Kubota V3600-E3 Install guide

V3600-E3 ·V3600-T-E3 ·
V3800-DI-T-E3 ·V3300-E3BG ·
V3600-T-E3BG
MODELS
KUBOTA SHOP MANUAL

TO THE READER
This Workshop Manual has been prepared to provide servicing personnel with
information on the mechanism, service and maintenance of V3600-E3B, V3600-T-E3B,
V3800DI-T-E3B, V3600-E3CB, V3600-T-E3CB, V3800DI-T-E3CB, V3300-E3BG,
V3600-T-E3BG and V3800DI-T-E3BG. It is divided into three parts, “General”,
“Mechanism” and “Servicing”.
QGeneral
Information on the engine identification, the general precautions, maintenance check
list, check and maintenance and special tools are described.
QMechanism
Information on the construction and function are included. This part should be
understood before proceeding with troubleshooting, disassembling and servicing.
Refer to Diesel Engine Mechanism Workshop Manual (Code No. 9Y021-01876) for
the one which has not been described to this workshop manual.
QServicing
Information on the troubleshooting, servicing specification lists, tightening torque,
checking and adjusting, disassembling and assembling, and servicing which cover
procedures, precautions, factory specifications and allowable limits.
All information illustrations and specifications contained in this manual are based on
the latest product information available at the time of publication.
The right is reserved to make changes in all information at any time without notice.
Due to covering many models of this manual, information or picture being used have
not been specified as one model.
October 2007
© KUBOTA Corporation 2007

1
V3-E3B SERIES, V3-E3CB SERIES, V3-E3BG SERIES, WSM SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
BEFORE SERVICING AND REPAIRING
• Read all instructions and safety instructions in this
manual and on your engine safety decals.
• Clean the work area and engine.
• Park the machine on a firm and level ground.
• Allow the engine to cool before proceeding.
• Stop the engine, and remove the key.
• Disconnect the battery negative cable.
• Hang a “DO NOT OPERATE” tag in operator
station.
SAFETY FIRST
This symbol, the industry’s “Safety Alert Symbol”, is used throughout this manual and on labels on
the machine itself to warn of the possibility of personal injury. Read these instructions carefully.
It is essential that you read the instructions and safety regulations before you attempt to repair or use
this unit.
DANGER : Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING : Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION : Indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury.
QIMPORTANT : Indicates that equipment or property damage could result if instructions are not
followed.
QNOTE : Gives helpful information.

2
V3-E3B SERIES, V3-E3CB SERIES, V3-E3BG SERIES, WSM SAFETY INSTRUCTIONS
SAFETY STARTING
• Do not start the engine by shorting across starter
terminals or bypassing the safety start switch.
• Unauthorized modifications to the engine may impair
the function and / or safety and affect engine life.
SAFETY WORKING
• Do not work on the machine while under the influence
of alcohol, medication, or other substances or while
fatigued.
• Wear close fitting clothing and safety equipment
appropriate to the job.
• Use tools appropriate to the work. Makeshift tools,
parts, and procedures are not recommended.
• When servicing is performed together by two or more
persons, take care to perform all work safely.
• Do not touch the rotating or hot parts while the engine
is running.
• Never remove the radiator cap while the engine is
running, or immediately after stopping. Otherwise, hot
water will spout out from radiator. Only remove
radiator cap when cool enough to touch with bare
hands. Slowly loosen the cap to first stop to relieve
pressure before removing completely.
• Escaping fluid (fuel or hydraulic oil) under pressure
can penetrate the skin causing serious injury. Relieve
pressure before disconnecting hydraulic or fuel lines.
Tighten all connections before applying pressure.
• Wear a suitable hearing protective device such as
earmuffs or earplugs to protect against objectionable
or uncomfortable loud noises.
• Do not open high-pressure fuel system.
High-pressure fluid remaining in fuel lines can cause
serious injury. Do not disconnect or attempt to repair
fuel lines, sensors, or any other components between
the high-pressure fuel pump and injectors on engines
with high pressure common rail fuel system.
• High voltage exceeding 100 V is generated in the
ECU, and is applied to the injector.
Pay sufficient caution to electric shock when
performing work activities.

