Kuppersbusch B6335.0 User manual

BEDIENUNGSANWEISUNG
INSTRUCTIONS FOR USE
B6335.0
B6330.0
B6120.0
H6120.0
Lesen Sie unbedingt die Gebrauchsanleitung vor
Aufstellung und Inbetriebnahme.
Bitte bewahren Sie diese Anleitung sorgfältig auf.
Please read the users instructions carefully before
installation of the appliance and before starting to use
it. Please, store these instructions carefully.
Service und Kundendienst
Telefon: 0209 – 401 631
Email: [email protected]
DE EN ES FR NL IT PT GR

18 User’s Guide
Safety Warnings
General advice
Follow ALL the safety warnings!
Caution, Danger of overheating!
When using the oven, do not cover the bottom with aluminium foil
or place pots, frying pans or the like inside. If this happens, the
oven will overheat, causing damage to the enamel.
• The oven becomes hot when in use. The cooling fan turns on when the oven overheats. The
cooling fan will remain on until the oven has cooled down, even after the appliance has been
turned off. The noises made by the fan are normal and do not mean that it is damaged.
• When preparing a dish with alcohol or yeast with settings that use hot air, there may be a
vinegary smell. If the smell is unpleasant, use a function that does not include the fan, such as
top/bottom heat.
• The electronic clock features Touch-Control technology. To operate, simply touch the glass
control symbols with your fi ngertip. The touch control sensitivity continuously adapts to
changing conditions. Make sure that the glass surface of the control panel is clean and free of
any obstacles when turning on the oven.
• If the oven does not respond correctly when you touch the glass, you will need to turn off the
oven for a few seconds and then turn it back on after a few seconds. Doing this causes the
sensors to adjust automatically so that they will react once more to fi ngertip control.
Connection and use
• Only KÜPPERSBUSCH hobs have been manufactured and tested for use over a KÜPPERS-
BUSCH oven. Do not use other hobs.
• Any handling or repair to the appliance, including replacement of the feed cable, should be
carried out by authorised Technical Service Personnel using original spare parts. Repairs or
handling by others may damage the appliance or cause malfunctioning that could be hazard-
ous to your safety
• Do not allow children to come near the oven while in use as it can reach very high
temperatures.
• Children should be supervised to ensure they do not play with the appliance.
• This appliance is not for use by persons (including children) with reduced physical, sensorial or
mental capacity, or those lacking experience and knowledge, except if they have been
supervised and instructed regarding use of the device by a person responsible for their safety

19
User’s Guide
english
Oven
• The oven must always be operated with the door closed.
• The manufacturer takes no responsibility for any use of the oven other than for the home
preparation of food.
• Only use the oven after it has been installed inside the kitchen unit.
• Do not store oil, fats or inflammable materials inside the oven. This may be dangerous if the
oven is turned on.
• Do not lean or sit on the open oven door. You could damage it, as well as endangering your
safety.
• In order to cook food in the oven, place the tray or grid shelf supplied with it over the shelf
runners inside the oven cavity. The tray and grid shelf have a system to make their partial
outward movement easy for food handling.
• Do not place containers or food on the bottom surface of the oven. Always use the trays and
grid.
• Do not pour water on the bottom surface of the oven when in use; this may damage the
enamel. Open the oven door as little as possible during cooking. This will reduce power
consumption.
• Use protective oven gloves when performing operations inside the oven.
• It is normal for condensation to occur on the oven door when cooking dishes with a high liquid
content.
Before First Use
• Remove packaging and the old appliance
• Remove packaging and recycle in an environmentally-friendly way.
• By returning the packaging material, raw materials are saved and also fewer waste products
are generated. Old appliances still contain valuable material. Leave your old appliance at a
collection point for valuable materials. Old appliances must be rendered inoperative before
disposing of them in order to prevent improper use.
Technical information
If you need to contact the after-sales service or order
spare parts, you must provide the technical information
supplied.
The oven’s technical information is on the right, on
the side frame. You can see it when the door is open.

