KT&C KPC-HDV122 User manual

HD CCTV
Digital Video Vandal Dome Camera
OPERATION MANUAL
Thank you for choosing our high quality camera.
Before attempting to connect operate this unit, please read and follow these instructions.
M160-HD(N)V122M-001

These servicing instructions are for use by qualied service personnel only.
To reduce the risk of electric shock do not perform any servicing other than
that contained in the operating instructions unless you are qualied to do so.
Use Class 2 Power Supply Only
CAUTION
2

CONTENTS
1. CAUTIONS
2. IMPORTANT SAFETY INSTRUCTION
3. FEATURES
4. EQUIPMENT AND ACCESSORIES
5. CAMERA COMPONENT DESCRIPTIONS
6. INSTALLATION
7. DIMENSIONS
8. SPECIFICATION
9. OSD MANUAL
• Menu structure
• Function Description
3

1. CAUTIONS
4
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions;
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that
may cause undesired operation.
Note
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.”
WARNING
This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.
Caution
Any changes or modications in construction of this devices which are not expressly
approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
1. A regulated DC12V 1A power supply is recommended for use with this camera
for the best picture and the most stable operation.
An unregulated power supply can cause damage to the camera.
When unregulated power supply is applied, product warranty will be out of subject.
2. It is recommended that the camera is used with a monitor that has a CCTV
quality 75Ω video impedance level.
If yur monitor is switched to high impedance then please adjust accordingly.
3. Do not attempt to disassemble the camera to gain access to the internal components.
Refer servicing to your dealer.
4. Never face the camera towards the sun or any bright or reective light,
which may cause smear on the picture and possible damage to the Image Sensor.
5. Do not remove the serial sticker for the warranty service.
6. Do not expose the camera to rain or other types of liquid.
7. The apparatus must be connected to a mains socket-outlet with a protective earthing
connection.

1. CAUTIONS
5
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with
separate collection systems)
This marking shown on the product or its literature, indicate that it should
not be disposed with other household wastes at the end of its working
life. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate this from other types of
wastes and recycle it responsibly to promote the sustainable reuse of
material resources.
This product should not be mixed with other commercial wastes
purchased this product, or their local government ofce, for details of
where and how they can take item for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract.
Household users should contact either the retailer where they for
disposal.

2. IMPORTANT SAFETY INSTRUCTION
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including ampliers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug does not t into your
outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specied by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specied by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to
avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long
periods of time.
14) Refer all servicing to qualied service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord
or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
6

3. FEATURES
• High Resolution.
SONY 1 / 3” 2.1 M Progressive Color CMOS Image Sensor,
1080p(1920x1080)@30fps
• Support Various Digital Video Output.
1080p@30fps, 1080p@25fps, 720p@60fps, 720p@50fps
• Video Outputs.
Primary HD-SDI (BNC)
Test/Setup TV Out (Test Point-adapter to BNC included), NTSC/PAL selectable
• OSD menu for setup and configuration.
• Lens Control : DC Iris
• 30 Long Life IR illuminations for 0 Lux viewing performance and
range to 20m.(65 feet) (LED type model only)
• Provides True Day/Night Capability with Motorized IR Cut Filter.
• Power Source : DC 12V / AC24V, DC12V
• IP66 Weather Resistant.
• 3-Axis Gimbal.
CAUTION panning(Pan + Horizontal) the bracket in excess of 1 rotations in one direction
may cause damage to the cable.
7
Pan Rotation Tilt Rotation Horizontal Rotation
70
˚70
˚
Standard Type LED Type
Tilting angle

4. EQUIPMENT AND ACCESSORIES
Camera
Template Manual
Screws / Plastic anchors / Wrench Service Video Output Test Cable
When using
Wall Mount Bracket
8

5. CAMERA COMPONENT DESCRIPTIONS
• LED Type
• Standard Type
9
• CONTROL FUNCTION
(OSD JOYSTICK)
LEFT
UP
RIGHT
DOWN
MENU
OSD Joystick
Cooling Fan
Cooling Fan
(*Option)
Service Video
Connector
Service Video
Connector
OSD Joystick
IR LED

6. INSTALLATION
10
Cover Screws(3ea):
are “captive and will
normally be retained in
cover. They are shown
here for illustration
purposes.
Screws(3ea)
Plastic Anchors
(3ea)
Template Lens Zoom Knob
Lens Focus Knob
When using the camera
without LED take off the rubber.
NOTE

