KSB Comeo Series Installation instructions

Multistage Horizontal Centrifugal Pump
Comeo
Installation/Operating Manual

Legal information/Copyright
Installation/Operating Manual Comeo
Original operating manual
All rights reserved. The contents provided herein must neither be distributed, copied, reproduced,
edited or processed for any other purpose, nor otherwise transmitted, published or made available to a
third party without the manufacturer's express written consent.
Subject to technical modification without prior notice.
© KSB B.V., Alphen aan den Rijn, Nederland 15/05/2017

Contents
3 of 36
Comeo
Contents
Glossary .................................................................................................................................................. 5
1 General.................................................................................................................................................... 6
1.1 Principles ...........................................................................................................................................................6
1.2 Installation of partly completed machinery....................................................................................................6
1.3 Target group.....................................................................................................................................................6
1.4 Other applicable documents............................................................................................................................6
1.5 Symbols .............................................................................................................................................................6
2 Safety...................................................................................................................................................... 8
2.1 Key to safety symbols/markings.......................................................................................................................8
2.2 General..............................................................................................................................................................8
2.3 Intended use .....................................................................................................................................................8
2.4 Personnel qualification and training...............................................................................................................9
2.5 Consequences and risks caused by non-compliance with this manual .........................................................9
2.6 Safety awareness ..............................................................................................................................................9
2.7 Safety information for the operator/user.......................................................................................................9
2.8 Safety information for maintenance, inspection and installation ..............................................................10
2.9 Unauthorised modes of operation................................................................................................................10
3 Transport/Temporary Storage/Disposal............................................................................................. 11
3.1 Checking the condition upon delivery..........................................................................................................11
3.2 Transport.........................................................................................................................................................11
3.3 Storage/preservation......................................................................................................................................12
3.4 Disposal ...........................................................................................................................................................13
3.5 Return to supplier...........................................................................................................................................13
4 Description of the Pump (Set)............................................................................................................. 14
4.1 General description ........................................................................................................................................14
4.2 Designation.....................................................................................................................................................14
4.3 Name plate......................................................................................................................................................14
4.4 Design details..................................................................................................................................................14
4.5 Configuration and function...........................................................................................................................15
4.6 Noise characteristics .......................................................................................................................................16
4.7 Scope of supply...............................................................................................................................................16
4.8 Dimensions and weights ................................................................................................................................16
5 Installation at Site................................................................................................................................ 17
5.1 Safety regulations...........................................................................................................................................17
5.2 Checks to be carried out prior to installation...............................................................................................17
5.3 Installing the pump set ..................................................................................................................................17
5.4 Piping ..............................................................................................................................................................18
5.4.1 Connecting the piping.......................................................................................................................18
5.5 Fitting a bypass ..............................................................................................................................................19
5.6 Electrical system..............................................................................................................................................19
5.6.1 Information for planning the electrical connection ........................................................................19
5.6.2 Electrical connection..........................................................................................................................20
5.7 Checking the direction of rotation................................................................................................................21
6 Commissioning/Start-up/Shutdown................................................................................................... 23
6.1 Commissioning/Start-up.................................................................................................................................23
6.1.1 Prerequisites for commissioning/start-up .........................................................................................23
6.1.2 Priming and venting the pump.........................................................................................................23
6.1.3 Start-up...............................................................................................................................................25
6.2 Operating limits..............................................................................................................................................25
6.2.1 Minimum flow rate / maximum flow rate........................................................................................26
6.3 Shutdown/storage/preservation ....................................................................................................................26
6.3.1 Measures to be taken for shutdown ................................................................................................26

