KSB S 100D Installation instructions

Submersible Borehole Pumps
S 100D; UPA 100C
Installation/Operating
Manual
Mat. No.: 01463258

Legal information/Copyright
Installation/Operating Manual S 100D; UPA 100C
Original operating manual
KSB Aktiengesellschaft
All rights reserved. The contents provided herein must neither be distributed, copied, reproduced, edited or
processed for any other purpose, nor otherwise transmitted, published or made available to a third party without
KSB's express written consent.
Subject to technical modification without prior notice.
© KSB Aktiengesellschaft Frankenthal 19.02.2013

Contents
Glossary .................................................................................................5
1 General ..................................................................................................6
1.1 Principles ...........................................................................................................6
1.2 Installation of partly completed machinery .................................................... 6
1.3 Target group ..................................................................................................... 6
1.4 Other applicable documents ............................................................................ 6
1.5 Symbols .............................................................................................................6
2 Safety .....................................................................................................8
2.1 Key to safety symbols/markings ....................................................................... 8
2.2 General .............................................................................................................. 8
2.3 Intended use .....................................................................................................8
2.4 Personnel qualification and training ............................................................... 9
2.5 Consequences and risks caused by non-compliance with these operating
instructions ........................................................................................................ 9
2.6 Safety awareness ..............................................................................................9
2.7 Safety information for the operator/user ..................................................... 10
2.8 Safety information for maintenance, inspection and installation work ..... 10
2.9 Unauthorised modes of operation ................................................................10
3 Transport/Temporary Storage/Disposal .............................................11
3.1 Checking the condition upon delivery .......................................................... 11
3.2 Transportation ................................................................................................11
3.3 Storage and preservation ............................................................................... 11
3.4 Return to supplier ........................................................................................... 12
3.5 Disposal ...........................................................................................................12
4 Description of the Pump (Set) ............................................................14
4.1 General description ........................................................................................ 14
4.2 Product Information as per Regulation No. 547/2012 (for 4" and 6" Water
Pumps) Implementing "Ecodesign" Directive 2009/125/EC ......................... 14
4.3 Designation ..................................................................................................... 14
4.4 Name plate ...................................................................................................... 15
4.5 Design .............................................................................................................. 15
4.6 Design and function .......................................................................................16
4.7 Scope of supply ............................................................................................... 16
4.8 Dimensions and weights ................................................................................17
5 Installation at Site ...............................................................................18
5.1 Checks to be carried out prior to installation ............................................... 18
5.2 Installing the pump set in vertical position ..................................................21
5.3 Installing the pump set in horizontal position .............................................23
5.4 Notes on electrical connection .....................................................................24
Contents
S 100D; UPA 100C 3 of 42

5.5 Connection to power supply .......................................................................... 26
6 Commissioning/Start-up/Shutdown ...................................................28
6.1 Commissioning/start-up ................................................................................. 28
6.2 Operating limits .............................................................................................. 29
6.3 Shutdown ........................................................................................................ 32
7 Servicing/Maintenance .......................................................................33
7.1 Servicing/inspection ........................................................................................ 33
8 Trouble-shooting ................................................................................34
9 Related Documents ............................................................................35
9.1 S 100D general assembly drawing ................................................................. 35
9.2 UPA 100C general assembly drawing ........................................................... 36
9.3 General assembly drawing DN 100 ................................................................ 37
10 EC Declaration of Conformity ............................................................38
11 Certificate of Decontamination .........................................................39
Index ....................................................................................................40
Contents
4 of 42 S 100D; UPA 100C

Glossary
Certificate of decontamination
A certificate of decontamination is enclosed by
the customer when returning the product to
the manufacturer to certify that the product
has been properly drained to eliminate any
environmental and health hazards arising from
components in contact with the fluid handled.
Glossary
S 100D; UPA 100C 5 of 42

