KStar K1012 User manual

READ AND SAVE THIS INSTRUCTIONS
FOR DOMESTIC COOKING ONLY
Installer: Leave this manual with the homeowner.
Homeowner: Cleaning, Maintenance and Operating
instructions on the coming pages.
RANGE HOOD ITEM NO.: K1012/K1012A
REFERED MODEL NO.: 3503A/3503D
NUMBER: E312110

INTENDED FOR DOMESTIC COOKING ONLY
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE
THE FOLLOWING:
1. Use this unit only in the manner intended by the manufacturer. If you have questions, contact the
manufacturer at the address or telephone number listed in the warranty.
2. Before servicing or cleaning unit, switch power off at service panel and lock service panel to
prevent power from being switched on accidentally. When the service disconnecting means
cannot be locked, securely fasten a prominent warning device, such as a tag, to the service
panel.
3. Installation work and electrical wiring must be done by a qualified person(s) in accordance with
all applicable codes and standards, including fire-rated construction codes and standards.
4. Sufficient air is needed for proper combustion and exhausting of gases through the flue (chimney)
of fuel burning equipment to prevent backdrafting. Follow the heating equipment manufacturer’s
guidelines and safety standards such as those published by the National Fire Protection
Association (NFPA), and the American Society for Heating, Refrigeration and Air Conditioning
Engineers (ASHRAE), and the local code authorities.
5. When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden
utilities.
6. Ducted fans must always be vented to the outdoors.
7. Do not use this unit with any separate solid-state speed control device.
8. To reduce the risk of fire, use only metal ductwork.
9. This unit must be grounded.
TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:
A. Never leave surface units unattended at high settings. Boilovers cause smoking and greasy
spillovers that may ignite. Heat oils slowly on low or medium settings.
B. Always turn hood ON when cooking at high heat or when flambeing food (i.e. Crepes Suzette,
Cherries Jubilee, Peppercorn Beef Flambe’).
C. Clean ventilating fans frequently. Grease should not be allowed to accumulate on fan or filter.
D. Use proper pan size. Always use cookware appropriate for the size of the surface element.
WARNING
TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A RANGE TOP GREASE
FIRE, OBSERVE THE FOLLOWING:*
1. SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal tray, then turn off the burner.
BE CAREFUL TO PREVENT BURNS. If the flames do not go out immediately, EVACUATE AND
CALL THE FIRE DEPARTMENT.
2. NEVER PICK UP A FLAMING PAN - You may be burned.
3. DO NOT USE WATER, including wet dishcloths or towels - violent steam explosion will result.
4. Use an extinguisher ONLY if:
A.You know you have a Class ABC extinguisher and you already know how to operate it.
B. The fire is small and contained in the area where it started.
C. The fire department is being called.
D. You can fight the fire with your back to an exit.
* Based on “Kitchen Fire Safety Tips” published by NFPA.

CAUTION
1. To reduce risk of fire and to properly exhaust air, be sure to duct air outside. Do not vent exhaust
air into spaces within walls or ceilings or into attics, crawl spaces, or garages.
2. Take care when using cleaning agents or detergents.
3. Avoid using food products that produce flames under the Range Hood.
4. For general ventilating use only. Do not use to exhaust hazardous or explosive materials and
vapors.
5. To avoid motor bearing damage and noisy and/or unbalanced impellers, keep drywall spray,
construction dust, etc. off power unit.
6. Your hood motor has a thermal overload which will automatically shut off the motor if it becomes
overheated. The motor will restart when it cools down. If the motor continues to shut off and
restart, have the hood serviced.
7. For best capture of cooking impurities, the bottom of the hood should be a minimum of 24" and a
maximum of 33" above the cooking surface.
8. Two installers are recommended because of the large size and weight of this hood.
9. This product is equipped with a thermostat which may start blower automatically. To reduce the
risk of injury and to prevent power from being switched on accidentally, switch power off at
service panel and lock or tag service panel.
10. Use with approved cord-connection kit only.
11. Please read specification label on product for further information and requirements.

