KT&C Omni IP Series User guide

1
KNC-p3LR3IR
KNC-p3LR4IR
KNC-p3LR6IR
3 Megapixel Plug & Play Capable
IP66 IR IP Low Profile Cameras
Network Mini Dome Camera
Quick Operation Guide

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
1
1
Thank you for selecting this KT&C Omni IP Series product. For
additional information please refer to the complete User Guide for
this cameras series. End users should contact their KT&C Certified
Dealer for service. Certified Dealers can obtain support directly from
KT&C.
About This Guide
While KT&C makes every effort to insure the completeness and
accuracy of the information contained in this Guide, we are not
responsible for typographical errors or misprints. At the same time,
KT&C reserves the right to make changes to improve the performance
of our products at any time without notice, and so the specifications
and content of this document are subject to change without notice.
Every effort will be made to include updates in new versions of this
manual and/or online.
DISCLAIMER STATEMENT
“Underwriters Laboratories Inc. (“UL”) has not tested the
performance or reliability of the security or signaling aspects of this
product. UL has only tested for fire, shock or casualty hazards as
outlined in UL’s Standard(s) for Safety, UL60950-1. UL Certification
does not cover the performance or reliability of the security or
signaling aspects of this product. UL MAKES NO REPRESENTATIONS,
WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE
PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING
RELATED FUNCTIONS OF THIS PRODUCT.

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
2
2
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to
comply with the limits for a digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own
expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized European
standards listed under the Low Voltage Directive 2006/95/EC, the
EMC Directive 2004/108/EC, the RoHS Directive 2011/65/EU.

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
3
3
2012/19/EU (WEEE directive): Products marked with
this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or
dispose of it at designated collection points. For more information
see: www.recyclethis.info.
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery
information. The battery is marked with this symbol,
which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your supplier
or to a designated collection point. For more information see:
www.recyclethis.info

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
4
4
Safety Instructions
These instructions are intended to ensure that the camera is installed
in a manner that avoids danger to persons or property loss.
These precautionary measures are divided into “Warnings” and
“Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment/property damage may occur if any of
the cautions are neglected.
Warnings
●In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region. Please
refer to technical specifications for detailed information.
●Input voltage should meet the requirements for both the SELV
(Safety Extra Low Voltage) and Limited Power Source for 12 VDC
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these
precautions to prevent
potential injury or material
damage.

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
5
5
according to the IEC60950-1 standard; or 802.3af PoE. Please
refer to technical specifications for detailed information.
●If connecting several devices to one power supply, to avoid any
overload that may cause over-heating or a fire hazard insure that
the power supply is adequate for the power load.
●Please make sure that all plugs are firmly connected to the
power sockets. When the product is mounted on wall or ceiling,
the device shall be firmly attached, taking into consideration any
wind, snow loading, or other factors. The mounting surface shall
be capable of supporting several times the base weight of the
camera.
●If smoke, unusual odors or noise come from the device, turn off
the power at once and unplug the power cable, and then
contact authorized service personnel.
Cautions
●Make sure the power supply voltage is correct before using the
camera.
●Do not drop the camera or subject it to physical shock.
●Do not touch lenses or sensor modules with fingers. If cleaning is
necessary, use clean cloth with a bit of ethanol and wipe gently.
If the camera will not be used for an extended period, please
protect the lens openings from damage and/or debris.
●Avoid aiming the camera at the sun or extremely bright light
sources. Blooming or smearing may occur in excessive light

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
6
6
(which is not a malfunction), and could compromise the
performance of the sensor.
●The sensor may be damaged if exposed to laser energy, so when
any laser equipment is in use, make sure that the sensor will not
be exposed to the laser beam.
●Do not place the camera in extremely hot or cold (see camera
specifications) locations. Do not exceed the rated environmental
(IP66) conditions. Do not expose the camera to high levels of
electromagnetic (RF) radiation.
●To avoid heat accumulation, good ventilation is required in the
operating environment.
●Keep the camera away from solvents while in use; exposure to
liquids should not exceed IP66 environmental conditions.
●During shipping, the camera shall be packed in its original
packing, or packing providing the equivalent protection.
●Improper use or replacement of any batteries (if so equipped)
may result in the hazard of explosion. Replace with the same or
equivalent type only. Dispose of used batteries according to the
instructions provided by the battery manufacturer.
●If the product does not function properly, Dealers please contact
KT&C; End Users please contact your KT&C Certified Dealer or an
authorized service center. Do not disassemble the camera for
repair or maintenance by yourself. (KT&C shall not assume any
responsibility for problems caused by unauthorized repair or
maintenance.)

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
7
7
Table of Contents
1 Appearance and Description .......................................................... 8
2 Installation.................................................................................... 10
2.1 Ceiling/Wall Mounting .................................................. 11
2.2 Wall/Ceiling Mounting with a Gang Box ........................ 15
2.3 Wall Bracket Mounting.................................................. 17
2.4 Install the Micro SD Card ............................................... 19
3 Setting the Camera Parameters over the LAN .............................. 21
4 Accessing via a Web Browser ....................................................... 26

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
8
8
1Appearance and Description
Figure 1-1 Cover, Base and Cables
Figure 1-2 Lock Screw & Reset Button

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
9
9
Table 1-1 Physical Description
No.
Description
1
Cover and Bubble
2
Camera/IR Module
3
Micro SD Card Slot
4
Network Cable
5
Lens
6
IR LED
7
Power Cable
8
Position Lock Hex Screw
9
RESET [WPS] Button
Press RESET about 10s when the camera is powering on or
rebooting to restore the default settings, including the user
name, password, IP address, port No., etc.