3
V3-E3B SERIES, V3-E3CB SERIES, V3-E3BG SERIES, WSM SAFETY INSTRUCTIONS
AVOID FIRES
• Fuel is extremely flammable and explosive under
certain conditions. Do not smoke or allow flames or
sparks in your working area.
• To avoid sparks from an accidental short circuit,
always disconnect the battery negative cable first and
connect it last.
• Battery gas can explode. Keep sparks and open
flame away from the top of battery, especially when
charging the battery.
• Make sure that no fuel has been spilled on the engine.
VENTILATE WORK AREA
• If the engine must be running to do some work, make
sure the area is well ventilated. Never run the engine
in a closed area. The exhaust gas contains poisonous
carbon monoxide.
PREVENT ACID BURNS
• Sulfuric acid in battery electrolyte is poisonous. It is
strong enough to burn skin, clothing and cause
blindness if splashed into eyes. Keep electrolyte
away from eyes, hands and clothing. If you spill
electrolyte on yourself, flush with water, and get
medical attention immediately.
DISPOSE OF FLUIDS PROPERLY
• Do not pour fluids into the ground, down a drain, or
into a stream, pond, or lake. Observe relevant
environmental protection regulations when disposing
of oil, fuel, coolant, electrolyte and other harmful
waste.

4
V3-E3B SERIES, V3-E3CB SERIES, V3-E3BG SERIES, WSM SAFETY INSTRUCTIONS
PREPARE FOR EMERGENCIES
• Keep a first aid kit and fire extinguisher handy at all
times.
• Keep emergency numbers for doctors, ambulance
service, hospital and fire department near your
telephone.

5
V3-E3B SERIES, V3-E3CB SERIES, V3-E3BG SERIES, WSM SPECIFICATIONS
SPECIFICATIONS
* The specification described above is of the standard engine of each model.
* Conversion Formula : HP = 0.746 kW, PS = 0.7355 kW
W1028103
Model V3600-E3B V3600-E3CB V3600-T-E3B V3600-T-
E3CB
V3800DI-T-
E3B
V3800DI-T-
E3CB
Number of Cylinder 4
Type Vertical, water-cooled, 4-cycle diesel engine
Bore ×Stroke 98 ×120 mm (3.86 ×4.72 in.) 100 ×120 mm (3.94 ×4.72 in.)
Total Displacement 3620 cm3(220.9 cu.in.) 3769 cm3(230.0 cu.in.)
ISO Net Continuous 40.2 kW / 2600 min-1 (rpm)
(53.9 HP / 2600 min-1 (rpm))
51.5 kW / 2600 min-1 (rpm)
(69.0 HP / 2600 min-1 (rpm))
60.9 kW / 2600 min-1 (rpm)
(81.6 HP / 2600 min-1 (rpm))
ISO / SAE Net Intermittent 46.3 kW / 2600 min-1 (rpm)
(62.1 HP / 2600 min-1 (rpm))
59.3 kW / 2600 min-1 (rpm)
(79.5 HP / 2600 min-1 (rpm))
70.1 kW / 2600 min-1 (rpm)
(94.0 HP / 2600 min-1 (rpm))
SAE Gross Intermittent 49.8 kW / 2600 min-1 (rpm)
(66.8 HP / 2600 min-1 (rpm))
63.0 kW / 2600 min-1 (rpm)
(84.5 HP / 2600 min-1 (rpm))
74.0 kW / 2600 min-1 (rpm)
(99.2 HP / 2600 min-1 (rpm))
Maximum Bare Speed 2800 min-1 (rpm)
Minimum Bare Idling Speed 775 to 825 min-1 (rpm)
Combustion Chamber Spherical Type (E-TVCS) Reentrant Type, Center Direct
Injection Type (E-CDIS)
Fuel Injection Pump Bosch Type Mini Pump
Governor All speed mechanical governor
Direction of Rotation Counter-clockwise (Viewed from flywheel side)
Injection Nozzle BOSCH Throttle Type Bosch P Type
Injection Timing 0.14 rad (8.0 °) before T.D.C. 0.070 rad (4.0 °) before T.D.C. 0.10 rad (6.0 °) before T.D.C.
Firing Order 1-3-4-2
Injection Pressure 13.73 MPa (140.0 kgf/cm2, 1991 psi)
1st stage 18.63 MPa
(190.0 kgf/cm2, 2702 psi),
2nd stage 23.54 MPa
(240.0 kgf/cm2, 3414 psi),
Compression Ratio 22.6 21.8 19.0
Lubricating System Forced lubrication by trochoid pump
Oil Pressure Indicating Electrical Type Switch
Lubricating Filter Full Flow Paper Filter (Cartridge Type)
Cooling System Pressurized radiator, forced circulation with water pump
Starting System Electric Starting with Starter
Starting Motor 12 V, 3.0 kW
Starting Support Device By Glow Plug in Combustion Chamber Intake Air Heater in Intake
Manifold
EGR NONE Internal EGR
(2 stage Exhaust Cam)
External EGR
(EGR Cooler + Mechanical EGR
Valve + Reed Valve)
Battery 12 V, 136 AH equivalent
Charging Alternator 12 V, 540 W
Fuel Diesel Fuel No. 2-D S500 or S15, see page G-7.
Lubricating Oil Class CF lubricating oil as per API classification is recommended.
For details on recommended lubricating oils, see page G-7.
Lubricating Oil Capacity 13.2 L (3.49 U.S.gals)
Weight (Dry) 264 kg
(582 lbs)
245 kg
(540 lbs)
275 kg
(606 lbs)
252 kg
(556 lbs)
288 kg
(635 lbs)
281 kg
(619 lbs)