Contents
4 of 36 Comeo
6.4 Returning to service .......................................................................................................................................27
7 Servicing/Maintenance........................................................................................................................ 28
7.1 Safety regulations...........................................................................................................................................28
7.2 Servicing/inspection........................................................................................................................................28
7.3 Drainage/cleaning ..........................................................................................................................................28
7.4 Tightening torques.........................................................................................................................................29
8 Trouble-shooting.................................................................................................................................. 30
9 Related Documents.............................................................................................................................. 31
9.1 General assembly drawing with list of components ....................................................................................31
9.2 Wiring diagrams .............................................................................................................................................32
10 EU Declaration of Conformity............................................................................................................. 33
11 Certificate of Decontamination........................................................................................................... 34
Index ..................................................................................................................................................... 35

Glossary
5 of 36
Comeo
Glossary
Certificate of decontamination
A certificate of decontamination is enclosed by the
customer when returning the product to the
manufacturer to certify that the product has been
properly drained to eliminate any environmental
and health hazards arising from components in
contact with the fluid handled.
Close-coupled design
Motor directly fitted to the pump via a flange or a
drive lantern
Discharge line
The pipeline which is connected to the discharge
nozzle
IE3
Efficiency class to IEC60034-30: 3=Premium
Efficiency (IE = International Efficiency)
Noise characteristics
The noise characteristics are indicated as surface
sound pressure level in dB(A).
Pump
Machine without drive, additional components or
accessories
Pump set
Complete pump set consisting of pump, drive,
additional components and accessories
Suction lift line/suction head line
The pipeline which is connected to the suction
nozzle

1 General
6 of 36 Comeo
1 General
1.1 Principles
This operating manual is supplied as an integral part of the type series and variants
indicated on the front cover. The manual describes the proper and safe use of this
equipment in all phases of operation.
The name plate indicates the type series, the main operating data and the serial
number. The serial number uniquely describes the product and is used as
identification in all further business processes.
In the event of damage, immediately contact your nearest KSB service centre to
maintain the right to claim under warranty.
Observe the noise characteristics, indicated as surface sound pressure level.
(ðSection4.6,Page16)
1.2 Installation of partly completed machinery
To install partly completed machinery supplied by KSB refer to the sub-sections under
Servicing/Maintenance.
1.3 Target group
This operating manual is aimed at the target group of trained and qualified specialist
technical personnel. (ðSection2.4,Page9)
1.4 Other applicable documents
Table1: Overview of other applicable documents
Document Contents
Data sheet Description of the technical data of the pump (set)
General arrangement drawing/
outline drawing
Description of mating and installation dimensions
for the pump (set), weights
Drawing of auxiliary connections Description of auxiliary connections
Hydraulic characteristic curve Characteristic curves showing head, NPSH
required, efficiency and power input
General assembly drawing1) Sectional drawing of the pump
Sub-supplier product literature1) Operating manuals and other product literature
describing accessories and integrated machinery
components
Spare parts lists1) Description of spare parts
Piping layout1) Description of auxiliary piping
List of components1) Description of all pump components
Drawing for assembly1) Sectional drawing of the installed shaft seal
For accessories and/or integrated machinery components observe the relevant
manufacturer's product literature.
1.5 Symbols
Table2: Symbols used in this manual
Symbol Description
✓Conditions which need to be fulfilled before proceeding with the
step-by-step instructions
⊳Safety instructions
⇨Result of an action
⇨Cross-references
1) If agreed upon in scope of supply

1 General
7 of 36
Comeo
Symbol Description
1.
2.
Step-by-step instructions
Note
Recommendations and important information on how to handle
the product

