KROHNE OPTISYS TUR 1050 User manual

Compact measuring system for turbidity
OPTISYS TUR 1050
OPTISYS TUR 1050OPTISYS TUR 1050
OPTISYS TUR 1050 Handbook
HandbookHandbook
Handbook
© KROHNE 02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en

All rights reserved. It is prohibited to reproduce this documentation, or any part thereof, without
the prior written authorisation of KROHNE Messtechnik GmbH.
Subject to change without notice.
2
www.krohne.com 02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
Copyright 2017 by
KROHNE Messtechnik GmbH - Ludwig-Krohne-Str. 5 - 47058 Duisburg (Germany)
: IMPRINT :::::::::::::::::::::::::::::::::::::::

CONTENTS
3
www.krohne.com02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
OPTISYS TUR 1050
1 Safety instructions 5
1.1 Intended use ..................................................................................................................... 5
1.2 Certification ...................................................................................................................... 5
1.2.1 CE ............................................................................................................................................ 5
1.2.2 ETL .......................................................................................................................................... 5
1.2.3 US EPA 180.1........................................................................................................................... 5
1.2.4 ISO 7027 and DIN 27027.......................................................................................................... 5
1.3 Safety instructions from the manufacturer ..................................................................... 6
1.3.1 Copyright and data protection ................................................................................................ 6
1.3.2 Disclaimer ............................................................................................................................... 6
1.3.3 Product liability and warranty ................................................................................................ 7
1.3.4 Information concerning the documentation........................................................................... 7
1.3.5 Warnings and symbols used................................................................................................... 8
1.4 Safety instructions for the operator................................................................................. 8
2 Device description 9
2.1 Scope of delivery............................................................................................................... 9
2.2 Device description .......................................................................................................... 10
2.3 Nameplates .................................................................................................................... 12
3 Installation 14
3.1 General notes on installation ......................................................................................... 14
3.2 Storage and transport .................................................................................................... 14
3.3 Requirements of the device............................................................................................ 14
3.4 Installation order............................................................................................................ 15
3.4.1 Placing the desiccant pouch and the humidity indicator ..................................................... 15
3.4.2 Selecting site and mounting ................................................................................................. 16
3.4.3 Mounting ............................................................................................................................... 18
3.4.4 Connecting the hoses............................................................................................................ 19
3.4.5 Drain vent .............................................................................................................................. 20
3.4.6 Inserting and fixing the ultrasonic cuvette with flow-through holder................................. 21
4 Electrical connections 22
4.1 Safety instructions.......................................................................................................... 22
4.2 Description of board and bulkheads .............................................................................. 22
4.3 Circuit breaker and specifications of power supply ...................................................... 23
4.4 Cable specifications........................................................................................................ 23
4.5 Installation order of the electrical connections............................................................. 23
4.5.1 Connecting the cables in the junction box power assembly ................................................ 24
4.5.2 Alarms terminal (signal output) ........................................................................................... 25
4.5.3 RS 485 or 4...20 mA signal output.........................................................................................25
4.5.4 Connecting the sensor interconnect cable........................................................................... 26