6
V3-E3B SERIES, V3-E3CB SERIES, V3-E3BG SERIES, WSM SPECIFICATIONS
* The specification described above is of the standard engine of each model.
* Conversion Formula : HP = 0.746 kW, PS = 0.7355 kW
W10455750
Model V3300-E3BG V3600-T-E3BG V3800DI-T-E3BG
Number of Cylinders 4
Type Vertical, Water-cooled, 4 cycle diesel engine
Bore ×Stroke 98 x 110 mm (3.86 x 4.33 in.) 98 x 120 mm (3.86 x 4.72 in.) 100 x 120 mm (3.94 x 4.72 in.)
Total Displacement 3318 cm3(202.48 cu.in.) 3620 cm3(220.9 cu.in.) 3769 cm3(230.0 cu.in.)
STANDBY
ISO 3046
SAE J-1349
33.6 kW / 1800 min-1 (rpm)
45.0 HP / 1800 min-1 (rpm)
43.1 kW / 1800 min-1 (rpm)
57.8 HP / 1800 min-1 (rpm)
47.8 kW / 1800 min-1 (rpm)
64.1 HP / 1800 min-1 (rpm)
(NET STANDBY SEA J-1995)
NET Continuous
ISO 3046
SAE J-1349
30.6 kW / 1800 min-1 (rpm)
41.0 HP / 1800 min-1 (rpm)
39.2 kW / 1800 min-1 (rpm)
52.5 HP / 1800 min-1 (rpm)
43.5 kW / 1800 min-1 (rpm)
58.3 HP / 1800 min-1 (rpm)
(NET Continuous SEA J-1995)
Governor Regulation Less than 5 % –
Combustion Chamber Spherical type (E-TVCS) Reentrant Type, Center Direct
Injection Type (E-CDIS)
Fuel Injection Pump Bosch Type Mini Pump
Governor All speed mechanical governor Mechanical + Electronic
governor
Direction of Rotation Counter-clockwise (viewed from flywheel side)
Injection Nozzle Bosch Throttle Type Bosch P Type
Injection Timing 0.16 rad (9.0 °) before T.D.C. 0.070 rad (4.0 °) before T.D.C. 0.096 rad (5.5 °) before T.D.C.
Firing Order 1-3-4-2
Injection Pressure 13.73 MPa (140.0 kgf/cm2, 1991 psi)
1st stage 18.63 MPa
(190.0 kgf/cm2, 2702 psi),
2nd stage 23.54 MPa
(240.0 kgf/cm2, 3414 psi),
Compression Ratio 22.6 21.8 19.0
Lubricating System Forced lubrication by trochoid pump
Oil Pressure Indication Electrical type switch
Lubricating Filter Full flow paper filter (Cartridge type)
Cooling System Pressurized radiator, forced circulation with water pump
Starting System Electric Starting with Starter
Starting Motor 12 V, 3.0 kW
Starting Support Device By glow plug in combustion chamber Intake Air Heater in Intake
Manifold
EGR None Internal EGR
(2 stage Exhaust Cam)
External EGR
(EGR Cooler + Mechanical
EGR Valve + Reed Valve)
Battery 12 V, 136 AH, equivalent
Charging Alternator 12 V, 540 W
Fuel Diesel Fuel No. 2-D S500 or S15, see page G-7.
Lubricating Oil Class CF lubricating oil as per API classification is recommended.
For details on recommended lubricating oils, see page G-7.
Lubricating Oil Capacity 13.2 L (3.49 U.S.gals)
Weight (Dry) 281 kg (619 lbs) 284 kg (626 lbs) 280 kg (617 lbs)