1 General
1.1 Principles
This manual is supplied as an integral part of the type series and variants indicated
on the front cover. It describes the proper and safe use of this equipment in all
phases of operation.
The name plate indicates the type series and size, the main operating data, the order
number and the order item number. The order number and order item number
uniquely identify the pump (set) and serve as identification for all further business
processes.
In the event of damage, contact your nearest KSB service centre immediately to
maintain the right to claim under warranty.
1.2 Installation of partly completed machinery
To install partly completed machinery supplied by KSB, refer to the sub-sections
under Servicing/Maintenance.
1.3 Target group
This manual is aimed at the target group of trained and qualified specialist technical
personnel.(⇨ Section 2.4 Page 9)
1.4 Other applicable documents
Table 1: Overview of other applicable documents
Document Contents
Data sheet Description of the technical data of the pump (set)
General arrangement drawing/
outline drawing
Description of mating and installation dimensions
for the pump (set), weights
Drawing of auxiliary connections Description of auxiliary connections
Hydraulic characteristic curve Characteristic curves showing head, NPSH
required, efficiency and power input
General assembly drawing1) Sectional drawing of the pump
Sub-supplier product literature1) Operating manuals and other product literature
describing accessories and integrated machinery
components
Spare parts lists1) Description of spare parts
Piping layout1) Description of auxiliary piping
List of components1) Description of all pump components
Drawing for assembly Sectional drawing for fitting the shaft seal
For accessories and/or integrated machinery components observe the relevant
manufacturer's product literature.
1.5 Symbols
Table 2: Symbols used in this manual
Symbol Description
✓Conditions which need to be fulfilled before proceeding with the
step-by-step instructions
⊳Safety instructions
⇨Result of an action
⇨Cross-references
1) If agreed to be included in the scope of supply
1 General
6 of 42 S 100D; UPA 100C

Symbol Description
1.
2.
Step-by-step instructions
Note
Recommendations and important information on how to handle
the product
1 General
S 100D; UPA 100C 7 of 42

2 Safety
All the information contained in this section refers to hazardous situations.
2.1 Key to safety symbols/markings
Table 3: Definition of safety symbols/markings
Symbol Description
!DANGER
DANGER
This signal word indicates a high-risk hazard which, if not avoided,
will result in death or serious injury.
!WARNING
WARNING
This signal word indicates a medium-risk hazard which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION
This signal word indicates a hazard which, if not avoided, could
result in damage to the machine and its functions.
Explosion protection
This symbol identifies information about avoiding explosions in
potentially explosive atmospheres in accordance with EC Directive
94/9/EC (ATEX).
General hazard
In conjunction with one of the signal words this symbol indicates a
hazard which will or could result in death or serious injury.
Electrical hazard
In conjunction with one of the signal words this symbol indicates a
hazard involving electrical voltage and identifies information about
protection against electrical voltage.
Machine damage
In conjunction with the signal word CAUTION this symbol indicates
a hazard for the machine and its functions.
2.2 General
This manual contains general installation, operating and maintenance instructions
that must be observed to ensure safe pump operation and prevent personal injury
and damage to property.
The safety information in all sections of this manual must be complied with.
This manual must be read and completely understood by the specialist personnel/
operators responsible prior to installation and commissioning.
The contents of this manual must be available to the specialist personnel at the site
at all times.
Information attached directly to the pump must always be complied with and be
kept in a perfectly legible condition at all times. This applies to, for example:
▪Arrow indicating the direction of rotation
▪Markings for connections
▪Name plate
The operator is responsible for ensuring compliance with all local regulations not
taken into account in this manual.
2.3 Intended use
The pump (set) must only be operated within the operating limits described in the
other applicable documents.(⇨ Section 1.4 Page 6)
▪Only operate pumps/pump sets which are in perfect technical condition.
▪Do not operate the pump (set) in partially assembled condition.
▪Only use the pump to handle the fluids described in the data sheet or product
literature of the pump model.
!DANGER
2 Safety
8 of 42 S 100D; UPA 100C

▪Never operate the pump without the fluid handled.
▪Observe the minimum flow rates indicated in the data sheet or product literature
(to prevent overheating, bearing damage, etc).
▪Observe the maximum flow rates indicated in the data sheet or product
literature (to prevent overheating, mechanical seal damage, cavitation damage,
bearing damage, etc).
▪Do not throttle the flow rate on the suction side of the pump (to prevent
cavitation damage).
▪Consult the manufacturer about any use or mode of operation not described in
the data sheet or product literature.
Prevention of foreseeable misuse
▪Never open discharge-side shut-off elements further than permitted.
–The maximum flow rate specified in the data sheet or product literature
would be exceeded.
– Risk of cavitation damage
▪Never exceed the permissible operating limits specified in the data sheet or
product literature regarding pressure, temperature, etc.
▪Observe all safety information and instructions in this manual.
2.4 Personnel qualification and training
All personnel involved must be fully qualified to transport, install, operate, maintain
and inspect the machinery this manual refers to.
The responsibilities, competence and supervision of all personnel involved in
transport, installation, operation, maintenance and inspection must be clearly
defined by the operator.
Deficits in knowledge must be rectified by means of training and instruction
provided by sufficiently trained specialist personnel. If required, the operator can
commission the manufacturer/supplier to train the personnel.
Training on the pump (set) must always be supervised by technical specialist
personnel.
2.5 Consequences and risks caused by non-compliance with these operating
instructions
▪Non-compliance with these operating instructions will lead to forfeiture of
warranty cover and of any and all rights to claims for damages.
▪Non-compliance can, for example, have the following consequences:
–Hazards to persons due to electrical, thermal, mechanical and chemical
effects and explosions
– Failure of important product functions
– Failure of prescribed maintenance and servicing practices
– Hazard to the environment due to leakage of hazardous substances
2.6 Safety awareness
In addition to the safety information contained in this manual and the intended use,
the following safety regulations shall be complied with:
▪Accident prevention, health and safety regulations
▪Explosion protection regulations
▪Safety regulations for handling hazardous substances
▪Applicable standards and laws
2 Safety
S 100D; UPA 100C 9 of 42