CONTENTS
4
www.krohne.com 02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
OPTISYS TUR 1050
5 Operation 27
5.1 Start-up........................................................................................................................... 27
5.2 Display and operating keys ............................................................................................ 28
5.3 Normal operation ...........................................................................................................28
5.4 Getting access with activated security access function ................................................ 29
5.5 Menu topology ................................................................................................................ 30
5.6 Calibration mode (main menu) ...................................................................................... 30
5.6.1 Calibration liquids................................................................................................................. 31
5.6.2 Calibration procedure (physical), inclusive indexing ........................................................... 31
5.6.3 Calibration procedure (offset calibration)............................................................................ 33
5.6.4 Calibration error ................................................................................................................... 35
5.7 Configuration mode (main menu) .................................................................................. 35
5.7.1 Selecting the output.............................................................................................................. 36
5.7.2 Setting the 4...20 mA output inclusive error level................................................................ 37
5.7.3 Configuring the RS 485 port.................................................................................................. 38
5.7.4 Configuring the alarm relays................................................................................................ 39
5.7.5 Offset calibration................................................................................................................... 41
5.7.6 Enabling or disabling the security access............................................................................ 41
5.7.7 Extended settings.................................................................................................................. 41
5.8 Restoring the factory settings........................................................................................ 47
5.9 Faults: reasons and remedies ....................................................................................... 47
6 Service 50
6.1 Service admonitions ....................................................................................................... 50
6.2 Maintenance ................................................................................................................... 50
6.2.1 Replacing or cleaning cuvette .............................................................................................. 50
6.2.2 Replacing desiccant pouch and humidity indicator.............................................................. 51
6.2.3 Replacing the source lamp................................................................................................... 51
6.3 Availability of services .................................................................................................... 52
6.4 Spare parts availability...................................................................................................52
6.5 Spare or accessory parts ............................................................................................... 52
6.6 Returning the device to the manufacturer..................................................................... 53
6.6.1 General information.............................................................................................................. 53
6.6.2 Form (for copying) to accompany a returned device............................................................ 54
6.7 Disposal .......................................................................................................................... 54
7 Technical data 55
7.1 Measuring principle........................................................................................................55
7.2 Technical data table .......................................................................................................56
7.3 Dimensions and weight .................................................................................................. 58
8 Notes 59

SAFETY INSTRUCTIONS 1
5
OPTISYS TUR 1050
www.krohne.com02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
1.1 Intended use
The OPTISYS TUR 1050 series consists of a white light (WL) version and an infrared (IR) version.
Both versions are designed to measure online the turbidity of water. Furthermore the two
following different measuring ranges are available: 0.02...100 NTU/FNU or 0.02...1000 NTU/FNU
1.2 Certification
1.2.1 CE
The device fulfils the statutory requirements of the following EC directives:
•Electromagnetic compatibility (EMC) in accordance with:
EN 61326-1:2006: Emission standard and immunity for industrial environments.
•Low Voltage Directive:
Safety requirements for electrical equipment for measurement, control and laboratory use in
accordance with EN 61010-1:2001, Edition 2.0.
The manufacturer certifies successful testing of the product by applying the CE marking.
1.2.2 ETL
The manufacturer tested the device and it fulfils the following ETL requirements:
•ETL: tested to UL 61010B-1, 1st Edition, January 24th, 2003.
•ETLc: tested to CS C22.2#1010.1-92.
1.2.3 US EPA 180.1
The white light version meets the design criteria specified by the US EPA 180.1 on turbidity
measurement.
1.2.4 ISO 7027 and DIN 27027
The infrared version meets the design criteria specified in ISO 7027 and DIN 27027 for the
measurement of the turbidity of a sample.
CE marking

1 SAFETY INSTRUCTIONS
6
OPTISYS TUR 1050
www.krohne.com 02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
1.3 Safety instructions from the manufacturer
1.3.1 Copyright and data protection
The contents of this document have been created with great care. Nevertheless, we provide no
guarantee that the contents are correct, complete or up-to-date.
The contents and works in this document are subject to copyright. Contributions from third
parties are identified as such. Reproduction, processing, dissemination and any type of use
beyond what is permitted under copyright requires written authorisation from the respective
author and/or the manufacturer.
The manufacturer tries always to observe the copyrights of others, and to draw on works created
in-house or works in the public domain.
The collection of personal data (such as names, street addresses or e-mail addresses) in the
manufacturer's documents is always on a voluntary basis whenever possible. Whenever
feasible, it is always possible to make use of the offerings and services without providing any
personal data.
We draw your attention to the fact that data transmission over the Internet (e.g. when
communicating by e-mail) may involve gaps in security. It is not possible to protect such data
completely against access by third parties.
We hereby expressly prohibit the use of the contact data published as part of our duty to publish
an imprint for the purpose of sending us any advertising or informational materials that we have
not expressly requested.
1.3.2 Disclaimer
The manufacturer will not be liable for any damage of any kind by using its product, including,
but not limited to direct, indirect or incidental and consequential damages.
This disclaimer does not apply in case the manufacturer has acted on purpose or with gross
negligence. In the event any applicable law does not allow such limitations on implied warranties
or the exclusion of limitation of certain damages, you may, if such law applies to you, not be
subject to some or all of the above disclaimer, exclusions or limitations.
Any product purchased from the manufacturer is warranted in accordance with the relevant
product documentation and our Terms and Conditions of Sale.
The manufacturer reserves the right to alter the content of its documents, including this
disclaimer in any way, at any time, for any reason, without prior notification, and will not be liable
in any way for possible consequences of such changes.

