KT&C KPC-LDD45NU User manual

HIGH PERFORMANCE
WDR DOME CAMERA
OPERATION MANUAL
Thank you for choosing our high quality camera.
Before attempting to connect or operate this unit, please read and follow these instructions.
M176-LD(N)D45-001

These servicing instructions are for use by qualied service personnel only.
To reduce the risk of electric shock, do not perform any servicing other than
that contained in the operating instructions unless you are qualied to do so.
Use Class 2 Power Supply Only
CAUTION
2
CONTENTS
1. CAUTIONS
2. IMPORTANT SAFETY INSTRUCTIONS
3. EQUIPMENT AND ACCESSORIES
4. CAMERA COMPONENT DESCRIPTIONS
5. INSTALLATION
6. DIMENSIONS
7. SPECIFICATIONS
8. OSD MANUAL
• Menu Structure
• Function Description

1. CAUTIONS
3
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
Note
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
WARNING
This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
Caution
Any changes or modications in construction of this devices which are not expressly
approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
1. A regulated DC12V 500mA power supply is recommended for use with
this camera for the best picture and the most stable operation.
An unregulated power supply can cause damage to the camera.
When an unregulated power supply is applied, the product warranty will
be void.
2. It is recommended that the camera be used with a monitor that has a CCTV
quality 75 video impedance level. If your monitor is switched to high impedance
then please adjust accordingly.
3. Do not attempt to disassemble the camera to gain access to the internal
components. Refer servicing to your dealer.
4. Never face the camera towards the sun or any bright or reective light, which
may cause smears on the picture and possible damage to the image sensor.
5. Do not remove the serial sticker for the warranty service.
6. Do not expose the camera to rain or other types of liquid.
7. The apparatus must be connected to a main socket-outlet with a protective
earth connection.

1. CAUTIONS
WEEE
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature, indicates that it should not be
disposed with other household wastes at the end of its working life. To prevent
possible harm to the environment or human health from uncontrolled waste
disposal, please separate this from other types of wastes and recycle it responsibly
to promote the sustainable reuse of material resources. Household users
should contact either the retailer where they purchased this product, or their
local government office, for details of where and how they can take item for
environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of
the purchase contract.
This product should not be mixed with other commercial wastes for disposal.
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL
4
This symbol is intended to alert the user to the presence of un-
insulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of
electric shock.
This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.

2. IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatuses (including ampliers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not t into your outlet, consult
an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where it exits from the apparatus.
11) Only use attachments/accessories specied by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specied by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to
avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long
periods of time.
14) Refer all servicing to qualied service personnel. Servicing is required when
the apparatus has been damaged in any way, such as when the power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, or the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
5

3. EQUIPMENT AND ACCESSORIES
Dome Type
-
+
Mount Guide
Manual
Screws(3ea) / L-Wrench Service Video Output Test Cable
6

4. CAMERA COMPONENT DESCRIPTIONS
7
NO PART NAME
1 Housing Top
2 Window
3 Cover PCB
4 PCB Module
5 Rubber Case
6 Housing Bottom
7 Holder Middle
8 Holder Top
9 Ball Ass'y
10 Holder Bottom
11 Wave Water
LED Type Standard Type
➊
➍
➌
➋
➎
➏
➐
➑
➓
➒

5. INSTALLATION
1. Attach the Camera to the ceiling with using the screws provided, taking into considering the camera
angle required for the surveillance function.
2. Adjust the LENS ANGLE to the desired location by hand.
8
M4 Tappint Screw - 3EA
Template
Pan: ±15°
Tilt:
LED Type: 0~75°
Standard Type: 0~90°
Rotate: ±180°
Pan Rotation Horizontal Rotation
CAUTION: With certain wide-angle lenses, the upper part of the image may be obscured when
the tilt angle exceeds 80°
CAUTION: panning(Pan + Horizontal) the bracket in excess of 1 rotations in one direction may
cause damage to the cable.
Tilt Rotation