PREPARETHEHOOD
Unpack hood and check contents.
You should receive:
1 - Hood
1 - Decorative Flue Assembly
1 - Parts Bag containing:
1 - Mounting Bracket 1-InstallationInstructions
1-Vent 1-WarrantyCard
1 - Duct fixing support 2 - Safety screws (ST4mm x30mm)
1 - Slidery duct fixing support
7 - Mounting Screws (4 x 50mm)
10 - Mounting Screws (4 x 8mm)
9 - Drywall Anchors (2 for φ8 holes)
2 - Mounting Screws (4 x 35mm for φ8 holes)
2 - Washer (for φ8 holes)
1 - Aluminum Flex Duct
DUCT FIXING SUPPORT
SLIDERY DUCT FIXING SUPPORT
SAFETY SCREW (ST4MM x30MM)
VENT
MOUNTING
SCREWS (4
X 8MM)
MOUNTING
SCREWS (4
X 35MM)
MOUNTING
SCREWS (4 X
50MM)
ANCHORS
WASHER
DRYWALL
ALUMINUM FLEX
DUCT
MOUNTING BRACKET

WARNING
STALL THE DUCTWORK
ote: This range hood must be properlyN
grounded. The unit should be installed by a
qualified electrician in accordance with all
applicable national and local electrical codes.
The minimum hood distance above cooktop must not
be less than 24’’. A maximum of 33” above cooktop is
highly recommended for best capture of cooking
uimp rities. Distances over 33” are at the installer and
users discretion.
IN
OTE: To reduce the risk of fire, use only metal
uctwork.
Deside where the ductwork will run between the
hood and the outside.
A straight, short duct run will allow the hood to
perform most efficiently.
Install the Aluminum Flex duct on the vent
towards hood location.
N
d
1.
2.
3.

INSTALL MOUNTING
BRACKETS
After eveluating the height of the hood,
place the hook center over installation
location. Drill 3 holes of Ø8mm on a
suitable place to fix the mounting
brackets.
Put the drywall anchors into the holes
and fix the mounting screws (4x50mm)
into the anchors, and install the hook
on the wall as shown.
IDERY DUCT
1.
2.
INSTALL SL
IXING SUPPORTF
. Calculate the final height of the
U-shaped section, drill 2 holes of Ø8mm
on a suitable place in line with the
slidery duct fixing support.
. Put the drywall anchors into the holes
and fix the mounting screws (4x50mm)
into the anchors, and install the hook on
the wall as shown. (The rest two pares
of 4x50mm screw and drywall anchors
are for spare)
1
2

NONE-DUCTED
RECIRCULATION FILTER
INSTALLATION
Purchase a non-ducted recirculation
filter from your dealer.
Install the filter by rotating it onto the
two
1.
2. equipment which is stands on
sides of the motor.
REP PARE THE HOOD Screw: 4x8mm
Note: On stainless steel hoods,
y remove the plastic
otective film from all exterior
rfaces of the hood and decorative
es, prior to final installation.
Pick out the hood from the carton.
Install the vent into the duct
connector of the cooker hood.
Fix the extensive pipe onto the vent.
carefull
pr
su
flu
3.
4.
5.

INSTALL THE HOOD
opening on the back of the hood
with the wall-mounting bracket. Gently lower the hood
until it securely engages the bracket.
Open the Al. filter and find the two φ8 mm holes
on the back of the hood. Level the hood with 2
mounting screws (4*35mm) with washer. Use drywall
anchors provided.
Measure the height of the glass to the slidery duct
fixing support. Adjust the height of the chimney
eys.
Shown as in the pic.
imney on the hood, use two screws(4x8mm)to
fix the chimney to the slidery duct fixing support.
Use the other two screws (4x8mm) to fix the bottom of
chimney.
After adjusting the position, open the filter and fix the
with safety screws.
ote: The two safety vents are positioned on the back
diameter of 6mm.
Note: at least two people will be required to mount
the hood.
1. Raise the hood into its mounting position.
2. Align the rectangular
3.
4.
according to the height. Then use the duct fixing
suppor with two screws (4x8mm) to fix the chimn
4x8mm
5. Put the ch
Screw
6.
7.
body inside
N
casing, with

