Communications Handbook for the MFC 300

2

3
1. Introduction
1.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
1.2 Items included with supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
1.3 Special Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2. PROFIBUS DP Device With RS-485 Interface
2.1 Software History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.2 PRIOFIBUS DP System Architecure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.3 Bus Conection PROFIBUS DP Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.4 GSD Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.4.1 Manufacturer specific GSD file: KR014510.GSD . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.4.2 Profile specific GSD file: PA039742. GSD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.4.3 Cyclic data exchange . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
2.5 Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
2.6 Data Structure of Function Block Output Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
2.7. Diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
2.8 Display Parameters (PROFIBUS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
2.9 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
3. PROFIBUS PA DEVICE (MBP INTERFACE & PA PROFILE 3.01)
3.1 Software History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
3.2 PROFIBUS PA System Architecture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
3.3 Bus Connection - PROFIBUS PA Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
3.4 GSD Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
3.4.1 Manufacturer specific GSD file: KRO14511.GSD & YPO124511.GSD . . . . . . . . .24
3.4.2 Profile specific GSD file: PA2139742. GSD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
3.4.3 Cyclic data exchange . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
3.5 Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
3.6 Data Structure of Function Block Output Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
3.7 Diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
3.8. Display Parameters (PROFIBUS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
3.9 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
OPTIMASS
CONTENTS

4
•Do not install, operate or maintain this device without reading, understanding and following
the factory-supplied handbook. Failure to do so, may result in injury or damage.
•Read these instructions carefully before starting installation and save them for future ref-
erence.
•Observe all warnings and instructions marked on the device.
•You MUST only use a power supply that has a protective earth.
•Do not use the device with covers removed!
•You MUST follow the installation instructions in the handbook, paying particular attention
to
•Handling
•Lifting
•Supporting and fixing the meter
•Cabling and connections.
•If the product does not operate normally, refer to the handbook or consult a qualified
KROHNE service engineer. There are no operator-serviceable parts inside the product.
EExxppllaannaattiioonnooffSSyymmbboollssUUsseedd
The follwing is a guide to the meaning of the symbols used in this handbook.The symbols fall
into two types. The rectangular symbols with blue background draws the reader’s attention to
general points of information. The triangular symbols with yellow background draw the read-
er’s attention to hazards or hazardous situations.
GGeenneerraallIInnffoorrmmaattiioonnInformation is important to the
installation/operation of the meter.
GGeenneerraallWWaarrnniinnggRisk of damage to the meter or installation.
EEXX--HHaazzaarrddoouussAArreeaaWWaarrnniinnggInstruction MUST be observed in order to
comply with Hazardous Areas Certification.
HHiigghhVVoollttaaggeeRisk of electric shock.
GGeenneerraallHHaazzaarrddNon specific hazard that could result in injury.
HHoottSSuurrffaacceeoorrHHiigghhTTeemmppeerraattuurreeRisk of burning.
HHeeaavvyyIItteemmRisk of injury.

5
These terms may appear in this manual or on the instrument:
WWaarrnniinnggssttaatteemmeenntt::Identify conditions or practice that could result in injury or loss of life.
or
CCaauuttiioonnssttaatteemmeenntt::Identify conditions or practice that could result in damage to the instru-
ment or other property.
DDiissccllaaiimmeerr::
•This document contains important information on the device. KROHNE attempts to be as
accurate and up-to-date as possible but assumes no responsibility for errors or omissions.
Nor does KROHNE make any commitment to update the information contained herein. This
manual and all other documents are subject to change without prior notice.
•KROHNE will not be liable for any damage of any kind by using this device, including, but
not limited to: direct; indirect; incidental; punitive and consequential damages.
•Any device purchased from KROHNE is warranted in accordance with the relevant product
documentation and our Terms and Conditions of Sale.
•KROHNE reserves the right to alter the content of its documents, including this disclaimer
in any way, at any time, for any reason, without prior notification and will not be liable in any
way for possible consequences of such changes.
PPrroodduuccttlliiaabbiilliittyyaannddWWaarrrraannttyy
•Responsibility for suitability and intended use of this device rests solely with the user.
Improper installation and operation of the device may lead to loss of warranty.
•In addition, the Terms and Conditions of Sale are applicable and are the basis for the pur-
chase contract.
•If a device needs to be returned to KROHNE, please note the information given at the back
of the Handbook. KROHNE regrets that they cannot repair or service a device unless
accompanied by the completed form
This instrument has been developed and manufactured by:
KROHNE Ltd
Rutherford Drive
Park Farm Industrial Estate
Wellingborough
Northants
NN8 6AE
United Kingdom
For information, maintenance or service, please contact your nearest local KROHNE represen-
tative.
See www.krohne.com
WWAARRNNIINNGG
No changes may be made to the devices. Unauthorized changes might affect the explosion
safety of the devices. Be sure to follow these instructions!
IIMMPPOORRTTAANNTT
•The prescriptions, regulations and electrical data described in the EC type examination cer-
tificate MUST be obeyed.
•In addition to the general regulations for low-voltage installations (e.g.HD384) the regula-
tions laid down in the standard for electrical installations in gas hazardous areas (e.g. EN
60079-14) or dust hazardous areas (e.g. EN 50 281-1-2) MUST be complied with.
•Installation, commissioning, utilization and maintenance must be carried out only by per-
sonnel trained in explosion safety.
•This manual must be read in conjunction with the OPTIMASS / OPTIGAS Handbooks.

