Radar (FMCW) Level Transmitter for liquids in storage
and process applications
Supplementary Instructions for ATEX applications
Supplementary Instructions for ATEX applicationsSupplementary Instructions for ATEX applications
Supplementary Instructions for ATEX applications
OPTIWAVE 5200 C/F
OPTIWAVE 5200 C/FOPTIWAVE 5200 C/F
OPTIWAVE 5200 C/F Supplementary Instructions
Supplementary InstructionsSupplementary Instructions
Supplementary Instructions
© KROHNE 11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en

CONTENTS
2
www.krohne.com 11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
OPTIWAVE 5200 C/F
1 General safety information 4
1.1 Scope of the document..................................................................................................... 4
1.2 Device description ............................................................................................................ 4
1.3 Standards and approvals.................................................................................................. 4
1.4 Device categories ............................................................................................................. 5
1.4.1 Ex ia-approved devices ........................................................................................................... 5
1.4.2 Ex db ia / Ex ia tb-approved devices ....................................................................................... 5
1.4.3 Ex ic-approved devices ........................................................................................................... 5
1.5 ATEX nameplates.............................................................................................................. 6
2 Installation 8
2.1 Precautions....................................................................................................................... 8
2.1.1 General notes.......................................................................................................................... 8
2.1.2 Electrostatic discharge........................................................................................................... 9
2.1.3 Optional purging system....................................................................................................... 10
2.1.4 Optional heating/cooling system ..........................................................................................11
2.2 Operating conditions ...................................................................................................... 12
2.2.1 Ambient and flange temperature ......................................................................................... 12
2.2.2 Maximum surface temperature of the housing for dust applications ................................. 19
2.2.3 Process pressure.................................................................................................................. 19
3 Electrical connections 20
3.1 General notes ................................................................................................................. 20
3.2 Terminal compartment .................................................................................................. 20
3.2.1 How to open the terminal compartment .............................................................................. 20
3.2.2 How to close the terminal compartment ............................................................................. 22
3.3 Terminal tightening capacity.......................................................................................... 22
3.4 Equipotential bonding system........................................................................................ 23
3.5 Ex ia equipment .............................................................................................................. 24
3.5.1 How to connect the electrical cables ................................................................................... 24
3.5.2 Maximum intrinsically-safe values for the electrical circuit............................................... 24
3.5.3 Supply voltage ....................................................................................................................... 24
3.5.4 Electrical schematic ............................................................................................................. 25
3.6 Ex db ia / Ex ia tb equipment .......................................................................................... 26
3.6.1 General notes........................................................................................................................ 26
3.6.2 How to connect the electrical cables ................................................................................... 26
3.6.3 Supply voltage ....................................................................................................................... 27
3.6.4 Electrical schematic ............................................................................................................. 27
3.7 Ex ic equipment .............................................................................................................. 29
3.7.1 How to connect the electrical cables ................................................................................... 29
3.7.2 Maximum intrinsically-safe values for the electrical circuit............................................... 29
3.7.3 Supply voltage ....................................................................................................................... 29
3.7.4 Electrical schematic ............................................................................................................. 30
4 Start-up 31

CONTENTS
3
www.krohne.com11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
OPTIWAVE 5200 C/F
5 Service 32
5.1 Periodic maintenance..................................................................................................... 32
5.2 Keep the device clean..................................................................................................... 32
5.3 Manufacturer.................................................................................................................. 32
5.4 Returning the device to the manufacturer..................................................................... 33
5.4.1 General information.............................................................................................................. 33
5.4.2 Form (for copying) to accompany a returned device............................................................ 34
6 Notes 35