2.7 Safety information for the operator/user
▪The operator shall fit contact guards for hot, cold and moving parts and check
that the guards function properly.
▪Do not remove any contact guards during operation.
▪Provide the personnel with protective equipment and make sure it is used.
▪Contain leakages (e.g. at the shaft seal) of hazardous fluids handled (e.g.
explosive, toxic, hot) so as to avoid any danger to persons and the environment.
Adhere to all relevant laws.
▪Eliminate all electrical hazards. (In this respect refer to the applicable national
safety regulations and/or regulations issued by the local energy supply
companies.)
▪If shutting down the pump does not increase potential risk, fit an emergency-
stop control device in the immediate vicinity of the pump (set) during pump set
installation.
2.8 Safety information for maintenance, inspection and installation work
▪Modifications or alterations of the pump are only permitted with the
manufacturer's prior consent.
▪Use only original spare parts or parts authorised by the manufacturer. The use of
other parts can invalidate any liability of the manufacturer for resulting damage.
▪The operator ensures that all maintenance, inspection and installation work is
performed by authorised, qualified specialist personnel who are thoroughly
familiar with the manual.
▪Only carry out work on the pump (set) during standstill of the pump.
▪The pump casing must have cooled down to ambient temperature.
▪Pump pressure must have been released and the pump must have been drained.
▪When taking the pump set out of service always adhere to the procedure
described in the manual.
▪Decontaminate pumps which handle fluids posing a health hazard.
▪As soon as the work is completed, re-install and/or re-activate any safety-relevant
and protective devices. Before returning the product to service, observe all
instructions on commissioning.(⇨ Section 6.1 Page 28)
2.9 Unauthorised modes of operation
Never operate the pump (set) outside the limits stated in the data sheet and in this
manual.
The warranty relating to the operating reliability and safety of the supplied pump
(set) is only valid if the equipment is used in accordance with its intended use.(⇨
Section 2.3 Page 8)
2 Safety
10 of 42 S 100D; UPA 100C

3 Transport/Temporary Storage/Disposal
3.1 Checking the condition upon delivery
1. On transfer of goods, check each packaging unit for damage.
2. In the event of in-transit damage, assess the exact damage, document it and
notify KSB or the supplying dealer (as applicable) and the insurer about the
damage in writing immediately.
NOTE
The pump set is supplied by the manufacturer/supplier in packaging which largely
prevents sagging or other damage during transport and/or storage.
3.2 Transportation
CAUTION
Pump set tipping over or slipping out of the suspension arrangement
Personal injury and damage to property!
▷Always make sure pump sets in upright position cannot tip over.
NOTE
Take into account the unequal weight distribution between pump and motor.
Select hoisting tackles suitable for the weight of the pump set.
Take care not to bend or damage the power supply cable during transport.
3.3 Storage and preservation
If commissioning is to take place some time after delivery, we recommend that the
following measures be taken:
WARNING
Pump set tipping over or rolling off
Risk of personal injury!
▷Always secure vertically positioned pump sets against tipping over.
▷Always secure horizontally positioned pump sets against rolling off.
WARNING
Ambient temperature below the specified minimum
Danger of frost!
▷Never subject the pump set to ambient temperatures which are lower than
those permitted for the drinking water/antifreeze mixture provided (see section
on drinking water/antifreeze mixture / order documentation).
WARNING
Laying cables at temperatures below zero degrees
Damage to the cables!
▷Observe the minimum permissible temperature at the cable surface of -25 °C for
moving cables.
▷Observe the minimum permissible temperature at the cable surface of -40 °C for
stationary cables.
3 Transport/Temporary Storage/Disposal
S 100D; UPA 100C 11 of 42