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
10
10
2Installation
Before you start:
Make sure the camera is in good condition and all the accessory
parts are included.
Make sure all related equipment is powered-off during the
installation.
Check to insure that the specifications of the camera are correct
for the installation environment.
Make sure the power supply voltage is 12VDC or PoE compliant to
avoid damage to the camera.
If the product does not function properly, Dealers please contact
KT&C; End Users please contact your KT&C Certified Dealer or an
authorized service center. Do not disassemble the camera for
repair or maintenance by yourself.
Make sure that the mounting surface is strong enough to withstand
three times the weight of the camera.
If the IR LEDS in this camera will be active, you must observe the
following precautions to prevent IR reflection:
●Dust or grease on the lens/dome cover will cause IR reflection.
Please do not remove the cover protective film until the
installation is finished. If there is dust or grease on the
lens/dome cover, clean the lens/dome cover with clean soft
cloth and isopropyl alcohol.

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
11
11
●Make sure that there is no reflective surface too close to the
camera lens. The IR light from the camera may reflect back into
the lens causing haze, distortion or improper scene exposure.
●The foam ring around the lens must be seated flush against the
inner surface of the cover/bubble to isolate the lens from the IR
LEDS. Fasten the lens/dome cover to camera body so that the
foam ring and the dome cover are attached seamlessly.
2.1 Ceiling/Wall Mounting
Steps:
1. Drill the screw holes and the cable hole in the ceiling according to
the supplied drill template.
Figure 2-1 Drill Template
Drill Template
1
1
11
Hole A:for cables routed through the ceiling
Screw hole 1:for Mounting Base
FRONT

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
12
12
The drill template matches the adapter plate included with the
camera; pairs of hole on the temple can be uses for mounting the
camera directly without the plate. The adapter plate also fits single
gang and round electrical boxes. See figure 2-2 below.
Figure 2-2 Adapter Plate
2. Loosen the four cover attachment screws with the supplied Allen
key to disassemble the camera.
Figure 2-3 Disassemble the Camera Cover

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
13
13
3. Fix the adapter plate to the ceiling with the supplied screws, and
expansion anchors if needed.
Figure 2-4 Fix the Adapter Plate
4. Attach the dome base to the plate with the supplied screws.
Figure 2-5 Fix the Dome Drive
5. Connect the power cable (if used) and network cable.
Adapter Plate
Side Outlet

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
14
14
Use a plier to remove the break-away part and route the cables via
side outlet (as shown in Figure 2-4) if no cable hole is drilled in step 1,
and connect the corresponding cables.
Figure 2-6 Remove a Section of the Edge
6. View the image via the web browser.
7. Slightly loosen the hex screw beside the WPS/RESET button to
adjust the direction of view.
8. Use the supplied adjusting tool for ease of adjusting the pan [±
30°], tilt [0~80°], and rotation direction [0~360°].
Figure 2-7 3-Axis Adjustment
Adjusting Tool
Rotation
Tilt
Pan

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
15
15
9. Tighten the hex screw to fix the camera in the desired direction.
10. Align the front cover to the dome base and tighten the front
cover screws.
Figure 2-8 Install the Front Cover
11. Carefully remove any protection film to complete installation.
Do not tear off the protection film until the installation is
completed.
Do not touch the inside face of the bubble with your fingers
2.2 Wall/Ceiling Mounting with a Gang Box
Steps:
1. Attach the adapter plate to the gang box with the supplied
PM4X8 screws, or with #6-32 screws which match the box.

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
16
16
Figure 2-9 Attach the Adapter Plate
2. Attach the dome base to the adapter plate with the supplied
PM4X8 screws.
Figure 2-10 Fix the Dome Drive
3. Connect the power cable if used, and the network cable.

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
17
17
4. Align the front cover to the dome base and tighten the front
cover screws.
Figure 2-11 Install the Front Cover
1. Carefully remove any protection film to complete installation.
Do not tear off the protection film until the installation is
completed.
Do not touch the inside face of the bubble with your fingers.
2.3 Wall Bracket Mounting
Steps:
1. Install the optional (special order) wall bracket to the wall with
the supplied screws in the wall bracket package.

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
18
18
You need to purchase the matching wall bracket separately.
Figure 2-12 Wall Bracket
2. Attach the dome base to the wall bracket with the supplied
screws.
Figure 2-13 Install the Camera

KNC-p3LR_IR Low Profile IP Camera·Quick Operation Guide
19
19
3. Align the front cover to the dome base and tighten the set screws
on the front cover to complete the installation.
Figure 2-14 Install the Front Cover
4. Carefully remove any protection film to complete installation.
Do not tear off the protection film until the installation is
completed.
Do not touch the inside face of the bubble with your fingers
2.4 Install the Micro SD Card
This series of camera supports local storage, please refer to the
following steps to install the micro SD card.
Steps:
1. Remove the front cover by loosening the four screws.