1 GENERAL SAFETY INFORMATION
4
OPTIWAVE 5200 C/F
www.krohne.com 11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
1.1 Scope of the document
These instructions are applicable only to the explosion-protection version of the radar level
transmitter. For all other data, use the Quick Start and Handbook. If you do not have these
documents, please contact the nearest office or download them from the manufacturer's
internet site.
1.2 Device description
This device is a 2-wire level transmitter that uses FMCW (Frequency-Modulated Continuous
Wave) radar technology. It measures the level, distance, volume, mass and flow rate of liquids,
liquid gases, pastes and slurries. It is suitable for installation on storage tanks, process tanks
and stilling wells. Measurements are displayed via a DTM (device type manager) for remote
communication or an optional integrated display screen with wizard-driven setup and online
help functions.
The level transmitter is approved for use in potentially explosive atmospheres when equipped
with the appropriate options.
1.3 Standards and approvals
INFORMATION!
The information in these supplementary instructions only contains the data applicable to
explosion protection. The technical data for the non-Ex version in the Handbook shall be valid in
its current version, provided that it is not rendered invalid or replaced by these supplementary
instructions.
WARNING!
Installation, commissioning and maintenance may only be carried out by "Personnel trained in
explosion protection".
DANGER!
In compliance with European Directive 2014/34/EU (ATEX 114), the ATEX version of the device
described in these Supplementary Instructions agrees with European Standards
EN 60079-0:2012 +A11, EN 60079-1:2014, EN 60079-11:2012, EN 60079-26:2015 and
EN 60079-31:2014. The Ex ia, Ex db ia, Ex ia tb and Ex ic versions are certified for use in
hazardous areas by the DEKRA Certification B.V. under the EU-Type Examination Certificate
DEKRA 11ATEX0166 X.
WARNING!
Carefully read the ATEX approval certificate. Obey the boundary conditions.

GENERAL SAFETY INFORMATION 1
5
OPTIWAVE 5200 C/F
www.krohne.com11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
1.4 Device categories
1.4.1 Ex ia-approved devices
The Ex ia-approved device is suitable for use in potentially explosive atmospheres of all
flammable substances in Gas Groups IIA, IIB and IIC. It is certified for applications requiring
Category 1/2 G (gases, vapours or mists) and EPL Ga/Gb equipment or 2 G and EPL Gb
equipment when fitted with the appropriate options.
The Ex ia-approved device is suitable for use in potentially explosive atmospheres of all
flammable substances in Dust Groups IIIA, IIIB and IIIC. It is certified for applications requiring
Category 1/2 D (dust) and EPL Da/Db equipment or 2 D and EPL Db equipment when fitted with
the appropriate options.
1.4.2 Ex db ia / Ex ia tb-approved devices
The Ex db ia-approved device is suitable for use in potentially explosive atmospheres of all
flammable substances in Gas Groups IIA, IIB and IIC. It is certified for applications requiring
Category 1/2 G (gases, vapours or mists) and EPL Ga/Gb equipment or 2 G and EPL Gb
equipment when fitted with the appropriate options.
The Ex ia tb-approved device is suitable for use in potentially explosive atmospheres of all
flammable substances in Dust Group IIIA, IIIB and IIIC. It is certified for applications requiring
Category 1/2 D (dust) and EPL Da/Db equipment or 2 D and EPL Db equipment when fitted with
the appropriate options.
1.4.3 Ex ic-approved devices
The Ex ic-approved device is suitable for use in potentially explosive atmospheres of all
flammable substances in Gas Groups IIA, IIB and IIC. It is certified for applications requiring
Category 3 G (gases, vapours or mists) and EPL Gc equipment when fitted with the appropriate
options.
The Ex ic-approved device is suitable for use in potentially explosive atmospheres of all
flammable substances in Dust Group IIIA, IIIB and IIIC. It is certified for applications requiring
Category 3 D (dust) and EPL Dc equipment when fitted with the appropriate options.