CAUTION
Improper storage
Damage to the power cables!
▷Support the power cables at the cable entries to prevent permanent
deformation. Observe the minimum bending radius2) of the cables.
▷Only remove the protective caps from the power cables at the time of
installation.
Store the submersible borehole pumps as follows:
1. In its original packaging: horizontally
2. Without packaging: vertically (with the motor below)
3. In a dry environment
4. Protected against direct sunlight and heat
5. Protected against dirt and dust
6. Protected against freezing
7. Protected against vermin
Further information on storing the pump set after use .
3.4 Return to supplier
1. Drain the pump as per operating instructions.
2. Always flush and clean the pump, particularly if it has been used for handling
noxious, explosive, hot or other hazardous fluids.
3. If the fluids handled by the pump (set) leave residues which might lead to
corrosion when coming into contact with atmospheric humidity, or which might
ignite when coming into contact with oxygen, the pump set must be
neutralised, and anhydrous inert gas must be blown through the pump for
drying purposes.
4. Always complete and enclose a certificate of decontamination when returning
the pump (set).
Always indicate any safety and decontamination measures taken.
NOTE
If required, a blank certificate of decontamination can be downloaded from the
KSB web site at: www.ksb.com/certificate_of_decontamination
3.5 Disposal
WARNING
Fluids, consumables and supplies which are hot or pose a health hazard
Hazard to persons and the environment!
▷Collect and properly dispose of flushing fluid and any residues of the fluid
handled.
▷Wear safety clothing and a protective mask, if required.
▷Observe all legal regulations on the disposal of fluids posing a health hazard.
1. Dismantle the pump (set).
Collect greases and other lubricants during dismantling.
2) See cable manufacturer's documentation or DIN VDE 0298-3.
3 Transport/Temporary Storage/Disposal
12 of 42 S 100D; UPA 100C

2. Separate and sort the pump materials, e.g. by:
- Metals
- Plastics
- Electronic waste
- Greases and other lubricants
3. Dispose of materials in accordance with local regulations or in another
controlled manner.
3 Transport/Temporary Storage/Disposal
S 100D; UPA 100C 13 of 42

4 Description of the Pump (Set)
4.1 General description
Pump for handling clean or slightly contaminated water.
Verify the fluid composition against the data sheet.
Not approved for handling explosive fluids or for forming part of an explosion-proof
system!
4.2 Product Information as per Regulation No. 547/2012 (for 4" and 6"
Water Pumps) Implementing "Ecodesign" Directive 2009/125/EC
▪Minimum efficiency index: see name plate, key to name plate (⇨ Section 4.4 Page
15)
▪The benchmark for most efficient water pumps is MEI ≥ 0.70.
▪Year of construction: see name plate, key to name plate (⇨ Section 4.4 Page 15)
▪Manufacturer’s name or trade mark, commercial registration number and place
of manufacture: see data sheet or order documentation
▪Product’s type and size identificator: see name plate, key to name plate (⇨
Section 4.4 Page 15)
▪Hydraulic pump efficiency (%) with trimmed impeller: see data sheet
▪Pump performance curves, including efficiency characteristics: see documented
characteristic curve
▪The efficiency of a pump with a trimmed impeller is usually lower than that of a
pump with the full impeller diameter. Trimming of the impeller will adapt the
pump to a fixed duty point, leading to reduced energy consumption. The
minimum efficiency index (MEI) is based on the full impeller diameter.
▪The operation of this water pump with variable duty points may be more
efficient and economic when controlled, for example, by the use of a variable
speed drive that matches the pump duty to the system.
▪Information on dismantling, recycling and disposal after decommissioning: (⇨
Section 3.5 Page 12)
▪Information on benchmark efficiency or benchmark efficiency graph for MEI =
0.7 (0.4) for the pump based on the model shown in the Figure are available at:
http://www.europump.org/efficiencycharts
4.3 Designation
Submersible borehole pump
Example: S 100D - 4 / 6
Table 4: Key to the designation
Code Description
S Type series
100 Nominal pump size [mm]
D Design status
4 Flow rate at best efficiency point [m³/h]
6 Number of stages
Submersible borehole pump
Example: UPA 100C 4 - 6
Table 5: Key to the designation
Code Description
UPA Type series
100 Nominal pump size [mm]
C Design status
4 Description of the Pump (Set)
14 of 42 S 100D; UPA 100C