SAFETY INSTRUCTIONS 1
7
OPTISYS TUR 1050
www.krohne.com02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
1.3.3 Product liability and warranty
The operator shall bear responsibility for the suitability of the device for the specific purpose.
The manufacturer accepts no liability for the consequences of misuse by the operator. Improper
installation or operation of the devices (systems) will cause the warranty to be void. The
respective "Standard Terms and Conditions" which form the basis for the sales contract shall
also apply.
1.3.4 Information concerning the documentation
To prevent any injury to the user or damage to the device it is essential that you read the
information in this document and observe applicable national standards, safety requirements
and accident prevention regulations.
If this document is not in your native language and if you have any problems understanding the
text, we advise you to contact your local office for assistance. The manufacturer can not accept
responsibility for any damage or injury caused by misunderstanding of the information in this
document.
This document is provided to help you establish operating conditions, which will permit safe and
efficient use of this device. Special considerations and precautions are also described in the
document, which appear in the form of icons as shown below.

1 SAFETY INSTRUCTIONS
8
OPTISYS TUR 1050
www.krohne.com 02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
1.3.5 Warnings and symbols used
Safety warnings are indicated by the following symbols.
• HANDLING
HANDLINGHANDLING
HANDLING
This symbol designates all instructions for actions to be carried out by the operator in the
specified sequence.
iRESULT
RESULTRESULT
RESULT
This symbol refers to all important consequences of the previous actions.
1.4 Safety instructions for the operator
DANGER!
This warning refers to the immediate danger when working with electricity.
DANGER!
This warning refers to the immediate danger of burns caused by heat or hot surfaces.
DANGER!
This warning refers to the immediate danger when using this device in a hazardous atmosphere.
DANGER!
These warnings must be observed without fail. Even partial disregard of this warning can lead to
serious health problems and even death. There is also the risk of seriously damaging the device
or parts of the operator's plant.
WARNING!
Disregarding this safety warning, even if only in part, poses the risk of serious health problems.
There is also the risk of damaging the device or parts of the operator's plant.
CAUTION!
Disregarding these instructions can result in damage to the device or to parts of the operator's
plant.
INFORMATION!
These instructions contain important information for the handling of the device.
LEGAL NOTICE!
This note contains information on statutory directives and standards.
WARNING!
In general, devices from the manufacturer may only be installed, commissioned, operated and
maintained by properly trained and authorized personnel.
This document is provided to help you establish operating conditions, which will permit safe and
efficient use of this device.

DEVICE DESCRIPTION 2
9
OPTISYS TUR 1050
www.krohne.com02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
2.1 Scope of delivery
INFORMATION!
Inspect the packaging carefully for damages or signs of rough handling. Report damage to the
carrier and to the local office of the manufacturer.
INFORMATION!
Do a check of the packing list to make sure that you have all the elements given in the order.
INFORMATION!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
INFORMATION!
Assembly materials and tools are not part of the delivery. Use the assembly materials and tools
in compliance with the applicable occupational health and safety directives.
Figure 2-1: Scope of delivery
1 Electronic device with flow-through assembly and ultrasonic cuvette
2 Tubing kit (drain vent, shut-off clamp, seal screw, backpressure valve, connection tubes with fittings for
ultrasonic cuvette assembly)
3 Junction box power assembly
4 Desiccant pack (desiccant pouch with humidity indicator)
5 Documentation

