Kvaser U100-X1 User manual

Kvaser U100-X1 User’s Guide
Copyright 2020-2021 Kvaser AB, Mölndal, Sweden
https://www.kvaser.com
Printed Sunday 14th November, 2021
We believe that the information contained herein was accurate in all respects at the time of printing.
Kvaser AB cannot, however, assume any responsibility for errors or omissions in this text. Also note
that the information in this document is subject to change without notice and should not be construed
as a commitment by Kvaser AB.

Kvaser U100-X1 User’s Guide 2 (21)
(This page is intentionally left blank.)
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 3 (21)
Contents
1 About this manual 4
2 Introduction 5
2.1 Welcome to Kvaser U100-X1 . . . . . . . . . . . . . . . . . . . . . . 5
2.2 Major features of Kvaser U100-X1 . . . . . . . . . . . . . . . . . . . 6
3 Kvaser U100-X1 hardware 7
3.1 Hardware installation . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2 USB connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.3 CAN connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.4 CAN bus termination . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.5 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.6 LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3.7 Interface mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.8 Updating the firmware . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.9 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4 Troubleshooting 15
5 Safety Instructions 16
5.1 Intended Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5.2 Usage Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
6 Disposal and Recycling Information 17
7 Legal Acknowledgements 18
7.1 EU Regulatory Compliance . . . . . . . . . . . . . . . . . . . . . . . 18
7.2 FCC Regulatory Compliance . . . . . . . . . . . . . . . . . . . . . . 19
7.3 Patents, Copyrights and Trademarks . . . . . . . . . . . . . . . . . . 20
8 Document Revision History 21
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 4 (21)
1 About this manual
This manual is intended for Kvaser U100-X1 users. This document contains a
description of the hardware’s properties and general instructions for connecting the
device to a computer.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 5 (21)
2 Introduction
This section will describe the functions and features of the Kvaser U100-X1.
2.1 Welcome to Kvaser U100-X1
Figure 1: Kvaser U100-X1
Kvaser U100-X1 is a small, yet powerful, CAN to USB interface. It provides
real-time transmission and reception of standard and extended CAN messages on
the bus with a high timestamp precision, and is compatible with applications that
use Kvaser’s CANlib.
This guide applies to Kvaser U100-X1 devices using at least firmware and driver
versions listed in Table 1. For minimum compatible firmware and driver versions of
Kvaser U100-X1 see Table 6 on Page 13.
Device Product Number Firmware Driver (Windows/Linux)
Kvaser U100-X1 73-30130-01266-0 v3.24 v5.36 (kcany/mhydra)
Table 1: Firmware and driver versions needed to support all functionality present in
this guide.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 6 (21)
2.2 Major features of Kvaser U100-X1
•USB CAN interface.
•Powered through the USB connector.
•Supports CAN FD, up to 8 Mbit/s (with correct physical layer implementation).
•Supports both 11-bit (CAN 2.0A) and 29-bit (CAN 2.0B active) identifiers.
•Lightweight robust housing made of glass fibre reinforced polyamide
overmolded with TPE.
•Intuitive LED UI.
•Reinforced galvanic isolation, design validated with 5000 VAC rms applied for
60 s.
•Industrial grade temperature range, −40 ◦C to +85 ◦C.
•20 000 msg/s, each timestamped with a resolution of 100 µs.
•Fully compatible with applications written for other Kvaser CAN hardware
with Kvaser CANlib.
•Support for SocketCAN.
•Fully compatible with J1939, CANopen, NMEA 2000 R
and DeviceNet.
•IP67 rated housing.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 7 (21)
3 Kvaser U100-X1 hardware
In this section you can read more about the CAN channels, power supply and LED
indicators.
3.1 Hardware installation
The Kvaser U100-X1 may be inserted in any free USB socket on the host
computer. You do not need to switch the power off before inserting or removing the
device. For the Kvaser U100-X1 to communicate with the host computer, a
compatible version of the Kvaser driver and firmware must be installed.
