Kubota 7780 User manual

CERTIFIED
KUBOTAMFG.CORP.
7780
7780
F
Th
sw
sp
op
the
High Speed Refrigerated
Centrifuge
rinted in Japan
m
7780-8P英文05.5.2511:36AMページ1

CERTIFIED
KUBOTAMFG.CORP.
Max. 22,000 rpm/52,490 xg
Max. 4 Liters
Foot switch(Optional)
The lid opens automatically when the
switch is pressed. A newly designed gas
spring produces smooth and quick
opening, while hands-free opening makes
the experiments easier.
Features
■High Capacity Rotor
Aluminium Rotor of 4 x 1 Liter at 15,760 xg
■Auto Interlock Lid
Lid can be opened/closed using one hand.
•To close lid
Push slightly and the lid locks automatically by an electrical
interlock system
•To open lid
Press the lid open key and the lid opens automatically after
releasing the interlock.
A foot switch (optional) also enables hands-free lid opening.
■Easy-to-use and convenient functions
•Memory flashing function for easy spin-down (Patent pending)
Automatically memorizes the duration of spin-down operation
ranging from 1 to 90 seconds. Merely pressing the key the
next time starts the spin-down procedure for the memorized
duration.
•Twenty (20) operation condition memory settings are
available, with one-touch saving, access and operation
possible.
•Equipped with a tachometer port to comply with GMP
requirements. Actual rotor speed is easy to check.
•Acceleration and deceleration curve can be varied in three
steps according to the type of sample and experimental
conditions.
•RCF (xg)-set operation function and stepped centrifugal force
function
•Integrator function that can attain optimization of centrifuging
conditions. G·sec value (integrated RCF value) can be
measured and the operation with this value set is possible.
•The timer can be set up to 990 minutes or seconds. During
hold operation, the elapsed time of operation is displayed.
•Pre-cooling function enables the rotor to reach low
temperatures before the experiments.
AG-1K4 Fixed Angle Rotor
4x1Liter
Light weight (made of Aluminium)
(30% less than AG-5006 6x500mL in weight)
7780-8P英文05.5.2511:37AMページ1

“SPEED” display
“MEMORY”
display
“TIME” display
“SPEED” knob “TIME” knob
“PROGRAM” key“TEMP LIMIT” lamp
“TIME” key
“STEP” key
“ACCEL” key “PROGRAM” selection key
“Pre-cooling” key “DECEL” key
“NORMAL” key
“FLASHING” key “STOP” key
“OPEN” key “OPEN” lamp
“START” key
“TEMP” knob“TEMP” display
Rapid deceleration
Rapid acceleration
Slow acceleration
Super slow acceleration
Slow deceleration
Super slow deceleration
(Natural deceleration)
Time
• For the super slow acceleration and the super slow deceleration,
a characteristic change-over speed Na and Nb can be set from
0 to 22,000 rpm.
• Natural deceleration starts at the chan
g
e-over speed Nb.
rpm
Speed
1,000
64cm width, 78cm depth, 86cm Height.
Acceleration and deceleration
characteristics
Acceleration and deceleration curves can be varied in three
steps according to the type of sample and experimental
conditions.
Acceleration and/or deceleration commencement speed can
be selected for the sample easy to stir.
Density gradient method is also possible.
http://www.centrifuge.
29-9 Hongo 3-chome, Bunkyo
Tel [phone] Fax +81
E-mail: [email protected]
Note: This catalogue is not for distribution in
products shown are not for sale in these coun
For yo
the ins
operat
Always discontinue
use when
phenomena listed
at right appear.
Safety
Precautions
DISCONTINUE
USE
(✳1) Those of projections are not included.
All specifications and external appearance subjec
* On Model 7780 only use KUBOTA made rotor
* The rotor mentioned in the catalogue is usable o
* Follow instructions given in the relevant Instruc
Specifications
Model
Maximum Speed
Maximum RCF
Maximum Capacity
Control system
abnormality detected display
Acceleration / Deceleration
Speed setting
Speed indication
RCF setting
RCF indication
Integrator setting and indication
Timer setting and indication
Temperature setting and indication
Refrigerant
Power requirements
Rated voltage and Rated current
Power consumption and Heat output
Dimensions, weight
Test standard
■Safety pursued
•7780 conforms to International safety standard IEC 61010-2-
020.
•The various alarm detector sensors secure operation. When
the alarm is detected, the operation stops.