6
OPTIMASS
1INTRODUCTION
1.1 General
These Instructions are supplementary to the “MFC300 (OPTIMASS) Handbook”. You must follow
that handbook in particular the Safety Information These Supplementary Instructions provide
additional information for device operation and connection to a PROFIBUS fieldbus.
1.2 Items included with supply
In addition to the standard scope of supply, these Supplementary Instructions for the MFC300
PROFIBUS RS-485 Interface will be included.
1.3 Special Notes
•Don’t switch off (power off) the MFC300 immediately after manual change of parameter val-
ues:
•Please wait approx. 10 seconds before you switch off the MFC300 after you have done
both a parameter download via PROFIBUS or a manual change of a parameter value
via the local display.
•Please wait approx. 15 sec before you switch off the MFC300 after you have carried
out a “Factory Reset” (PROFIBUS “Coldstart”) via PROFIBUS or local display.
•“Deactivation of the Service Parameter Lock” of the MFC300 via PROFIBUS:
•After writing down the service password (via PROFIBUS) the “Deactivation of the
Service Parameter Lock” will last at least 10 min. if the internal password timer of
the MFC300 won't be retriggered by writing this password again. The “Deactivation of
the Service Parameter Lock” will be terminated at once by a PROFIBUS Cold-/Warm-
Start or if the internal password timer of the MFC300 elapsed.

7
OPTIMASS
2PROFIBUS DP DEVICE WITH RS-485 INTERFACE & PA PROFILE 3.01
PLC PLC
PROFIBUS-DP
with max. 12 Mbit/s
Other devices with
PROFIBUS RS485
interface
Other devices with
PROFIBUS RS485
interface
2.1 Software history
IIssssuueeddSSiiggnnaallCCoonnvveerrtteerrAApppplliiccaattiioonnPPrrooggrraammSSyysstteemmIInntteeggrraattiioonn
Month/
Year Hardware Firmware Hardware Software Driver Version Model Name as used in the GSD:
11/06
MFC300 Signal
Converter with
RS485 Interface
and PA Profile
3.01 ("Profibus
DP device")
V2.2.1
/ 061117
• Simatic PCS7
• Others
• HW Config
• others
GSD
(Manufacturer specif-
ic, for standard
DP/PA segment cou-
pler )
KR014510.GSD "MFC300 (RS-485)
Rev. 1"
GSD
(Profile specific, for
standard DP/PA seg-
ment coupler)
PA039742.GSD "Flow,dens,temp
3AI, 1TOT (PhyL 0)"
Laptop/ PC PDM > 6.0 DD 4510 0300 01
Laptop/ PC Pactware DTM
(generic Flow DTM)
0300_1030001_
FDT12.exe
2.2 System Architecture
BB- DC
IIII
D-C-
R2 R1R1
+5V
I= 110nH
R1 = 390
R2 = 220
1
2.3 Bus Connection Profibus DP Device
For a detailed description of the electrical connections of the MFC300 please refer to the OPTI-
MASS Handbok.
The illustration above shows a typical instrumentation with PROFIBUS devices with RS-485
interface in non-hazardous locations. The PROFIBUS devices with RS-485 interface do not
need any segment coupler. They can be connected directly to the PROFIBUS DP Network.

