KStar K1005 User manual

READANDSAVETHISINSTRUCTIONS
FORDOMESTICCOOKING ONLY
Installer:Leavethismanual withthehomeowner.
Homeowner:Cleaning,MaintenanceandOperating
instructionsonthecomingpages.
RANGEHOODITEMNO.:K1005/K1005A
REFEREDMODELNO.:3505A
NUMBER: E312110

INTENDEDFORDOMESTICCOOKING ONLY
WARNING
TOREDUCETHERISKOFFIRE,ELECTRICSHOCK,ORINJURYTOPERSONS,OBSERVE
THEFOLLOWING:
1.Usethisunitonlyinthe mannerintendedbythe manufacturer.If you havequestions,contactthe
manufacturerat the address ortelephonenumberlisted inthe warranty.
2.Beforeservicingorcleaningunit, switchpoweroff atservicepaneland lock servicepanelto
preventpowerfrombeing switched on accidentally.When the servicedisconnectingmeans
cannotbelocked,securelyfasten aprominentwarningdevice,suchasatag,tothe service
panel.
3.Installation workand electricalwiringmustbedonebyaqualified person(s)inaccordancewith
all applicablecodesand standards, includingfire-rated constructioncodesandstandards.
4.Sufficientairisneeded forpropercombustion and exhaustingof gasesthroughthe flue (chimney)
offuelburningequipmenttopreventbackdrafting.Followthe heatingequipmentmanufacturer s
guidelinesandsafetystandardssuchasthosepublished bytheNationalFireProtection
Association (NFPA),andtheAmerican SocietyforHeating,Refrigeration and AirConditioning
Engineers(ASHRAE), and the localcodeauthorities.
5.When cuttingordrillingintowall orceiling,do notdamageelectricalwiringand otherhidden
utilities.
6.Ducted fansmust alwaysbevented tothe outdoors.
7.Donot usethisunit withanyseparatesolid-statespeed controldevice.
8.Toreducethe risk offire, useonlymetalductwork.
9.Thisunit must begrounded.
TO REDUCETHERISK OFARANGETOPGREASEFIRE:
A.Neverleavesurfaceunitsunattended athighsettings.Boiloverscausesmokingand greasy
spilloversthat mayignite. Heat oilsslowlyon lowormediumsettings.
B.Alwaysturnhood ONwhen cookingathighheatorwhen flambeingfood (i.e.CrepesSuzette,
CherriesJubilee, PeppercornBeefFlambe).
C. Clean ventilatingfansfrequently. Greaseshouldnot beallowed toaccumulateon fan orfilter.
D. Useproperpan size. Alwaysusecookwareappropriateforthe sizeofthe surfaceelement.
WARNING
TOREDUCETHERISKOFINJURYTOPERSONSINTHEEVENTOFARANGETOPGREASE
FIRE, OBSERVE THEFOLLOWING:*
1.SMOTHERFLAMES withaclose-fittinglid,cookiesheet, ormetaltray,thenturnoff the burner.
BE CAREFULTOPREVENTBURNS.If the flamesdo notgooutimmediately,EVACUATEAND
CALL THEFIREDEPARTMENT.
2.NEVERPICKUPAFLAMING PAN-Youmaybeburned.
3.DO NOTUSE WATER, includingwet dishclothsortowels-violent steamexplosion will result.
4.Usean extinguisherONLYif:
A.YouknowyouhaveaClass ABCextinguisherand you alreadyknowhowtooperateit.
B. The fireissmall and containedinthe areawhereit started.
C. The firedepartment isbeingcalled.
D. Youcanfight the firewithyourback toan exit.
*Based on “KitchenFireSafetyTips”published byNFPA.

CAUTION
1.Toreducerisk offireand toproperlyexhaustair,besuretoductairoutside.Donotventexhaust
airintospaceswithinwallsorceilingsorintoattics, crawlspaces, orgarages.
2.Takecarewhen usingcleaningagentsordetergents.
3.Avoidusingfood productsthatproduceflamesunderthe RangeHood.
4.Forgeneralventilatinguseonly.Donotusetoexhausthazardousorexplosivematerialsand
vapors.
5.Toavoidmotorbearingdamageand noisy and/orunbalancedimpellers,keepdrywall spray,
construction dust, etc.off powerunit.
6.Yourhood motorhasathermaloverload whichwillautomaticallyshutoff the motorifitbecomes
overheated.The motorwillrestartwhen itcoolsdown.Ifthe motorcontinuestoshutoff and
restart, havethe hoodserviced.
7.Forbestcaptureof cookingimpurities,the bottomofthe hood shouldbeaminimumof 24"and a
maximumof33"abovethe cookingsurface.
8.Twoinstallersarerecommended becauseofthelargesizeandweight ofthishood.
9.Thisproductisequipped withathermostatwhichmaystartblowerautomatically.Toreducethe
risk ofinjuryand topreventpowerfrombeingswitched on accidentally,switchpoweroffat
servicepaneland lock ortagservicepanel.
10.Usewithapproved cord-connection kit only.
11.Pleasereadspecification labelon product forfurtherinformation and requirements.