2 Safety
8 of 36 Comeo
2 Safety
!DANGER
All the information contained in this section refers to hazardous situations.
2.1 Key to safety symbols/markings
Table3: Definition of safety symbols/markings
Symbol Description
!DANGER
DANGER
This signal word indicates a high-risk hazard which, if not avoided,
will result in death or serious injury.
!WARNING
WARNING
This signal word indicates a medium-risk hazard which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION
This signal word indicates a hazard which, if not avoided, could
result in damage to the machine and its functions.
General hazard
In conjunction with one of the signal words this symbol indicates a
hazard which will or could result in death or serious injury.
Electrical hazard
In conjunction with one of the signal words this symbol indicates a
hazard involving electrical voltage and identifies information about
protection against electrical voltage.
Machine damage
In conjunction with the signal word CAUTION this symbol indicates
a hazard for the machine and its functions.
2.2 General
This operating manual contains general installation, operating and maintenance
instructions that must be observed to ensure safe operation of the system and
prevent personal injury and damage to property.
The safety information in all sections of this manual must be complied with.
The operating manual must be read and understood by the responsible specialist
personnel/operators prior to installation and commissioning.
The contents of this operating manual must be available to the specialist personnel
at the site at all times.
Information attached directly to the product must always be complied with and kept
in a perfectly legible condition at all times. This applies to, for example:
▪Arrow indicating the direction of rotation
▪Markings for connections
▪Name plate
The operator is responsible for ensuring compliance with all local regulations not
taken into account in this operating manual.
2.3 Intended use
▪The pump (set) must only be operated within the operating limits described in
the other applicable documents. (ðSection1.4,Page6)
▪Only operate pumps/pump sets which are in perfect technical condition.
▪Do not operate the pump (set) in partially assembled condition.
▪Only use the pump to handle the fluids described in the data sheet or product
literature of the pump model or variant.
▪Never operate the pump without the fluid to be handled.
▪Observe the minimum flow rates indicated in the data sheet or product literature
(to prevent overheating, bearing damage, etc.).

2 Safety
9 of 36
Comeo
▪Observe the maximum flow rates indicated in the data sheet or product
literature (to prevent overheating, mechanical seal damage, cavitation damage,
bearing damage, etc.)
▪Do not throttle the flow rate on the suction side of the pump (to prevent
cavitation damage).
▪Consult the manufacturer about any use or mode of operation not described in
the data sheet or product literature.
Prevention of foreseeable misuse
▪Never open the discharge-side shut-off elements further than permitted.
–The maximum flow rates specified in the product literature or data sheet
would be exceeded.
–Risk of cavitation damage
▪Never exceed the permissible operating limits specified in the data sheet or
product literature regarding pressure, temperature, etc.
▪Observe all safety information and instructions in this manual.
2.4 Personnel qualification and training
All personnel involved must be fully qualified to transport, install, operate, maintain
and inspect the machinery this manual refers to.
The responsibilities, competence and supervision of all personnel involved in
transport, installation, operation, maintenance and inspection must be clearly
defined by the operator.
Deficits in knowledge must be rectified by means of training and instruction
provided by sufficiently trained specialist personnel. If required, the operator can
commission the manufacturer/supplier to train the personnel.
Training on the pump (set) must always be supervised by technical specialist
personnel.
2.5 Consequences and risks caused by non-compliance with this manual
▪Non-compliance with this operating manual will lead to forfeiture of warranty
cover and of any and all rights to claims for damages.
▪Non-compliance can, for example, have the following consequences:
–Hazards to persons due to electrical, thermal, mechanical and chemical
effects and explosions
–Failure of important product functions
–Failure of prescribed maintenance and servicing practices
–Hazard to the environment due to leakage of hazardous substances
2.6 Safety awareness
In addition to the safety information contained in this manual and the intended use,
the following safety regulations shall be complied with:
▪Accident prevention, health and safety regulations
▪Explosion protection regulations
▪Safety regulations for handling hazardous substances
▪Applicable standards, directives and laws
2.7 Safety information for the operator/user
▪The operator shall fit contact guards for hot, cold and moving parts and check
that the guards function properly.
▪Do not remove any contact guards during operation.
▪Provide the personnel with protective equipment and make sure it is used.