8
MMFFCCTTeerrmmiinnaallssBB-CC-DD-
PPRROOFFIIBBUUSSDDeessiiggnnaattiioonnssT +B-A-T+B-A
Termination
positive
TxD+/RxD+
second connection
TxD-/RxD-
Second connection
Termination
negative
TxD+/RxD+
first connection
TxD-/RxD-
first connection
BB- DCD-C-
IIII
+5V
R2 R1R1
I= 110nH
R1 = 390
R2 = 220
3
BB- DCD-C-
IIII
+5V
R2 R1R1
I= 110nH
R1 = 390
R2 = 220
2
1External connection PROFIBUS DP device at low datarates connected with spur. (Spurs are
only allowed at low data rates)
2 External connection PROFIBUS DP last device, internal bus termination is active.
3 External connections PROFIBUS DP device in trunk.
Please also refer to publication: “
Installation Guidelines for PROFIBUS DP/FMS ” (PNO Order
Number 2.112/2.111)

9
2.4 GSD Files
Supported baud rates are listed in the GSD file (see below). After power-on or PROFIBUS time-
out a baud rate search is active to detect the current transfer speed on the bus. It is not neces-
sary to set the baud rate manually.
If the transfer speed is changed during operation the baud rate search will not be started by
the device. A new power-up or a manual interruption of the PROFIBUS communication is
required to activate the baud rate search in this case.
A “PROFIBUS GSD ZIP” file (e.g. GSD-31777815.zip) including both all KROHNE GSD files and
additional data files can be downloaded from the KROHNE homepage http://www.krohne.com
or contact “KROHNE Marketing”. The GSD file contains information that will be needed for
project planning of the PROFIBUS DP communication network. The relevant data files (e.g.
MFC300_n.bmp; MFC300_n.dib) must be loaded into the bus configuration system/master sys-
tem before start-up of the bus system.
The MFC300 PROFIBUS RS-485 Interface is according to the PROFIBUS PA Profile V 3.01. The
device supports two Ident-No:
•Ident-No. “4510hex” belongs to the GSD file KR014510.GSD and includes the complete func-
tionality concerning the cyclic data exchange of the coriolis mass flow meter MFC300.
•The application of the manufacturer independent Ident-No. “9742hex” (GSD file
“PA039742.GSD”) provides interchangeability of devices, i.e. an exchange of coriolis mass
flow meters of different vendors.
Please follow the instructions in the manual of the host supplier when installing the GSD File
you need and the additional files (MFC300_n.bmp and MFC300_n.dib) into the PLC. If separated
by the bus configuration system the device entry of the MFC300 PROFIBUS RS-485 Interface
with PA Profile 3.01 will be located within the slave family PROFIBUS PA.
22..44..11MMaannuuffaaccttuurreerrssppeecciiffiiccGGSSDDffiillee::KKRR001144551100..GGSSDD
KROHNE delivers the GSD files with the entire device functionality, as follows:
BBlloocckk
NNuummbbeerr
SSttaannddaarrdd--CCoonnffiigguurraattiioonn
function block output: value + status)
KKRR001144551100..GGSSDD
IIddeenntt--NNoo..44551100DDeeffaauullttuunniitt::
1 Mass Flow AI-FB kg/s
2 Density AI-FB kg/m3
3 Medium Temperature AI-FB K
4 Mass Totaliser Totaliser-FB kg
5 Volume Totaliser Totaliser-FB m3
6 Mass Totaliser Totaliser-FB kg
7 Volume Flow AI-FB m3/h
8 Concentration 1 AI-FB %
9 Concentration 2 AI-FB %
10 Concentration Mass Flow 1 AI-FB kg/s
11 Concentration Mass Flow 2 AI-FB kg/s

10
“Total” cyclic transfer of the totaliser value with status to the master
“SetTot + Total” cyclic transfer of the totaliser value with status to the master + cyclic
control data from master to the device via the parameter SetTot
“ModeTot + Total” cyclic transfer of the totaliser value with status to the master + cyclic
control data from master to the device via the parameter ModeTot
“SetTot+ModeTot+T
otal”
cyclic transfer of the totaliser value with status to the master + cyclic
control data from master to the device via the parameters SetTot and
ModeTot (in the given order)
“SetTot” cyclic control data from master to the device via the parameter SetTot
“ModeTot” cyclic control data from master to the device via the parameter ModeTot
“SetTot + ModeTot” cyclic control data from master to the device via the parameters SetTot
and ModeTot (in the given order)
The Byte SetTot and ModeTot are being sent cyclically from the Master to the device if these
bytes are inserted as output data via the PLC configurator. The meaning of these control bytes
are as follows:
AI = Analog Input Function Block
FB = Function Block
There are separate settings to select the units for local display and PROFIBUS. Modifications of
the units of the display will have no effect on the data transferred via PROFIBUS. A master
class 2 tool is required to modify the units for PROFIBUS transfer.
During network configuration the user has to define which function block outputs of the
MFC300-DP should be transferred cyclically to the master. This is done by a bus configuration
tool (e.g. for PC-S7 from Siemens this will be done with the tool “HW- Config”). This tool offers
the functions described as follows:
1. It is possible to configure an “Empty” block (the code of an “Empty” block is defined as
0x00) on each block number. This means, that for this block no data is transmitted in the
cyclic data telegram.
2. There is NO “Totaliser (TOT)” function block allowed on block position 1, 2, 3, 7, 8, 9, 10 and
11! An “Analog Input (AI)” function block or an “Empty” block is allowed here only!
Note: All codes supported of “Analog Input (AI)” - and “Totaliser (TOT)” – function blocks will
be found in the corresponding GSD files.
3. There is NO “Analog Input (AI)” function block allowed on block position 4, 5 and 6! A
“Totaliser (TOT)” function block or an “Empty” block is allowed here only!
4. There is a choice of 7 different totaliser functions, which can be allocated to the blocks 4, 5
and / or 6. The 7 functions are defined as follows:

11
Block Number Standard-Configuration
(function block output value)
PA039742. GSD
Ident-No. 9742
Default
unit:
1 Mass Flow AI-FB kg/s
2 Density AI-FB kg/m3
3 Medium Temperature AI-FB K
4 Mass Totaliser Totaliser-FB kg
All other values of ModeTot are not allowed. Value is ignored; totaliser remains in its last valid
setting.
The standard block configuration may be changed by the customer but using the default set-
tings is highly recommended. If the standard block configuration should be changed by the
customer an acyclic master tool must be used to change the “channel parameter” value of the
block which should be connected to another transducer output value.
22..44..22PPrrooffiilleessppeecciiffiiccGGSSDDffiillee::PPAA003399774422..GGSSDD
The functionality of the profile specific GSD file is limited. This GSD file includes only four
blocks:
SSeettTToott::
SetTot =0: Totaliser is totalising.
SetTot =1:
Totaliser will be reset to 0 and stays at 0 until SetTot is switched back again
to 0. If the value of SetTot changes from “1” to “0” the totaliser starts count-
ing from 0.
SetTot =2:
Totaliser is set to the value defined by PresetTot. PresetTot can be written via
a acyclic master (totaliser in block 4 = Slot 4 Index 32; totaliser in block 5 =
Slot 5 Index 32; totaliser in block 6 = Slot 6 Index 32). If the value of SetTot
changes from “2” to “0” the totaliser starts counting from the current value
defined by PresetTot.
SetTot ? 2: not allowed. Value is ignored; totaliser remains in its last valid setting.
MMooddeeTToott::
ModeTot = 0 totaliser totalises positive and negative values.
ModeTot = 1 totalises only positive values.
ModeTot = 2 totalises only negative values.
ModeTot = 3 totaliser is stopped, no totalization will be done.
ModeTot = 248 totalises all values as positive (negative values will be multiplied with “-1.0”)
ModeTot = 249 totalises all values as negative (positive values will be multiplied with “-1.0”)
The device has to be switched from “Manufacturer Specific” (full functionality) to “Profile
Specific” (interchangeable basic configuration) by using a master class 2 tool (IDENT_NUM-
BER_SELECTOR: Slot 0, Index 40 change byte value to 0). After this the device has to be pro-
jected by using the PA039742.GSD file.
22..44..33CCyycclliiccddaattaaeexxcchhaannggee
During network configuration the user has to define which function block outputs of the
MFC300 PROFIBUS RS-485 should be transferred cyclically to the master. Network configura-
tion will be done using one of the GSD files described above. The order of transmission of a
function block always remains the same even if a function block is defined as an “Empty” block
(in this case, no function block output data will be sent to the master and all function block out-
puts following the “Empty” block will move up one position).