•Safety is increased by a rotor setup condition sensor that
detects whether or not the rotor is properly set on the driver
shaft. (Patent pending)
•Automatic rotor identification. (Patented, Patent pending)
Rotor type is automatically identified.
■Sample temperature kept at 4°C
(At the ambient temperature of 25°C. Please refer to the rotor.)
■Design incorporates friendliness to the
global environment and recycling
A limited amount of plastic is used to reduce the load on the
environment.
Acceleration/deceleration characteristics graph
7780-8P英文05.5.2511:32AMページ1

High RCF 36,530 xg ~ 21,000 xg Fixed Angle Rotor
Sealing Adaptor fo
250mL~1,000mL
Cap support structure enables high g-force centrifugation without tube breakage. (excluding AG-6512C) (Patent pending)
High g-force enables separation of sticky protein.
Speed down or special tube is not necessary to prevent tube from breakage.
Plate Rotor
Shield cover is useful for prevention against contamination.
Useful for DNA extraction & purification, ethanol precipitation, purification of PCR product in PCR plate, elimination
of Dye-terminator.
●50 mL conical tube (PP) with cap of 36 mm diameter or less made by BIO-BIK, CORNING, FALCON, GREINER, IWAKI, NUNC
and SARSTEAD can be accommodated. 35 mL Oak ridge conical tube (PC, PPCO) made by NALGE NUNC is acceptable.
●AG-508CA can accommodate 15 mL conical tubes (PP) made by BIO-BIK, CORNING, FISHER and GREINER. AG-6512C can
accommodate 15 mL conical tube (PP) made by any company.
12x96wellplate 4xdeepwellplate 2deepwellplate+
filterplate
4xsquarewellplate 2xPCRplate
Tray Code No.055-6380(Optional)
CodeNo.＊Nominal
Capacity
10mL
055-4280 Oakridge
typetube
50mL
055-4290 Oakridge
typetube
055-4510 250mL
Bottle
HighSpeedRotor
AG-506R・AG-508R・AG-1008A・
AG-5004・AG-5006
AG-6512C＊3
12x50mLConicaltube 30x117 11,500 21,000 11,500 21,000
12x15mLConicaltube 17x121 11,500 17,590 11,500 17,590
AG-508CA
8x50mLConicaltube 30x117 16,500 36,530 15,200 30,990
8x15mLConicaltube＊17x121 16,500 35,920 15,200 30,480
Atkeeping4℃＊
Tubesize Max.Speed Max.RCF Max.Speed Max.RCF
diam.xlengthmm rpm xg rpm xg
RS-751GS
12xmicroplate
4xdeepwellplate 86(W)x128(D)x90(H) 5,000 4,390
Max.SizeofPlate Max.Speed Max.RCF
mm rpm xg
＊showing maximum speed and RCF when keeping the sample
at 4°C. (At the ambient temperature 25°C)
＊Adaptor (Code No.055-1250) is necessary.
＊Tray(CodeNo.055-6380)isnecessary.
RS-745GS
12xmicroplate
4xdeepwellplate 86(W)x128(D)x90(H) 4,200 3,100
RMP-89G
8xmicroplate
4xdeepwellplate 86(W)x130(D)x89(H) 2,400 1,080
＊Tray(CodeNo.055-6380)isnecessary.
＊Tray(CodeNo.055-6370)isavailable(optional).
withshieldcover
withshieldcover
＊3,7
＊3,7
＊AdaptorismadeofPolyathetaleandthe
FEP:TeflonFEP,PSF:Polysulfone,PC:
7780-8P英文05.5.2511:32AMページ2

Sealing Adaptor for Biohazard-proof
250mL~1,000mL Large Volume Fixed Angle Rotor
on
UNC
can
Available for 10 mL and 50 mL Oak
ridge type tubes and 250 mL
bottles.
Autoclavable (121°C).
●Tube adaptor is available for various capacities.
As for details, please contact your dealer.
●Tube adaptor is available for various capacities.
As for details, please contact your dealer.
●Tube adaptor is available for various capacities.
As for details, please contact your dealer.