1 GENERAL SAFETY INFORMATION
6
OPTIWAVE 5200 C/F
www.krohne.com 11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
1.5 ATEX nameplates
Signal converter housing (compact and remote (field) versions)
Figure 1-1: Nameplate on the signal converter housing (compact and remote (field) versions)
1 ATEX certification number
2 Equipment approval category (explosive atmosphere –gas), types of device protection including approved Gas Groups
and temperature classes (T6...T4 or T3 or T2 –depends on the antenna type) and equipment protection level
Equipment category (explosive atmosphere –dust), types of device protection including approved Gas Groups, maxi-
mum surface temperature degree of ingress protection (if fitted with the appropriate cable glands) and equipment
protection level
3 4...20 mA passive
4...20 mA passive4...20 mA passive
4...20 mA passive –HART output option (Ex ia or Ex ic approvals):
HART output option (Ex ia or Ex ic approvals):HART output option (Ex ia or Ex ic approvals):
HART output option (Ex ia or Ex ic approvals): Intrinsically-safe circuit data
4...20 mA passive
4...20 mA passive4...20 mA passive
4...20 mA passive –HART output option (Ex db ia or Ex ia tb approvals):
HART output option (Ex db ia or Ex ia tb approvals):HART output option (Ex db ia or Ex ia tb approvals):
HART output option (Ex db ia or Ex ia tb approvals): Maximum voltage in accordance with
EN 60079-0. Refer to 6for the input voltage range.
Fieldbus (FF or PROFIBUS PA) options:
Fieldbus (FF or PROFIBUS PA) options:Fieldbus (FF or PROFIBUS PA) options:
Fieldbus (FF or PROFIBUS PA) options: Entity or FISCO power supply parameters
4 4...20 mA passive
4...20 mA passive4...20 mA passive
4...20 mA passive –HART output option (Ex db ia or Ex ia tb approvals):
HART output option (Ex db ia or Ex ia tb approvals):HART output option (Ex db ia or Ex ia tb approvals):
HART output option (Ex db ia or Ex ia tb approvals): Minimum waiting time after power-off before
it is safe to open the terminal compartment
5 Notified body number (production site)
6 Cable entry type and size (M20×1.5 or ½NPT)
7 Input voltage range and maximum current (4...20 mA passive –HART) / basic current (FF or PROFIBUS PA)
8 Type code –for more data, refer to "Order code" in the handbook

GENERAL SAFETY INFORMATION 1
7
OPTIWAVE 5200 C/F
www.krohne.com11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
Antenna housing (remote (field) version)
Figure 1-2: Nameplate on the antenna housing (remote (field) version)
1 ATEX certification number
2 Equipment approval category (explosive atmosphere –gas), types of device protection including approved Gas Groups,
temperature classes (T6...T4 or T3 or T2 –depends on the antenna type) and equipment protection level
Equipment category (explosive atmosphere –dust), types of device protection for explosive atmospheres with dust,
zones, maximum surface temperature, equipment protection level and degree of ingress protection (if fitted with the
appropriate cable glands)
3 Notified body number (production site)
4 Type code –for more data, refer to "Order code" in the handbook

2 INSTALLATION
8
OPTIWAVE 5200 C/F
www.krohne.com 11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
2.1 Precautions
2.1.1 General notes
WARNING!
When you install the device, obey the conditions in the EU-Type Examination certificate. These
conditions include:
• The special conditions for safe use.
• The Essential Health and Safety Requirements.
The certificate is given on the DVD-ROM supplied with the device. You can also download the
certificate from our internet site.
DANGER!
This installation must agree with EN 60079-14: Explosive atmospheres
– Part 14: Electrical
installations design, selection and erection.
DANGER!
Devices with the PTFE Wave Horn antenna option contain a PTFE boundary wall between the
process and the signal converter. Do not use the device in the process if the PTFE part is not
resistant to corrosion by the tank product.
Devices with the PP Wave Horn antenna option contain a PP boundary wall between the process
and the signal converter. Do not use the device in the process if the PP part is not resistant to
corrosion by the tank product.

INSTALLATION 2
9
OPTIWAVE 5200 C/F
www.krohne.com11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
2.1.2 Electrostatic discharge
Do not install in a location where the electrostatic charge can increase. This includes:
•locations near ventilation systems,
•locations where there is a risk of an increase in electrostatic charge caused by compressed
air and dust,
•locations near machines that use friction,
•locations near systems that apply electrons as a spray (e.g. near electrostatic painting
systems), and
•locations near other machines and systems that can have large electrostatic charges.
DANGER!
Risk of electrostatic discharge from the painted surfaces of the aluminium housing and the Wave
Horn and Wave-Stick antennas made of PP or PTFE.
DANGER!
Take the necessary antistatic precautions if:
• you handle the device in potentially explosive atmospheres,
• you install the device in potentially explosive atmospheres or
• you use the device in potentially explosive atmospheres.
Install the device correctly to prevent electrostatic discharge. Make sure that all equipment is
correctly grounded.
Make sure that the housing and adjacent objects do not rub together.
If dirt collects on the device, clean it with a damp cloth.
Figure 2-1: ESD warning sticker (below the device nameplate)
1 Text: Plastic Parts
2 Text: Warning! Potential electrostatic hazard –see instructions

