KROHNE IFC100 User manual

Signal converter for electromagnetic flowmeters
Electronic Revision:
ER 2.1.xx
(SW.REV. 3.0x)
IFC 100
IFC 100IFC 100
IFC 100 Quick Start
Quick StartQuick Start
Quick Start
© KROHNE 07/2010 - 4000124104 - QS IFC 100 R04 en
The documentation is only complete when used in combination with the relevant
documentation for the sensor.
.book Page 1 Thursday, July 1, 2010 3:45 PM

CONTENTS
2 www.krohne.com 07/2010 - 4000124104 - QS IFC 100 R04 en
IFC 100
1 Safety instructions 3
2 Installation 4
2.1 Intended use ..................................................................................................................... 4
2.2 Scope of delivery............................................................................................................... 4
2.3 Storage ............................................................................................................................. 5
2.4 Transport .......................................................................................................................... 5
2.5 Installation specifications ................................................................................................5
2.6 Mounting of the compact version..................................................................................... 6
2.7 Mounting the wall-mounted housing, remote version .................................................... 6
2.7.1 Wall mounting......................................................................................................................... 6
2.7.2 Mounting plate, wall-mounted version .................................................................................. 8
3 Electrical connections 9
3.1 Safety instructions............................................................................................................ 9
3.2 Important notes on electrical connection........................................................................ 9
3.3 Electrical cables for remote device versions, notes...................................................... 10
3.3.1 Notes on signal cable A ........................................................................................................ 10
3.3.2 Notes on field current cable C.............................................................................................. 10
3.3.3 Requirements for signal cables provided by the customer ................................................. 11
3.4 Preparing the signal and field current cables ............................................................... 12
3.4.1 Signal cable A (type DS 300), construction........................................................................... 12
3.4.2 Length of signal cable A........................................................................................................ 13
3.4.3 Preparing signal cable A, connection to signal converter ................................................... 14
3.4.4 Preparing field current cable C, connection to signal converter......................................... 15
3.4.5 Prepare signal cable A, connect to measuring sensor........................................................ 17
3.4.6 Preparing field current cable C, connection to measuring sensor ..................................... 18
3.5 Connecting the signal and field current cables............................................................. 19
3.5.1 Connecting the signal and field current cables to the signal converter, remote version... 20
3.5.2 Connection diagram for signal and field current cable ....................................................... 22
3.6 Grounding the measuring sensor .................................................................................. 23
3.6.1 Classical method................................................................................................................... 23
3.7 Connecting the power..................................................................................................... 24
3.8 Overview of outputs ........................................................................................................26
3.8.1 Description of the CG number .............................................................................................. 26
3.8.2 Fixed, non-alterable output versions ................................................................................... 26
3.9 Electrical connection of the outputs .............................................................................. 27
3.9.1 Electrical connection of the outputs.....................................................................................27
3.9.2 Laying electrical cables correctly......................................................................................... 28
4 Start-up 29
4.1 Switching on the power .................................................................................................. 29
4.2 Starting the signal converter ......................................................................................... 29
5 Notes 30
.book Page 2 Thursday, July 1, 2010 3:45 PM

SAFETY INSTRUCTIONS 1
3
IFC 100
www.krohne.com07/2010 - 4000124104 - QS IFC 100 R04 en
Safety instructions
Warnings and symbols used
HANDLING
• This symbol designates all instructions for actions to be carried out by the operator in the
specified sequence.
iRESULT
RESULTRESULT
RESULT
This symbol refers to all important consequences of the previous actions.
Safety instructions for the operator
DANGER!
This information refers to the immediate danger when working with electricity.
DANGER!
These warnings must be observed without fail. Even partial disregard of this warning can lead to
serious health problems and even death. There is also the risk of seriously damaging the device
or parts of the operator's plant.
WARNING!
Disregarding this safety warning, even if only in part, poses the risk of serious health problems.
There is also the risk of damaging the device or parts of the operator's plant.
CAUTION!
Disregarding these instructions can result in damage to the device or to parts of the operator's
plant.
INFORMATION!
These instructions contain important information for the handling of the device.
CAUTION!
Installation, assembly, start-up and maintenance may only be performed by appropriately
trained personnel. The regional occupational health and safety directives must always be
observed.
LEGAL NOTICE!
The responsibility as to the suitability and intended use of this device rests solely with the user.
The supplier assumes no responsibility in the event of improper use by the customer. Improper
installation and operation may lead to loss of warranty. In addition, the "Terms and Conditions of
Sale" apply. They appear on the back of the invoice and form the basis of the purchase contract.
INFORMATION!
• Further information can be found on the supplied CD-ROM in the manual, on the data sheet,
in special manuals, certificates and on the manufacturer's website.
• If you need to return the device to the manufacturer or supplier, please fill out the form
contained on the CD-ROM and send it with the device. Unfortunately, the manufacturer
cannot repair or inspect the device without the completed form.
.book Page 3 Thursday, July 1, 2010 3:45 PM