7
V3-E3B SERIES, V3-E3CB SERIES, V3-E3BG SERIES, WSM PERFORMANCE CURVES
PERFORMANCE CURVES
(1) Brake Horse Power (2) Engine Speed (3) B.S.F.C. (4) Torque

8
V3-E3B SERIES, V3-E3CB SERIES, V3-E3BG SERIES, WSM DIMENSIONS
DIMENSIONS

9
V3-E3B SERIES, V3-E3CB SERIES, V3-E3BG SERIES, WSM DIMENSIONS

CONTENTS
GENERAL
1. ENGINE IDENTIFICATION ............................................................................. G-1
[1] MODEL NAME AND ENGINE SERIAL NUMBER ................................ G-1
[2] E3B ENGINE............................................................................................. G-3
[3] CYLINDER NUMBER ............................................................................... G-3
2. GENERAL PRECAUTIONS ............................................................................ G-4
3. MAINTENANCE CHECK LIST ....................................................................... G-5
4. CHECK AND MAINTENANCE ....................................................................... G-8
[1] DAILY CHECK POINTS........................................................................... G-8
[2] CHECK POINTS OF INITIAL 50 HOURS ........................................... G-10
[3] CHECK POINT OF EVERY 50 HOURS ............................................. G-11
[4] CHECK POINTS OF EVERY 250 HOURS ......................................... G-12
[5] CHECK POINTS OF EVERY 500 HOURS ......................................... G-14
[6] CHECK POINT OF EVERY 1000 HOURS ......................................... G-18
[7] CHECK POINTS OF EVERY 1 OR 2 MONTHS ............................... G-19
[8] CHECK POINTS OF EVERY 1500 HOURS ....................................... G-21
[9] CHECK POINTS OF EVERY 3000 HOURS ....................................... G-23
[10]CHECK POINTS OF EVERY 1 YEAR ................................................ G-28
[11]CHECK POINTS OF EVERY 2 YEARS.............................................. G-29
5. SPECIAL TOOLS.......................................................................................... G-32

G-1
V3-E3B SERIES, V3-E3CB SERIES, V3-E3BG SERIES, WSM G GENERAL
1. ENGINE IDENTIFICATION
[1] MODEL NAME AND ENGINE SERIAL NUMBER
When contacting the manufacture, always specify your engine
model name and serial number.
The engine model and its serial number need to be identified
before the engine can be serviced or parts replaced.
QEngine Serial Number
The engine serial number is an identified number for the engine.
It is marked after the engine model number.
It indicates month and year of manufacture as follows.
•Year of manufacture
W1010477
Alphabet or
Number Year Alphabet or
Number Year
1 2001 F 2015
2 2002 G 2016
3 2003 H 2017
4 2004 J 2018
5 2005 K 2019
6 2006 L 2020
7 2007 M 2021
8 2008 N 2022
9 2009 P 2023
A 2010 R 2024
B 2011 S 2025
C 2012 T 2026
D 2013 V 2027
E 2014
(1) Engine Model Name and Serial
Number

