KROHNE OPTIWAVE 7300 C User manual

24 GHz Non-contact Radar (FMCW) Level Meter
for distance, level, volume and mass measurement of liquids
OPTIWAVE 7300 C
OPTIWAVE 7300 COPTIWAVE 7300 C
OPTIWAVE 7300 C Handbook
HandbookHandbook
Handbook
© KROHNE 03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en

All rights reserved. It is prohibited to reproduce this documentation, or any part thereof, without
the prior written authorisation of KROHNE Messtechnik GmbH.
Subject to change without notice.
2
www.krohne.com 03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
Copyright 2015 by
KROHNE Messtechnik GmbH - Ludwig-Krohne-Str. 5 - 47058 Duisburg (Germany)
: IMPRINT :::::::::::::::::::::::::::::::::::::::

CONTENTS
3
www.krohne.com03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
OPTIWAVE 7300 C
1 Safety instructions 7
1.1 Software history ............................................................................................................... 7
1.2 Intended use ..................................................................................................................... 7
1.3 Certification ...................................................................................................................... 8
1.4 Electromagnetic compatibility ......................................................................................... 8
1.5 Radio approvals ................................................................................................................ 8
1.5.1 European Union (EU)............................................................................................................... 8
1.5.2 U.S.A. and Canada................................................................................................................. 10
1.6 Safety instructions from the manufacturer ................................................................... 11
1.6.1 Copyright and data protection .............................................................................................. 11
1.6.2 Disclaimer ............................................................................................................................. 11
1.6.3 Product liability and warranty .............................................................................................. 12
1.6.4 Information concerning the documentation......................................................................... 12
1.6.5 Warnings and symbols used................................................................................................. 13
1.7 Safety instructions for the operator............................................................................... 13
2 Device description 14
2.1 Scope of delivery............................................................................................................. 14
2.2 Device description .......................................................................................................... 16
2.3 Visual Check ................................................................................................................... 17
2.4 Nameplates .................................................................................................................... 18
2.4.1 Non-Ex nameplate ................................................................................................................ 18
3 Installation 19
3.1 General notes on installation ......................................................................................... 19
3.2 Storage ........................................................................................................................... 19
3.3 Transport ........................................................................................................................ 20
3.4 Pre-installation requirements ....................................................................................... 20
3.5 How to prepare the tank before you install the device.................................................. 21
3.5.1 Pressure and temperature ranges....................................................................................... 21
3.5.2 Recommended mounting position........................................................................................ 22
3.5.3 Theoretical data for hygienic applications ........................................................................... 23
3.6 Installation recommendations for liquids...................................................................... 24
3.6.1 General requirements .......................................................................................................... 24
3.6.2 Standpipes (stilling wells and bypass chambers) ................................................................ 25
3.7 How to install the device on the tank ............................................................................. 28
3.7.1 How to install a device with a flange connection ................................................................. 28
3.7.2 How to install a device with a threaded connection............................................................. 30
3.7.3 How to install a device with a hygienic connection .............................................................. 32
3.7.4 How to attach antenna extensions ....................................................................................... 36
3.7.5 How to turn or remove the signal converter ........................................................................ 38
3.7.6 How to attach the weather protection to the device............................................................. 39
3.7.7 How to open the weather protection .................................................................................... 40