20 User’s Guide
Cleaning and Care
Please read this chapter before using the appliance for the fi rst time.
If it is cleaned as it should be and regularly cared for, the oven should stay beautiful and as good
as new for many years. Here is a series of instructions that allow you to care for and clean all of
the surfaces thoroughly, without damaging them.
For all surfaces
Danger of death!
Do not use steam and/or pressure cleaning devices on the oven.
The appliance could become damaged and may create a situation
where there is danger of death.
Danger of burning!
Leave the appliance to cool until you can touch it with your hand
before cleaning it.
• Clean the appliance after each use. Stains or baked-on food that have not been removed may
burn the next time the appliance heats up. Often, these types of stains or dirt cannot be
removed without leaving marks.
• If there are light stains, clean the surfaces with a cloth, brush or soft sponge and hot water and
some dishwashing detergent. Rinse with cold water so that there is no detergent left which
might decolour the surface or cause more stains. Dry with a cloth immediately after
Here are some instructions for more diffi cult-to-remove stains concerning the different surfaces
and elements.
Never clean with
• aggressive products or bleaches that contain active oxygen,
chlorine or other corrosive ingredients.
• cleaning products that can cause scratches, such as abrasive
agents, steel wool, soapy steel wool, hard brushes, metal
scourers, plastic sponges or sponges with a surface that
scratches (scouring side)

21
User’s Guide
english
Use of the oven
The oven is determined for the cooking, roast, baking, and keeping warm of dishes. In order to
thaw of raw meat or fish the oven may not be used.
Use the oven only if inserted in a suitable piece of furniture. Use the oven exclusively as described
in these instructions for use. Any other use is not in accordance with the requirements and can
lead to material damages or even personal damages. The manufacturer assumes no liability for
damages which have originated from not designated use.
The oven is determined exclusively for the use in the private household. A commercial use is
excluded. The oven is not suited for heating a room. The light in the oven is planned only to the
lighting of the done space and not as a room lighting. The oven door is only the close the oven.
Use the oven only for cooking, roasting, baking, and keeping warm
of dishes!
Scope of delivery
Scope of delivery:
1 × Oven
1 × Enamelled baking tray
1 x Gridiron
Assembly material:
2 × Erection bolts
Accesories:
1 × Instructions for Use
1 × Installation Instrucions

22 User’s Guide
Description of the oven
1Control panel
2Door lock (only for
pyrolytic models)
3Grill element
4Tray supports
5Grid shelf
6Tray
7Hinge
8Inner Glass
9Air cooling outlet
10 Unit mounting
11 Lamp
12 Back Wall Panel
13 Fan
14 Oven Seal
15 Door
1
10
12
13
14
15
5
6
7
8
3
2
4
9
11
Control panel
4Pilot light cooking zone.
5Cooking zone controls.
1Temperature control dial.
2Electric clock/timer.
3Function control dial.
3 2 1
B6335.0 / B6330.0
Models
5 4 3 2 1
H6120.0 Models

23
User’s Guide
english
Oven functions
NOTE
For a description of how to use each of the
features, see the cooking guide that comes
with your oven.
SWITCHING OFF
TOP / BOTTOM HEAT
GRILL
LARGE-AREA GRILL
BOTTOM HEAT
LARGE-AREA GRILL WITH FAN
ÖKOTHERM HOT AIR
FAST PREHEATING
PIZZA-FUNCTION
ECO, for cooking with minimum energy
consumption
DEFROSTING
ÖKOCLEAN@
Control Panel - Sensor keys
B6335.0, B6330.0, B6120.0, H6120.0 Models
Conventional oven cooking functions.

24 User’s Guide
Electronic clock/timer description
1KEYS
, and : Enable you to programme the
electronic clock/timer functions.
2SYMBOLS
Clock Settings
TIMER: Lights up when the clock/
timer is selected. Generates an acoustic
signal when the time is up. The oven does
not turn off at the end of the timer period.
This function can also be used while the
oven is cooking.
and PROGRAMMING: Light up to indi-
cate that the oven is programmed (cooking
time, stop time or total).
• Cooking Time: This function allows you
to programme the cooking time, after which
the oven will turn off automatically.
If a cooking time has been selected and the
oven is switched off manually before the pro-
grammed time has finished, the clock will
continue to display the time until the end of
the process.
• Cooking Stop Time: This setting al-
lows you to programme the time for cook-
ing to stop, after which the oven will turn off
automatically.
• and Cooking Time and Cooking
Stop Time: This setting allows you to pro-
gramme the cooking time and cooking stop
time. The oven switches on automatically at
the set time and operates for the selected
cooking time (Cooking Time). It then switch-
es off automatically at the indicated time
(Cooking Stop Time).
CLOCK/TIMER LOCK: Indicates that the
touch keys for the clock/timer are locked,
preventing modifications by small children.
Other functions
HEATING: Indicates that the oven is trans-
mitting heat to the food.
ÖKOCLEAN: Lights up while the Küppers-
busch ÖkoClean®function is in progress.
WARNING
The sensitivity of the touch keys adapts
continually to environmental conditions.
Make sure the surface of the control panel is
clean and free of obstacles when plugging
in the oven.
If the clock does not respond correctly when
you touch the keys, unplug the oven for a
few seconds and then plug it in again. Doing
this causes the sensors to adjust automati-
cally so that they will react once more to fin-
gertip control.
SETTING THE TIME
• To set the time on the oven, the function and
temperature dials must be in the position.
• When you plug in the oven, you will see the
clock flashing 12:00.
• Touch or to adjust the hours and
then the minutes. You will hear a double
beep confirming the time is set.
• If you wish to modify the time, touch or
until the time starts flashing. Touch
and and follow the instructions in the previ-
ous point.
2 1 2