Sealing adaptor for high
speed fixed angle rotor
for10mLOakridgetypetube
CodeNo.055-4280
CodeNo.＊Nominal Tube Tubesize Rotor Max.Speed Max.RCF
Capacity Diaxlengthmm rpm xg
10mL FEP3114-0010 16.0x81.5 AG-506R 22,000 49,240
055-4280 Oakridge PSF3115-0010 16.0x82.0
typetube PC3118-0010 16.1x81.7 AG-508R 19,000 41,170
PPCO3119-0010 16.0x81.4
50mL FEP3114-0050 28.8x107.7
055-4290 Oakridge PSF3115-0050 29.0x107.7 AG-1008A 15,500 34,110
typetube PC3118-0050 28.8x107.0
PPCO3119-0050 28.8x106.7
055-4510 250mL PPCO3120-0250 61.8x127.7 AG-5004 11,000 20,160
Bottle PC3122-0250 61.8x127.6 AG-5006 10,000 18,450
for50mLOakridgetypetube
CodeNo.055-4290
for250mLbottle
CodeNo.055-4510
HighSpeedRotor
AG-506R・AG-508R・AG-1008A・
AG-5004・AG-5006
Atkeeping4℃＊
Tubesize Max.Speed Max.RCF Max.Speed Max.RCF
diam.xlengthmm rpm xg rpm ×g
AG-2506
6x250mL 60〜62.4x119〜137 13,000 26,830 12,500 24,810
7m
AG-5004
4x500mL 69〜70.2x155〜170.5 11,000 20,700 11,000 20,700
AG-5006
6x500mL 69〜70.2x155〜170.5 10,000 18,890 10,000 18,890
＊showing maximum speed and RCF when keeping the sample
at 4°C. (At the ambient temperature 25°C)
0
0
0
0
CF
0
CF
mple
ssary.
0
0
ssary.
ional).
＊2,3
AG-1K4
4x1,000mL 95.5x198.5 9,000 15,760 9,000 15,760
＊3
＊2,3
＊AdaptorismadeofPolyathetaleandthecapofacrylic
FEP:TeflonFEP,PSF:Polysulfone,PC:Polycarbonate,PPCO:Polypropylenecopolymer
7780-8P英文05.5.2511:34AMページ2

7mL~100mL Middle Volume Fixed Angle Rotor
AG-716
16x7mL 15.9〜16.4x60〜64 22,000 48,700 21,000 44,370
AG-1212
12x12mL 15.9〜16.4x103〜109 22,000 51,950 20,500 45,100
AG-1224
24x12mL 15.9〜16.4x103〜105 18,500 42,860 17,000 36,190
AG-506R
6x50mL 28.7〜29x103〜109 22,000 52,490 19,500 41,240
AG-508R
8x50mL 28.7〜29x103〜109 19,000 43,590 17,000 34,900
AG-1008A
8x100mL 38x114 15,500 35,190 14,000 28,710
RA-360G
24x15mL 16x126 3,500 2,270 3,500 2,270
＊3
＊2,3
＊1,3
＊3
Micro
Swing
＊showing maximum speed and RCF when keeping the sample
at 4°C. (At the ambient temperature 25°C)
e
✽1The RCF figure
As to RCF of th
✽2Sealing cap an
your dealer for
✽3Please confirm
✽4RS-410G can
✽5S17019 tube ra
12x15 mL coni
Atkeeping4℃＊
Tubesize Max.Speed Max.RCF Max.Speed Max.RCF
diam.xlengthmm rpm xg rpm ×g
●Tube adaptor is available for various capacities.
As for details, please contact your dealer.
●Tube adaptor is available for various capacities.
As for details, please contact your dealer.
●Tube adaptor is available for various capacities.
As for details, please contact your dealer.
