diagram and parts list. If any part is missing or
damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement.
·Turn off the cold and hot water at the angle stops and turn on the old faucet to release and built up pressure
·Flush angle stops to release any debris prior to installation
·Pre-drilled hole size requirement: 1 3/8" (min) - 1 1/2" (max)
·Max countertop thickness: 1 3/4"
Kitchen Sink - KHT400-33
Kitchen Faucet - KPF-1610SS
Cut-Out Template
Undermounting Hardware
Top Mount Hardware
Bottom Grid - KBG-T400-33
Drain - ST-1

4
Tools you will need:
4
NOTE: Specialized tools may be necessary to install Kraus Stainless Steel Kitchen
sinks with countertop materials other than wood, marble or granite.
Phillips Screwdriver Pencil
Tape Measure
Putty Knife
Safety Goggles Silicone Adhesive Jig Saw
Drill
Scissors Screwdriver

55
Model #: KHT400-33
Sink Dimensions: 33” x 22” x 9”
Min Cabinet Size: 36”
Matching Grid: KBG-T400-33
Drain Model #: ST-1
Dimensions:
33" (838.2mm)
30 1/2" (774.7mm)
22" (558.8mm)
17" (431.8mm)
3 1/2" (90mm)
1 3/8" (35mm)
3 1/2" (88.9mm)
2" (50.8mm)
4 1/2" (114.3mm)
1 1/4"
(31.8mm)
3/8"
(10mm)
9" (228.6mm)
3/8"
(10mm)

66
Topmount Installation
Step 1. Position Template
·Check the cut-out template against the actual sink to ensure a proper
sized cut-out.
·Place the cut-out template in the desired location on the countertop.
NOTE: Make sure clearance is suitable for backsplash, faucet and plumbing for the sink.
Step 2. Trace Template
·Trace template on countertop with a pencil.
Paper Template
Paper Template

7
Step 3. Cut Countertop
·Cut the opening in the countertop by carefully following the traced line.
NOTE: Please use the appropriate saw that best fits your countertop material.

8
Step 4. Attach Mounting Hardware
·Attach mounting hardware to the prongs protruding from the underside of the sink rim.
·Make sure the hooked side of the mounting clip is facing away from the sink.
Insert

9
Step 5. Apply Silicone or Plumber's Putty
·Clean and dry the surface around the opening of the sink.
·Turn the unit upside down to apply sealant. Apply silicone-based sealant (not included) underneath the edge of the
sink.

10
Step 6. Secure Sink to Countertop
• Insert the sink into the opening, check the alignment of the sink to the cutout in the countertop and press firmly.
• Tighten the screws in the front of the sink, followed by the ones in the back and on the sides of the sink.
• Remove excess silicone-based sealant.
· Allow sealant to set for 30-60 minutes.
Sealant or Putty
Sink
Countertop
Fasten the Screw

11
Step 7. Install Plumbing Fixtures
·Connect drain to sink. Connect trap to drain. Connect water supply connections to faucet according to manufacturer's
instructions.
·Run water into sink and check for leaks.

12
Undermount Installation
Step 1. Determine reveal type
·Use scissors to cut along the line of the paper template for your desired reveal type (Negative, Positive, or Flush
Reveal)
KRAUS Recommended Installation Type
3/8" Positive Reveal
Flush/Zero Reveal
1/8" Negative Reveal
1/8" NEGATIVE
FLUSH/ZERO REVEAL
3/8" POSITIVE
CENTERLINE

13
·Check the cut-out template against the actual sink to ensure a proper
sized cut-out.
·Place the cut-out template in the desired location on the countertop.
Step 2. Position template
Paper Template
NOTE: Make sure clearance is suitable for backsplash, faucet and plumbing for the sink.
Step 3. Trace Template
·Trace template on countertop with a pencil.
Paper Template

14
·Cut the opening in the countertop by carefully following the traced line.
Step 4. Cut countertop
NOTE: Please use the appropriate saw that best fits your countertop
material.
·Turn countertop over and align sink with countertop. Decide location
for mounting brackets.
·Mounting holes should be 1/2" from edge of sink.
Step 5. Set up mounting brackets

15
·Drill 3/8" diameter x 1/2" deep hole in the countertop.
Step 6. Drill hole in countertop
·Insert anchors into drilled holes and lightly tap with a hammer until flush.
Step 7. Install anchors

16
·Use a bead of silicone (or preferred adhesive) around the rim of the
sink. Check the alignment of the sink to the cutout in the countertop.
Place sink over cutout hole and press firmly.
Step 8. Secure sink to countertop
Step 9. Attach mounting hardware
NOTE: Use acetone or rubbing alcohol to remove any excess sealant.
·Attach mounting hardware to secure bowl. Remove excess sealant
from inside lip.
·Allow sealant to set for 30 - 60 minutes.

17
·Connect drain to sink. Connect trap to drain. Connect water supply connections to faucet according to manufacturer's
instructions.
·Run water into sink and check for leaks.
Step 10. Install plumbing fixtures
Maintenance
Clean your sink on a regular basis with warm soapy water. Rinse the sink after using cleaning products. Wipe the sink
surface with a soft cloth to remove any liquid residue. Do not cut food directly on the surface of the sink. Do not leave
sharp objects on the surface of the sink for an extended period of time. Do not use abrasive cleaning products, sanding
tools, steel wool or bleaching products.

18
Diagram and Parts List
1. Spray Head
2. Faucet Body
3. Mounting Hardware
A. Rubber Washer
B. Metal Washer
C. Mounting Nut
D. Mounting Screws
4. Supply Hose
5. Hot & Cold Waterlines
6. Hose
7. Washer
8. Weight
9. Hex Wrench
10. Washer (2.2GPM)
Please note: This faucet is designed with a 1.8 gpm flow rate in compliance with CEC standards. To adjust the flow rate to 2.2
gpm, replace the washer (7) with the 2.2 gpm washer provided in package. Work with your local jurisdiction to make sure you
are in compliance prior to and modification. All modifications are done so at the end users discretion, Kraus is not liable for
any indiscretions that may occur which lead to non-compliance.

19
10 3/4"
274mm
8 3/4"
221mm
4 1/2"
115mm
18"
456mm
6 3/8"
162mm
2 1/8"
54mm
Faucet Installation Procedure
Installer Tip
Shut off main water supply before installing new faucet

20
1. Remove mounting hardware
·Remove the mounting screws (3D), mounting nut (3C), metal (3B)
and rubber washer (3A) from the mounting pipe.
2. Install faucet mounting hardware
·Insert faucet body (2) into hole in countertop. Install mounting
hardware (3A, B, C & D) from underneath the countertop.