25
User’s Guide
english
NOTE
The clock light has a night mode so the display
light will dim between 00:00 and 6:00 hours.
WARNING
In the event of a power failure, your elec-
tronic clock/timer settings will be erased.
If this happens, turn the function and tem-
perature dials to the position.
The indication 12:00 will show, and you will
then be able to set the time as described
above.
Use of the oven
MANUAL OPERATION
• After setting the clock, the oven is ready for
use. Select a cooking function and tempera-
ture.
• You will notice that the symbol lights up
during cooking to indicate that heat is being
transmitted to the food. This symbol disap-
pears when the selected temperature has
been reached.
• Set the controls to to turn off the oven.
INFORMATION
When you start cooking, your oven will show
the time the oven has been cooking.
OVEN TIMER OPERATION
Programming the Buzzer
1. Touch or until the symbol on the
display starts flashing, then press . The
indication ‘00:00’ will appear on the display.
2. Select the time after which you want the
alarm to sound by pressing or . You
will hear 2 beeps to confirm that the time has
been set and the clock will start counting
down from the selected time. The symbol
will flash slowly.
3. Once the time has expired, an acoustic
signal will sound for 90 seconds and the
symbol will flash quickly.
NOTE
With the Buzzer function, the oven will not
turn off when the time expires.
4. Touch any key to stop the alarm. The
symbol will then disappear.
If you wish to modify the time on the buzzer,
repeat the steps shown. Upon entering the tim-
er control, the time currently remaining will ap-
pear, which you will be able to adjust.
NOTE
With the Buzzer function, the remaining time
will show permanently on the display. With
this programmed function, it is not possible
to view the time or the total programmed
cooking time.
Programming Cooking Time
1. Touch or until the symbol on the
display starts flashing, then press . The
indication ‘00:00’ will appear on the display.
2.
Select the time after which you want the
alarm to sound by pressing or .
You
will hear 2 beeps to confirm that the time has
been set and the clock will start counting
down from the selected time.The symbol
will flash slowly.

26 User’s Guide
3. Select a function and a cooking temperature
using the oven commands.
4. Once the cooking time is up, the oven will
turn off, an alarm will sound and the
symbol will flash quickly.
5. Touch any key to stop the alarm and turn off
the symbol. The oven will switch on again.
6. Set the controls to the position to turn off
the oven.
You can change the remaining cooking time at
any time by touching or until the
symbol starts to flash quickly. Now press to
change the time.
NOTE
With the Cooking Time function, the
remaining time will show permanently on the
display. You cannot see the current time on
the display when this function is set.
Programming the Cooking Stop Time
1. Touch or until the symbol on the
display starts to flash and press . You will
see the current time on the timer display.
2. Select the time after which you want the
alarm to sound by pressing or . You
will hear 2 beeps to confirm that the time has
been set and the clock will start counting
down from the selected time. The sym-
bol will flash slowly.
3. Select a cooking function and temperature.
4. When the cycle is finished, the oven will turn
itself off, a buzzer will sound and symbol
will flash quickly.
5. Touch any sensor to stop the alarm and to
turn off the , symbol. The oven will switch
on again.
6. Set the controls to the position to turn off
the oven.
You can change the remaining cooking time at
any time by touching or until the
symbol starts to flash quickly. Now press to
change the time.
Programming Cooking Time
and Cooking Stop Time
1. Touch or until the symbol on the
display starts flashing, then press . The
indication ‘00:00’ will appear on the display.
2. Select the cooking time by touching or
. Next, a double beep will sound, the re-
maining time will appear on the display and
the symbol will flash slowly.
3. Touch or until the symbol on the
display starts flashing, then press . You
will see the expected completion time on the
timer display.
4. Select the cooking end time by touching
or . Next, a double beep will sound and the
current time will be displayed on the display.
5. Select a cooking function and temperature.
The oven will remain disconnected with the
and symbols lit up. The oven is now
programmed.
6. When it is time to start cooking, the oven will
turn on and will operate for the programmed
cooking time.
7. While cooking, the cooking time remaining will
be displayed and the symbol will flash
slowly.
8. When the cooking time is up, the oven will
turn off, a buzzer will sound, and the
symbol will flash quickly.
9. Touch any sensor to stop the buzzer and
turn off the symbol. The oven will switch
on again.
10. Set the controls to the position to turn
off the oven.
You can change the remaining cooking time at
any time by touching or until the
symbol starts to flash quickly. Now press to
change the time.