2 Safety
10 of 36 Comeo
▪Contain leakages (e.g. at the shaft seal) of hazardous fluids handled (e.g.
explosive, toxic, hot) so as to avoid any danger to persons and the environment.
Adhere to all relevant laws.
▪Eliminate all electrical hazards. (In this respect refer to the applicable national
safety regulations and/or regulations issued by the local energy supply
companies.)
▪If shutting down the pump does not increase potential risk, fit an emergency-
stop control device in the immediate vicinity of the pump (set) during pump set
installation.
2.8 Safety information for maintenance, inspection and installation
▪Modifications or alterations of the pump are only permitted with the
manufacturer's prior consent.
▪Use only original spare parts or parts authorised by the manufacturer. The use of
other parts can invalidate any liability of the manufacturer for resulting damage.
▪The operator ensures that maintenance, inspection and installation is performed
by authorised, qualified specialist personnel who are thoroughly familiar with
the manual.
▪Only carry out work on the pump (set) during standstill of the pump.
▪Only perform work on the pump set when it has been disconnected from the
power supply (de-energised).
▪The pump casing must have cooled down to ambient temperature.
▪Pump pressure must have been released and the pump must have been drained.
▪When taking the pump set out of service always adhere to the procedure
described in the manual. (ðSection6.3,Page26)
▪Decontaminate pumps which handle fluids posing a health hazard.
▪As soon as the work has been completed, re-install and re-activate any safety-
relevant devices and protective devices. Before returning the product to service,
observe all instructions on commissioning. (ðSection6.1,Page23)
2.9 Unauthorised modes of operation
Never operate the pump (set) outside the limits stated in the data sheet and in this
manual.
The warranty relating to the operating reliability and safety of the supplied pump
(set) is only valid if the equipment is used in accordance with its intended use.
(ðSection2.3,Page8)

3 Transport/Temporary Storage/Disposal
11 of 36
Comeo
3 Transport/Temporary Storage/Disposal
3.1 Checking the condition upon delivery
1. On transfer of goods, check each packaging unit for damage.
2. In the event of in-transit damage, assess the exact damage, document it and
notify KSB or the supplying dealer and the insurer about the damage in writing
immediately.
3.2 Transport
Transporting the pump set
DANGER
Improper transport
Danger to life from falling parts!
Damage to the pump set!
▷Use the attachment point provided for attaching the lifting accessory.
▷Never suspend the pump set by its power cable.
▷Use the lifting chain/rope included in the scope of supply exclusively for
lowering or lifting the pump set into/out of the pump sump.
▷Securely attach the lifting chain/rope to the pump and crane.
▷Use tested, marked and approved lifting accessories only.
▷Observe the regional transport regulations.
▷Observe the product literature supplied by the lifting accessory manufacturer.
▷The load-carrying capacity of the lifting accessory must be higher than the
weight indicated on the name plate of the pump set to be lifted. Take into
account any additional system components to be lifted.
WARNING
Improper lifting/moving of heavy assemblies or components
Personal injury and damage to property!
▷Use suitable transport devices, lifting equipment and lifting tackle to move
heavy assemblies or components.
To transport the pump/pump set suspend it from the lifting tackle as shown.

3 Transport/Temporary Storage/Disposal
12 of 36 Comeo
Fig.1: Transporting the pump set
3.3 Storage/preservation
If commissioning is to take place some time after delivery, we recommend that the
following measures be taken:
CAUTION
Damage during storage by humidity, dirt, or vermin
Corrosion/contamination of the pump (set)!
▷For outdoor storage cover the packed or unpacked pump (set) and accessories
with waterproof material.
▪Store the pump set in dry, vibration-free conditions and, if possible, in its original
packaging.
▪Fill some antifreeze (e.g. glycol) into the pump to protect it from frost/freezing.
▪Manually rotate the shaft once every three months as well as shortly before start-
up.
▪Spray the inside of the mechanical seal chamber with a preservative to prevent
seizure of the mechanical seal.
Table4: Ambient conditions for storage
Ambient condition Value
Relative humidity 5% to 80%2)
(non-condensing)
Ambient temperature -10°C to +40°C3)
2) At +20°C
3) Optional: -10°C to +55°C