5. INSTALLATION
3. Connect the VIDEO OUT CABLE and check the video image. Change the SETTINGS accordingly
using the OSD controller.
4. After the SETTING is completed, install the TOP COVER.
9
Controller
Test Video Connector
L-Wrench(T-20)
M4 Star Screw(T-20)
Video Output Test Cable

5. INSTALLATION
• MONITOR CONNECTION
- DC12V/AC24V
- DC12V
10
When you install the camera, please glue the end of cable to
keep it stable in order to protect the camera from humidity problems.
CAMERA
BNC FEMALE
DC12V/AC24V
POWER SUPPLY
DC12V/AC24V
(TERMINAL BLOCK)
VIDEO IN
MONITOR
CAMERA
BNC FEMALE
DC12V
(DC JACK)
DC12V ADAPTER
VIDEO IN
MONITOR

6. DIMENSIONS
Unit(mm)
11
Ø120
55
Ø106

12
7. SPECIFICATIONS
LED Type Standard Type
Image Sensor 1/3” 960H SONY Double Scan Super HAD CCD II
Scanning System 2 : 1 Interlace
H Resolution. 750TV Lines
Scanning Frequency NTSC: 15.734KHz(H), 59.94Hz(V) / PAL: 15.625KHz(H), 50Hz(V)
Total Pixels No. NTSC: 1028(H) X 508(V) / PAL: 1028(H) X 596(V)
Effective Pixels No. NTSC: 976(H) X 494(V) / PAL: 976(H) X 582(V)
S/N Ratio More than 50dB(3DNR ON)
Min. Illumination 0Lux 0.1Lux
Sync System Internal
Gamma r= 0.45
Video Output 1.0 Vp-p Composite(75Ω)
Lens Board Lens
Digital Zoom Ratio 3x
Electronic Shutter NTSC: 1/60 ~1/100,000sec, PAL: 1/50 ~1/100,000sec
Digital Slow Shutter OFF, 2 ~ 256 Field
Flickerless ON / OFF
WDR ON / OFF (Level adjustable)
BLC ON / OFF (Level adjustment, Area selection)
HLC ON / AUTO / OFF (Level adjustable)
AGC OFF, 6 ~ 36dB
DNR(2D/3D) ON / OFF (Level adjustable)
Image Function Image reverse(NORMAL/H / V / HV), Freeze, Contrast, Sharpness
Day & Night True Day & Night With ICR Mechanism
COLOR / BW / AUTO COLOR / BW / AUTO
IR LED 850nm, 15ea -
IR LED Distance up to 15M -
Motion Detection 4 Zones (Level adjustable, Area adjustment)
Privacy Masking 15 Zones (Area adjustment)
White Balance ATW / PUSH / USER1 / USER2 / ANTI CR /
MANUAL / PUSH-LOCK
OSD Built in (Joystick)
Language
ENGLISH / JAPANESE / GERMAN / FRENCH /
RUSSIAN / PORTUGUESE / SPANISH / CHINESE
HINDI, TAMIL, TURKISH, ARABIC, FARSI
Operating Temperature 14°F~122°F(-10°C~+50°C)
Storage Temperature -4°F~140°F(-20°C~+60°C)
Humidity Less than 80%
Power
Consumption
DC DC12V (±10%), Max. 250mA DC12V (±10%), Max. 150mA
DUAL DC12V (±10%), Max. 340mA
AC24V (±10%), Max. 4.0W
DC12V (±10%), Max. 200mA
AC24V (±10%), Max. 2.5W
Dimension (mm) Ø120mm x 55mm
Weight Approx. 350g
IP Rating IP 66
Specications and designs are subject to change for improving the
functionality of this product without notice.