2INSTALLATION
4
IFC 100
www.krohne.com 07/2010 - 4000124104 - QS IFC 100 R04 en
Installation
2.1 Intended use
The electromagnetic flowmeters are designed exclusively to measure the flow and conductivity
of electrically conductive, liquid media.
2.2 Scope of delivery
DANGER!
For devices used in hazardous areas, additional safety notes apply; please refer to the Ex
documentation.
WARNING!
If the device is not used according to the operating conditions (refer to chapter "Technical data),
the intended protection could be affected.
INFORMATION!
Inspect the cartons carefully for damage or signs of rough handling. Report damage to the
carrier and to the local office of the manufacturer.
INFORMATION!
Check the packing list to check if you received completely all that you ordered.
INFORMATION!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
Figure 2-1: Scope of delivery
1 Device in the version as ordered
2 Documentation (calibration report, Quick Start, CD-ROM with product documentation for measuring sensor and signal
converter)
3 Signal cable (only for remote version)
.book Page 4 Thursday, July 1, 2010 3:45 PM

INSTALLATION 2
5
IFC 100
www.krohne.com07/2010 - 4000124104 - QS IFC 100 R04 en
2.3 Storage
•Store the device in a dry, dust-free location.
•Avoid continuous direct sunlight.
•Store the device in its original packing.
•Storage temperature: -40...+70°C / -40...+158°F
2.4 Transport
Signal converter
•No special requirements.
Compact version
•Do not lift the device by the signal converter housing.
•Do not use lifting chains.
•To transport flange devices, use lifting straps. Wrap these around both process connections.
2.5 Installation specifications
INFORMATION!
The following precautions must be taken to ensure reliable installation.
• Make sure that there is adequate space to the sides.
• Protect the signal converter from direct sunlight and install a sun shade if necessary.
• Signal converters installed in control cabinets require adequate cooling, e.g. by fan or heat
exchanger.
• Do not expose the signal converter to intense vibration. The flowmeters are tested for a
vibration level in accordance with IEC 68-2-3.
.book Page 5 Thursday, July 1, 2010 3:45 PM

2INSTALLATION
6
IFC 100
www.krohne.com 07/2010 - 4000124104 - QS IFC 100 R04 en
2.6 Mounting of the compact version
2.7 Mounting the wall-mounted housing, remote version
2.7.1 Wall mounting
1 Prepare the holes with the aid of the mounting plate. For further information refer to Mounting
plate, wall-mounted version
on page 8.
2 Fasten the device securely to the wall with the mounting plate.
INFORMATION!
The signal converter is mounted directly on the measuring sensor. For installation of the
flowmeter, please observe the instructions in the supplied product documentation for the
measuring sensor.
INFORMATION!
Assembly materials and tools are not part of the delivery. Use the assembly materials and tools
in compliance with the applicable occupational health and safety directives.
Figure 2-2: Mounting the wall-mounted housing
.book Page 6 Thursday, July 1, 2010 3:45 PM

INSTALLATION 2
7
IFC 100
www.krohne.com07/2010 - 4000124104 - QS IFC 100 R04 en
Mounting multiple devices next to each other
[mm] [inches]
aØ6.5 Ø0.26
b87.2 3.4
c241 9.5
d310 12.2
e257 10.1
.book Page 7 Thursday, July 1, 2010 3:45 PM

2INSTALLATION
8
IFC 100
www.krohne.com 07/2010 - 4000124104 - QS IFC 100 R04 en
2.7.2 Mounting plate, wall-mounted version
Dimensions in mm and inches
[mm] [inches]
aØ6.5 Ø0.26
b87.2 3.4
c241 9.5
.book Page 8 Thursday, July 1, 2010 3:45 PM