PREPARE THE HOOD
Unpack hood and check contents.
Youshouldreceive:
1-Hood
1-DecorativeFlue Assembly
1-PartsBagcontaining:
1- MountingBracket1-Installation Instructions
1-Vent1-WarrantyCard
1-Duct fixingsupport2-Safetyscrew(ST4mmx30mm)
1-Slideryduct fixingsupport
7-MountingScrews(4x40mm)
8-MountingScrews(4x8mm)
9-Drywall Anchors( 8holes)
2-Washer(4x12 x1mm)
1-AluminumFlexDuct
VENT
DUCTFIXINGSUPPORT
SLIDERYDUCTFIXING
SUPPORT
MOUNTING
SCREWS(4
X8MM)
MOUNTING
SCREWS(4X
40MM)
DRYWALL
ANCHORS
WASHER
ALUMINUMFLEX
DUCT
MOUNTING BRACKET
SAFETYSCREW(ST4MM
x30MM)
DECO
RATI
VE
FL
UE

WARNING
Note:Thisrangehood mustbeproperlygrounded. Theunitshouldbeinstalledbyaqualified
electricianinaccordance withall applicablenational and local electrical codes.
Theminimumhood distanceabovecooktopmust not beless than 24 . Amaximumof33”above
cooktopishighlyrecommended forbest captureofcookingimpurities. Distancesover33”areat the
installerand usersdiscretion.
INSTALL THE DUCTWORK
NOTE:To reduce therisk offire, useonlymetal ductwork.
1.Deside wherethe ductworkwillrun between the hoodand
the outside.
2.Astraight, short duct runwillallowthe hoodtoperformmost
efficiently.
3.Install the AluminumFlexduct on the vent towardshood
location.

INSTALL MOUNTINGBRACKETS
1. Aftereveluatingthe heightofthe hood,placethe hook
centeroverinstallation location. Drill 3holesof Ø8mm
on asuitableplacetofixthe mountingbrackets.
2. Putthe drywall anchorsintothe holesand fixthe
mountingscrews(4x50mm) intothe anchors,andinstall
the hookonthewall asshown.
INSTALL SLIDERYDUCT
FIXINGSUPPORT
1.CalculatethefinalheightoftheU-shaped section,drill
2holesof Ø8mmon asuitableplaceinline withthe
slideryduct fixingsupport.
2.Putthe drywall anchorsintothe holesand fixthe
mountingscrews(4x50mm) intothe anchors,and
install thehookonthewall asshown.(Theresttwo
paresof4x50mmscrewand drywall anchorsarefor
spare)

NONE-DUCTEDRECIRCULATIONFILTERINSTALLATION
1.Purchaseanon-ductedrecirculation filterfrom
yourdealer.
2.Install the filterbyrotatingitontothe equipment
whichisstandsontwosidesofthe motor.
PREPARE THE HOOD
Note:Onstainless steelhoods,carefullyremovethe
plasticprotectivefilmfromall exteriorsurfacesofthe
hood and decorativeflues, priortofinal installation.
3.Pick out thehood fromthe carton.
4.Install the ventintotheductconnectorofthe cooker
hood.
5.Fixthe extensivepipeontothe vent.

INSTALL THE HOOD
Note:atleasttwopeoplewill berequiredtomountthe
hood.
1.Raisethe hood intoitsmountingposition.
2.Alignthe rectangularopeningon the back ofthe hood with
the wall-mountingbracket. Gentlylowerthe hooduntil it
securelyengagesthe bracket.
3.Open the Al.filterand find the two 8mmholeson the
back ofthe hood.Levelthe hood with2mounting screws
(4*35mm) withwasher. Usedrywallanchorsprovided.
4.Measurethe heightofthe glass tothe slideryductfixing
support. Adjustthe heightofthe chimneyaccording tothe
height. Thenusethe ductfixingsupporwithtwoscrews
(4x8mm) tofixthe chimneys. Shownasinthepic.
5.Putthechimneyonthehood,usetwoscrews(4x8mm)tofix
the chimneytotheslideryduct fixingsupport.
6.Usetheothertwoscrews(4x8mm) tofixthe bottomof
chimney.
7.Afteradjustingthe position,open the filterand fixthe body
inside withsafetyscrews.
Note:Thetwosafetyventsarepositioned on theback casing,
withdiameterof6mm.
4x8mm