CONTENTS
4
www.krohne.com 03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
OPTIWAVE 7300 C
4 Electrical connections 41
4.1 Safety instructions.......................................................................................................... 41
4.2 Electrical installation: outputs 1 and 2 .......................................................................... 41
4.2.1 Non-Ex devices ..................................................................................................................... 42
4.2.2 Devices for hazardous locations........................................................................................... 43
4.3 Protection category ........................................................................................................43
4.4 Networks ........................................................................................................................ 44
4.4.1 General information.............................................................................................................. 44
4.4.2 Point-to-point connection..................................................................................................... 44
4.4.3 Multi-drop networks ............................................................................................................. 45
5 Start-up 46
5.1 Start-up checklist........................................................................................................... 46
5.2 Operating concept ..........................................................................................................46
5.3 Digital display screen .....................................................................................................47
5.3.1 Local display screen layout .................................................................................................. 47
5.3.2 Keypad buttons ..................................................................................................................... 47
5.3.3 Help screens ......................................................................................................................... 47
5.3.4 How to start the device ......................................................................................................... 48
5.4 Remote communication with PACTware™ .................................................................... 48
5.5 Remote communication with the AMS™ Device Manager............................................. 49
6 Operation 50
6.1 User modes .................................................................................................................... 50
6.2 Operator mode................................................................................................................ 50
6.3 Supervisor mode ............................................................................................................52
6.3.1 General notes........................................................................................................................ 52
6.3.2 How to get access to the supervisor mode .......................................................................... 52
6.3.3 Menu overview ...................................................................................................................... 53
6.3.4 Keypad functions................................................................................................................... 54
6.3.5 Function description ............................................................................................................. 58
6.4 Further information on device configuration................................................................. 70
6.4.1 Protection of the device settings .......................................................................................... 70
6.4.2 Network configuration .......................................................................................................... 70
6.4.3 Linearisation ......................................................................................................................... 71
6.4.4 Distance measurement ........................................................................................................ 71
6.4.5 Level measurement .............................................................................................................. 72
6.4.6 How to configure the device to measure volume or mass................................................... 74
6.4.7 How to make a filter to remove radar signal interference .................................................. 75
6.4.8 How to measure correctly in tanks with curved or conical bottoms ................................... 76
6.5 Service mode .................................................................................................................. 77
6.6 Errors.............................................................................................................................. 77
6.6.1 General information.............................................................................................................. 77
6.6.2 Error handling....................................................................................................................... 80

CONTENTS
5
www.krohne.com03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
OPTIWAVE 7300 C
7 Service 83
7.1 Periodic maintenance..................................................................................................... 83
7.2 How to clean the top surface of the device .................................................................... 83
7.3 How to clean horn antennas under process conditions ................................................ 84
7.4 How to replace device components ............................................................................... 85
7.4.1 Service warranty ................................................................................................................... 85
7.4.2 Replacement of the display cover.........................................................................................86
7.4.3 Replacement of the complete electronic module................................................................ 88
7.4.4 Replacement of the terminal module................................................................................... 90
7.5 Spare parts availability...................................................................................................92
7.6 Availability of services .................................................................................................... 92
7.7 Returning the device to the manufacturer..................................................................... 92
7.7.1 General information.............................................................................................................. 92
7.7.2 Form (for copying) to accompany a returned device............................................................ 93
7.8 Disposal .......................................................................................................................... 93
8 Technical data 94
8.1 Measuring principle........................................................................................................94
8.2 Technical data................................................................................................................. 95
8.3 Antenna selection......................................................................................................... 101
8.4 Guidelines for maximum operating pressure.............................................................. 102
8.5 Dimensions and weights .............................................................................................. 104
9 Description of HART interface 115
9.1 General description ...................................................................................................... 115
9.2 Software history ...........................................................................................................115
9.3 Connection variants...................................................................................................... 116
9.3.1 Point-to-Point connection - analogue / digital mode......................................................... 116
9.3.2 Multi-Drop connection (2-wire connection) ....................................................................... 116
9.4 HART® device variables............................................................................................... 117
9.5 Field Communicator 375/475 (FC 375/475) ................................................................. 117
9.5.1 Installation .......................................................................................................................... 117
9.5.2 Operation............................................................................................................................. 117
9.6 Asset Management Solutions (AMS)............................................................................ 118
9.6.1 Installation .......................................................................................................................... 118
9.6.2 Operation............................................................................................................................. 118
9.6.3 Parameter for the basic configuration ............................................................................... 118
9.7 Field Device Tool / Device Type Manager (FDT / DTM) ................................................ 118
9.7.1 Installation .......................................................................................................................... 118
9.7.2 Operation............................................................................................................................. 118
9.8 HART®menu tree for Basic-DD .................................................................................. 119
9.8.1 Overview Basic-DD menu tree (positions in menu tree).................................................... 119
9.8.2 Basic-DD menu tree (details for settings).......................................................................... 119
9.9 HART®menu tree for AMS .......................................................................................... 121
9.9.1 Overview AMS menu tree (positions in menu tree)............................................................ 121
9.9.2 AMS menu tree (details for settings).................................................................................. 121

CONTENTS
6
www.krohne.com 03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
OPTIWAVE 7300 C
10 Appendix 124
10.1 Order code .................................................................................................................. 124
10.2 List of spare parts ...................................................................................................... 130
10.3 List of accessories...................................................................................................... 133
10.4 Glossary ...................................................................................................................... 135
11 Notes 138

