KROHNE OPTISWIRL 5080 Wiring diagram

Vortex flowmeter for high temperature applications
Flameproof version
ATEX category:
ATEX category:ATEX category:
ATEX category: II 1 G, II 2/1 (1) G and II 2 D
Equipment protection level:
Equipment protection level:Equipment protection level:
Equipment protection level: Ga, Gb and Db
OPTISWIRL 5080
OPTISWIRL 5080OPTISWIRL 5080
OPTISWIRL 5080 Supplementary Instructions
Supplementary InstructionsSupplementary Instructions
Supplementary Instructions
© KROHNE 07/2020 - 4008054001 - AD OPTISW5080 Exd Gb-Db en R01

CONTENTS
2
www.krohne.com 07/2020 - 4008054001 - AD OPTISW5080 Exd Gb-Db en R01
OPTISWIRL 5080
1 Safety instructions 3
1.1 General notes ................................................................................................................... 3
1.2 EU conformity ................................................................................................................... 3
1.3 Approval according to the IECEx scheme ........................................................................ 4
1.4 Safety instructions............................................................................................................ 4
2 Device description 5
2.1 Device description ............................................................................................................ 5
2.2 Marking............................................................................................................................. 5
2.3 Safety specifications......................................................................................................... 7
2.4 Flammable products ........................................................................................................ 7
2.5 Ambient temperature / temperature classes.................................................................. 8
2.6 Electrical data................................................................................................................. 10
3 Installation 11
3.1 Mounting ......................................................................................................................... 11
3.2 Special conditions........................................................................................................... 12
4 Electrical connections 13
4.1 General notes ................................................................................................................. 13
4.2 Power supply .................................................................................................................. 13
4.3 Outputs ........................................................................................................................... 14
4.4 Grounding ....................................................................................................................... 14
5 Operation 15
5.1 Start-up........................................................................................................................... 15
5.2 Operation ........................................................................................................................ 15
5.3 Electrostatic charge .......................................................................................................15
6 Service 16
6.1 Maintenance ................................................................................................................... 16
6.2 Dismantling .................................................................................................................... 16
7 Notes 18

SAFETY INSTRUCTIONS 1
3
OPTISWIRL 5080
www.krohne.com07/2020 - 4008054001 - AD OPTISW5080 Exd Gb-Db en R01
1.1 General notes
These additional instructions apply to flameproof versions of vortex flowmeters with following
specifications:
•ATEX category:
II 2/1 (1) G and II 2D for compact version and remote signal converter
II 1G and II 2D for remote flow sensor
•Equipment protection level (EPL):
Gb and Db for compact version and remote signal converter; Ga and Db for remote flow
sensor
•Ex marking compact version: Ex db [ia Ga] ia IIC T4 Gb and Ex tb IIIC T85°C Db
Ex marking remote signal converter: Ex db [ia Ga] IIC T4 Gb and Ex tb IIIC T85°C Db
Ex marking remote flow sensor: Ex ia IIC T4 Ga and Ex tb IIIC T103°C Db
They complete the standard documentation for the non explosion-protection versions.
The information given in this instruction contains only the data relevant to explosion protection.
The technical details given in the manual for the non explosion-protected versions remain
unchanged unless they will be excluded or replaced by this instruction.
1.2 EU conformity
The manufacturer declares with the EU declaration of conformity on his own responsibility
conformity with the protection goals of directive 2014/34/EU for use in hazardous areas with gas
and dust.
Conformity with harmonised standards was checked by a Notified Body in accordance with
EN 60079-0:2012, EN 60079-1:2014, EN 60079-11:2012, EN 60079-26:2007 and
EN 60079-31:2014.
The EU declaration of conformity for the equipment categories is based on the EU type
examination certificate:
The "X" after the certificate number refers to special conditions for safe use of the device, which
have been listed in these instructions.
If needed the EU type examination certificate can be downloaded from the manufacturer's
website.
Sira 19ATEX2001 X
Sira 19ATEX2001 XSira 19ATEX2001 X
Sira 19ATEX2001 X