MAINTENANCE
PropermaintenanceoftheRangeHoodwill assure
properperformanceofthe unit.
Filters
The filtersmustbecleaned approximatelyonceevery30
hoursofoperation (when the centralsegmentonthe
displaygoeson orstartsblinking).
Useawarmdetergentsolution.Greasefiltersare
dishwashersafe.
Removefilterbypushingfiltertowardstheback ofhood
and rotatingfilterdownward.
Ductfree(Carbon)Filters
Theductfree filtersshouldbechanged every6months. Rotatethefilterstoremoveand replace.
Hood Cleaning
Stainless steelisone oftheeasiest materials
tokeepclean.Occasionalcarewill helppreserveitsfine appearance.
Cleaningtips:
lHot waterwithsoapordetergent isall that isusuallyneeded.
lFollowall cleaningbyrinsingwithclearwater.Wipe drywithaclean,softclothtoavoidwater
marks.
lFordiscolorationsordepositsthatpersist, useanon-scratchinghouseholdcleanserorstainless
steelpolishingpowderwithalittlewaterand asoft cloth.
lForstubborncases,useaplasticscouringpad orsoftbristlebrushtogetherwithcleaserand
water.Rublightlyindirection ofpolishinglinesor"grain"ofthe stainless finish.Avoidusingtoo
muchpressurewhichmaymarthe surface.
lDO NOTallowdepositstoremainforlongperiodsof time.
lDONOTuseordinarysteelwoolorsteelbrushes.Smallbitsofsteelmayadheretothesurface
causingrust.
lDONOTallowsaltsolutions,disinfectants,bleaches,orcleaningcompoundstoremainin
contactwithstainless steelforextended periods.Manyofthesecompoundscontainchemicals
whichmaybeharmful. Rinsewithwaterafterexposureand wipedrywithaclean cloth.
Painted surfacesshouldbecleaned withwarmwaterand milddetergent only.

OPERATION
Controls
Always trun thehoodONbeforecooking inordertoestablishanairflow inthekitchen.After
turing off therange, letthehood run forafewminutes tocleartheair.
lPushbutton
1. Pushstopbutton,and the motorwill stop.
2. Pushthe Lowbutton, thebuzzerwill buzz once, and themotorrunsat lowspeed.
3. Pushthe highbutton, the buzzerwillbuzz once, and themotorrunsat midspeed.
4. Pushthe Highbutton,the buzzerwill buzz once, and themotorrunsat highspeed.
5. Pushthe light buttonandthetwolightswillcomeon. Pushit againand the light will turnoff.
Low Mid High
Light
Stop
Low Mid High
Light
Stop
Low Mid High
Light
Stop

HALOGENBULBS
ALWAYS SWITCHOFF THEELECTRICITYSUPPLY
BEFORECARRYINGOUTANYOPERATIONSONTHE
APPLIANCE.
Tochangebulbs:
1.Rotatethe coverinanticlockwise,asshown.CAUTION:
BULBMAYBE HOT,PLEASE ROTATEWHENTHE
BULBISCOOL!
2.ReplacewithaTypeJC,12Volt, 20Watt Max,G-4Base
bulb.Donottouchreplacementbulbwithbarehands!If
the bulbistouched withthe barehand,itshouldbe
cleaned withalint-free clothmoistened withmethylated
spirit.
LEDLIGHTS
ALWAYS SWITCH OFFTHEELECTRICITYSUPPLYBEFORECARRYINGOUTANY
OPERATIONSONTHEAPPLIANCE.
Tochangethelight:
1.Open the filterand find the springofthe light, pushthe springand the lgightwill beslipout.
Changethe lightaswithsamekind of4Volt,3Watt LEDlight. CAUTION:LIGHTMAYBE
HOT,PLEASE ROTATEWHENTHELIGHTISCOOL!
WARRANTY
Wewillwarrantthisproductfree fromdefectsinmaterialand qualityforone yearand motorfor
5years.Ifanyproblemsoccurfromcorrectusage,pleasecontacttheservicedepartmentfor
underwarrantyservice.
Thiswarrantydoesnotcoverthe following:
Thefiltermeshand bulb.
Commercialuse.
Amendment ofthe dateofmanufactureon theratingplate.
Damaged caused tothebodybyusageofdetergentsprayer.
Pollution made tothe ledparts, glass partsand S/Sparts.
Incorrect installation, misuse, abuseorneglect.
Incorrectlyfitted toinsufficient orunsuitablepower.
Takenapartorserviced byunauthorized serviceengineersorreplaced withothermanufactures
components.
Forcommercialusethe maintenanceand free serviceshouldbediscussedwithourauthorized
agent.
Beyond the 12monthlimited warrantyperiod,the purchasershouldpayforchargeof
componentsandcall out.
Intheevent ofaservicecall, pleaseprovide the warrantycardand receipt ofdateofpurchase.