27
User’s Guide
english
Safety functions
SAFETY CHILD LOCK
This function can be selected at any time while
using the oven.
To activate the function, touch and hold
key for several seconds until you hear a beep
and the symbol appears on the display.
The clock/timer is locked.
If the oven is off and you activate the child
safety function, the oven will not work even if a
cooking function is selected.
If this function is activated while you are
cooking, it will only lock the electronic clock/
timer settings.
To disable the function, press key for sever-
al seconds until you hear a beep.
Küppersbusch ÖkoClean® Function
This function makes it easy to remove grease
and other food debris that may have stuck to
the sides of the oven.
For easier cleaning, do not allow dirt to accu-
mulate. Clean the oven frequently.
PROGRAMMING THE
ÖKOCLEAN®FUNCTION
WARNING
Do not pour water into a hot oven as this can
damage the enamel of the oven.
Always run the cycle on a cold oven. The result
could be affected and the varnish damaged if it
is run when the oven is too hot.
First remove the trays and all accessories from
the oven interior, including the tray supports
and telescopic guide rails.
To do this, follow the instructions in the in-
stallation and maintenance guide accom-
panying the oven.
1. With the oven cold, spread a cloth out on the
bottom of the oven.
2. Gently pour 200 ml of water into the bottom
of the oven cavity.
INFORMATION
For best results, add a teaspoon of mild
washing up detergent to the glass of water
before pouring onto the cloth.
3. Turn the control dial to the position.
4. You will hear a beep indicating that the Öko-
Clean®cycle has started. The symbol will
flash slowly and the time remaining to com-
plete the cycle will appear on the display.

28 User’s Guide
IMPORTANT
The duration of this cycle cannot be
changed. To stop the cycle before it is fin-
ished, turn the control dial to the posi-
tion.
5. When the cycle is finished, the oven will turn
itself off, an alarm will sound and the
symbol will flash quickly.
IMPORTANT
Do not open the oven door until the Öko-
Clean®function is complete.
The cooling cycle is necessary for the func-
tion to work properly.
6. Touch any sensor with your fingertip to stop
the alarm and turn off the symbol.
7. Turn the control dial to the position.
8. Any traces of dirt and excess water can now
be removed from the oven with the damp
cloth.
The ÖkoClean®function takes place at a low
temperature. However, cooling times can vary
depending on the room temperature.
WARNING
Before touching the inside surface of the
oven, make sure that it has cooled properly.
If a deeper clean is required after using the
ÖkoClean®function, use neutral detergents
and non-abrasive sponges.

kWh/cycle*
kWh/cycle*
L
*
*
0.68
0.86
70
81
1
31 kg
B6335.0
B6330.0

K01-180191/01
Cod. 3370645-002
Küppersbusch Hausgeräte GmbH
Postfach 10 01 32, D-45801 Gelsenkirchen,
Küppersbuschstraße 16, D-45883 Gelsenkirchen
Telefon: [phone], Telefax: [phone]
www.kueppersbusch.de
Teka Austria GmbH
Eitnergasse 13, A-1230 Wien
Telefon: [phone], Telefax: (01) 86680-50
www.kueppersbusch.at