3 Transport/Temporary Storage/Disposal
13 of 36
Comeo
3.4 Disposal
WARNING
Fluids handled, consumables and supplies which are hot and/or pose a health
hazard
Hazard to persons and the environment!
▷Collect and properly dispose of flushing fluid and any fluid residues.
▷Wear safety clothing and a protective mask if required.
▷Observe all legal regulations on the disposal of fluids posing a health hazard.
1. Dismantle the pump (set).
Collect greases and other lubricants during dismantling.
2. Separate and sort the pump materials, e.g. by:
- Metals
- Plastics
- Electronic waste
- Greases and other lubricants
3. Dispose of materials in accordance with local regulations or in another
controlled manner.
3.5 Return to supplier
1. Drain the pump as per operating instructions. (ðSection7.3,Page28)
2. Flush and clean the pump, particularly if it has been used for handling noxious,
explosive, hot or other hazardous fluids.
3. If the pump set has handled fluids whose residues could lead to corrosion
damage in the presence of atmospheric humidity or could ignite upon contact
with oxygen, the pump set must also be neutralised, and anhydrous inert gas
must be blown through the pump to ensure drying.
4. Always complete and enclose a certificate of decontamination when returning
the pump.
Indicate any safety measures and decontamination measures taken.
(ðSection11,Page34)
NOTE
If required, a blank certificate of decontamination can be downloaded from the
following web site: www.ksb.com/certificate_of_decontamination

4 Description of the Pump (Set)
14 of 36 Comeo
4 Description of the Pump (Set)
4.1 General description
▪Multistage horizontal centrifugal pump
Pump for handling clean or slightly aggressive aqueous fluids.
4.2 Designation
Example: Comeo C 2/2
Table5: Designation key
Code Description
Comeo Type series
C Material variant
C Pump casing made of cast stainless steel
G Pump casing made of cast iron
2 Size, flow rate [m³/h] at BEP
2, 4, 6
2 Number of stages4)
4.3 Name plate
Comeo C 4/6 B
1.1kW 50 Hz
KSB B.V.
QH 4.3 m³/h 40.4 m
Hmin 9.0 m
n fix. 2880rpm
SN 01/2017 1234657-123
Eff. 59.7%
Seal. code 32
ID 48239965
PO 700113778
P/T PN10 - 15/60°C
Kalkovenweg 13
Alphen aan den Rijn NL
www.ksb.com
5
6
7
8
12
13
3
4
1
2
9
10
11
14
Made in NL
EAC
Fig.2: Name plate (example) Comeo
1 Designation 2 Power required
3 Rated frequency 4 Flow rate5)
5 Head5) 6 Minimum head
7 Rated speed 8 Efficiency
9 Mechanical seal code 10 Maximum pressure
11 Permissible fluid temperature 12 KSB material number
13 Week/year of production, serial
number
14 KSB purchase order number
4.4 Design details
Design
▪Centrifugal pump
▪Multistage
▪Close-coupled design
▪Extended motor shaft
▪Maximum pressure class PN 10
4) Default: stages 2, 4 und 6; optional: intermediate stages 1, 3 and 5
5) At best efficiency point (Qopt)