G-2
V3-E3B SERIES, V3-E3CB SERIES, V3-E3BG SERIES, WSM G GENERAL
•Month of manufacture
* Alphabetical letters “I” and “O” are not used.
e.g. V3600 - 8 B A001
(a) (b)(c) (d)
W1011076
Month Engine Lot Number
January A0001 ~ A9999 B0001 ~ BZ999
February C0001 ~ C9999 D0001 ~ DZ999
March E0001 ~ E9999 F0001 ~ FZ999
April G0001 ~ G9999 H0001 ~ HZ999
May J0001 ~ J9999 K0001 ~ KZ999
June L0001 ~ L9999 M0001 ~ MZ999
July N0001 ~ N9999 P0001 ~ PZ999
August Q0001 ~ Q9999 R0001 ~ RZ999
September S0001 ~ S9999 T0001 ~ TZ999
October U0001 ~ U9999 V0001 ~ VZ999
November W0001 ~ W9999 X0001 ~ XZ999
December Y0001 ~ Y9999 Z0001 ~ ZZ999
(a) Engine Model Name : V3600
(b) Year : 8indicates 2008
(c) Month : Aor Bindicates January
(d) Lot number : (0001 ~ 9999 or A001 ~ Z999)

G-3
V3-E3B SERIES, V3-E3CB SERIES, V3-E3BG SERIES, WSM G GENERAL
[2] E3B ENGINE
[Example : Engine Model Name V3600-E3B-XXXX]
The emission controls previously implemented in various countries to prevent air pollution will be stepped up as
Non-Road Emission Standards continue to change. The timing or applicable date of the specific Non-Road Emission
regulations depends on the engine output classification.
Over the past several years, Kubota has been supplying diesel engines that comply with regulations in the
respective countries affected by Non-Road Emission regulations. For Kubota Engines, E3B will be the designation
that identifies engine models affected by the next emission phase (See the table below).
When servicing or repairing ###-E3B series engines, use only replacement parts for that specific E3B engine,
designated by the appropriate E3B Kubota Parts List and perform all maintenance services listed in the appropriate
Kubota Operator's Manual or in the appropriate E3B Kubota Workshop Manual. Use of incorrect replacement parts
or replacement parts from other emission level engines (for example: E2B engines), may result in emission levels out
of compliance with the original E3B design and EPA or other applicable regulations.Please refer to the emission label
located on the engine head cover to identify Output classification and Emission Control Information. E3B engines are
identified with "ET" at the end of the Model designation, on the US EPA label. Please note : E3B is not marked on the
engine.
W1031971
[3] CYLINDER NUMBER
The cylinder numbers of kubota diesel engine are designated as
shown in the figure.
The sequence of cylinder numbers is given as No.1, No.2, No.3
and No.4 starting from the gear case side.
W1011077
Category (1) Engine output classification EU regulation
K From 19 to less than 37 kW STAGE ΙΙΙA
J From 37 to less than 75 kW STAGE ΙΙΙA
I From 75 to less than 130 kW STAGE ΙΙΙA
Category (2) Engine output classification EPA regulation
ET
Less than 19kW Tier 4
From 19 to less than 56 kW Interim Tier 4
From 56 to less than 75 kW Tier 3
From 75 to less than 130 kW Tier 3
(1) EU regulation engine output classification category
(2) “E3B” engines are identified with “ET” at the end of the Model designation, on
the US EPA label.
“E3B” designates Tier 3 and some Interim Tier 4 / Tier 4 models, depending on
engine output classification.

G-4
V3-E3B SERIES, V3-E3CB SERIES, V3-E3BG SERIES, WSM G GENERAL
2. GENERAL PRECAUTIONS
• During disassembly, carefully arrange removed parts in a clean
area to prevent confusion later. Screws, bolts and nuts should be
replaced in their original position to prevent reassembly errors.
• When special tools are required, use KUBOTA genuine special
tools. Special tools which are not frequently used should be
made according to the drawings provided.
• Before disassembling or servicing live wires, make sure to
always disconnect the grounding cable from the battery first.
• Remove oil and dirt from parts before measuring.
• Use only KUBOTA genuine parts for parts replacement to
maintain engine performance and to ensure safety.
• Gaskets and O-rings must be replaced during reassembly.
Apply grease to new O-rings or oil seals before assembling.
• When reassembling external or internal snap rings, position them
so that the sharp edge faces against the direction from which
force is applied.
• Be sure to perform run-in the serviced or reassembled engine.
Do not attempt to give heavy load at once, or serious damage
may result to the engine.
W1011734
(1) Grease
(2) Force
(3) Place the Sharp Edge against the
Direction of Force
(A) External Snap Ring
(B) Internal Snap Ring