6. INSTALLATION
• MONITOR CONNECTION
- DC12V/AC24V
- DC12V
- Service Video connector
11
When you install the camera, please glue up the end of cable to
keep it stable in order to protect the camera from the humidity problems.
MONITOR
BNC FEMALE VIDEO
HD SDI IN
DC 12V / AC 24V
POWER SUPPLY
SDI
RECEIVER
DISPLAY
DEVICE
RS485(+)
RS485(-)
MONITOR
BNC FEMALE VIDEO
HD SDI IN
DC 12V POWER SUPPLY
SDI
RECEIVER
DISPLAY
DEVICE
RS485(+)
RS485(-)
VIDEO IN
HANDHELD
MONITOR
Service
Video
Connector
OPEN
COVER
TEST CABLE

7. DIMENSIONS
Unit(mm)
12
Ø112.8
Ø151
Ø107
123.4
71.5
Ø124

8. SPECIFICATION
Image Device 2.1 Mega Pixel, 1/3” Exmor CMOS
Effective Pixels 1984 (H) x 1105 (V) 30fps
Unit cell size 2.8um (H) x 2.8um (V)
Video output mode HD-SDI: 1080p@30fps, 1080p@25fps, 720p@60fps, 720p@50fps
TV Out: NTSC / PAL selectable
Minimum illumination 0.1 Lux
Video output HD-SDI / 1.0 Vp-p Composite (75Ω)
S/N Ratio More than 50dB
Shutter speed Auto / Manual selectable
Manual shutter speed 1/30(25), 1/60(50), 1/120(100), 1/240, 1/500,
1/1K, 1/2K, 1/4K, 1/8K, 1/16K, 1/30K, 1/60K
WDR / BLC OFF / WDR / BLC / D-WDR
True Day/Night IR Cut / Pass Filter change
Controllable Max Gain 29 dB
White Balance AUTO / AUTOext / PUSH / MANUAL
Lens Control DC IRIS
OSD Menu Yes
Power
Consumption
W/O
Heater DC12V DC 12V (±10%), Max.200mA
DUAL DC 12V (±10%), Max.260mA / AC 24V (±10%), Max.3.7W
Heater
(Option) DC12V DC 12V (±10%), Max.1.05A
DUAL DC 12V (±10%), Max.500mA / AC 24V (±10%), Max.14.5W
Dimension 151(Ø) x 123.4(mm)
Weight 950g
Conformity CE, FCC, KC
IP Rating IP66 (Weatherproof)
Temperature / Humidity
(no condensing) Operation: -40~50 / 20~80% Storage: -20~70 / 20~95%
LED TYPE
Power
Consumption
W/O
Heater DC12V DC 12V (±10%), Max.450mA
DUAL DC 12V (±10%), Max.560mA / AC 24V (±10%), Max.6.9W
Heater
(Option) DC12V DC 12V (±10%), Max.1.26A
DUAL DC 12V (±10%), Max.810mA / AC 24V (±10%), Max.18W
Minimum illumination 0 Lux
IR LED 850nm, 30ea
IR Beam Range Up to 20M (65 Feet)
Specications and designs are subject to change for improving the
functionality of this product without notice.
13