SAFETY INSTRUCTIONS 1
7
OPTIWAVE 7300 C
www.krohne.com03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
1.1 Software history
Data about software revisions is shown in the Supervisor menu. Go to Test > Information >
Test > Information >Test > Information >
Test > Information >
Device ID
Device IDDevice ID
Device ID. For more data, refer to
Function description on page 58. If it is not possible to refer to
the device menu, record the serial number of the device (given on the device nameplate) and
speak to the supplier.
1.2 Intended use
This radar level transmitter measures distance, level, mass, volume and reflectivity of liquids,
pastes and slurries.
It can be installed on tanks, reactors and open channels.
Release date
(back end)
[YYYY-MM-DD]
Back end Front end DTM revision Hardware NE 53 level
2006-10-31 1.0.1.95 1.0.0.26 1.0.0.32 2139580100 n/a
2008-02-01 1.0.1.96 1.0.0.27 1.0.0.34 2139580100 3
End of back end board ref. 2138270200 production
2010-03-01 2.0.2.00
1.0.2.00 1
1.0.0.28 1.0.0.35 4000659201 2 1
3
2010-05-01 2.0.2.01
1.0.2.01 1
1.0.0.28 1.0.0.35 4000659201 2 3
n/a
2012-03-05 2.0.2.02
1.0.2.02 1
1.0.0.28 1.0.0.36 4000659201 2 3
3
2012-03-05 2.0.2.03
1.0.2.03 1
1.0.0.28 1.0.0.36 4000659201 2 3
3
2013-01-22 2.0.2.04
1.0.2.04 1
1.0.0.28 1.0.0.37 3 4000659201 2 3
3
2015-01-26 S2.0.2.04/FastMotion 4 1.0.0.28 1.0.0.37 3 4000659201 2
1This back end firmware revision is only used for device upgrades
2It is possible to upgrade the hardware (ref. 2139580100) with back end firmware revision 1.0.2.04
3If your computer uses the Windows XP operating system, install DTM revision V 1.0.0.36. If your computer uses the Windows 7 operating
system, install DTM revision V 1.0.0.37.
4The back end firmware revision S2.0.2.04 is applicable only for the fast motion software option. All other devices use backend version
2.0.2.04.

1 SAFETY INSTRUCTIONS
8
OPTIWAVE 7300 C
www.krohne.com 03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
1.3 Certification
In accordance with the commitment to customer service and safety, the device
described in this document meets the following safety requirements:
•Electromagnetic Compatibility (EMC) Directive 2004/108/EC in conjunction with EN 61326-1
(2013).
•Radio Equipment and Telecommunications Terminal Equipment (R & TTE) Directive
1999/05/EC in conjunction with ETSI EN 302 372-2 (2011) and ETSI EN 302 729-2 (2011). For
more data, refer to
European Union (EU) on page 8.
•Low-Voltage Directive 2006/95/EC in conjunction with EN 61010-1 (2001).
All devices are based on the CE marking and meet the requirements of NAMUR Guideline NE 21
and NE 43.
1.4 Electromagnetic compatibility
The device design agrees with European Standard EN 61326-1.
You can install the device on open-air tanks and tanks that are not made of metal. But refer to
Radio approvals on page 8. This agrees with Immunity and Emissions requirements for industrial
environments.
1.5 Radio approvals
1.5.1 European Union (EU)
DANGER!
For devices used in hazardous areas, additional safety notes apply; please refer to the Ex
documentation.
INFORMATION!
Device operation agrees with residential-class (class B) immunity and emissions requirements if
the antenna is used in a closed tank made of metal.
LEGAL NOTICE!
This level transmitter is intended for installation in closed metallic tanks and open-air
installations. It meets the requirements of the R & TTE (Radio Equipment and
Telecommunications Terminal Equipment) Directive 1999/05/EC for use in the member
countries of the EU.
The device operates using a frequency band (24...26 GHz) that is not harmonized within the EU.
According to article 6.4 of the R&TTE Directive, the product is marked by the CE sign + notified
body number (0682) + Class II identifier (= alert sign).
Refer to EN 302372 and EN 302729 for installation conditions.