MAINTENANCE
oper maintenance of the Range Hood will
sure proper performance of the unit.
nce
display goes on or starts blinking).
se a warm detergent solution. Grease filters are
leaning tips:
Hot water with soap or detergent is all that is usually needed.
Follow all cleaning by rinsing with clear water. Wipe dry with a clean, soft cloth to avoid water
marks.
For discolorations or deposits that persist, use a non-scratching household cleanser or stainless
steel polishing powder with a little water and a soft cloth.
For stubborn cases, use a plastic scouring pad or soft bristle brush together with cleaser and
water. Rub lightly in direction of polishing lines or "grain" of the stainless finish. Avoid using too
much pressure which may mar the surface.
DO NOT allow deposits to remain for long periods of time.
DO NOT use ordinary steel wool or steel brushes. Small bits of steel may adhere to the surface
causing rust.
DO NOT allow salt solutions, disinfectants, bleaches, or cleaning compounds to remain in
contact with stainless steel for extended periods. Many of these compounds contain chemicals
which may be harmful. Rinse with water after exposure and wipe dry with a clean cloth.
inted surfaces should be cleaned with warm water and mild detergent only.
Pr
as
Filters
The filters must be cleaned approximately o
every 30 hours of operation (when the central
segment on the
U
dishwasher safe.
Remove filter by pushing filter towards the back of
od and rotho ating filter downward.
Ductfree(Carbon) Filters
The ductfree filters should be changed every 6
months. Rotate the filters to remove and replace.
Hood Cleaning
Stainless steel is one of the easiest materials
to keep clean. Occasional care will help preserve its fine appearance.
C







Pa

OPERATION
Controls
Always trun the hood ON before cooking in order to establish an air flow in the kitchen. After
button)
turing off the range, let the hood run for a few minutes to clear the air.
tronic Button(Brighting words button and blElec ue ring
1. Power: When power-on ,the output is off ,and the machine is standby.
2. “light”key Press the key once,the lamp is lit.Once more,the lamp put out,and this operation is
culation.a cir
3. T
he Add key ,also the switch that control power-on .The motor has three speed : low﹑
medium﹑high.
1) Press the key once,the motor start working,with its low speed(that the switch control the
power-on,and the speed indicator is lit.
2) At the low speed,Press the key again to shift up to medium speed.Then the position
indicator is lit.
3) Press the key when the motor at its medium speed.It will be shift up to high speed.Then
the position indicator is lit,the position indicator is put out.
4) when the motor at its high speed,prss the key again,the motor will work at its normal
condition.Of course,working at its high speed.
. The Dec key4 ,also the switch that control the power-off.
1) Press the key once ,the motor will shift down one level,Continully press the Dec key till
the machine at no speed,then the switch control power-off.(the motor stop working),the
speed indicator is put out.
. The Timer key :51) The timer key is used for timing setting,when the motor or lamps are working.10min
delay,the motor will be off work.

HALOGEN BULBS
ALWAYS SWITCH OFF THE ELECTRICITY
EFORE CARRYING OUT ANY
tt Max,
o not touch replacement
EDLIGHTS
SUPPLY B
O
PERATIONS ON THE APPLIANCE.
To change bulbs:
1. Rotate the cover in anticlockwise, as shown.
CAUTION: BULB MAY BE HOT,PLEASE
ROTATE WHEN THE BULB IS COOL!
2. Replace with a Type JC, 12Volt, 20Wa
G-4 Base bulb. D
bulb with bare hands! If the bulb is touched
with the bare hand, it should be cleaned with
a lint-free cloth moistened with methylated
spirit.
L
PPLY BEFORE CARRYING OUT ANY
CE.
change the light:
O
us
h e kind of 4Volt,3
a E
O EN THELIGHT IS
O
ALWAYS SWITCH OFF THE ELECTRICITY
SU
OPERATIONS ON THE APPLIAN
To
1. pen the filter and find the spring of the light,
h the spring and the lgight will be slip out.
ange the light as with sam
p
C
W tt LED light. CAUTION: LIGHT MAY B
H T,PLEASE ROTATE WH
C OL!
WARRANTY
We will warrant this product free from defects in material and quality for one year and motor for
5 years. If any problems o
ccur from correct usage, please contact the service department for
This warranty does not cover the following:
The filter mesh and bulb.
Commercial use.
Amendment of the date of manufacture on the rating plate.
Damaged caused to the body by usage of detergent sprayer.
Pollution made to the led parts, glass parts and S/S parts.
Incorrect installation, misuse, abuse or neglect.
Incorrectly fitted to insufficient or unsuitable power.
Taken apart or serviced by unauthorized service engineers or replaced with other manufacture’s
components.
For commercial use the maintenance and free service should be discussed with our authorized
agent.
Beyond the 12 month limited warranty period, the purchaser should pay for charge of
components and call out.
In the event of a service call, please provide the warranty card and receipt of date of purchase.
under warranty service.

K-Star International Group Inc.
K-Star Electronic Appliance Inc.
Toll Free:[phone]
Email:[email protected]
http://www.kstarus.com