9. OSD MANUAL
• Menu structure
SETUP
EXPOSURE
WHITE BALANCE
WDR / BLC
DNR
DAY & NIGHT
SPECIAL
SYSTEN
Reset Data All
EXT
Main Sub Menu Sub Menu
EXPOSURE
BRIGHTNESS 0 ~ 20
AE MODE NORMAL AE / INDOOR
LENS(IRIS) MANUAL / AUTO
SHUTTER MANUAL /
AUTO LEVEL 1/30(25), 1/60(50), 1/120(100), 1/240, 1/500,
1/1K, 1/2K, 1/4K, 1/8K, 1/16K, 1/30K, 1/60K.
RETURN BACK / EXIT
DSS Off / X2 / X3 / X4 / X5 / X6 / X7 / X8
AGC 0 ~ 10
BASE FREQ 60Hz / 50Hz
RESET DATA BACK / DEF.
RETURN BACK / EXIT.
WHITE
BALANCE
WB MODE AUTO
/AUTOext
/PUSH
/MANUAL
COLORTEMP. LOW / MIDDLE / HIGH
R-GAIN 0 ~ 20
B-GAIN 0 ~ 20
RETURN BACK / EXIT
SATURATION 0 ~ 20
RESET DATA BACK / DEF.
RETURN BACK / EXIT.
WDR/BLC
MODE OFF / WDR / BLC / D-WDR
WDR WGT 0 ~ 4
BLC OSD OFF, ON
BLC POS-X 0 ~ 20
BLC POS-Y 0 ~ 20
BLC SIZE-X 0 ~ 20
BLC SIZE-Y 0 ~ 20
RESET DATA BACK / DEF.
RETURN BACK / EXIT.
DNR OFF, LOW, MIDDLE, HIGH
DAY&NIGHT COLOR / B&W /
AUTO
D&N DETECT SENSE
DELAY 1sec, 3, 5, 10, 15, 20, 25, 30, 40, 50, 60sec
D->N LEVEL 0 ~ 10
N->D LEVEL 0 ~ 10
RESET DATE BACK / DEF.
RETURN BACK / EXIT.
14

9. OSD MANUAL
Main Sub Menu Sub Menu
SHARPNESS 0 ~ 20
GAMMA 0 ~ 4
FLIP OFF, H FLIP, V FLIP, HV FLIP
LENS SHADING OFF, ON
DZOOM 1x, 2x, 4x, 6x, 8x, 10x, 12x, 14x, 16x, 18x, 20x
RESET DATA BACK / DEF.
RETURN BACK / EXIT.
SPECIAL
PRIVACY OFF/ ON
ZONE NO. 0 ~ 23
ZONE OP. OFF / ON
X-POS 0 ~ 60
Y-POS 0 ~ 40
X-SIZ 0 ~ 40
Y-SIZ 0 ~ 40
COLOR BLK, WHI, YEL, CYN, GRN,
MAG, RED, BLU
TRANS. 0 ~ 4
RESET DATA BACK / DEF.
RETURN BACK / EXIT.
HLMASK OFF/ ON
LEVEL 0 ~ 20
COLOR BLK, WHI, YEL, CYN, GRN,
MAG, RED, BLU
RESET DATA BACK / DEF.
RETURN BACK / EXIT.
PATTERN OFF / 0 / 1
DISPLAY INFO. CAMERA ID. NUM. OFF/ ON
RETURN BACK / EXIT.
RESET DATA BACK / DEF.
RETURN BACK / EXIT.
SYSTEM
COMM. ADJUST
CAMERA ID. 1 ~ 254
BAUD RATE 2400 / 4800 / 9600 / 19200 / 38400 /
57600 / 115200 bps
APPLY & EXIT OK / ON
RETURN BACK / EXIT.
SDI FORMAT 1080P / 720P
SDI FPS 30(60) / 25(50)
CVBS FORMAT NTSC /
PAL
CVBS OUT AUTO / OFF / ON(WDR OFF)
CVBS VIEW CROP / FULL
RETURN BACK / EXIT.
FAN ACTION
(Option) OFF /
ON /
AUTO
FAN ON LEVEL 0 ~ 10
FAN OFF LEVEL 0 ~ 10
RETURN BACK / EXIT.
APPLY OK / ON
SYSTEM INFO. S/W VERSION
SET VERSION
RETURN BACK / EXIT.
REBOOT
RETURN BACK / EXIT.
15

16
9. OSD MANUAL
• Function Description
0. SETUP
- EXPOSURE : Go sub menu for camera exposure control.
- WHITE BALANCE : Go sub menu for camera white balance control.
- WDR/BLC : Go sub menu for camera WDR or BLC action.
- DNR : Control noise reduction setting.
- DAY & NIGHT : Go sub menu for camera day & night control.
- IMAGE : Go sub menu for adjust image functions.
- SPECIAL : Go sub menu for special feature control.
- SYSTEM : Go sub menu for system control & information.
- Reset Data All : Reset camera’s all feature data to default value.
1. EXPOSURE
- BRIGHTNESS : Adjust image brightness value.
- AE MODE : Adjust AE control mode.
- LENS(IRIS) : Select lens iris control type.
- SHUTTER : Select shutter speed control type.
• LEVEL : Adjust shutter speed at manual shutter mode.
- DSS : Adjust digital slow shutter control level.
- AGC : Adjust max gain level for brightness control.
- BASE FREQ : Select basic control frequency for control camera feature.
2. WHITE BALANCE
- WB MODE : Select white balance control mode.
• AUTO : Full auto control mode in color temperature rage
2300K~10000K.
• AUTOext : Extended auto mode for special illumination.
• PUSH
: Enable fix the control setting for specific environment. Push & release, for fix WB control setting.
• MANUAL : Enable WB control setting by user’s intention.
◦COLOR TEMP. : Select color temperature range for WB control at manual mode
◦ R-GAIN : Adjust red color gain for WB control at maual mode.
◦ B-GAIN : Adjust blue color gain for WB control at manual mode.
- SATURATION : Adjust color saturation level.