2 DEVICE DESCRIPTION
10
OPTISYS TUR 1050
www.krohne.com 02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
2.2 Device description
Front view of the complete device
Figure 2-2: Description of the complete device
1 Intake tubing
2 Shut-off clamp (stops the intake flow during cuvette cleanings and replacements)
3 Drain tubing
4 Backpressure valve (allows adjustment of the amount of back pressure, which helps to control the flow rate and elim-
inate small bubbles)
5 Display (LCD)
6 Operation keys
7 Drain hose connection (inner Ø: 4.75 mm / 0.19", outer Ø: 8 mm / 0.31"), the hose has to lead to a suitable drain site
8 Drain vent hole
9 Sensor interconnect cable
10 Drain hose
11 Terminal box
12 Intake hose
13 Intake hose connection (inner Ø: 4.75 mm / 0.19",outer Ø: 8 mm / 0.31"), has to supply the sensor with a dependable
sample flow
14 Pressure regulator

DEVICE DESCRIPTION 2
11
OPTISYS TUR 1050
www.krohne.com02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
The device is available with a white light source or an infrared light source. There are no visible
differences between these versions. Both versions provide the possibility of ultrasonic cleaning.
Every device has a pressure regulator for the incoming flow which reduces pressures up to
14 bar / 203 psi down to 1 bar / 15 psi.
Dehumidification system
The device is equipped with a continuous dehumidification system that works with the help of a
replaceable desiccant pouch in the electronic device. While the system heat is used to warm the
air, a fan inside the device continuously circulates this heated and by the desiccant pouch
dehumidified air around the optical well and the electronic device. This features eliminates the
need for a dry purge line.
The device monitors the replaceable desiccant pouch condition continuously. The lower line of
the display shows the message "DESC" in the event that you have to replace a saturated
desiccant pouch that may cause problems.
Liquid crystal display (LCD)
For a better readability in low light or no light conditions the LCD is backlight. The backlight
always stays on, but the brightness is adjustable.
Ultrasonic cuvette with flow-through holder
Figure 2-3: Description of ultrasonic cuvette with flow-through holder
1 Intake tubing
2 Drain tubing
3 Bolt
4 Ultrasonic cuvette
5 Bottom plate with ultrasonic transducer (at the bottom side)

2 DEVICE DESCRIPTION
12
OPTISYS TUR 1050
www.krohne.com 02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
RS 485 interface
In addition to the Modbus communication the device can operate in two other RS 485 modes:
•Online: the device operates as a small SCADA system (Supervisory Control and Data
Acquisition) with an optional software package (to get this package contact the manufacturer
or your local sales office). This system allows the connection of up to 255 devices which all
have to be an OPTISYS TUR 1050. Furthermore this system offers a direct interface with
common database and spreadsheet software.
•Simple: the device can provide basic communications with the help of simple programs.
Examples for such programs are Hilgraeve hyperterminal (included in most Microsoft
Windows packages) or Visual Basic.
Ultrasonic cleaning
This feature helps to clean the ultrasonic cuvette continuously. The system works by sending an
ultrasonic frequency through spring connections in the upper part of the device to a piezo
transducer at the bottom of the ultrasonic cuvette.
The ultrasonic cleaning can increase the time between cleanings significantly. However it cannot
substitute the manual cleaning entirely.
2.3 Nameplates
INFORMATION!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
Infrared version
Figure 2-4: Example for nameplate for infrared version
1 Manufacturer and address
2 WEEE waste bin symbol
3 ETL symbol
4 CE symbol
5 Logistics numbers
6 Electrical data
7 Serial number
8 Device designation and order code

DEVICE DESCRIPTION 2
13
OPTISYS TUR 1050
www.krohne.com02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
White light version
Figure 2-5: Example for nameplate for white light version
1 Manufacturer and address
2 WEEE waste bin symbol
3 ETL symbol
4 CE symbol
5 Logistics numbers
6 Electrical data
7 Serial number
8 Device designation and order code