The driver is installed by running the file kvaser_drivers_setup.exe . For
instructions on how to update the firmware, see Section 3.8, Updating the
firmware, on Page 13. The latest version of the driver and firmware can be
downloaded from www.kvaser.com/download.
The firmware is downloaded and installed directly on the Kvaser U100-X1 and the
driver is installed on the host computer. After the driver has been installed on the
host computer, the firmware may then be downloaded and installed on the Kvaser
U100-X1.
3.2 USB connection
The USB connector for the Kvaser U100-X1 is a standard USB type “A” connector
(see Figure 2).
Figure 2: A standard USB type “A” connector.
Connect the device to your computer using any high quality USB 2.0 certified
cable. The maximum USB cable length is 5 m (∼16 ft). If you need a longer cable,
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 8 (21)
you can use USB hubs or USB extension cables with a built-in hub. By chaining up
to 5 hubs, you can achieve an effective cable length of up to 25 m (∼82 ft).
As USB cables become longer they are more sensitive to EMI,
because they make a longer antenna that can pick up more
noise. These issues can be mitigated by using higher quality
cables with better shielding. Thicker cables tend to be better than
thin ones, and braided shielding tends to be more reliable than
only foil. Furthermore, longer cables may introduce signal
degradation and timing issues that, if necessary, can be mitigated
using shorter cable segments combined with hubs that amplify
the signal and handle delays on a per-cable basis.
3.3 CAN connection
The Kvaser U100-X1 has one CAN channel.
The CAN connector for the Kvaser U100-X1 is the 9-pin J1939-13 Type II
connector (see Figure 3) which has the pinning described in Table 2 on Page 9.
Figure 3: J1939-13 Type II CAN connector.
Figure 4: J1939-13 Type II Can connector pinout.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 9 (21)
J1939-13 Pin Function
A GND
B Not connected
C CAN_HI
D CAN_LOW
E SHIELD
F-J Not connected
Table 2: J1939-13 Type II pin configuration.
3.4 CAN bus termination
Every CAN bus must be terminated with a 120 Ohm resistor at each end of the
bus. The Kvaser U100-X1 does not contain any CAN bus termination, because
their inclusion could cause severe disturbance in a system which is already
correctly terminated.
For laboratory or testing use, the exact value of the termination resistors is not
always critical. Sometimes a single terminator is sufficient. For production, proper
termination is essential. If you see error frames on the bus, you should check the
termination.
To save yourself a lot of trouble, always terminate the CAN
bus properly.
3.5 Power supply
The Kvaser U100-X1 is powered through the USB connector.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 10 (21)
3.6 LED Indicators
A Kvaser U100-X1 device has two traffic LED bars where part of each LED bar is
also used as a status area. The TX LED Bar has a status area towards the USB
end of the bar, and the RX LED bar has a status area towards the CAN end of the
bar. This is shown in Figure 5.
Figure 5: The TX and RX LED bars on the Kvaser U100-X1 include status areas.
Different colors are used for different types of information and different blink
patterns define the current state, see Table 3 and Table 4 on Page 11.
Color Information type
Yellow Traffic
Green Status
Red Error
White Alert
Blue System
Table 3: Different types of information.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 11 (21)
State Definition
Off The indicator is off and no light is emitted.
Slow Blink The indicator is repeatedly turned on and off. The on and off phases are equal in
time.
Fast Blink The indicator is repeatedly turned on and off but with a higher frequency than Slow
Blink. The on and off times are still equal.
On The indicator is constantly emitting light.
Dynamic The indicator is moving and/or increasing/decreasing in size.
Table 4: Definitions of the indicator states.