4 Description of the Pump (Set)
15 of 36
Comeo
Installation
▪Horizontal installation
Drive
▪Single-phase AC motor or three-phase motor
▪To IEC60034-7
▪Efficiency class IE3 to IEC60034-30 (for three-phase motors ≥0.75kW)
▪Frequency 50/60 Hz
▪2 poles
▪Thermal class F
▪IP55 enclosure
▪Duty cycle: continuous duty S1
▪Thermal circuit breaker with automatic reset and start-up for single-phase AC
motor
Shaft seal
▪Mechanical seal
▪To EN12756
▪Uncooled
▪Maintenance-free
4.5 Configuration and function
1
2
3
45
6
Fig.3: Sectional drawing
1 Suction nozzle 2 Impeller
3 Pump shroud 4 Discharge nozzle
5 Screw plug for filling 6 Screw plug for draining
Design The horizontal multistage centrifugal pump is designed for handling clean or slightly
aggressive fluids containing water. The pump is easy to install, commission and
operate. The hydraulic assembly is driven by an electric motor. All hydraulic system
components of the pump are made of stainless steel. The pump casings are available
in stainless steel or cast iron.
The pump is suitable for transporting cold and warm water and boosting the
pressure thereof without any wear on the components within the specified operating
range. Fluids whose viscosity or density differ from water can also be transported. In
this case, a motor with adjusted rating might be required.
The pump is designed with openings for measuring, draining and venting. These
openings are closed with screw plugs. Connection (5) serves to fill and vent the pump
or measure the inlet pressure and suction pressure using a G1/4 connection.
Connection (6) serves to drain the pump or measure the discharge pressure using a
G1/4 connection.
Function The rotating impeller causes the pressure to drop at the impeller inlet. This pressure
drop makes the fluid enter the suction nozzle (1). Each stage (2) consists of an
impeller and a diffuser. The flow rate of the pump is determined by the free passage
of the stage. The pressure at the stage depends on the impeller diameter. Given the

4 Description of the Pump (Set)
16 of 36 Comeo
modular design system, the number of impellers can be selected to ideally match the
required duty point. After the fluid has left the last impeller, it is guided back
through the pump in the passage between the pump stages and the pump casing (3)
and leaves the pump at the discharge nozzle (4).
Sealing The pump is sealed by a standardised mechanical seal.
4.6 Noise characteristics
The noise characteristics given refer to the motor. See motor literature supplied.
4.7 Scope of supply
Depending on the model, the following items are included in the scope of supply:
▪Pump
▪Electric motor
4.8 Dimensions and weights
For dimensions and weights refer to the general arrangement drawing/outline
drawing or data sheet of the pump set.

5 Installation at Site
17 of 36
Comeo
5 Installation at Site
5.1 Safety regulations
DANGER
Installation in potentially explosive atmospheres
Explosion hazard!
▷Never install the pump in potentially explosive atmospheres.
▷Observe the information given in the data sheet and on the name plates of the
pump system.
WARNING
Pump with long-term preservation: Harmful preservatives in drinking water
systems
Danger of poisoning!
▷Flush the system prior to commissioning.
▷If necessary, dismantle the pump and thoroughly remove the preservative from
all wetted components.
▷Observe the data given in the order confirmation.
5.2 Checks to be carried out prior to installation
Place of installation
WARNING
Installation on mounting surface which is unsecured and cannot support the load
Personal injury and damage to property!
▷Use a concrete of compressive strength class C12/15 which meets the
requirements of exposure class XC1 to EN206-1.
▷The mounting surface must have set and must be completely horizontal and
even.
▷Observe the weights indicated.
1. Check the structural requirements.
All structural work required must have been prepared in accordance with the
dimensions stated in the outline drawing/general arrangement drawing.
5.3 Installing the pump set
CAUTION
Ingress of leakage into the motor
Damage to the pump!
▷Never install the pump set with the "motor below".
1. Install and fasten the pump set on a sturdy and level foundation in a dry, frost-
proof room.
2. Make sure that sufficient air can reach the fan opening of the motor.
(The clearance above the fan opening must measure at least 1/4 of the diameter
of the fan cover air intake.)
3. Place a spirit level on the discharge nozzle to align the pump set.