G-5
V3-E3B SERIES, V3-E3CB SERIES, V3-E3BG SERIES, WSM G GENERAL
3. MAINTENANCE CHECK LIST
To maintain long-lasting and safe engine performance, make it a rule to carry out regular inspections by following
the table below.
[V3600-E3B, V3600-T-E3B, V3600-E3CB, V3600-T-E3CB, V3300-E3BG, V3600-T-E3BG]
* The items listed above (* marked) are registered as emission related critical parts by KUBOTA in the U.S.EPA
nonroad emission regulation.
As the engine owner, you are responsible for the performance of the required maintenance on the engine according
to the above instruction.
W1029462
Item
Service Interval
Initial
50 hrs
Every
50 hrs
Every
250
hrs
Every
500
hrs
Every
1000
hrs
Every 1
or 2
months
Every
1500
hrs
Every
3000
hrs
Every
1 year
Every
2
years
Changing engine oil ,, ,
Replacing oil filter cartridge ,,
*Checking fuel hoses and clamps ,
*Cleaning air filter element
(Replace the element after 6 times cleanings) ,
*Cleaning fuel filter ,
Checking battery electrolyte level ,
Checking radiator hoses and clamps ,
*Checking intake air line ,
Checking fan belt tension and damage ,,
*Replacing fuel filter cartridge ,
Replacing fan belt ,,
Cleaning radiator interior ,
Checking valve clearance ,
Recharging battery ,
*Checking injection nozzle condition ,
*Checking turbocharger ,
Checking fuel injection pump ,
*Checking injection timing (spill timing) ,
*Replacing air filter element ,
Changing radiator coolant (L.L.C.) ,
Replacing radiator hoses and clamps ,
*Replacing fuel hoses and clamps ,
*Replacing intake air line ,
Replacing battery ,

G-6
V3-E3B SERIES, V3-E3CB SERIES, V3-E3BG SERIES, WSM G GENERAL
[V3800DI-T-E3B, V3800DI-T-E3CB, V3800DI-T-E3BG]
* The items listed above (* marked) are registered as emission related critical parts by KUBOTA in the U.S.EPA
nonroad emission regulation.
As the engine owner, you are responsible for the performance of the required maintenance on the engine according
to the above instruction.
W1026550
Item
Service Interval
Initial
50 hrs
Every
50 hrs
Every
250
hrs
Every
500
hrs
Every
1000
hrs
Every 1
or 2
months
Every
1500
hrs
Every
3000
hrs
Every
1 year
Every
2
years
Changing engine oil ,, ,
Replacing oil filter cartridge ,,
*Checking fuel hoses and clamps ,
*Cleaning air filter element
(Replace the element after 6 times cleanings) ,
*Cleaning fuel filter ,
Checking battery electrolyte level ,
Checking radiator hoses and clamps ,
*Checking intake air line ,
Checking fan belt tension and damage ,,
*Replacing fuel filter cartridge ,
Replacing fan belt ,,
Cleaning radiator interior ,
Checking valve clearance ,
Recharging battery ,
*Checking injection nozzle condition ,
*Checking turbocharger ,
Checking fuel injection pump ,
*Checking injection timing (spill timing) ,
*Replacing air filter element ,
Changing radiator coolant (L.L.C.) ,
Replacing radiator hoses and clamps ,
*Replacing fuel hoses and clamps ,
*Replacing intake air line ,
Replacing battery ,