3.7 Interface mode
The device is in interface mode when connected to a computer via USB. If the
status area is presenting a steady white light, the device is in interface mode,
working correctly and ready to be used. When connected to a computer for the first
time, the status area will Fast Blink with blue light until the Kvaser Drivers are
installed and the device has automatically received a USB configuration. The
status area will change from white to green when going bus on. Table 5
summarises the information shown in interface mode.
Description Status area LED bar
Power is on On (White) -
Waiting for USB configuration Fast Blink (Blue) -
CAN channel is bus on On (Green) -
CAN channel traffic On (Yellow) Dynamic (Yellow)
Error frame - Dynamic (Red)
CAN channel is error passive Fast Blink (Red) -
CAN overrun On (Red) -
Firmware update Slow Blink (Blue) -
Locate hardware Slow Blink (White) Slow Blink (White)
Table 5: LED inidications in interface mode.
The Kvaser U100-X1 has one TX LED Bar and one RX LED Bar. Each LED Bar
has a status area, the TX LED Bar has a status area towards the USB end of the
bar, and the RX LED bar has a status area towards the CAN end of the bar. This is
shown in Figure 5 on Page 10.
The TX LED bar lit area grows from the USB end of the LED bar towards the CAN
end of the bar as CAN TX traffic is increased. Likewise, the RX LED bar lit area
grows from the CAN end of the LED bar towards the USB end of the bar as the
message rate of the received traffic is increased, see Figure 6 on Page 12. In this
example the unit is transmitting data, which shows a yellow TX status area. No
CAN traffic is received and as such the RX status area is green.
The total size of the LED bars are indicating the current bus load, e.g. Figure 6 on
Page 12 shows only receiving CAN messages at 50% bus load. Figure 7 on
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 12 (21)
Figure 6: The TX LED bar lights up from the USB side to the CAN side of the unit,
while the RX LED bar lights up from the CAN side to the USB side of the unit.
Page 12 shows two different bus load conditions. The image on the left shows the
unit transmitting and receiving data corresponding to 50% bus load in each
direction for a total of 100% bus load. The image on the right shows the unit
transmitting data corresponding to 100% bus load.
Figure 7: The total size of the LED Bars is proportional to the bus load. Both
images indicate a bus load of 100%.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 13 (21)
3.8 Updating the firmware
For the Kvaser U100-X1 to communicate with the host computer, compatible
versions of the Kvaser CANlib (including driver) and firmware must be installed.
The latest versions of firmware and drivers can be downloaded for free at
www.kvaser.com/download.
Connect the Kvaser U100-X1 to your PC with the USB cable and start the
update.exe application. A window opens showing the Firmware Update
Instructions, read and follow those carefully.
To check the current firmware version, open “Kvaser Device Guide” which can be
found in the Control Panel. Select “Kvaser U100-X1” in the tree view to the left,
and click on the channel. The firmware revision information now appears in the
right half of the window.
The absolute minimum firmware and driver versions needed in order to use Kvaser
U100-X1 are listed in Table 6
Device Min. Firmware Version Min. Driver Version
Kvaser U100-X1 v3.22.578 v5.31
Table 6: Minimum compatible driver and firmware versions of Kvaser U100-X1.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 14 (21)
3.9 Technical data
In Table 7 below you will find the Kvaser U100-X1’s technical specifications.
CAN Channels 1
CAN Transceivers ADM3055E (Compliant with ISO 11898-2)
CAN Controller Built into the processor.
Galvanic isolation Yes, reinforced. Design validated with 5000 VAC rms applied for 60 s.
CAN Bit Rate 10 kbit/s to 1 Mbit/s
CAN FD Bit Rate Up to 8 Mbit/s (with correct physical layer implementation).