12
Quality Quality-Substatus Limits
Gr Gr QS QS QS QS Qu Qu
2726252423222120
0 0 = bad
0 1 = uncertain
1 0 = good (Non Cascade)
1 1 = good (Cascade) - not supported
SSttaattuuss==bbaadd
0 0 0 0 0 0 = non-specific
0 0 0 0 0 1 = configuration error
0 0 0 0 1 0 = not connected
0 0 0 0 1 1 = device failure
0 0 0 1 0 0 = sensor failure
0 0 0 1 0 1 = no communication (last usable value)
0 0 0 1 1 0 = no communication (no usable value)
0 0 0 1 1 1 = out of service
Byte n Byte n+1 Byte n+2 Byte n+3
Bit7 Bit6 Bit7 Bit6 Bit7 Bit7
VZ 27262524232221202-1 2-2 2-3 2-4 2-5 2-6 2-7 2-8 2-9 2-10 2-11 2-12 2-13 2-14 2-15 2-16 2-17 2-18 2-19 2-20 2-21 2-22 2-23
Exponent Mantissa Mantissa Mantissa
Example: 40 F0 00 00 (hex) = 0100 0000 1111 0000 0000 0000 0000 0000 (binary)
Formula: Value = (-1)VZ * 2 (Exponent - 127) * (1 + Mantissa)
Value = (-1)0 * 2 (129 - 127) * (1 + 2-1 + 2-2 + 2-3)
Value = 1 * 4 * (1 + 0,5 + 0,25 + 0,125)
Value = 7,5
SSttaattuussVVaalluuee
The meanings of the status byte (unsigned integer) are given in the following tables
2.5 Profiles
The MFC300 PROFIBUS RS-485 Interface supports the PROFIBUS PA Profile Version 3.01.
The MFC300 PROFIBUS RS-485 Interface with PA Profile 3.01 supports the following blocks:
•One physical block.
This block contains the parameters defined in PA Profile 3.01.
•One transducer block for coriolis mass flow devices.
This block provides the parameters and functions defined in PA Profile 3.01.
•Eight “Analog Input (AI)” function blocks: as default “Mass Flow”, “Density”, “Medium
Temperature”, “Volume Flow”, “Concentration 1”, “Concentration 2”, “Concentration Mass
Flow 1” and “Concentration Mass Flow 2”.
•Three “Totaliser (TOT)” function blocks: as default the first and the third totaliser will
totalise “Mass” and second one will totalise “Volume”
2.6 Data Structure of Function Block Output Values
The data structure of function block outputs consists of 5 bytes: a 4 byte float value (Float
Format according IEEE Standard 754 Short Real Number) followed by a 1 byte status value. If
all 11 function block outputs have been projected (see above), 55 byte will be transmitted.
FFllooaattVVaalluuee
The following table gives an example of the float format

13
SSttaattuuss==LLiimmiittss
0 0 = ok
0 1 = low limited
1 0 = high limited
1 1 = constant
SSttaattuuss==ggoooodd((NNoonn--CCaassccaaddee))
100000 =ok
1 0 0 0 0 1 = update event
1 0 0 0 1 0 = active advisory alarm (priority < 8)
1 0 0 0 1 1 = active critical alarm (priority > 8)
1 0 0 1 0 0 = unacknowledged update event
1 0 0 1 0 1 = unacknowledged advisory alarm
1 0 0 1 1 0 = unacknowledged critical alarm
1 0 1 0 0 0 = initiate fail safe
1 0 1 0 0 1 = maintenance required
SSttaattuuss==uunncceerrttaaiinn
0 1 0 0 0 0 = non-specific
0 1 0 0 0 1 = last usable value
0 1 0 0 1 0 = substitute-set
0 1 0 0 1 1 = initial value
0 1 0 1 0 0 = sensor conversion not accurate
0 1 0 1 0 1 = engineering unit violation (unit not in the valid set)
0 1 0 1 1 0 = sub-normal
0 1 0 1 1 1 = configuration error
0 1 1 0 0 0 = simulated value
0 1 1 0 0 1 = sensor calibration
Check the first two quality bits in order to get the quality information of the measurement
value:
GGoooodd
((nnoonnCCaassccaaddee))function block output value is ok and can be used without restrictions
GGoooodd
((CCaassccaaddee))will not be supported, because it is not applicable for the device
UUnncceerrttaaiinnfunction block output value can be used but the accuracy can not be guar-
anteed (e.g. function block outputs value has been frozen or A/D converter
is saturated or out of range)
BBaaddfunction block output value is bad - don’t use it for process control!
The „Quality-Substatus“- and „Limit“-Bits will be used for further diagnostics or limit check-
ing.
Attention: The status should be monitored because a number will be transmitted even if
the status of the measurement value is bad or uncertain. This is the only way to check the
quality of the transmitted measurement values.
2.7 Diagnosis
If the device internal diagnostic functions detect an error additional information will be sent to
the Master (for further information have a look at the UNIT_DIAG_BIT(i) definitions of the cor-
responding GSD-file).