G-7
V3-E3B SERIES, V3-E3CB SERIES, V3-E3BG SERIES, WSM G GENERAL
QNOTE
Engine Oil :
•Refer to the following table for the suitable American Petroleum Institute (API) classification of engine oil
according to the engine type (with internal EGR, external EGR or non-EGR) and the Fuel Type Used :
(Low Sulfur, Ultra Low Sulfur or High Sulfur Fuels).
EGR : Exhaust Gas Re-circulation
W1024941
•CJ4 classification oil is intended for use in engines equipped with DPF (Diesel Particulate Filter) and is Not
Recommended for use in Kubota E3 specification engines.
•Oil used in the engine should have API classification and Proper SAE Engine Oil Viscosity according to
the ambient temperatures where the engine is operated.
•With strict emission control regulations now in effect, the CF-4 and CG-4 engine oils have been developed
for use with low sulfur fuels, for On-Highway vehicle engines. When a Non-Road engine runs on high
sulfur fuel, it is advisable to use a "CF or better" classification engine oil with a high Total Base Number
(a minimum TBN of 10 is recommended).
Fuel :
•Cetane Rating : The minimum recommended Fuel Cetane Rating is 45. A cetane rating greater than 50 is
preferred, especially for ambient temperatures below −20 °C (−4 °F) or elevations above 1500 m (5000 ft).
•Diesel Fuel Specification Type and Sulfur Content % (ppm) used, must be compliant with all applicable
emission regulations for the area in which the engine is operated.
•Use of diesel fuel with sulfur content less than 0.10 % (1000 ppm) is strongly recommended.
•If high-sulfur fuel (sulfur content 0.50 % (5000 ppm) to 1.0 % (10000 ppm)) is used as a diesel fuel, change
the engine oil and oil filter at shorter intervals. (approximately half)
•DO NOT USE Fuels that have sulfur content greater than 1.0 % (10000 ppm).
•Diesel fuels specified to EN 590 or ASTM D975 are recommended.
• No.2-D is a distillate fuel of lower volatility for engines in industrial and heavy mobile service. (SAE J313
JUN87)
•Since KUBOTA diesel engines of less than 56 kW (75 hp) utilize EPA Tier 4 and Interim Tier 4 standards,
the use of low sulfur fuel or ultra low sulfur fuel is mandatory for these engines, when operated in US EPA
regulated areas. Therefore, please use No.2-D S500 or S15 diesel fuel as an alternative to No.2-D, and use
No.1-D S500 or S15 diesel fuel as an alternative to No.1-D for ambient temperatures below −10 °C (14 °F).
1) SAE : Society of Automotive Engineers
2) EN : European Norm
3) ASTM : American Society of Testing and Materials
4) US EPA : United States Environmental Protection Agency
5) No.1-D or No.2-D, S500 : Low Sulfur Diesel (LSD) less than 500 ppm or 0.05 wt.%
No.1-D or No.2-D, S15 : Ultra Low Sulfur Diesel (ULSD) 15 ppm or 0.0015 wt.%
Fuel Type
Engine oil classification (API classification)
Engines with non-EGR
Engines with internal EGR Engines with external EGR
High Sulfur Fuel
[0.05 % (500 ppm) ≤
Sulfur Content <
0.50 % (5000 ppm)]
CF
(If the "CF-4, CG-4, CH-4, or CI-4" engine
oil is used with a high-sulfur fuel, change
the engine oil at shorter intervals.
(approximately half))
–
Low Sulfur Fuel
[Sulfur Content <
0.05 % (500 ppm)] or
Ultra Low Sulfur Fuel
[Sulfur Content <
0.0015 % (15 ppm)]
CF, CF-4, CG-4, CH-4 or CI-4
CF or CI-4
(Class CF-4, CG-4 and CH-4 engine oils
cannot be used on EGR type engines.)

G-8
V3-E3B SERIES, V3-E3CB SERIES, V3-E3BG SERIES, WSM G GENERAL
4. CHECK AND MAINTENANCE
[1] DAILY CHECK POINTS
Checking Engine Oil Level
1. Level the engine.
2. To check the oil level, draw out the dipstick (1), wipe it clean,
reinsert it, and draw it out again.
Check to see that the oil level lies between the two notches.
3. If the level is too low, add new oil to the specified level.
IMPORTANTQ
• When using an oil of different maker or viscosity from the
previous one, drain old oil. Never mix two different types of
oil.
NOTEQ
• Be sure to inspect the engine, locating it on a horizontal
place. If placed on gradients, accurately, oil quantity may
not be measured.
• Be sure to keep the oil level between upper and lower limits
of the dipstick. Too much oil may cause a drop in output or
excessive blow-by gas. On the closed breather type engine
in which mist is sucked through port, too much oil may
caused oil hammer. While too little oil, may seize the
engine’s rotating and sliding parts.
W1035676
(1) Dipstick (a) Maximum
(b) Minimum