17
9. OSD MANUAL
3. WDR / BLC
- MODE : Select WDR for BLC mode.
• WDR : Act in wdie dynamic rage mode. Controled video frame rate in 1/2.
• BLC : Act in Backlight compensation mode.
• D-WDR : Digital wide dynamic range control.
- WDR WGT : WDR weight control level settig at WDR mode.
- BLC OSD : Display BLC control zone in screen.
- BLC POS-X : Select BLC control zone vertical position.
- BLC POS-Y : Select BLC control zone horizontal position.
- BLC SIZ-X : Select BLC control zone vertical size.
- BLC SIZ-Y : Select BLC control zone horizontal size.
4. DNR: Reduce image’s noise
5. DAY & NIGHT
- MODE : Select TDN(True Day & Night control) mode.
• AUTO : Camera controlled automatically to decide day or night
environment using input level data from CDS sense.
• COLOR : Fix to mode at day environment setting.
Make video image act in color.
• B&W : Fix to mode at night environment setting.
Make video image act in B/W.
■D/N DETECT : Select AGC or CDS control for TDN auto control.
■ DELAY : Delay time for change day or night mode at auto mode.
■ D->N LEVEL : Threshold level(AGC or CDS) for change Day to Night mode.
■ N->D LEVEL : Threshold level(AGC or CDS) for change Night to Day mode.
6. IMAGE
- SHARPNESS : Adjust image sharpness level.
- GAMMA : Gamma Curve Select.
- FLIP : Vertical & Horizontal flip setting.
- LENS SHADING : Enable lens shading compensation.
- DZOOM : Select digital zoom magnification.
7. SPECIAL
- PRIVACY : Setting for protect private area in image using mask setting.
• ZONE NO. : Select private mask zone number.
• ZONE OP. : Select zone mask display on/off.
• X-POS : Select zone horizontal position.
• Y-POS : Select zone vertical position.
• X-SIZ : Select zone horizontal size.
• Y-SIZ : Select zone vertical size.
• COLOR : Select mask color
• TRANS. : Select mask transparency level.

18
9. OSD MANUAL
- HLMASK : Mask image high light area.
• LEVEL : Select high light level.
• COLOR : Select mask color.
- PATTERN : Color bar display Select.
- DISPLAY INFO. : Camera information OSD on/off.
• CAMERA ID.
8. SYSTEM
- COMM. ADJUST : Setting for RS485 communication.
• CAMERA ID. : Camera ID
• BAUDRATE : Baud rate setting
• 485REG. : Enable or disable RS485 termination register.
- SDI FORMAT : 1080P / 720P
- SDI FPS : 30 or 25 fps in 1080p mode. 60 or 50 fps in 720p mode.
- CVBS FORMAT : NTSC / PAL
• CVBS OUT : Select mode for CVBS out action.
◦ON, OFF : Enable or Disable CVBS out data.
◦AUTO : Check automatically CVBS video cable connection.
If connected, CVBS out data is enable and WDR mode
is setted off automatically.
• CVBS VIEW : CVBS out video angle setting.
◦CROP : Cut the scene outside area for keep image aspect ratio.
◦FULL : Fill the full angle scene into image with
H-V size & ratio change.
- FAN ACTION
(* Option) : Select Fan action on/off.
• FAN ON LEV : Select temperature level for fan action start.
• FAN OFF MG : Select temperature level margin for fan action stop.
- APPLY : Apply all video setting changed at once
Use the Set button to apply.
- SYSTEM INFO.
• S/W VERSION : Camera’s basic software version.
• SET VERSION : Camera’s feature control setting version.