14
A Quick Setup
RReeffDDiissppllaayyDDeessccrriippttiioonn&&SSeettttiinnggss
A3 Reset
A3.1 Reset Errors
This menu function can be used to reset all
errors that are not removed automatically
(power fail, counter overflow)
step 1: reset?
NNoo: Exit the function
YYeessResets the errors and exits the func-
tion.
The following reset menus for the counters (totaliser) are only available, if
the quick access has been activated in the menu setup > device > quick
setup. Each counter (totaliser) can be activated for quick access independently.
A3.2 > FB4 Totaliser 1
(for PROFIBUS Devices) the counter can be
reset to zero in this menu
step 1: reset counter?
no: exits the function without reset
yes: resets the counter and exits the function
A3.3 > FB5 Totaliser 2
for PROFIBUS Devices the counter can be
reset to zero in this menu
step 1: reset counter?
NNooexits the function without reset
YYeessresets the counter and exits the func-
tion
A3.4 > FB6 Totaliser 3
(where fitted)
(for PROFIBUS Devices) the counter can be
reset to zero in this menu
step 1: reset counter?
NNooexits the function without reset
YYeessresets the counter and exits the func-
tion
A4 Station Address
(only for PROFIBUS devices)
A4 -> Station Address selects the address of the device at the PROFIBUS
DP interface.
Note:
The PROFIBUS address can also be changed using the PROFIBUS service
“set_slave_add”. The input range is 0...125 according to the PROFIBUS spec-
ification. Address 126 is the default address and cannot be set via the
PROFIBUS service “set_slave_add” - use menu instead to reset to default
address.
B Test level
BB33IInnffoorrmmaattiioonn
B3.5 PROFIBUS
available if there is a PROFIBUS interface in existence; displays the
below mentioned information about the PROFIBUS interface:
KROHNE Ident No.
Software Revision of the PROFIBUS software
Date of Production
2.8 Display Paramters (PROFIBUS)
(MFC300 PROFIBUS RS-485 Interface with PA Profile 3.01)
For a detailed description please see ”MFC 300 (OPTIMASS) Handbook”. Some special settings concerning
the PROFIBUS features easily operated via the local menu are described in the following tables.

15
C Setup
CC44II//OOTToottaalliisseerr
C 4.y Totaliser 1, 2 or 3
Allows you to control the three PROFIBUS counters The three menus
are identical so they are grouped together and their functions are
described in one go.
C 4.y.1 Function of Totaliser IInnccrreemmeennttaallTToottaallTotalises only positive values
DDeeccrreemmeennttaallTToottaallTotalises only negative values
AAbbssoolluutteeTToottaallTotalises positive and negative values
SSttooppTToottaalliisseerrTotaliser is stopped.
AAllllAAssPPo
ossiittiivveeneg. input values will be multiplied with
"-1.0"
AAllllAAssNNeeggaattiivveepos. input values will be multiplied with
"-1.0"
C 4.y.2 Measurement •Volume flow •Mass flow
•Voncentration total1 •Concentration total2
•Conc volume flow 1 •Conc volume flow 2
C 4.y.3 Preset Value
(predefines a “threshold” using the High Limit value and the Low Limit
value of the totaliser affected; the “THRESHOLD” bit will be set in the
long status information bytes of the PROFIBUS interface if the actual
value of the totaliser is outside these limits. This can be also used as a
status output choosing the function "preset counter X”
C 4.y.4 Reset Totaliser
(The current value of the totaliser can be set to zero)
Step 1: reset totaliser?
no: exits the function without reset
yes: resets the totaliser to zero and exits the function; totaliser
will restart counting at once
C 4.y.5 Error behaviour
(defines the behaviour of this function block in case of errors)
hold meas. value
totalization is continued based on the
last incoming value with good status
before the first occurrence of bad sta-
tus
ignore error:
totalization is continued using the input
values despite the bad status. The sta-
tus is ignored
stop totaliser totalization is stopped during occur-
rence of bad status of incoming values
C 4.y.6 information (The KROHNE Ident. No. of the circuit board, the software version
number and the production date of the circuit board will be displayed)
Note:
If you choose “y” = 1 all settings will effect FB 4 (Totaliser 1)
if you choose “y” = 2 all settings will effect FB 5 (Totaliser 2)
if you choose “y” = 3 all settings will effect FB 6 (Totaliser 3)