8. OSD MANUAL
• Menu structure
Main MENU 1st Sub MENU 2nd Sub MENU 3rd Sub MENU 4th Sub MENU 5th Sub MENU
EXPOSURE
AUTO
HIGH LUMINANCE FLICKERLESS OFF / ON
BRIGHTNESS 0 ~ 255
LOW LUMINANCE
MODE OFF, AGC, SLOW, AGC->SLOW,
SLOW->AGC, AGC->SLOW->AGC
AGC MAX 6, 12, 18, 24, 30, 36
DSS MAX 2, 4, 8, 16, 32, 64, 128, 256
BRIGHTNESS x0.25,x0.50,x0.75,x1.00
RETURN
MANUAL
MODE SHUT, SLOW
SHUT
MODE (SHUT) ONLY
1/50(PAL), 1/60(NTSC), 1/100(NTSC), 1/120(PAL),
1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000, 1/50000, 1/100000
MODE (SLOW) ONLY 2, 4, 8, 16, 32, 64, 128, 256
AGC 6, 12, 18, 24, 30, 36, 42, 44.8
RETURN
WHITE
BALANCE
ATW
SPEED 0 ~ 255
DELAY CNT 0 ~ 255
ATW FRAME x0.5, x1.0, x1.5, x2.0
ENVIRONMENT INDOOR, OUTDOOR
RETURN
PUSH
USER1
B-GAIN 0 ~ 255
R-GAIN 0 ~ 255
RETURN
USER2
B-GAIN 0 ~ 255
R-GAIN 0 ~ 255
RETURN
ANTI CR
MANUAL
LEVEL UP PUSH ENTER
LEVEL DOWN PUSH ENTER
PRESET
RETURN
PUSH LOCK
DAY&NIGHT
COLOR
AUTO
BURST OFF, ON
DELAY CNT 0 ~ 15
DAY > NIGHT (000 ~ 014) (LED TYPE)
(000 ~ 254)
NIGHT > DAY (001 ~ 015) (LED TYPE)
(001 ~ 255)
IR OPTIMIZER
(LED TYPE)
ON MODE CENTER, AUTO
LEVEL 000 ~ 031
OFF
RETURN
BW
BURST OFF, ON
IR OPTIMIZER
(LED TYPE)
ON MODE CENTER, AUTO
LEVEL 000 ~ 031
OFF
RETURN
13

8. OSD MANUAL
Main MENU 1st Sub MENU 2nd Sub MENU 3rd Sub MENU 4th Sub MENU 5th Sub MENU
WDR/BLC
WDR MODE ON
LEVEL 0 ~ 15
CONTRAST1 0 ~ 7
CONTRAST2 0 ~ 4
OFF
BLC MODE ON BLC ZONE CENTER, TOP, BOTTOM,
LEFT, RIGHT
LEVEL 0 ~ 254
OFF
HLC MODE ON, AUTO CLIP LEVEL 0 ~ 255 SCALE 0 ~ 15
OFF
DNR
2DNR MODE OFF, ON
2DNR LEVEL 0 ~ 15
3DNR MODE OFF, ON
3DNR LEVEL 0 ~ 63
RETURN
MIRROR OFF, V-FLIP, H-FLIP, HV-FLIP
FREEZE OFF, ON
EZOOM 1.0x ~ 3.0x
CONTRAST 0 ~ 63
SHARPNESS 0 ~ 15
RETURN
SPECIAL
CAMERA TITLE ON EDIT MODE RETURN
OFF
LANGUAGE ENGLISH / 中文 / Р у с с к и й / ESPAÑOL / DEUTSCH / FRANCAIS /
PORTUGUÊS / 日本語 / HINDI / TAMIL / TURKISH / ARABIC / FARSI
PRIVACY
AREA SEL 1/15 ~ 15/15
MODE OFF, ON
POSITION PUSH ENTER
COLOR "WHITE, BLACK, RED, GREEN, BLUE,
YELLOW, CYAN, MAGENTA"
TRANSP 0.00, 0.50, 0.75, 1.00
MOSAIC OFF, ON
RETURN
MOTION DET ON
DETECT SENSE 0 ~ 127
BLOCK DISP OFF, ON
MONITOR AREA
AREA SEL 1/4 ~ 4/4
MODE OFF, ON
TOP 0 ~ 15
BOTTOM 0 ~ 15
LEFT 0 ~ 23
RIGHT 0 ~ 23
RETURN
OFF
RETURN
FACTORY
DEFAULT
EXIT
SAVE&EXIT
14