ELECTRICAL CONNECTIONS 3
9
IFC 100
www.krohne.com07/2010 - 4000124104 - QS IFC 100 R04 en
Electrical connections
3.1 Safety instructions
3.2 Important notes on electrical connection
DANGER!
All work on the electrical connections may only be carried out with the power disconnected. Take
note of the voltage data on the nameplate!
DANGER!
Observe the national regulations for electrical installations!
DANGER!
For devices used in hazardous areas, additional safety notes apply; please refer to the Ex
documentation.
WARNING!
Observe without fail the local occupational health and safety regulations. Any work done on the
electrical components of the measuring device may only be carried out by properly trained
specialists.
INFORMATION!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
DANGER!
Electrical connection is carried out in conformity with the VDE 0100 directive "Regulations for
electrical power installations with line voltages up to 1000 V" or equivalent national regulations.
CAUTION!
• Use suitable cable entries for the various electrical cables.
• The sensor and converter are configured together in the factory. For this reason, please
connect the devices in pairs. Ensure that the sensor constant GK/GKL (see type plates) are
identically set.
• If delivered separately or when installing devices that were not configured together, set the
converter to the DN size and GK/GKL of the sensor.
.book Page 9 Thursday, July 1, 2010 3:45 PM

3ELECTRICAL CONNECTIONS
10
IFC 100
www.krohne.com 07/2010 - 4000124104 - QS IFC 100 R04 en
3.3 Electrical cables for remote device versions, notes
3.3.1 Notes on signal cable A
Observe the following notes:
•Lay the signal cable with fastening elements.
•It is permissible to lay the signal cable in water or in the ground.
•The insulating material is flame-retardant to EN 50625-2-1, IEC 60322-1.
•The signal cable does not contain any halogens and is unplasticized, and remains flexible at
low temperatures.
•The connection of the inner shield is carried out via the stranded drain wire (1).
•The connection of the outer shield (60) is carried out via the stranded drain wire (6).
3.3.2 Notes on field current cable C
INFORMATION!
Signal cable A (type DS 300) with double shielding ensures proper transmission of measured
values.
DANGER!
A shielded two-wire copper cable is used as the field current cable. The shielding MUST
MUSTMUST
MUST be
connected in the housing of the measuring sensor and signal converter.
INFORMATION!
The field current cable is not part of the scope of supply.
.book Page 10 Thursday, July 1, 2010 3:45 PM

ELECTRICAL CONNECTIONS 3
11
IFC 100
www.krohne.com07/2010 - 4000124104 - QS IFC 100 R04 en
3.3.3 Requirements for signal cables provided by the customer
Electrical safety
•To EN 60811 (Low Voltage Directive) or equivalent national regulations.
Capacitance of the insulated conductors
•Insulated conductor / insulated conductor < 50 pF/m
•Insulated conductor / shield < 150 pF/m
Insulation resistance
•Riso > 100 GΩxkm
•Umax < 24 V
•Imax < 100 mA
Test voltages
•Insulated conductor / inner shield 500 V
•Insulated conductor / insulated conductor 1000 V
•Insulated conductor / outer shield 1000 V
Twisting of the insulated conductors
•At least 10 twists per meter, important for screening magnetic fields.
INFORMATION!
If the signal cable was not ordered, it is to be provided by the customer. The following
requirements regarding the electrical values of the signal cable must be observed:
.book Page 11 Thursday, July 1, 2010 3:45 PM

3ELECTRICAL CONNECTIONS
12
IFC 100
www.krohne.com 07/2010 - 4000124104 - QS IFC 100 R04 en
3.4 Preparing the signal and field current cables
3.4.1 Signal cable A (type DS 300), construction
•Signal cable A is a double-shielded cable for signal transmission between the measuring
sensor and signal converter.
•Bending radius: ≥50 mm / 2"
INFORMATION!
Assembly materials and tools are not part of the delivery. Use the assembly materials and tools
in compliance with the applicable occupational health and safety directives.
Figure 3-1: Construction of signal cable A
1 Stranded drain wire (1) for the inner shield (10), 1.0 mm2Cu / AWG 17 (not insulated, bare)
2 Insulated wire (2), 0.5 mm2Cu / AWG 20
3 Insulated wire (3), 0.5 mm2Cu / AWG 20
4 Outer sheath
5 Insulation layers
6 Stranded drain wire (6) for the outer shield (60)
.book Page 12 Thursday, July 1, 2010 3:45 PM