16
RReeffDDiissppllaayyDDeessccrriippttiioonn&&SSeettttiinnggss
CC55II//OOPPRROOFFIIBBUUSS((TThhiissffeeaattuurreeiissaavvaaiillaabblleeffoorrPPRROOFFIIBBUUSSddeevviicceessoonnllyy..))
Using the menu functions mentioned below you will be able to control basically the eight analogue input
blocks of this PROFIBUS device. These eight menus are identical so they are grouped together and their
functions are described in one go.
C5.y.1 Measurement
Selects the measurement (channel) for the analogue input block for
the PROFIBUS interface
Mass flow: Temperature
Density: Concentration 1:
Concentration 2: Concentration mass flow 2
Concentration mass flow 1: Concentration volume flow 1
Concentration volume flow 2 Sensor deviation:
Sensor average: Drive energy
Tube frequency: Tube strain
Inner cylinder strain: Electronics temperature *
Flow velocity Volume flow
Supply**
* This is the electronic temperature
** This is internal supply voltage for the PROFIBUS
C5.y.2 Time Constant Time constant for this function block
C5.y.3 Error Behaviour
Defines the behaviour of this function block in case of errors
Hold Value: last valid OUT value stored will be used as
OUT value
Ignore Error: OUT has the wrong calculated value and sta-
tus Bad as calculated
Replace Value: “replacement value” will be used as OUT value
Note:
If you choose “y” = 1 all settings will effect FB 1 (Analog Inp.1)
if you choose “y” = 2 all settings will effect FB 2 (Analog Inp.2)
if you choose “y” = 3 all settings will effect FB 3 (Analog Inp.3)
if you choose “y” = 4 all settings will effect FB 7 (Analog Inp.4)
if you choose “y” = 5 all settings will effect FB 8 (Analog Inp.5)
if you choose “y” = 6 all settings will effect FB 9 (Analog Inp.6)
if you choose “y” = 7 all settings will effect FB 10 (Analog Inp.7)
if you choose “y” = 8 all settings will effect FB 11 (Analog Inp.8)
CC66-->>DDeevviiccee
In this menu all functions are grouped that have no effect on the measurement or any output directly.
C6.3.1 Function
One line Display shows one line of measurement on
this page
Two lines Display shows two lines of measurement on
this page
Three lines Display shows three lines of measurement on
this page

17
RReeffDDiissppllaayyDDeessccrriippttiioonn&&SSeettttiinnggss
CC66DDeevviicceeccttdd......
C6.3.2 Measurement 1.line
Mass flow: Temperature
Density: Concentration 1
Concentration flow 1 Diagnosis 1
Diagnosis 2: Diagnosis 3
Flow Velocity: VolumeFlow
C6.3.8
Measurement 2.line
(Only available if this
line is activated)
Bargraph* Flow Velocity
Volume Flow: Mass Flow
Temperature: Density
Concentration 1: Concentration Flow 1
Diagnosis 1: Diagnosis 2
Diagnosis 3: FB4 Totaliser 1
FB5 totaliser 2: FB6 Totaliser 3
Operating Hours
* Analogue display of the value selected for the first line
C6.3.10
Measurement 3.line
(Only available if this
line is activated)
Flow Velocity Volume Flow:
Mass Flow Temperature:
Density Concentration 1:
Concentration Flow 1 Diagnosis 1:
Diagnosis 2 Diagnosis 3:
FB4 Totaliser 1 FB5 totaliser 2:
FB6 Totaliser 3 Operating Hours
CC66..44-->>22..MMeeaass..ppaaggee
In case of a PROFIBUS device the second measurement page is meant to check the output values of the
different function blocks. Only PROFIBUS values can be selected here. The analogue inputs are shown with
exactly the value, as seen on the PROFIBUS.
C6.4.1 Measurement 1.line
FB1 Analog inp. 1 FB2 Analog inp. 2
FB3 Analog inp. 3 FB4 Totaliser 1
FB5 Totaliser 2 FB6 Totaliser 3
FB7 Analog inp. 4: FB8 Analog inp. 5
FB9 Analog inp. 6: FB10 Analog inp. 7
FB11 Analog inp. 8
C6.4.2 Format 1.line Fixed number of digits after the decimal point or automatic, where
the number of digits is automatically adjusted to the available space.
C6.4.3 Measurement 2.line
FB1 Analog inp. 1 FB2 Analog inp. 2
FB3 Analog inp. 3 FB4 Totaliser 1
FB5 Totaliser 2 FB6 Totaliser 3
FB7 Analog inp. 4: FB8 Analog inp. 5
FB9 Analog inp. 6: FB10 Analog inp. 7
FB11 Analog inp. 8
C6.4.4 Format 2.line Fixed number of digits after the decimal point or automatic, where
the number of digits is automatically adjusted to the available space.
C6.4.5 Measurement 3.line
FB1 Analog inp. 1 FB2 Analog inp. 2
FB3 Analog inp. 3 FB4 Totaliser 1
FB5 TOTALISER 2 FB6 Totaliser 3
FB7 Analog inp. 4: FB8 Analog inp. 5
FB9 Analog inp. 6: FB10 Analog inp. 7
FB11 Analog inp. 8
C6.4.6 Format 3.line Fixed number of digits after the decimal point or automatic, where
the number of digits is automatically adjusted to the available space.