2 INSTALLATION
10
OPTIWAVE 5200 C/F
www.krohne.com 11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
2.1.3 Optional purging system
The purging system is supplied as an option for devices that have Metallic Horn antennas with a
minimum flange size of DN150.
The pressure of the fluid put into in the purging system must not be more than 6 barg.
Connection and operation of the purging connection are the responsibility of the user. The
operator is also responsible for selection of a suitable fluid to purge the device.
If the tank is installed in Zone 0 or Zone 1, make sure that the purging fluid temperature is not
more than 80% of the ignition temperature of the tank contents. The purging fluid temperature
must be between the minimum and maximum limits for the gasket (for more data, refer to the
handbook) and the type of antenna (for more data, refer to
Ambient and flange temperature on
page 12).
If the tank is installed in Zone 2 or if there is no hazardous atmosphere, the purging fluid
temperature must be between the minimum and maximum limits for the gasket (for more data,
refer to the handbook) and the type of antenna (for more data, refer to
Ambient and flange
temperature
on page 12).
Figure 2-2: Optional purging system
1 G¼threaded connection for purging system (the plug is supplied by the manufacturer)
INFORMATION!
If delivered with the device, the purging connection is plugged with a G 1/4 screw and engaged on
a minimum of 5 threads.
WARNING!
If the G 1/4 screw is removed from the purging connection, make sure that the installation
agrees with the Ex requirements for the purging system.

INSTALLATION 2
11
OPTIWAVE 5200 C/F
www.krohne.com11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
2.1.4 Optional heating/cooling system
The heating/cooling system is supplied as an option for devices that have Metallic Horn antennas
with a minimum flange size of DN150.
The operating pressure of the heating/cooling system must not be more than 6 barg. The
process pressure must not be more than 2 barg.
If the tank is installed in Zone 0 or Zone 1, make sure that the temperature of the fluid in the
heating/cooling system is not more than 80% of the ignition temperature of the tank contents.
The temperature of the fluid in the the heating/cooling system must be between the minimum
and maximum limits for the gasket (for more data, refer to the handbook) and the type of
antenna (for more data, refer to
Ambient and flange temperature on page 12).
Figure 2-3: Optional heating/cooling system
1 G¼threaded connection for the heating/cooling system inlet (the plug is supplied by the manufacturer)
2 G¼threaded connection for the heating/cooling system outlet (the plug is supplied by the manufacturer)

2 INSTALLATION
12
OPTIWAVE 5200 C/F
www.krohne.com 11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
2.2 Operating conditions
The allowable ambient temperature and corresponding flange temperature range for the device
depends on the temperature classes marked on the nameplate.
2.2.1 Ambient and flange temperature
The ATEX equipment category, IEC equipment protection level and temperature class give the
ambient temperature and related flange temperature ranges for the device.
For more data, refer to "Pressure and temperature ranges" in the Installation chapter of the
handbook.
WARNING!
The gasket temperature must be in the approved limits. The minimum gasket temperature is:
The gasket temperature must be in the approved limits. The minimum gasket temperature is:The gasket temperature must be in the approved limits. The minimum gasket temperature is:
The gasket temperature must be in the approved limits. The minimum gasket temperature is:
Gasket material Antenna type Minimum process connection temperature
[°C] [°F]
PFA Metallic Horn
Wave-Guide
-60 -76
EPDM -50 -58
FKM/FPM -40 -40
Kalrez
®
6375 -20 -4
-PTFE Wave Horn -50 -58
-PP Wave Horn
Wave-Stick
-20 -4
Definitions
Figure 2-4: Definitions
1 Compact version: Signal converter, process connection and antenna
2 Remote (Field) version: remote converter
3 Remote (Field) version: antenna housing, process connection and antenna