SAFETY INSTRUCTIONS 1
9
OPTIWAVE 7300 C
www.krohne.com03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
According to ETSI EN 302 372-2 (2011), the radiated power outside a metallic tank is less than
-30 dBm.
The radio approval report is given on the DVD-ROM supplied with the device.
The device agrees with the ETSI EN 302 729 standard for Level Probing Radar (LPR)
equipment
It is possible to use the device in open-air installations, but the R&TTE Directive (1999/5/EC) and
the related standards must be approved in the country where the device is installed.
At this time, the R&TTE Directive is approved in the countries that follow: Austria, Belgium,
Denmark, Finland, France, Germany, Greece, Iceland, Ireland, Italy, Liechtenstein, Luxembourg,
Netherlands, Norway, Portugal, Spain, Sweden, United Kingdom, Czech Republic, Estonia,
Cyprus, Latvia, Lithuania, Hungary, Malta, Poland, Slovenia, Slovakia, Romania and Bulgaria.
Use approved personnel to install the device. Obey these instructions:
• Install the device in a permanent location. The device must point down at a constant angle.
• Install the device more than 4 km / 2.485 mi away from radio astronomy sites.
• If the device is 4...40 km / 2.485...24.855 mi away from radio astronomy sites, do not install the
device more than 15 m / 49.21 ft above the ground.
Figure 1-1: Radio approval information on the nameplate
1 CE sign
2 Notified body number (0682 = CETECOM)
3 Class II identifier
CAUTION!
If it is necessary to install the device less than 4 km / 2.485 mi from radio astronomy sites, you
must get the approval of the national regulatory authority before installation (e.g. ANFR
(France), Bundesnetzagentur (Germany), Ofcom (United Kingdom) etc.).

1 SAFETY INSTRUCTIONS
10
OPTIWAVE 7300 C
www.krohne.com 03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
Locations of radio astronomy sites (stations) in Europe and northern Eurasia
For more data, refer to this page (in English) on the website for the Committee on Radio
Astronomy Frequencies (CRAF): http://www.craf.eu/raobs.htm.
1.5.2 U.S.A. and Canada
This legal information is shown on a label on the rear side of the device.
The radio approval report is given on the DVD-ROM supplied with the device.
Country Name of the station Location
Latitude, ϕLongitude, λ
Finland Metsähovi 60°13'04" N 24°23'37" E
Tuorla 60°24'56" N 22°26'31" E
France Plateau de Bure 44°38'01" N 05°54'26" E
Floirac 44°50'10" N 00°31'37" W
Germany Effelsberg 50°31'32" N 06°53'00" E
Hungary Penc 47°47'22" N 19°16'53" E
Italy Medicina 44°31'14" N 11°38'49" E
Noto 36°52'34" N 14°59'21" E
Sardinia 39°29'50" N 09°14'40" E
Latvia Ventspils 57°33'12" N 21°51'17" E
Poland Kraków –Fort Skala 50°03'18" N 19°49'36" E
Torun –Piwnice 52°54'48" N 18°33'30" E
Russia Dmitrov 56°26'00" N 37°27'00" E
Kalyazin 57°13'22" N 37°54'01" E
Pushchino 54°49'00" N 37°40'00" E
Zelenchukskaya 43°49'53" N 41°35'32" E
Spain Yebes 40°31'27" N 03°05'22" W
Robledo 40°25'38" N 04°14'57" W
Switzerland Bleien 47°20’26" N 08°06’44" E
Sweden Onsala 57°23’45" N 11°55’35" E
UK Cambridge 52°09'59" N 00°02'20" E
Darnhall 53°09'22" N 02°32'03" W
Jodrell Bank 53°14'10" N 02°18'26" W
Knockin 52°47'24" N 02°59'45" W
Pickmere 53°17'18" N 02°26'38" W
LEGAL NOTICE!
This device complies with Part 15 of the FCC Rules and with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference which may cause un-
desired operation.
Changes or modifications made to this equipment not expressly approved by the manufacturer
may void the FCC and IC authorizations to operate this equipment.

SAFETY INSTRUCTIONS 1
11
OPTIWAVE 7300 C
www.krohne.com03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
1.6 Safety instructions from the manufacturer
1.6.1 Copyright and data protection
The contents of this document have been created with great care. Nevertheless, we provide no
guarantee that the contents are correct, complete or up-to-date.
The contents and works in this document are subject to copyright. Contributions from third
parties are identified as such. Reproduction, processing, dissemination and any type of use
beyond what is permitted under copyright requires written authorisation from the respective
author and/or the manufacturer.
The manufacturer tries always to observe the copyrights of others, and to draw on works created
in-house or works in the public domain.
The collection of personal data (such as names, street addresses or e-mail addresses) in the
manufacturer's documents is always on a voluntary basis whenever possible. Whenever
feasible, it is always possible to make use of the offerings and services without providing any
personal data.
We draw your attention to the fact that data transmission over the Internet (e.g. when
communicating by e-mail) may involve gaps in security. It is not possible to protect such data
completely against access by third parties.
We hereby expressly prohibit the use of the contact data published as part of our duty to publish
an imprint for the purpose of sending us any advertising or informational materials that we have
not expressly requested.
1.6.2 Disclaimer
The manufacturer will not be liable for any damage of any kind by using its product, including,
but not limited to direct, indirect or incidental and consequential damages.
This disclaimer does not apply in case the manufacturer has acted on purpose or with gross
negligence. In the event any applicable law does not allow such limitations on implied warranties
or the exclusion of limitation of certain damages, you may, if such law applies to you, not be
subject to some or all of the above disclaimer, exclusions or limitations.
Any product purchased from the manufacturer is warranted in accordance with the relevant
product documentation and our Terms and Conditions of Sale.
The manufacturer reserves the right to alter the content of its documents, including this
disclaimer in any way, at any time, for any reason, without prior notification, and will not be liable
in any way for possible consequences of such changes.