＊2
＊2
7780-8P英文05.5.2511:36AMページ2

RS-35G swinging bucket rotor
16x2mL 9.5〜11.0x36〜42 15,000 18,360 053-5130 ―
4x0.5mL 7.0〜7.9x25〜34 15,000 16,100 053-5130 ―
20x0.5mL 7.0〜7.9x25〜34 15,000 16,100 053-5140 ―
36x0.4mL 5.4〜6.1x26〜48 15,000 18,360 053-5150 ―
16x0.2mLPCR 5.9〜6.3x20〜24 15,000 11,820 053-5130 055-0500
RA-159G
72x2mL 9.5〜11.0x36〜42 13,500 24,250 ― ―
72x0.5mL 7.0〜7.9x25〜34 13,500 24,040 ― 055-7590
72x0.4mL 5.4〜6.1x26〜48 13,500 23,640 ― 055-7580
72x0.2mLPCR 5.9〜6.3x20〜24 13,500 20,580 ― 055-0500
44,370
45,100
36,190
41,240
34,900
28,710
2,270
Micro Rotor
Swinging Bucket Rotor
AG-224
24x2mL 9.5〜11.0x36〜42 22,000 44,370 ― ―
24x0.5mL 7.0〜7.9x25〜34 22,000 39,500 ― 055-7590
24x0.4mL 5.4〜6.1x26〜48 22,000 43,830 ― 055-7580
24x0.2mLPCR 5.9〜6.3x20〜24 15,000 16,100 ― 055-0500
＊3
＊3
＊1
＊1
＊1
＊1
g the sample
RS-1400GA
4x250/350mL 67〜71x100〜128 5,000/4,000 4,810/3,080 ― ―
RS-200G
4x50mL 28.7〜29x103〜109 11,500 20,700 ― ―
48x2mL 10.7x42 5,000 4,160 attachedtorotor S17008
48x5mLRIAtube 12.5x55〜75 5,000 4,160 attachedtorotor S17006
48x7mL 12〜12.5x100〜112 5,000 4,160 attachedtorotor S17007
28x7mLbloodcollectingtube 12.5〜13x75〜106 5,000 4,160 attachedtorotor S17027
12x15mLConicaltube 16.5x120.6 5,000 4,160 attachedtorotor S17019
12x15mLConicaltube 16.5x120.6 5,000 4,470 S13130 ―
28x10mLbloodcollectingtube/15mL 15.5〜17x87〜110 5,000 4,160 attachedtorotor S17015
4x50mL 34x110 5,000 4,160 attachedtorotor S17050
4x50mL 27〜35.8x82〜110 5,000 4,160 attachedtorotor 055-5670
4x50mLConicaltube 29.5x117 5,000 4,160 attachedtorotor S17049
4x100mL 44〜45x110 5,000 4,160 attachedtorotor S17100
4x200mL 56.5x104 5,000 4,160 attachedtorotor ―
80x2mL 9.5〜11x36〜42 3,500 2,290 053-5820 055-4800
96x6mLRIAtube 10〜12.3x65〜95 3,500 2,190 053-5820 055-4730
80x10mL 12.5〜13.8x65〜95 3,500 2,260 053-5820 055-4740
4 8x10mLbloodcollectingtube/15mL 15〜17.2x81〜110 3,500 2,330 053-5820 055-4750
68x5/7mLbloodcollectingtube
12.5〜13.7x62〜110 3,500 2,300 053-5840 055-0260
6 8x10mLbloodcollectingtube/15mL 15〜17.2x52〜110 3,500 2,300 053-5840 ―
28x15mLConicaltube 17x121 3,500 2,300 053-5840 ―
32x15mLConicaltube 17x121 3,500 2,330 053-5820 055-4780
8x50mL 27〜36.4x85〜110 3,500 2,330 053-5820 055-4760
16x50mLConicaltube 30x117 3,500 2,330 053-5820 055-6070
4x100mL 38〜46.5x75〜120 3,500 2,330 053-5820 055-4770
4x175mLConicaltube 61x118 3,500 2,330 053-5820 055-4850
4x200mLConicaltube 61x130 3,500 2,330 053-5820 055-4850
4x225mLConicaltube 61x137 3,500 2,330 053-5820 055-4850
4x250mL 60〜61.8x100〜130 3,500 2.380 053-5820 055-4850
RS-410G
RS-720G
✽1The RCF figure shows RCF of the outer tube.
As to RCF of the inside, please contact your local dealer.
✽2Sealing cap and sealing adaptor for bio-hazard proof are available. Please contact
your dealer for details.
✽3Please confirm the delivery schedule with your dealer.
✽4RS-410G can accommodate sealing cap (Code No.S17111) (optional).
✽5S17019 tube rack cannot be accommodated with the sealing cap. Code No.S13130
12x15 mL conical bucket can accommodate sealing cap (Code No.S17111) (optional).
✽6175 mL conical tube is made by Falcon (Catalog No.352076) and requires a cushion (Catalog No.352090).
200 mL conical tube is made by Nalge Nunc (Catalog No. 376813) and requires a cushion
(Catalog No.377585).
225 mL conical tube is made by Falcon (Catalog No.352075) and requires a cushion (Catalog No.352090).
✽7Please check the strength of plates before using the centrifuge. The plate at the bottom may be damaged.
✽8As to RCF display, please refer to Instruction and Service manual.