Time stamp resolution 100 µs
Max message rate 20 000 msg/s per channel
Error Frame Detection Yes
Error Frame Generation No
Silent mode No
Kvaser MagiSync No
Kvaser tprogramming No
Kvaser CANtegrity No
PC interface USB 2.0
Power consumption Typical 250 mA
Software requirements Windows (7 or later), Linux
Dimensions 38 x 128 x 26 mm for body
Cable length USB 1.0 m, CAN 0.3 m
Weight 212 g including connectors
Operating temperature −40 ◦C to +85 ◦C
Storage temperature −40 ◦C to +85 ◦C
Relative humidity 0 % to 85 % (non-condensing)
IP Rating Housing IP67
IP Rating CAN connector IP67 Mated
IP Rating USB connector IP40 Mated
Table 7: Technical Specifications
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 15 (21)
4 Troubleshooting
Use “Kvaser Device Guide” in the Control Panel to verify that the computer can
communicate with the Kvaser U100-X1. If the firmware version shown is all zeros,
there are communication problems. If the LED Bar or the status indication is not
flashing or does not light up at all, check the power supply.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 16 (21)
5 Safety Instructions
5.1 Intended Use
Kvaser CAN Interfaces are used to connect computer systems to CAN networks.
The Kvaser U100-X1 is intended for connection to a computer via the USB
interface.
5.2 Usage Warning
WARNING FOR ALL USERS
WARNING! - YOUR USE OF THIS DEVICE MUST BE DONE WITH CAUTION AND A FULL
UNDERSTANDING OF THE RISKS!
THIS WARNING IS PRESENTED TO INFORM YOU THAT THE OPERATION OF THIS DEVICE
MAY BE DANGEROUS. YOUR ACTIONS CAN INFLUENCE THE BEHAVIOR OF A CAN-BASED
DISTRIBUTED EMBEDDED SYSTEM, AND DEPENDING ON THE APPLICATION, THE
CONSEQUENCES OF YOUR IMPROPER ACTIONS COULD CAUSE SERIOUS OPERATIONAL
MALFUNCTION, LOSS OF INFORMATION, DAMAGE TO EQUIPMENT, AND PHYSICAL
INJURY TO YOURSELF AND OTHERS. A POTENTIALLY HAZARDOUS OPERATING
CONDITION IS PRESENT WHEN THE FOLLOWING TWO CONDITIONS ARE
CONCURRENTLY TRUE: THE PRODUCT IS PHYSICALLY INTERCONNECTED TO A REAL
DISTRIBUTED EMBEDDED SYSTEM; AND THE FUNCTIONS AND OPERATIONS OF THE
REAL DISTRIBUTED EMBEDDED SYSTEM ARE CONTROLLABLE OR INFLUENCED BY THE
USE OF THE CAN NETWORK. A POTENTIALLY HAZARDOUS OPERATING CONDITION MAY
RESULT FROM THE ACTIVITY OR NON-ACTIVITY OF SOME DISTRIBUTED EMBEDDED
SYSTEM FUNCTIONS AND OPERATIONS, WHICH MAY RESULT IN SERIOUS PHYSICAL
HARM OR DEATH OR CAUSE DAMAGE TO EQUIPMENT, DEVICES, OR THE SURROUNDING
ENVIRONMENT.
WITH THIS DEVICE, YOU MAY POTENTIALLY:
•CAUSE A CHANGE IN THE OPERATION OF THE SYSTEM, MODULE, DEVICE,
CIRCUIT, OR OUTPUT.
•TURN ON OR ACTIVATE A MODULE, DEVICE, CIRCUIT, OUTPUT, OR FUNCTION.
•TURN OFF OR DEACTIVATE A MODULE, DEVICE, CIRCUIT, OUTPUT, OR
FUNCTION.
•INHIBIT, TURN OFF, OR DEACTIVATE NORMAL OPERATION.
•MODIFY THE BEHAVIOR OF A DISTRIBUTED PRODUCT.
•ACTIVATE AN UNINTENDED OPERATION.
•PLACE THE SYSTEM, MODULE, DEVICE, CIRCUIT, OR OUTPUT INTO AN
UNINTENDED MODE.