1 SAFETY INSTRUCTIONS
4
OPTISWIRL 5080
www.krohne.com 07/2020 - 4008054001 - AD OPTISW5080 Exd Gb-Db en R01
1.3 Approval according to the IECEx scheme
Conformity of the vortex flowmeter for use in hazardous areas with gas and dust was tested in
accordance with the "IECEx Certification Scheme for Explosive Atmospheres" according to
IEC 60079-0:2011, IEC 60079-1:2014, IEC 60079-11:2011, IEC 60079-26:2004 and
IEC 60079-31:2013. The number of the IEC certificate is:
The "X" after the certificate number refers to special conditions for safe use of the device, which
have been listed in these instructions.
If needed, the IEC certificate can be downloaded from the manufacturer's website.
1.4 Safety instructions
If these instructions are not followed, there is a risk of explosion.
Assembly, installation, start-up and maintenance may only be performed by personnel trained in
personnel trained inpersonnel trained in
personnel trained in
explosion protection
explosion protectionexplosion protection
explosion protection!
IECEx SIR 19.0001 X
IECEx SIR 19.0001 XIECEx SIR 19.0001 X
IECEx SIR 19.0001 X
CAUTION!
Operating conditions and place of installation may require compliance with additional standards,
directives or laws. The responsibility for compliance rests solely with the operator or his agent.

DEVICE DESCRIPTION 2
5
OPTISWIRL 5080
www.krohne.com07/2020 - 4008054001 - AD OPTISW5080 Exd Gb-Db en R01
2.1 Device description
Vortex flowmeters measure and display the flow of flammable and non-flammable gases, steam
and liquids. They transmit a 4...20 mA or digital multidrop, and a pulse output signal, as
applicable, using HART
®
communication protocol for remote configuration, calibration and
monitoring.
2.2 Marking
The marking of the devices is shown on the nameplate below. On both the compact devices and
the remote versions, the main plate is located on the signal converter housing. When the
flowmeter is remotely mounted, the junction box on the flow sensor body has a nameplate
showing its hazardous location rating.
Compact devices with two signal converters for dual measurement (Dual Version) are each
marked with a nameplate. The details relevant to explosion protection are identical on both
nameplates.
Figure 2-1: Example of a nameplate for the compact version
1 Model number and serial number
2 Marking according to the notified body
3 Note for disposal
4 Manufacturer logo
5 IP rating for enclosure
6 Manufacturer address
7 Note for electrical data
8 Warning for opening enclosure in hazardous areas
SEE CERTIFICATE FOR ELECTRICALDATA.
WARNING
EXPLOSION HAZARD
Do not open when an explosive gas or dust atmosphere is present.
• Substitution of components may impair suitability for intrinsic
safety.
• Do not open when energized.
Failure to follow these instructions can result in death
or serious injury.
!
47058 DUISBURG GERMANY
ST.
S/N ORIGIN
SUPPLY MWP @ 100° F (38°C)
MAX. AMB.TEMP. 176°F (80°C) MAX. PROC. TEMP.
REF K-FACT. PULSES / ft
3
- PULSES / liter
K-FACTOR PULSES /
CUST. TAG
CABLE ENTRIES
IP 66 ENCLOSURE
SIRA 19ATEX2001X
II 2/1 (1) G II 2D
Ex db [ia Ga] ia IIC T4 Gb
Ex tb IIIC T85°C Db
THIS PRODUCT IS PROTECTED BY THE FOLLOWING PATENTS:
US 7,212,928; US 7,853,415; US 9,322,683; (Model 84C)
AND EP 1585943. ADDITIONAL PATENTS ARE PENDING.
KROHNE MESSTECHNIK GMBH
!
MODEL
CERT No: SIRA19ATEX2001X
When used with a Remote Sensor Housing it must bear