ELECTRICAL CONNECTIONS 3
13
IFC 100
www.krohne.com07/2010 - 4000124104 - QS IFC 100 R04 en
3.4.2 Length of signal cable A
INFORMATION!
For temperatures of the medium above 150
° C / 300 ° F, a special signal cable and a ZD
intermediate socket are necessary. These are available including the changed electrical
connection diagrams.
Measuring sensor Nominal size Min. electrical
conductivity
[µS/cm]
Curve for signal
cable A
DN [mm] [inches]
OPTIFLUX 1000 F 10...150 3/8...6 5A1
OPTIFLUX 2000 F 25...150 1...6 20 A1
200...1200 8...48 20 A2
OPTIFLUX 4000 F 2.5...150 1/10...6 1A1
200...1200 8...48 1A2
OPTIFLUX 5000 F 2.5...100 1/10...4 1A1
150...250 6...10 1A2
OPTIFLUX 6000 F 2.5...150 1/10...6 1A1
WATERFLUX 3000 F 25...600 1...24 20 A1
Figure 3-2: Maximum length of signal cable A
1 Maximum length of signal cable A between the measuring sensor and signal converter [m]
2 Maximum length of signal cable A between the measuring sensor and signal converter [ft]
3 Electrical conductivity of the medium being measured [μS/cm]
.book Page 13 Thursday, July 1, 2010 3:45 PM

3ELECTRICAL CONNECTIONS
14
IFC 100
www.krohne.com 07/2010 - 4000124104 - QS IFC 100 R04 en
3.4.3 Preparing signal cable A, connection to signal converter
•Connection of the two shields in the signal converter is carried out via the stranded drain
wires.
•Bending radius: ≥50 mm / 2"
Required materials
•PVC insulation tubing, Ø2.5 mm / 0.1"
•Heat-shrinkable tubing
•2x wire end ferrules to DIN 46 228: E 1.5-8 for the stranded drain wires (1, 6)
•2x wire end ferrules to DIN 46 228: E 0.5-8 for the insulated conductors (2, 3)
1 Strip the conductor to dimension a.
2 Cut off the inner shield (10) and the outer shield (60). Make sure not to damage the stranded
drain wires (1, 6).
3 Slide the insulation tubing over the stranded drain wires (1, 6)
4 Crimp the wire end ferrules onto the stranded drain wire.
5 Crimp the wire end ferrules onto the conductors (2, 3).
6 Pull the heat-shrinkable tubing over the prepared signal cable.
INFORMATION!
Assembly materials and tools are not part of the delivery. Use the assembly materials and tools
in compliance with the applicable occupational health and safety directives.
Figure 3-3: Preparation of signal cable A
a = 80 mm / 3.15"
.book Page 14 Thursday, July 1, 2010 3:45 PM

ELECTRICAL CONNECTIONS 3
15
IFC 100
www.krohne.com07/2010 - 4000124104 - QS IFC 100 R04 en
3.4.4 Preparing field current cable C, connection to signal converter
•Field current cable C is not part of the scope of supply.
•Bending radius: ≥50 mm / 2"
Required materials:
•Shielded, at least 2-wire copper cable with suitable heat-shrinkable tubing
•Insulating tubing, size according to the cable being used
•DIN 46 228 wire end ferrules: size according to the cable being used
Length and cross-section of field current cable C
DANGER!
A shielded two-wire copper cable is used as the field current cable. The shielding MUST
MUSTMUST
MUST be
connected in the housing of the measuring sensor and signal converter.
INFORMATION!
Assembly materials and tools are not part of the delivery. Use the assembly materials and tools
in compliance with the applicable occupational health and safety directives.
Length Cross-section AF(Cu)
[m] [ft] [mm2][AWG]
0...150 0...500 2 x 0.75 Cu 1 2 x 18
150...300 500...1000 2 x 1.50 Cu 1 2 x 14
300...600 1000...2000 2 x 2.50 Cu 1 2 x 12
1Cu = copper cross-section
.book Page 15 Thursday, July 1, 2010 3:45 PM