3 INSTALLATION
14
OPTISYS TUR 1050
www.krohne.com 02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
3.1 General notes on installation
3.2 Storage and transport
•Store and transport the device in a dry, dust-free environment.
•Store and transport the device in an environment with a temperature between -20...+60°C/
-4...+176°F.
•The original packing is designed to protect the equipment. It has to be used if the device is
transported or sent back to the manufacturer.
3.3 Requirements of the device
The device was designed to require very low input pressure. Though the device offers a wide
pressure range, as it has an integrated pressure regulator:
•Input pressure range: 0.07...14 bar / 1...200 psi (built in regulator set at 1 bar / 15 psi)
•Maximum allowable flow rate of the cuvette: 0.1...1 l/min / 0.026...0.26 gal/min
•Maximum fluid temperature: +50°C / +122°F
INFORMATION!
Inspect the packaging carefully for damages or signs of rough handling. Report damage to the
carrier and to the local office of the manufacturer.
INFORMATION!
Do a check of the packing list to make sure that you have all the elements given in the order.
INFORMATION!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
INFORMATION!
The device must not be heated by radiated heat (e.g. exposure to the sun) to a electronics
housing surface temperature above the maximum permissible ambient temperature. If it is
necessary to prevent damage from heat sources, a heat protection (e.g. sun shade) has to be
installed.

INSTALLATION 3
15
OPTISYS TUR 1050
www.krohne.com02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
3.4 Installation order
To install the device in the correct way, follow the order of the following sections and their
instructions.
3.4.1 Placing the desiccant pouch and the humidity indicator
Execute the following steps to insert or replace the desiccant pouch and the humidity indicator
(Humonitor
®
card) or to inspect the seal:
• Move the lock ring counterclockwise and pull out the ultrasonic cuvette with flow-through
holder (detailed information on page 21).
• Unscrew the four corner thumbscrews of the electronic device manually according to 1in the
following drawing (if the screws are too tight, use a screwdriver for slotted grub screws).
• Remove the upper half of the electronic device 2.
• Prior to installing the desiccant pouch for the first time, remove the shipping support (plastic
tube with a red flag reaching outside) within the upper part of the device; after removing you
can discard the tube.
CAUTION!
Installation, assembly, start-up and maintenance may only be performed by appropriately
trained personnel. The regional occupational health and safety directives must always be
observed.
CAUTION!
A missing or saturated desiccant pouch affects not only the performance of the whole device, but
can also destroy the internal electronics!
If the seal at the device base does not fit properly or is defective, the lifetime of the desiccant
decreases. Therefore assure the following items:
• Do not start-up the device with a desiccant pouch missing, replace a saturated pouch!
• Replace the desiccant pouch when the display shows the message "DESC".
• Inspect the enclosure seal each time you replace the desiccant.
• If the seal is not properly seated or damaged, reseat or replace it!
Figure 3-1: Desiccant pack (desiccant pouch with humidity indicator)
CAUTION!
The desiccant degrades prematurely after removing the protective packaging. Therefore do not
open the packaging before usage, install the desiccant pouch quickly and close the device as
soon as possible.

3 INSTALLATION
16
OPTISYS TUR 1050
www.krohne.com 02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
• If you want to replace the desiccant pouch and the humidity indicator, take them out at first 3.
• Take the shrink packed desiccant pouch and the humidity indicator out of the protective
packaging.
• Put the humidity indicator on the bottom of the lower part of the electronic device and lay the
desiccant pouch on it 4and 5.
• Inspect the seal and reseat or replace it if necessary.
• Reassemble everything in reverse order 6.
• To expedite the recognition of the new desiccant, reset the powered device by disconnecting
the sensor interconnect cable for two seconds and reconnecting it.
3.4.2 Selecting site and mounting
The preferred way of mounting of the device is wall mounting. If this is not possible, you can
mount the device on any suitable level surface. Irrespective of this possibilities always note the
following guidelines:
•Choose a location that is easily accessible for operation and service and that is as close as
possible to the sampling point to ensure a quick response time (maximum distance:
3m/10ft)
•Leave at least 20 cm / 8" of free space above the device for easy service (e.g. removal of the
flow head and insertion of calibration cuvettes), see position number 1in the following
drawing.
•Ensure that the front display rests at eye level.
•Refer to chapter "Dimensions" for the device dimensions.
•Use screws M6 / 1/4" to fix the electronic device 2and M4 / 3/16" to fix the junction box
power assembly 3.