INSTALLATION 2
13
OPTIWAVE 5200 C/F
www.krohne.com11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
The temperature data that follows is applicable to devices that have the 4...20 mA passive -
HART, PROFIBUS PA or FOUNDATION™fieldbus output options.
Compact versions
Equipment category 1/2 G or EPL Ga/Gb: Ex ia and Ex db ia devices
WARNING!
Compact version only: If the device is used in a potentially explosive atmosphere that contains
dust, do not install the device on the side of the tank.
If the device must operate at a high process temperature, make sure that the maximum flange
temperature and maximum ambient temperature are not more than the values given in the
table.
Temperature
class
Maximum ambient temperature Max. flange
temperature
PP Wave Horn PTFE Wave Horn
Wave-Stick
Metallic Horn
Wave-Guide
(standard
temperature)
Metallic Horn
Wave-Guide
(high-
temperature)
[°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F]
T6 +46 +115 +46 +115 +46 +115 +46 +115 +45 +113
T5 +41 +106 +42 +108 +41 +106 +44 +111 +55 +131
T4 +38 +100 +40 +104 +39 +102 +43 +109 +60 +140
Temperature
class
Minimum ambient temperature Min. flange
temperature
PP Wave Horn
Wave-Stick
PTFE Wave Horn Metallic Horn
Wave-Guide
(standard
temperature)
Metallic Horn
Wave-Guide
(high-
temperature)
[°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F]
T6...T2 -40 -40 -40 -40 -40 -40 -40 -40 -20 -4

2 INSTALLATION
14
OPTIWAVE 5200 C/F
www.krohne.com 11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
Compact version
Equipment category 2 G or EPL Gb: Ex ia and Ex db ia devices
Equipment category 3 G or EPL Gc: Ex ic devices
Temperature
class
Maximum ambient temperature Max. flange
temperature
PP Wave Horn PTFE Wave Horn
Wave-Stick
Metallic Horn
Wave-Guide
(standard
temperature)
Metallic Horn
Wave-Guide
(high-
temperature)
[°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F]
T6 +46 +115 +46 +115 +46 +115 +46 +115 +45 +113
+41 +106 +42 +108 +41 +106 +44 +111 +55 +131
+38 +100 +40 +104 +39 +102 +43 +109 +60 +140
T5 +53 +127 +55 +131 +54 +129 +58 +136 +75 +167
+40 +104 +44 +111 +43 +109 +54 +129 +100 +212
T4 +77 +171 +77 +171 +77 +171 +79 +174 +85 +185
+69 +156 +71 +160 +70 +158 +76 +169 +110 +230
- - +57 +135 +54 +129 +71 +160 +135 1 +275 1
T3 - - +50 +122 +48 +118 +68 +154 +150 1 +302 1
------+64 +147 +180 1 +356 1
------+61 +142 +200 1 +392 1
T2 ------+53 +127 +250 1 +482 1
1Make sure that gasket temperature is in the specified limits. For more data, refer to the handbook.
Temperature
class
Minimum ambient temperature Min. flange
temperature
PP Wave Horn
Wave-Stick
PTFE Wave Horn Metallic Horn
Wave-Guide
(standard
temperature)
Metallic Horn
Wave-Guide
(high-
temperature)
[°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F]
T6...T2 -40 -40 -40 -40 -40 -40 -40 -40 -40 1 -40 1
- - -36 -32 -35 -31 -37 -34 -50 1 -58 1
-------37 -34 -60 1 -76 1
1Make sure that gasket temperature is in the specified limits. For more data, refer to the handbook.

INSTALLATION 2
15
OPTIWAVE 5200 C/F
www.krohne.com11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
Remote (Field) versions (antenna housing only)
Equipment category 1/2 G or EPL Ga/Gb: Ex ia and Ex db ia devices
Temperature
class
Maximum ambient temperature Max. flange
temperature
PP Wave Horn PTFE Wave Horn
Wave-Stick
Metallic Horn
Wave-Guide
(standard
temperature)
Metallic Horn
Wave-Guide
(high-
temperature)
[°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F]
T6 +46 +115 +46 +115 +46 +115 +46 +115 +45 +113
T5 +41 +106 +41 +106 +41 +106 +44 +111 +55 +131
T4 +39 +102 +39 +102 +39 +102 +43 +109 +60 +140
Temperature
class
Minimum ambient temperature Min. flange
temperature
PP Wave Horn
Wave-Stick
PTFE Wave Horn Metallic Horn
Wave-Guide
(standard
temperature)
Metallic Horn
Wave-Guide
(high-
temperature)
[°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F]
T6...T2 -40 -40 -40 -40 -40 -40 -40 -40 -20 -4
INFORMATION!
Remote converter
Remote converterRemote converter
Remote converter
The maximum ambient temperature, T
a
, permitted depends on the temperature class:
• T
a
= +60 ° C for class T6
• T
a
= +70 ° C for class T5
• T
a
= +80 ° C for class T4