3ELECTRICAL CONNECTIONS
16
IFC 100
www.krohne.com 07/2010 - 4000124104 - QS IFC 100 R04 en
1 Strip the conductor to dimension a.
2 If a stranded drain wire is present, remove the shield that is present. Make sure not to damage
the stranded drain wire.
3 Slide an insulating tube over the stranded drain wire.
4 Crimp a wire end ferrule onto the stranded drain wire.
5 Crimp wire end ferrules onto the conductors.
6 Pull a shrinkable tube over the prepared cable.
Figure 3-4: Field current cable C, preparation for the signal converter
a = 80 mm / 3.15"
.book Page 16 Thursday, July 1, 2010 3:45 PM

ELECTRICAL CONNECTIONS 3
17
IFC 100
www.krohne.com07/2010 - 4000124104 - QS IFC 100 R04 en
3.4.5 Prepare signal cable A, connect to measuring sensor
•The outer shield (60) is connected in the terminal compartment of the measuring sensor
directly via the shield and a clip.
•Bending radius: ≥50 mm / 2"
Required materials
•PVC insulation tubing, Ø2.0...2.5 mm / 0.08...0.1"
•Heat-shrinkable tubing
•Wire end ferrule to DIN 46 228: E 1.5-8 for the stranded drain wire (1)
•2x wire end ferrules to DIN 46 228: E 0.5-8 for the insulated conductors (2, 3)
1 Strip the conductor to dimension a.
2 Trim the outer shield (60) to dimension b and pull it over the outer sheath.
3 Remove the stranded drain wire (6) of the outer shield and the inner shield (10). Make sure not
to damage the stranded drain wire (1) of the inner shield.
4 Slide an insulating tube over the stranded drain wire (1).
5 Crimp the wire end ferrules onto conductors 2 and 3 and the stranded drain wire (1).
6 Pull the heat-shrinkable tubing over the prepared signal cable.
INFORMATION!
Assembly materials and tools are not part of the delivery. Use the assembly materials and tools
in compliance with the applicable occupational health and safety directives.
Figure 3-5: Prepare signal cable A, connect to measuring sensor
a = 50 mm / 2"
b = 10 mm / 0.39"
.book Page 17 Thursday, July 1, 2010 3:45 PM

3ELECTRICAL CONNECTIONS
18
IFC 100
www.krohne.com 07/2010 - 4000124104 - QS IFC 100 R04 en
3.4.6 Preparing field current cable C, connection to measuring sensor
•The field current cable is not part of the scope of supply.
•The shield is connected in the terminal compartment of the measuring sensor directly via the
shield and a clip.
•Bending radius: ≥50 mm / 2"
Required materials
•Shielded 2-wire insulated copper cable
•Insulating tubing, size according to the cable being used
•Heat-shrinkable tubing
•DIN 46 228 wire end ferrules: size according to the cable being used
1 Strip the conductor to dimension a.
2 Trim the outer shield to dimension b and pull it over the outer sheath.
3 Crimp wire end ferrules onto both conductors.
4 Pull a shrinkable tube over the prepared cable.
INFORMATION!
Assembly materials and tools are not part of the delivery. Use the assembly materials and tools
in compliance with the applicable occupational health and safety directives.
Figure 3-6: Preparation of field current cable C
a = 50 mm / 2"
b = 10 mm / 0.4"
.book Page 18 Thursday, July 1, 2010 3:45 PM

ELECTRICAL CONNECTIONS 3
19
IFC 100
www.krohne.com07/2010 - 4000124104 - QS IFC 100 R04 en
3.5 Connecting the signal and field current cables
DANGER!
Cables may only be connected when the power is switched off.
DANGER!
The device must be grounded in accordance with regulations in order to protect personnel
against electric shocks.
DANGER!
For devices used in hazardous areas, additional safety notes apply; please refer to the Ex
documentation.
WARNING!
Observe without fail the local occupational health and safety regulations. Any work done on the
electrical components of the measuring device may only be carried out by properly trained
specialists.
.book Page 19 Thursday, July 1, 2010 3:45 PM

3ELECTRICAL CONNECTIONS
20
IFC 100
www.krohne.com 07/2010 - 4000124104 - QS IFC 100 R04 en
3.5.1 Connecting the signal and field current cables to the signal converter, remote
version
Open housing
1 Loosen the 4 screws with a suitable tool.
2 Lift the housing at the top and bottom at the same time.
3 Slide the housing cover upward.
4 The housing cover is guided and held by the inside hinge.
INFORMATION!
The compact version is supplied preassembled from the factory.
Figure 3-7: Open housing
.book Page 20 Thursday, July 1, 2010 3:45 PM