18
RReeffDDiissppllaayyDDeessccrriippttiioonn&&SSeettttiinnggss
CC66DDeevviicceeccttdd......
C6.6 Special Functions
C6.6.1 Reset Errors
This menu function can be used to reset all errors, that are not
removed automatically (e.g. power fail)
step 1:
Reset? no: exit the function
yes: resets the errors and exits the function.
C6.6.2 Save Settings
In this menu all settings can be saved in different storage places)
Step 1
Save Settings?
break Exit the menu without saving
backup 1 Saves the settings in the backup 1 stor-
age place
backup 2 Saves the settings in the backup 2 stor-
age place
Step 2
Go on with copy? (Note: There is no possibility to
undo this command!)
NNooExit function without saving
YYeessCopy the actual settings to the selected stor-
age place and exits the function.
Note: PROFIBUS interface settings will not be saved
C6.6.3 Load Settings
(in this menu all settings can be loaded from different storage places,
where settings have been saved before)
step 1
Load Settings?
break Exits the menu without loading
factory settings Loads the settings from the deliv-
ery
backup 1 Loads the settings from the back-
up 1 storage place)
backup 2 Loads the settings from the back-
up 2 storage place)
step 2
go on with copy? (Note: There is no possibility to
undo this command!)
NNooexit function without saving
YYeesscopy the actual settings to the selected stor-
age place and exits the function
Note: PROFIBUS interface settings will not be loaded
C6.8 Physical Block This menu is only available, if a PROFIBUS interface is present
C6.8.1 Station Address
Selects the PROFIBUS station address of the device
NNoottee::
The PROFIBUS address can also be changed using the PROFIBUS
service “set_slave_add”. The input range is 0...125 according to the
PROFIBUS specification. Address 126 is the default address and can-
not be set via the PROFIBUS service “set_slave_add” - use menu
instead to reset to default address.

19
RReeffDDiissppllaayyDDeessccrriippttiioonn&&SSeettttiinnggss
CC66DDeevviicceeccttdd......
C6.8.2 Information Gives information about the hardware version, software version and
the calibration/test date of this interface
C6.8.3 Diag. extension
Gives a representation of the status information, that is also avail-
able on the PROFIBUS interface. The status is displayed in hexa-
decimal format.
C6.8.4 Diag. extension 2
C6.8.5 Diag. extension i.
(intern)
C6.9 quick setup
In this menu some settings in the Quick Setup can be activated. In the default configuration the settings in
the Quick Setup are activated.
C6.9.1 reset totaliser 1
The reset can be activated in the Quick Setup to get a quick access
of the function
YYeessquick access activated
NNooquick access not activated
C6.9.2 reset totaliser 2
The reset can be activated in the Quick Setup to get a quick access
of the function
YYeessquick access activated
NNooquick access not activated
C6.9.3 reset totaliser 3
The reset can be activated in the Quick Setup to get a quick access
of the function
YYeessquick access activated
NNooquick access not activated
DDSSeerrvviiccee
This menu is protected. You will need to use the service password to gain access.
D2 System In this menu all functions related to different data sets can be
found.
D2.2 Service Parameters
D2.2.1 Cold start
Resetting of the MFC300 can be done here but all changes up to
this point are automatically stored and cannot be discarded.
step 1 reset?
NNooterminates the function
yyeessperforms the reset and leaves the pro-
gramming mode
D2.2.2 Save Factory Data
Copies the actual data into the factory setting, this overwrites the
factory settings done during calibration)
Step 1
Save Settings?
break exits the menu without saving
factory settings saves the settings as factory
settings
Step 2
go on with copy? (there is no possibility to undo
this command)
NNooexit menu without saving
YYeesscopy the actual settings to the selected
storage place.

20
RReeffDDiissppllaayyDDeessccrriippttiioonn&&SSeettttiinnggss
DD22SSyysstteemmccttdd......
D2.2.4 Identification No
Sets a different device modus for the cyclic communication of the
PROFIBUS interface
MFC300
complete functionality concerning the cyclic data
exchange of the coriolis mass flow meter MFC300
is supported (including manufacturer specific
extensions)
Profile only the profile defined functions concerning the
cyclic data exchange are supported - no extras
D2.2.5 PB Cold Start
Reset?
NNooterminates the function
YYeessPROFIBUS cold start will be carried out at
once. The programming mode is terminat-
ed
NNoottee::
During a PROFIBUS cold start nearly all parameter values of the
whole device will be set to their default values (e.g. the PROFIBUS
address will not be changed) without disconnecting an already
established connection to a PROFIBUS Master system
Current Device Revision
Use the display of the “MFC300 with PROFIBUS RS-485 Interface” to open the path:
“test\information\Profibus” ( == menu B3.5)
This menu will provide the following information:
KROHNE Ident No.
Software Revision of the PROFIBUS software
Date of Production
