INSTALLATION GUIDE
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2021 Kraus USA Plumbing LLC I REV. NOV 17, 2021
Kohra™ Two Handle 8-Inch
Widespread Basin Bathroom
Faucet
FUS-14003

1
Congratulations on the purchase of your new
Please keep the box and packaging materials until your product is
completely installed. If you have any questions, require technical
assistance, or have any problems with your product:
Please contact our Customer Service Team
1-800-775-0703 / [e-mail]
Have the model number available, and retain a copy of your receipt
with purchase date for reference.
If for any reason this product does not meet your expectations,
please be sure to repack this product in the original box and
packaging material to avoid damage during transit.
DO NOT RETURN TO STORE

2
Prior to Installation:
•Make sure you have all necessary parts by checking the diagram and parts list. If
any part is missing or damaged, please contact Kraus Customer Service at 800-775-
0703 for a replacement
•
•
Pre-drilled countertop hole size requirement: 1-3/8”(min)
•
Max countertop thickness: 1 7/8”
Tools you will need:
13
Wrench Phillips Screwdriver Safety Goggles
Silicone Sealant
(optional)
Pipe Tape
Turn o the hot and cold water lines at the angle stops and turn on the old faucet
to release any built-up pressure
STOP
•
Read all instructions and safety warnings and ensure you have all tools, parts,
and equipment necessary for a safe installation.
Care & Maintenance
* To keep the product clean & shining, follow the steps below:
1. Rinse with clean water & dry with a soft cloth
2. Do not clean with soaps, acid, polish, abrasives or harsh cleaners
3. Do not use cloth with a coarse surface
4. Unscrew the aerator and clean when necessary
* This installation manual is subject to change without further notice.
ACID

Diagram and Parts List
3
A
F1
F2
G
H1
H2
H3
H4
A. Hot Handle Valve
B. Spout
C. Aerator
D. Aerator Wrench
E. Cold Handle Valve
F. Spout Mounting Hardware
F1. Rubber & Metal Washer
F2. Mounting Nut
G. Three Way Connector
H. Hot & Cold Handle
Mounting Hardware
H1. Spacer
H2. Metal Washer
H3. Mounting Nut
H4. Mounting Screws
I. Hex Wrench
H1
H2
H3
H4
I
B
C
D
E

Diagram and Parts List
4
o
n
m
a
b h i j k
c
d
e
f
g
l
a. Waste Stopper
b. Drain Flange
c. Rubber Washer
d. Concave Washer
e. Metal Washer
f. Mounting Nut
g. Tail Pipe
h. Top Hat Washer
i. Drain Off Pole
j. Washer
k. Retaining Nut
l. Clip
m. Extender Rod
n. Thumb Screw
o. Lift Rod

Faucet Dimension
Installer Tip:
5
6.3
14 7/8"
(379mm)
7"
(177.1mm)
3 5/8" (91.3mm)
5 3/8"
(136.6mm)
4 3/4"
(121.7mm)
1/2-14NPSM-2A
MAX 1 7/8"
(47.1mm)
8 3/4"
(223.8mm)
Ø1 1/4"
(32mm)
Ø2 1/8"
(54mm)
1 3/4" -2 3/4”
(43.3-68.3mm)
5 5/8"
(141.6mm)
1 1/4-18UNEF-2A

Step 1: Remove mounting hardware
Step 2: Installing the faucet assembly
6
Remove three way connector (G)
and mounting hardware (F) from
spout (B). Remove mounting
hardware (H) from hot and cold
valves (A&E).
Insert spout (B) through hole in
sink or countertop. Secure spout
with mounting nut (F2) with an
adjustable wrench.
H
F
G
H
F1
F2
A
B
E
B
F2
B
1
2
3
Installer Tip: Make sure slot
opening of u-washer (F1) faces
toward rear of sink.

Step 3: Installing handles
Step 4: Attach connector
7
Insert hot & cold handle valves
(A&E) through hole in sink or
countertop. Attach hot & cold
mounting hardware (H). Secure
with adjustable wrench and Phillips
head screwdriver.
Attach three way connector (G) to
spout (B). Attach supply lines of hot
& cold valves (A&E) to three way
connector (G). Push until you hear
a click.
H
H
B
GEA
A
A
E
B
1
G
E
2
H4
H3
1
1
2
2
1
2
2
1
2
2
Click
Click Click
Installer Tip: Pull supply lines
moderately to ensure connection is
secure.
3
4

Attach waterlines (not included)
to valves (A&E) and angle
stops. Tighten until snug. Turn
on angle stops and check for
leaks. (DO NOT TURN FAUCET
ON)
Remove waste stopper (a) and
drain flange (b) from tail pipe
(g). Remove concave washer (d),
metal washer (e) and mounting
nut (f) from drain flange (b).
A
B
E
a
b
c
f
d
e
g
Installer Tip: Recommended
waterlines: 3/8 in. OD x ½ in IPS
Step 5: Connect waterlines
Step 6: Install drain
8

Step 6: Install drain - continued
9
e
g
f1
d
b
c
Insert 2
i
m
Insert 1
a
g
gl
k
B
o
m
n
Insert drain flange (b) through
drain hole with rubber washer
(c) attached. From underneath,
place concave (d) and metal (e)
washer on drain flange. Secure
with mounting nut (f). Thread
tailpipe (g) onto drain (b) and
hand tighten.
2
1
1
2
1
2
3
Insert waste stopper (a) into
drain flange. Remove extender
rod (m) and clip (l) from drain
off pole (i). Remove nut (k).
Insert drain off pole (i) into
drain pole opening of tailpipe
(g). See Insert 1. Secure nut (k)
to drain off pole opening of
tailpipe (g).
Insert lift rod (o) through spout
(B) and connect with extender
rod (m). Tighten thumb screw
(n).
Installer Tip: For quick removal,
rotate stopper 90 degrees left or
right, so drain off pole (i) does not
go through hole in stopper (a).
3