1 SAFETY INSTRUCTIONS
12
OPTIWAVE 7300 C
www.krohne.com 03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
1.6.3 Product liability and warranty
The operator shall bear responsibility for the suitability of the device for the specific purpose.
The manufacturer accepts no liability for the consequences of misuse by the operator. Improper
installation or operation of the devices (systems) will cause the warranty to be void. The
respective "Standard Terms and Conditions" which form the basis for the sales contract shall
also apply.
1.6.4 Information concerning the documentation
To prevent any injury to the user or damage to the device it is essential that you read the
information in this document and observe applicable national standards, safety requirements
and accident prevention regulations.
If this document is not in your native language and if you have any problems understanding the
text, we advise you to contact your local office for assistance. The manufacturer can not accept
responsibility for any damage or injury caused by misunderstanding of the information in this
document.
This document is provided to help you establish operating conditions, which will permit safe and
efficient use of this device. Special considerations and precautions are also described in the
document, which appear in the form of icons as shown below.

SAFETY INSTRUCTIONS 1
13
OPTIWAVE 7300 C
www.krohne.com03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
1.6.5 Warnings and symbols used
Safety warnings are indicated by the following symbols.
• HANDLING
HANDLINGHANDLING
HANDLING
This symbol designates all instructions for actions to be carried out by the operator in the
specified sequence.
iRESULT
RESULTRESULT
RESULT
This symbol refers to all important consequences of the previous actions.
1.7 Safety instructions for the operator
DANGER!
This warning refers to the immediate danger when working with electricity.
DANGER!
This warning refers to the immediate danger of burns caused by heat or hot surfaces.
DANGER!
This warning refers to the immediate danger when using this device in a hazardous atmosphere.
DANGER!
These warnings must be observed without fail. Even partial disregard of this warning can lead to
serious health problems and even death. There is also the risk of seriously damaging the device
or parts of the operator's plant.
WARNING!
Disregarding this safety warning, even if only in part, poses the risk of serious health problems.
There is also the risk of damaging the device or parts of the operator's plant.
CAUTION!
Disregarding these instructions can result in damage to the device or to parts of the operator's
plant.
INFORMATION!
These instructions contain important information for the handling of the device.
LEGAL NOTICE!
This note contains information on statutory directives and standards.
WARNING!
In general, devices from the manufacturer may only be installed, commissioned, operated and
maintained by properly trained and authorized personnel.
This document is provided to help you establish operating conditions, which will permit safe and
efficient use of this device.

2 DEVICE DESCRIPTION
14
OPTIWAVE 7300 C
www.krohne.com 03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
2.1 Scope of delivery
INFORMATION!
Do a check of the packing list to make sure that you have all the elements given in the order.
Scope of delivery –horn antenna
Figure 2-1: Scope of delivery –horn antenna
1 Signal converter and antenna in compact version
2 Antenna extensions (option)
3 Quick Start
4 DVD-ROM (including Handbook, Quick Start, Technical Datasheet and related software)
Scope of delivery –Drop antenna
Figure 2-2: Scope of delivery –Drop antenna
1 Signal converter and antenna in compact version
2 Antenna extensions (option) and O-ring for each antenna extension
3 Quick Start
4 DVD-ROM (including Handbook, Quick Start, Technical Datasheet, and related software)

DEVICE DESCRIPTION 2
15
OPTIWAVE 7300 C
www.krohne.com03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
Scope of delivery –hygienic antenna
Figure 2-3: Scope of delivery –hygienic antenna
1 Signal converter and antenna in compact version
2 Quick Start
3 DVD-ROM (including Handbook, Quick Start, Technical Datasheet, and related software)
INFORMATION!
No special tools or training required!