Code Description
4 Flow rate at best efficiency point [m³/h]
6 Number of stages
4.4 Name plate
Order No. 99720202635-000100-01
1
2
3
5
6
7
18
19
20
Pump UPA 100C - 2 / 8
Q
Q
Q
Motor
0.37 kW
400 V
Temp.
Min. flow velocity past the motor = 0.2 m/s
EN 60034-1 IP 68
Mat. No.: 01 000 854 ZN 3823 - D 88
0.16 M3/H
2.5 M3/H
1.69 M3/H
H
H
H
43.00 M
16.00 M
29.71 M
3~ DN 100 0.37
50 HZ
1.1 A 0.74 COS
20 °C max. 2870 rpm
8
9
13
14
11
22
21
23
24
MEI ≥ 0.4 η --.- % Mat. No. __________
2012
Weight 12 kg
10
12
4
15
16
17
Fig. 1: Name plate
1 Order number 2 Minimum efficiency index
3 Pump designation 4 Efficiency (see data sheet)
5 Minimum flow rate 6 Maximum flow rate
7 Flow rate at duty point 8 Motor designation
9 Rated power 10 Voltage
11 Frequency 12 Weight
13 Maximum fluid temperature 14 Minimum available flow along the
motor
15 Year of construction 16 Material number
17 Maximum head 18 Minimum head
19 Head at duty point 20 Power factor
21 Amperage 22 Speed
23 VDE Standard 24 Motor enclosure
4.5 Design
Design
▪Centrifugal pump
▪Submersible motor in squirrel-cage design
▪Rigid connection between pump and motor
▪Shroud design
Impeller type
▪Radial or mixed flow versions
Bearing in the motor
▪Thrust bearing with tilting pads to absorb the pump's hydraulic thrust
Shaft seal in the motor
▪Shaft seal
4 Description of the Pump (Set)
S 100D; UPA 100C 15 of 42

4.6 Design and function
1
2
3
4
5
6
7
5
Fig. 2: Sectional drawing of example: UPA 100C
Pump and motor are connected by a sleeve coupling. The stage casings are supported
by a pump shroud, by straps or stud bolts. A suction strainer protects the pump from
coarse particles in the fluid. The pipe is connected via a non-return valve or
connecting branch, with either internal thread or flanged ends.
The fluid flows along the motor and enters the suction casing (2) through the suction
strainer (1). It is accelerated outward by the suction impeller (3). In the flow passage
of the stage casing (4) the kinetic energy of the fluid is converted into pressure
energy, and the fluid is routed to the next impeller (5). This process is repeated in all
stages until the fluid has passed the last impeller (5). It is then guided through the
integrated non-return valve to the connection branch (7), where it leaves the pump.
The integrated non-return valve prevents uncontrolled backflow of the fluid.
4.7 Scope of supply
Depending on the model, the following items are included in the scope of supply:
▪Pump set with motor lead
Design
Function
4 Description of the Pump (Set)
16 of 42 S 100D; UPA 100C

▪Electric extension cable
optional: connected or supplied loosely
▪Back-up name plate
▪Accessories, such as:
–Cable connector
– Cable ties
– Cooling shroud
– Pedestals
– Electrical protection devices
– Automatic control units
NOTE
A separate name plate is included in KSB's scope of supply.
This name plate must be attached in a clearly visible position outside the place of
installation, e.g. at the control panel, pipeline or mounting bracket.
4.8 Dimensions and weights
For dimensions and weights please refer to the data sheet of the pump (set).
4 Description of the Pump (Set)
S 100D; UPA 100C 17 of 42

5 Installation at Site
5.1 Checks to be carried out prior to installation
5.1.1 Checking the motor fill
The pump set can be installed directly in vertical or horizontal 3) position without any
further preparations. The motors are filled at the factory with water and antifreeze
agent. The loss of a few drops of liquid fill will not impair the motor function as the
motor will self-prime with clean well water after it has been installed. If larger
quantities of leakage are suspected, contact the manufacturer!
5.1.2 Checking the installation position
WARNING
Impermissible installation position
Damage to the machine! Damage to the bearings!
▷For angled installation, always install the pump set with the discharge side at a
rising slope.
The pump set can be installed in vertical or, depending on the number of stages, also
in angled or horizontal position.
Never install the pump set with the pump positioned at the lowest point.
A
B
Fig. 3: Installation position
A Permissible B Impermissible
Notes on horizontal installation
Only install the pump set in horizontal position if the following criteria are met:
▪Has the pump set been ordered for horizontal installation?
▪Has a sufficiently dimensioned cooling jacket or shroud been provided?
Horizontal installation of pump sets which were originally designed for vertical
installation is impermissible!
Horizontal installation of pump sets without a cooling jacket is impermissible.
Horizontal installation is impermissible for pumps with the following number of
stages.
See order documentation.
Table 6: Number of stages which are impermissible for horizontal installation
S 100D 1 / .. 2 / .. 4 / .. 7 / .. 12 / ..
Number of
stages
25 27 24 23 17
30 30 33 28 21
3) Only if equipped with a cooling jacket
5 Installation at Site
18 of 42 S 100D; UPA 100C