5 Installation at Site
18 of 36 Comeo
5.4 Piping
5.4.1 Connecting the piping
DANGER
Impermissible loads acting on the pump nozzles
Danger to life from leakage of hot, toxic, corrosive or flammable fluids!
▷Do not use the pump as an anchorage point for the piping.
▷Anchor the pipes in close proximity to the pump and connect them properly
without transmitting any stresses or strains.
▷Take appropriate measures to compensate for thermal expansion of the piping.
CAUTION
Incorrect earthing during welding work at the piping
Destruction of rolling element bearings (pitting effect)!
▷Never earth the electric welding equipment on the pump or baseplate.
▷Prevent current flowing through the rolling element bearings.
NOTE
Installing check and shut-off elements in the system is recommended, depending on
the type of plant and pump. However, such elements must not obstruct proper
drainage or hinder disassembly of the pump.
NOTE
VdS-certified pumps must be connected in compliance with current information
from VdS CEA 4001.
üThe suction lift line has been laid with a rising slope, the suction head line with a
downward slope towards the pump.
üA flow stabilisation section having a length equivalent to at least twice the
diameter of the suction flange has been provided upstream of the suction flange.
üThe nominal diameters of the pipelines are at least equal to the nominal
diameters of the pump nozzles.
As far as the nominal diameters in the suction and discharge line, and installation
of check valves and shut-off elements in a fire protection system are concerned,
observe the sizing specifications in the relevant directives.
üAdapters to larger nominal diameters are designed with a diffuser angle of
approx. 8° to avoid excessive pressure losses.
üThe pipelines have been anchored in close proximity to the pump and connected
without transmitting any stresses or strains.
1. Thoroughly clean, flush and blow through all vessels, pipelines and connections
(especially of new installations).
2. Before installing the pump in the piping, remove the flange covers on the
suction and discharge nozzles of the pump.
CAUTION
Welding beads, scale and other impurities in the piping
Damage to the pump!
▷Remove any impurities from the piping.
▷If necessary, install a filter.

5 Installation at Site
19 of 36
Comeo
3. If required, install a filter in the piping (see figure: Filter in the piping).
1
2
Fig.4: Filter in the piping
1 Differential pressure gauge 2 Filter
NOTE
Use a filter with laid-in wire mesh of 0.5 mm x 0.25 mm (mesh size x wire diameter)
made of corrosion-resistant material.
Use a filter with a filter area three times the cross-section of the piping.
Conical filters have proved suitable.
4. Connect the pump nozzles to the piping.
CAUTION
Aggressive flushing and pickling agents
Damage to the pump!
▷Match the cleaning operation mode and duration for flushing and pickling
service to the casing and seal materials used.
5.5 Fitting a bypass
NOTE
If the pump is operated against a closed valve, installing a bypass is recommended.
The bypass capacity must correspond to at least 10 % of the optimum volume flow
rate.
5.6 Electrical system
5.6.1 Information for planning the electrical connection
Rated current
The permissible rated current of the motor is shown on the motor name plate. It
indicates the operating range of the motor. The motor protection switch can be pre-
set to this value to protect the motor. By measuring the actual current of the pump
during operation the motor protection switch can be pre-set to a specific value for
protecting the pump/motor combination. This current value can also be used to select
appropriate electrical equipment such as drives with frequency inverter, master
switch, conductor diameter, etc.

5 Installation at Site
20 of 36 Comeo
5.6.2 Electrical connection
DANGER
Incorrect connection
Explosion hazard!
▷The connection point of the cable ends must be located outside hazardous
areas or in an area approved for electrical equipment.
DANGER
Operating a pump set that has not been fully connected
Explosion hazard!
Damage to the pump set!
▷Never start up a pump set with power cables that have not been fully
connected or non-operational monitoring devices.
DANGER
Connection of damaged power cables
Danger of death from electric shock!
▷Check the power cables for damage before connecting them.
▷Never connect damaged power cables.
▷Replace damaged power cables.
DANGER
Electrical connection work by unqualified personnel
Risk of fatal injury due to electric shock!
▷Always have the electrical connections installed by a trained and qualified
electrician.
▷Observe regulations IEC 60364 and, for explosion-proof models, .
WARNING
Incorrect connection to the mains
Damage to the mains network, short circuit!
▷Observe the technical specifications of the local energy supply companies.
CAUTION
Improper routing of power cable
Damage to the power cables!
▷Never move the power cables at temperatures below - 25 ℃.
▷Never kink or crush the power cables.
▷Never lift the pump set by the power cables.
▷Adjust the length of the power cables to the site requirements.
