KRUG+PRIESTER IDEAL AP60 PRO User manual

www.ideal.de
Luftreiniger

25
EN

26
Thank you for choosing a device from IDEAL.
• The device is used exclusively for cleaning the ambient air indoors.
• Please read these operating instructions before starting to use the device
and please follow the safety instructions.
The operating instructions must be kept available with the device at all times.
Read and save these instructions:
to persons associated with use of the appliance.
• Only use the device indoors.
• Only use a wall socket that supplies the correct voltage (see rating plate).
• Do not modify or repair the device.
• Do not use the device if the power cable or mains plug is damaged or if the
connection at the wall socket is not stable.
• Make sure that the power cable does not get crushed while you are using the
device and that it cannot be damaged in any other way. Place the cable so
that no one will trip over it. Do not place the power cable under strain.
• Disconnect the plug from the wall socket for cleaning purposes, before
time.
• Do not touch the plug or the device if you have wet hands.
• Keep packing material, such as plastic wrapping, away from children! (Risk
of suffocation)
• Place the device at least 10 cm away from the wall.
• Keep the device away from areas subjected to draft (wind).
• Make sure that furniture, fabrics or other objects do not come in contact with
the air intake/outlet or block them.
• Place the device on a stable, even surface and make sure there is
• Do not spray any insect repellent.
• Do not use in rooms where the device may come into contact with fuel va-
pour or metal dust.
• Do not use any volatile liquids, petroleum, kerosene, paint thinner or
polishing paste to clean the device. Such liquids may damage the surface of
the device.
• Do not expose the device to rain, water, moisture or high humidity, and do
not set it up in a bathroom or kitchen next to a sink.
• Make sure that no foreign objects get into the outlet grilles.
• The device is not suitable for removing harmful gases (carbon monoxide,
e.g. from heating appliances).
• The appliance is not to be used by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction.

27
• Children being supervised not to play with the appliance.
• Do not block the air intake and outlet.
technical parameters. Improper usage may pose a threat to life and health.
• Disconnect the mains plug prior to any cleaning or maintenance work.
• Do not use any solvents. These could damage the housing surface.
• Do not use any substances containing silicone, since this could destroy the
air quality sensor.
• Do not test the effectiveness of the air quality sensor with high quantities of
gas, or alcohol, since this could destroy the air quality sensor.
• Clean the textile cover with a vacuum cleaner.
• If necessary, the textile cover can also be washed by hand (please refer to
the care instructions on the label).
• WARNING: Chemical Burn Hazard. Keep batteries away from children.
• This product contains a lithium button/coin cell battery. If a new or used
lithium button/coin cell battery is swallowed or enters the body, it can cause
severe internal burns and can lead to death in as little as 2 hours. Always
completely secure the battery compartment. If the battery compartment does
not close securely, stop using the product, remove the batteries, and keep it
away from children. If you think batteries might have been swallowed or
placed inside any part of the body, seek immediate medical attention.
Risk of injury due to electric shock.
Always disconnect the mains plug prior to:
• Carrying out maintenance work or cleaning
• Moving the device
• Do not use any spray cans with flammable content near to the

28
• With self-adhesive
• With 3V lithium battery
•
needs to be replaced.
•
•
•
www.ideal.de
Luftreiniger

29
Take out the power cable ( ), operating
instructions ( ) and remote control ( with
Remove top packaging tray. Grasp the
lift it out of the box.
• The air intake ducts on the top can be used as handles
(see adjacent diagram).
• Place the device at least 10 cm away from the wall.
• Keep the device away from areas subjected to draft (wind).
• Make sure that furniture, fabrics or other objects do not come in contact with the air intake/
outlet or block them.
5.
6.
7.
8.
Please remove and dispose the self-adhesive
tape ( Transport safety).
The front panel is hooked from below at two
ends and is kept closed by totally 4 magnets.
)
and then swing it downwards ( ).
Remove the single piece of
cardboard ( Transport safety).
Remove the front panel ( ).

30
),
then pivot upwards and press shut ( ).
( ), then to the socket ( ).
Note:
Use the original packaging to store the air
protect the activated carbon.
the notches provided and lock in position by
turning clockwise ( ).
using the recessed grips provided and turn it
anti-clockwise ( ).
) and remove
).
7.
8.
9.
14.
13.
protective covers (motor protection grille,
ventilation outlet grille, door, etc.) fully and
securely attached is not permitted.
Safety information

31
Air outlet grill
Front panel Power cable
Filter cartridge
Control panel
Air intake ducts

32
A On/off button D Quiet button E Air quality indicator
F Filter replacement
indicator
Quiet indicator
K IR receiver
Timer indicator Fan speed indicator
J Daylight sensor L Air quality sensor
B Fan speed button C Timer button
The air quality sensor (L A) and after being
disconnected from the mains power supply. Once the air quality sensor has been calibrated, the
(F) and air quality indicators (E) flash red alternately.
M Dust sensor

33
• Press the on/off button (A
. In automatic mode, the fan speed ( ) automatically
adapts to the measured air quality. The worse the air quality, the higher the fan speed.
• Press the fan speed button (B
fan speed . Press again to increase the fan speed to .
Press again to increase the fan speed to , or to the turbofan speed .
maximum capacity. This can only be selected manually.
after the
A).
• Press the timer button (C) to activate the timer. Press repeatedly to increase the timer time:
(h) . Each number lights up in turn. Press the timer button again (no number
lights up) to disable the timer function.
• The timer indicator counts the respective time with ( Countdown). The remaining time is
displayed.
A On/off button D Quiet button E Air quality indicator
F Filter replacement
indicator
Quiet indicator
K IR receiver
Timer indicator Fan speed indicator
J Daylight sensor L Air quality sensor
B Fan speed button C Timer button