✽9INSEPACK II 5/7 mL of Sekisui, VENOJECT II 5/7 mL of Terumo, NEOTUBE 5/7 mL of Nipro and
VACUTAINER 5/7 mL of Beckton Dickenson can be used.
Sealing cap is available and is biohazard-proof. Autoclavable (121°C)
＊3
＊3,4
＊3
＊5
＊5
＊9
＊8
＊8
＊8
＊8
＊6,8
＊6,8
＊6,8
g4℃＊
Max.RCF
×g
TubeRack
Tubesize Max.Speed Max.RCF Bucket Adaptor
diam.xlengthmm rpm xg CodeNo. CodeNo.
●Tube adaptor is available for various capacities.
As for details, please contact your dealer.
7780-8P英文05.5.2511:37AMページ2

http://www.centrifuge.jp
Copyright © 2005 KUBOTA CORPORATION F4, Printed in Japan
29-9 Hongo 3-chome, Bunkyo-ku, Tokyo 113-0033, Japan
Tel [phone] Fax [phone]
E-mail: [email protected]
Note: This catalogue is not for distribution in the USA, Canada, Mexico and Australia as
products shown are not for sale in these countries.
For your safe use of the equipments, be sure to read
the instruction manual carefully before you start its
operation.
Always discontinue
use when
phenomena listed
at right appear.
IMPORTANT
To prevent occurrences of functional failures or accidents,
turn off the power switch, pull out the power cable plug from
the plug socket and be sure to contact your nearest Kubota
Dealer, or an office of Kubota Corporation when there is no
Kubota Dealer in your neighbourhood.
Parts may be adversely affected by heat, humidity and specimens or
deteriorated by aging resulting in functional failures or may even lose their
safety characteristic to cause accidents.
•The rotor or bucket has been found to be damaged or corroded.
•A burnt smell comes out of the equipment.
•You receive a minor electrification when you touch the
equipment body by a naked hand.
•Some other abnormality or failure has been found occurring.
Safety
Precautions
DISCONTINUE
USE
(✳1) Those of projections are not included.
All specifications and external appearance subject to change without notice.
* On Model 7780 only use KUBOTA made rotor, adapter and tube rack. Do not attempt use rotors, adapters or tube racks made by other manufacturers.
* The rotor mentioned in the catalogue is usable on other KUBOTA centrifuge models. For details, refer to the catalogues relevant to each model.
* Follow instructions given in the relevant Instruction & Service Manual for operating centrifuges.
Specifications
Model 7780
Maximum Speed¡22,000rpm
Maximum RCF¡52,490xg
Maximum Capacity¡4,000mL
Control system¡Micro-processor control (Brushless motor)
Speed, RCF, Time, g·sec, Temperature, Acceleration & Deceleration, 20 channel memories
abnormality detected display¡Lid open, Imbalance, Over speed, Abnormally high temperature, Rotor mounting abnormality
Function for detecting an occurrence of electrical abnormality in motor, inverter,
lid interlock, speed sensor and temperature sensor.
Acceleration / Deceleration¡Three-level selectors; Rapid, Slow and Super Slow
Speed setting¡From 300 to 22,000rpm, 10rpm increments
Speed indication¡Digital display, From 0 to 22,500rpm, 10rpm increments
RCF setting¡From 10 to 52,490xg, 10xg increments
RCF indication¡Digital display, From 0 to 54,900xg, 10xg increments
Integrator setting and indication¡Digital display, From 1.00 to 9.99x109g·sec
Timer setting and indication¡Digital display, with Hold and Memory Flashing
from 1 sec to 100 sec, in 1 sec increment
from 100 sec to 990 sec, in 10 sec increments
from 1 min to 100 min, in 1 min increment
from 100 min to 990 min, in 10 min increments
Temperature setting and indication¡Digital display, 1˚C increments, Pre-cooling
Temperature setting range –20˚C to +40˚C
Temperature indication –20˚C to +43˚C
Refrigerant¡R 404A
Power requirements¡Single phase AC220V±10%, 230V±10%, 50/60Hz, 30A
Rated voltage and Rated current¡220/230V, 50/60Hz, 12A
Power consumption and Heat output¡3500W, 13MJ/h
Dimensions, weight¡64(W) x 78(D) x 86(H)cm✳1, 235kg
Test standard¡IEC 61010-2-020 Class 1
7780-8P英文05.5.2511:34AMページ1