2 DEVICE DESCRIPTION
16
OPTIWAVE 7300 C
www.krohne.com 03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
2.2 Device description
This device is a 24 GHz FMCW-radar level transmitter. It is a non-contact technology and is 2-
wire loop-powered. It is designed to measure the distance, level, mass, volume and reflectivity of
liquids, pastes and slurries.
Radar level transmitters use an antenna to emit a signal to the surface of the measured product.
The device has many antennas available. Thus, it can measure most products even in difficult
conditions. Also refer to
Technical data on page 94.
The device has a set-up wizard, fully-potted electronic circuit boards and online help functions.
You usually will not need this Handbook to install, set up and operate the device.
If it is ordered with the applicable options, it can be certified for use in hazardous areas.
These output options are available:
•1 output: 4...20 mA (HART)
•2 outputs: 4...20 mA (HART) + 4...20 mA
•2 outputs: 16 mA (HART) + 4...20 mA fast motion software (5 measurements per second)
These accessories are available:
•Stainless steel weather protection.
•RS232 / HART
®
converter (VIATOR).
•USB / HART
®
converter.
INFORMATION!
For more data on accessories, refer to List of accessories on page 133
.

DEVICE DESCRIPTION 2
17
OPTIWAVE 7300 C
www.krohne.com03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
2.3 Visual Check
If the device is supplied with an FKM/FPM gasket, there is no symbol on the side of the process
connection.
WARNING!
If the display screen glass is broken, do not touch.
INFORMATION!
Inspect the packaging carefully for damages or signs of rough handling. Report damage to the
carrier and to the local office of the manufacturer.
Figure 2-4: Visual check
1 Device nameplate (for more data, refer to
Non-Ex nameplate on page 18)
2 Process connection data (size and pressure rating, material reference and heat number)
3 Gasket material data - refer to the illustration that follows
Figure 2-5: Symbols for the supplied gasket material (on the side of the process connection)
1 EPDM
2 Kalrez
®
6375
INFORMATION!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
INFORMATION!
Compare the material references on the side of the process connection with the order.

2 DEVICE DESCRIPTION
18
OPTIWAVE 7300 C
www.krohne.com 03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
2.4 Nameplates
2.4.1 Non-Ex nameplate
INFORMATION!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
Figure 2-6: Non-Ex nameplate
1 Indicator arrow to cable entry / cable entry size. Notified body for radio approval.
2 Hardware revision / Software revision
3 Nominal voltage for operation. For further information, refer to
Non-Ex devices on page 42.
4 Degree of ingress protection (according to EN 60529 / IEC 60529)
5 Customer tag number
6 Date of manufacture
7 Order number
8 Type code (defined in order)
9 Model name and number
10 Company name and address

INSTALLATION 3
19
OPTIWAVE 7300 C
www.krohne.com03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
3.1 General notes on installation
3.2 Storage
•Store the device in a dry and dust-free location.
•Keep the converter out of the sunlight.
•Store the device in its original packing.
INFORMATION!
Inspect the packaging carefully for damages or signs of rough handling. Report damage to the
carrier and to the local office of the manufacturer.
INFORMATION!
Do a check of the packing list to make sure that you have all the elements given in the order.
INFORMATION!
Look at the device nameplate to ensure that the device is delivered according to your order.
Check for the correct supply voltage printed on the nameplate.
WARNING!
Do not keep the device in a vertical position. This will damage the antenna and the device will not
measure correctly.
Figure 3-1: Storage conditions
1 When you put the device into storage, do not keep it in a vertical position
2 Put the device on its side. We recommend that you use the packaging in which it was delivered.
3 Storage temperature range: -40...+85°C / -40...+185°F

3 INSTALLATION
20
OPTIWAVE 7300 C
www.krohne.com 03/2015 - 4000172406 - HB OPTIWAVE 7300 R08 en
3.3 Transport
3.4 Pre-installation requirements
•Make sure that there is sufficient space on all sides.
•Protect the signal converter from direct sunlight. If necessary, install the weather protection
accessory.
•Do not subject the signal converter to heavy vibrations. The devices are tested for vibration
and agree with EN 50178 and IEC 60068-2-6.
Figure 3-2: How to lift the device
1 Remove the converter before you lift the device with a hoist.
WARNING!
Lift the device carefully to prevent damage to the antenna.
INFORMATION!
Obey the precautions that follow to make sure that the device is correctly installed.