34
The Quiet button (D) is provided for particularly low-noise, unobtrusive operation
(e.g. bedrooms). Press the Quiet button (D) to switch the fan speed ( ) to its lowest capacity
and switch off all indicators. Only the Quiet indicator ( ) is dimly lit.
The air quality is displayed in 3 colours:
Green: good air quality
Yellow: average air quality
Red: poor air quality
An illuminated red "
The display brightness is automatically adjusted to the ambient light.
Receives the signals from the remote control.
A On/off button D Quiet button E Air quality indicator
F Filter replacement
indicator
Quiet indicator
K IR receiver
Timer indicator Fan speed indicator
J Daylight sensor L Air quality sensor
B Fan speed button C Timer button

35
• Always use 3V lithium batteries CR2025 for the remote control.
• Incorrect battery usage may result in leakage of battery fluid and/or damage.
• If the remote control is not going to be used for a long time, please remove the battery.
• Make sure that no objects or furnishings are situated between the remote control and the
• Locations where fluorescent tubes are flickering because they are defective or old.
• Do not store the remote control in direct sunlight and/or close to radiators/heaters.
•
The remote control has a pre-installed lithium
battery CR2025. to
activate the remote control battery.
K).

36
Batteries must NOT be disposed of with household waste. As the user, you are legally obligated
to return used batteries for proper disposal. You can hand in your batteries at public collection
points in your community or wherever the same type of batteries are sold.
• It is very important that you make sure that the polarity of the batteries is correct.
• Batteries that are leaking fluid are dangerous. Only touch these with suitable gloves.
• Keep batteries out of the reach of children.
period of time.
• The cells shall be disposed of properly, including keeping them away from children.
• Even used cells may cause injury.
• Open the battery compartment by pressing
(A) and pulling out (B) at the same time.
Take out the flat battery.
• Insert a new battery into the battery compart-
ment, making sure the polarity is correct (+ / -).
• Always use 3V lithium batteries CR2025.
• Slide the battery compartment back into its
seating (C).
The remote control comes with a self-
D). If required, this
can be stuck on the back of the remote
remote control can easily be attached to any
ferromagnetic surface
AC
B
D

37
Select the required fan speed .
.
P.
.
Select the required timer time .
Press the locking button
Press the locking button again to unlock.
pressing and holding down the on/off button (A) on the device.
Note:
When you operate the remote control, the air quality indicator (E) lights up for approx. 1 second
function is activated, the air quality indicator (E) lights up briefly in red.
P On/off button
N Fan speed buttons
O Automatic button
Q Quiet button
S Locking button
R Timer buttons
Turbo Auto 8h
4h
2h
1h
3
2
1
A On/off button E Air quality indicator

38
The front panel is hooked in at the bottom in two
places, and kept shut with 4 magnets. Open the
front panel from the top and hold ( ), pivot
downwards ( ) and take off ( ).
using the recessed grips provided and turn it
anti-clockwise ( ).
). Remove the
).
in the notches provided and lock in position by
turning clockwise ( ).
),
then pivot upwards and press shut ( ). Connect
), then to
the socket ( ).
F, see page 34)
1.
2.
3.
4.
5.
6.
7.
10.
11.
9.
8.

39
smartphone/tablet (iOS /Android).
Press and hold down the Quiet button (D) until the air quality indicator (E) flashes
The WLAN is enabled
when the air quality indicator (E) flashes blue
The WLAN is disabled
when the air quality indicator (E) flashes white.
Press and hold down the Quiet button (D), plug in the power cable and continue to hold down
the Quiet button (D) until the air quality indicator (E) flashes pink
The WLAN is reset to factory settings.
Note:
smartphone/tablet should be maintained during setup (connection setup).
D Quiet button E Air quality indicator

40
F, page 34) lights up.
• Clean the control panel with a dry, lint-free cloth.
• Clean the openings for the air quality sensor (L) and the dust sensor (M page 32) with a
vacuum cleaner.
cartridge (" " page 38).
• Do not use any solvents. These could damage the housing surface, the control panel and the
air quality sensor.
• Do not use any substances containing silicone, since this could destroy the air quality sensor.
• Do not test the effectiveness of the air quality sensor with high quantities of gas, or alcohol,
since this could destroy the air quality sensor.
You can source accessories via your dealer or at .
Wall mount Order no. 8741 001
Trolley Order no. 8741 002

41
Make sure that the power cable is not
damaged in any way.
Check both ends of the power cable. Make
sure that these are plugged in and that the
(page 30).
cartridge is inserted.
in place with all 3 tabs and is fully locked
(, page 30).
Disable the locking function on the remote
control ( , page 37).
Unplug the power cable and then plug it
back in.
Check the battery (3V lithium CR2025).
Clean the IR receiver with a dry, lint-free
cloth.
(page 35).
Having joined the power cord or
remote control is blocked for
about 10 seconds

42
on/off button (A, page 32).
Disable the Quiet function by pressing
the Quiet button (D, page 34).
Wait until the calibration process
(see , page 32) has been completed
(this may take a few minutes)
Clean the openings for the air quality
sensor L, dust sensor M (page 32), the air
intake ducts and the interior of the air
located) with a vacuum cleaner.
Calibrate the air quality sensor by briefly
disconnecting it from the mains again!
becomes saturated and reliable
of the odours.
fan speed (page 33).

43
Place the device on an even surface.
Use the fan speed button (B, page 33) to
set a lower fan speed ( , page 33).
Clean the relevant section on the control
panel (J, page 32)!
The display intensity automatically adapts
to its surroundings.
Contact: Service
•
•
Service