ONLY THOSE PERSONS WHO:
(A) ARE PROPERLY TRAINED AND QUALIFIED WITH RESPECT TO THE USE OF THE
DEVICE,
(B) UNDERSTAND THE WARNINGS ABOVE, AND
(C) UNDERSTAND HOW THIS DEVICE INTERACTS WITH AND IMPACTS THE FUNCTION
AND SAFETY OF OTHER PRODUCTS IN A DISTRIBUTED SYSTEM AND THE APPLICATION
FOR WHICH THIS DEVICE WILL BE APPLIED, MAY USE THE DEVICE.
PLEASE NOTE THAT YOU CAN INTEGRATE THIS PRODUCT AS A SUBSYSTEM INTO
HIGHER-LEVEL SYSTEMS. IN CASE YOU DO SO, KVASER AB HEREBY DECLARES THAT
KVASER AB’S WARRANTY SHALL BE LIMITED TO THE CORRECTION OF DEFECTS, AND
KVASER AB HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY OVER AND ABOVE THE
REFUNDING OF THE PRICE PAID FOR THIS DEVICE, SINCE KVASER AB DOES NOT HAVE
ANY INFLUENCE ON THE IMPLEMENTATIONS OF THE HIGHER-LEVEL SYSTEM, WHICH
MAY BE DEFECTIVE.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 17 (21)
6 Disposal and Recycling Information
When this product reaches its end of life, please dispose of it
according to your local environmental laws and guidelines.
For information about Kvaser’s recycling programs, visit:
https://www.kvaser.com/en/kvaser/recycling-policy.html
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 18 (21)
7 Legal Acknowledgements
7.1 EU Regulatory Compliance
Company Name:
Postal address:
Postcode:
City:
Telephone number:
E-mail address:
Product:
EU Declaration of Conformity (DoC)
We
Kvaser AB
Aminogatan 25
431 53
M¨olndal
[phone]
[e-mail]
declare that the DoC is issued under our sole responsibility and belongs to the following product:
Kvaser U100-X1
Object of the declaration (identification of apparatus allowing traceability):
Product: Kvaser U100-X1
Type: 73-30130-01266-0
The object of the declaration described above is in conformity with the relevant Union harmonisation
legislation:
Electromagnetic Compatibility (EMC) Directive 2014/30/EU (Art. 6)
RoHS recast Directive 2011/65/EU (Art. 4.1)
The following harmonised standards and technical specifications have been applied
(title, date of standard/specification):
EN 55032 (2012) EN 55035 (2017)
EN 61000-6-3 (2007 + A1:2011) EN 50581 (2012)
Signed for and on behalf of:
M¨olndal
Place of issue
2021-03-05
Date of issue Claes Haglund, Supply Chain and Quality director
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 19 (21)
7.2 FCC Regulatory Compliance
Federal Communications Commission (FCC) Compliance Information Statement
IDENTIFICATION OBJECT:
Product: Kvaser U100-X1
Type: 73-30130-01266-0
APPLICABLE COMPLIANCE STATEMENTS:
CFR Title 47 Part 15 §15.107, §15.109
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
RESPONSIBLE PARTY (IN USA) NAME:
Kvaser Inc.
23881 Via Fabricante, Suite 503
Mission Viejo, CA 92691
Internet contact: [email protected]
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser U100-X1 User’s Guide 20 (21)
7.3 Patents, Copyrights and Trademarks
All trademarks are the property of their respective owner. Windows is a registered
trademark of Microsoft Corporation in the United States and other countries.
Adobe, the Adobe logo, and Reader are either registered trademarks or trademarks
of Adobe Systems Incorporated in the United States and/or other countries.
MagiSync is a trademark of Kvaser AB.
DeviceNet is a trademark of Open DeviceNet Vendor Association, Inc.
NMEA 2000 is the registered trademark of the National Marine Electronics
Association, Inc.
For information about Kvaser related CAN patents, see www.kvaser.com/patent.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