2 INSTALLATION
16
OPTIWAVE 5200 C/F
www.krohne.com 11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
Remote (Field) version (antenna housing only)
Equipment category 2 G or EPL Gb: Ex ia and Ex db ia devices
Equipment category 3 G or EPL Gc: Ex ic devices
Temperature
class
Maximum ambient temperature Max. flange
temperature
PP Wave Horn PTFE Wave Horn
Wave-Stick
Metallic Horn
Wave Guide
(standard
temperature)
Metallic Horn
Wave-Guide
(high-
temperature)
[°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F]
T6 +46 +115 +46 +115 +46 +115 +46 +115 +45 +113
+41 +106 +41 +106 +41 +106 +44 +111 +55 +131
+39 +102 +39 +102 +39 +102 +43 +109 +60 +140
T5 +54 +129 +54 +129 +54 +129 +59 +138 +75 +167
+43 +109 +43 +109 +41 +106 +55 +131 +100 +212
T4 +77 +171 +77 +171 +77 +171 +79 174 +85 +185
+70 +158 +71 +160 +70 +158 +77 +171 +110 +230
- - +55 +131 +53 +127 +72 +162 +135 1 +275 1
T3 - - +48 +118 +45 +113 +66 +151 +150 1 +302 1
------+63 +145 +180 1 +356 1
------+57 +135 +200 1 +392 1
T2 ------+53 +127 +250 1 +482 1
1Make sure that gasket temperature is in the specified limits. For more data, refer to the handbook.
Temperature
class
Minimum ambient temperature Min. flange
temperature
PP Wave Horn
Wave-Stick
PTFE Wave Horn Metallic Horn
Wave Guide
(standard
temperature)
Metallic Horn
Wave-Guide
(high-
temperature)
[°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F]
T6...T2 -40 -40 -40 -40 -40 -40 -40 -40 -40 1 -40 1
- - -36 -33 -35 -31 -39 -38 -50 1 -58 1
-------37 -34 -60 1 -76 1
1Make sure that gasket temperature is in the specified limits. For more data, refer to the handbook.
INFORMATION!
Remote converter
Remote converterRemote converter
Remote converter
The maximum ambient temperature, T
a
, permitted depends on the temperature class:
• T
a
= +60 ° C for class T6
• T
a
= +70 ° C for class T5
• T
a
= +80 ° C for class T4

INSTALLATION 2
17
OPTIWAVE 5200 C/F
www.krohne.com11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
Compact and Remote (Field) versions - PP and PFTE Wave Horn antennas
Equipment category 1/2 D, 2 D or EPL Da/Db, Db: Ex ia and Ex ia tb devices
Equipment category 3 D or EPL Dc: Ex ic devices
Flange
temperature
Ambient temperature
PP Wave Horn PTFE Wave Horn and Wave-Stick
Compact version Remote (Field)
version
Compact version Remote (Field)
version
[°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F]
+80 +176 +80 +176 +80 +176 +80 +176 +80 +176
+90 +194 +75 +167 +75 +167 +76 +169 +76 +169
+100 +212 +70 +158 +71 +160 +72 +162 +71 +160
+110 +230 - - - - +68 +154 +67 +153
+120 +248 - - - - +63 +145 +62 +144
+130 +266 - - - - +59 +138 +58 +136
+140 +284 - - - - +55 +131 +54 +129
+150 +302 - - - - +51 +124 +49 +120
+160 +320 --------
+170 +338 --------
+180 +356 --------
+190 +374 --------
+200 +392 --------
+210 +410 --------
+220 +428 --------
+230 +446 --------
+240 +464 --------
+250 +482 --------