INSTALLATION 3
17
OPTISYS TUR 1050
www.krohne.com02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
Mounting procedure
• Take a water-level, a pencil and ruler and use the dimensions in the following drawing to mark
the six mounting hole locations on the mounting surface.
Note:
Note:Note:
Note: Do not use the drawing on the following page directly as mounting template as the
printed dimensions there differ from reality!
• Drill six holes into the mounting surface and insert six screw anchors into them.
• Use screws M4 / 3/16" to fix the junction box power assembly at first.
• Put the electronic device on top of the junction box power assembly and use screws M6 / 1/4"
to fix it.
INFORMATION!
The design of the device recommends that the junction box power assembly cradles in a hutch
below the electronic device. Therefore the correct procedure is to fix the junction box power
assembly first and then mount the electronic device on top of it.
Figure 3-2: Mounting field terminal box

3 INSTALLATION
18
OPTISYS TUR 1050
www.krohne.com 02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
3.4.3 Mounting
[mm] ["]
a51 2.0
b147 5.79
c90 3.54
d87 3.43
CAUTION!
Please do not use this directly as mounting template as the printed dimensions here differ from
reality!

INSTALLATION 3
19
OPTISYS TUR 1050
www.krohne.com02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
3.4.4 Connecting the hoses
The scope of delivery contains two tubings with fittings (intake tubing, drain tubing) for the
connection between the flow-through holder and the flow intake and flow drain. The intake
tubing has a shut-off clamp and the drain tubing has a backpressure valve. Connect the hoses
according to the following drawing:
The hose for the connection between the sampling point and the device as well as the hose for
the flow drain do not belong to the scope of delivery. For this purpose use hoses with the
following specifications:
•Inner diameter: 4.75 mm / 3/16".
•Outer diameter: 8 mm / 5/16".
•Flexible and opaque hose material to prevent algae growth if direct sunlight can reach the
hose.
CAUTION!
Do not connect the sensor interconnect cable with the upper part of the device now and regard
the installation order in the chapter "Electrical connections"! The reason is that you will have to
do the internal wiring at first and the connection of the sensor interconnect cable afterwards, the
reverse order could damage the device!
Figure 3-3: Connecting the hoses
1 Intake tubing with shut-off clamp
2 Drain hose with backpressure valve
3 Sensor interconnect cable

3 INSTALLATION
20
OPTISYS TUR 1050
www.krohne.com 02/2017 - 4002444302 - MA OPTISYS TUR 1050 R03 en
Assemble the plumbing and connect the hoses according to the following drawing:
• Slip the coupling nut over the hose 1
• Insert spreading ring into the hose 2
• Fix the nut on the thread of the pressure regulator 3
• Intake hose connection 4
• Drain hose connection 5
3.4.5 Drain vent
The device has a drain vent in the "Out" bulkhead fitting. The drain vent allows atmospheric
equalization, thus helping to alleviate bubble formation in the cuvette.
In some pressurised systems there may occur a continuous leakage at the drain vent hole.
Therefore the scope of delivery contains a seal screw that you can insert into the vent hole and
tighten.
Figure 3-4: Procedure to assemble the plumbing and connect the hoses
INFORMATION!
To prevent that the drain water causes any damages, assure that the drain hose leads to a
suitable drain site.
CAUTION!
The manufacturer accepts no responsibility for damage caused by the introduction of vapours,
fluids or other materials into the device process stream which are not compatible with the
device
’ s wetted materials. Always note the list of wetted parts in the technical data table before
introducing any media into the device process stream!
INFORMATION!
During initial flow minor leakage may occur at the drain vent. This will subside once the normal
flow is established.