S 100D 1 / .. 2 / .. 4 / .. 7 / .. 12 / ..
35 33 40 33 25
40 38 -- -- --
50 44 -- -- --
-- 50 -- -- --
5.1.3 Electric wiring
DANGER
Unqualified personnel connecting extension leads
Installation in a well - electric shock!
▷The extension lead must be connected by a professional electrician only.
▷The cable ends must be dry and clean.
DANGER
Earth conductor not properly connected
Danger of death from electric shock!
▷Never operate the motor without earth conductor.
▷The earth conductor must be connected by a professional electrician only.
NOTE
The motor lead is selected for submerged operation and must be completely
submerged, including the cable connector.
See order documentation for any other use!
Submersible motors are supplied fitted with a motor lead. The motor lead has been
extended with a suitably sized extension cable to meet the length required for the
specific installation. Unless otherwise indicated, the motor lead is designed for
submerged operation only. To meet this condition the cable connector also has to be
completely submerged.
Extension cables connected by KSB
If agreed with KSB, the extension cable can be supplied connected to the motor lead
with a watertight cable connector.
▪Unless otherwise specified in the order documentation, KSB's extension cables
are designed for:
–Being laid in free air
– A voltage drop along the cable of ᅀU ≦3 %
For any other ways of laying the cable, e.g. in cable ducts, etc. observe the
information on the maximum current-carrying capacity as per the applicable
directives.
Extension cables connected by the operator
If the supplied extension cable is to be connected at the site, observe the following
points:
1. Observe the installation instructions of the cable connector to be used.
2. If the operator is responsible for connecting an extension cable, make sure the
extension cable is selected and dimensioned for a maximum voltage drop of ≦3
%. The extension cable has to be approved for the applicable operating
conditions.
3. In 4-core cables the earth conductor is part of the power cable and must also be
connected in the cable connector when connecting an extension cable.
5 Installation at Site
S 100D; UPA 100C 19 of 42

4. 3-core motor leads do not include an earth conductor. A separate earth
conductor is connected on the outside of the motor. The earth conductor has to
be extended separately.
If no earth conductor is provided, the operator shall be responsible for earthing
the motor externally. (Core size corresponding to phase conductor, min. 4 mm2)
5. Connect the shield of shielded extension cables to the earth conductor. 3-core
motor leads as described in paragraph 4 must be earthed externally; connect the
shield of the extension cable to the earth conductor.
6. Transfer the core identification of the motor lead to the cores of the extension
cable. Make sure the colour codes match when connecting the cores.
The core codes depend on the wiring type of the motor:
Table 7: Core codes
Motors for DOL starting with 1 lead
U V W
.
Motors for start/delta starting with 2 leads
U 1 V 1 W 1 U 2 V 2 W 2
.
Motors for DOL starting with 2 parallel leads
U1 - 1 V1 - 1 W1 - 1 U1 - 2 V1 - 2 W1 - 2
5.1.4 Measuring the insulation resistance
DANGER
Hazardous voltage during and after measurement
Danger of death from electric shock!
▷Do not touch the contact points during and immediately after measurement.
▷Insulation resistance measurement must be effected by a trained electrician
only.
Measure the insulation resistance prior to installation and prior to connection to the
power supply.
Insulation resistance measurement must be effected by a trained electrician only.
Prior to the measurement, ensure compliance with the operating instructions of the
device for measuring the insulation resistance.
✓An insulation resistance measuring device with a measuring voltage of 1000 V DC
is available.
✓The contact points are clean and dry.
1. Measurement period: 1 minute4)
2. Minimum insulation resistance at 20 °C - 30 °C: > 200 MOhm
4) The measured value must be steady; a longer measurement period might be needed for larger cable cross-sections.
5 Installation at Site
20 of 42 S 100D; UPA 100C