2 INSTALLATION
18
OPTIWAVE 5200 C/F
www.krohne.com 11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
Compact and Remote (Field) versions - Metallic Horn and Wave Guide antennas
Equipment category 1/2 D, 2 D or EPL Da/Db, Db: Ex ia and Ex ia tb devices
Equipment category 3 D or EPL Dc: Ex ic devices
Flange
temperature
Ambient temperature
Metallic Horn
Wave Guide
(standard temperature)
Metallic Horn
Wave Guide
(high-temperature)
Compact version Remote (Field)
version
Compact version Remote (Field)
version
[°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F] [°C] [°F]
+80 +176 +80 +176 +80 +176 +80 +176 +80 +176
+90 +194 +75 +167 +75 +167 +78 +172 +79 +174
+100 +212 +71 +160 +70 +158 +77 +171 +77 +171
+110 +230 +66 +151 +65 +149 +75 +167 +76 +169
+120 +248 +62 +144 +60 +140 +74 +165 +75 +167
+130 +266 +57 +135 +55 +131 +72 +162 +73 +163
+140 +284 +53 +127 +51 +124 +71 +160 +72 +162
+150 +302 +48 +118 +46 +115 +69 +156 +71 +160
+160 +320 - - - - +67 +153 +69 +156
+170 +338 - - - - +66 +151 +68 +154
+180 +356 - - - - +64 +147 +67 +153
+190 +374 - - - - +63 +145 +65 +149
+200 +392 - - - - +61 +142 +64 +147
+210 +410 - - - - +60 +140 +63 +145
+220 +428 - - - - +58 +136 +61 +142
+230 +446 - - - - +56 +133 +60 +140
+240 +464 - - - - +55 +131 +59 +138
+250 +482 - - - - +53 +127 +57 +135

INSTALLATION 2
19
OPTIWAVE 5200 C/F
www.krohne.com11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
2.2.2 Maximum surface temperature of the housing for dust applications
For more data, refer to the table for Ex ia, Ex ia tb and Ex ic devices in the "Ambient and flange
temperature" section.
2.2.3 Process pressure
WARNING!
Equipmentcategory1/2D,2D,3DorEPLDa/Db,Db, Dc: Ex ia, Ex ia tb and Ex ic devices only
Equipmentcategory1/2D,2D,3DorEPLDa/Db,Db, Dc: Ex ia, Ex ia tb and Ex ic devices onlyEquipmentcategory1/2D,2D,3DorEPLDa/Db,Db, Dc: Ex ia, Ex ia tb and Ex ic devices only
Equipmentcategory1/2D,2D,3DorEPLDa/Db,Db, Dc: Ex ia, Ex ia tb and Ex ic devices only
If the ambient and flange temperatures of the device are not more than values given in the table
for Ex ia, Ex ia tb and Ex ic devices, the surface temperature of the housing (compact or remote
version) will not be more than +90
° C / +194 ° F. In these conditions, the maximum surface
temperature of other parts (process connection etc.) can be more than the maximum housing
surface temperature, but it will not be more than the process temperature.
Equipment category and
Equipment protection level (EPL)
Allowable process pressure
[kPa] [psi]
1/2 G or Ga/Gb 80…110 11.6…16
Others As per non-Ex device As per non-Ex device

3 ELECTRICAL CONNECTIONS
20
OPTIWAVE 5200 C/F
www.krohne.com 11/2016 - 4001905804 - AD ATEX OPTIWAVE 5200 R04 en
3.1 General notes
3.2 Terminal compartment
3.2.1 How to open the terminal compartment
WARNING!
• De-energize the circuit.
• Use the applicable cable glands for the cable entry openings in the housing (M20×1.5 or
½ NPT). For the cable entry size, refer to the device nameplate.
• If ambient temperature >65 ° C / >149 ° F, use heat-resistant cables, cable glands and cable
entry plugs certified for continuous operation above +80
° C / +176 ° F.
WARNING!
If dirt collects on the housing, clean the device with a damp cloth before you remove the terminal
compartment cover.
How to open the Ex i terminal compartment
Figure 3-1: How to open the Ex i terminal compartment
How to open the Ex d / Ex t terminal compartment
Figure 3-2: How to open the Ex d / Ex t terminal compartment
1 Cover stop
2 Terminal compartment cover
