Kvaser Hybrid CAN/LIN User manual

Kvaser Hybrid CAN/LIN User’s Guide
Copyright 2021 Kvaser AB, Mölndal, Sweden
https://www.kvaser.com
Printed Sunday 14th November, 2021
We believe that the information contained herein was accurate in all respects at the time of printing.
Kvaser AB cannot, however, assume any responsibility for errors or omissions in this text. Also note
that the information in this document is subject to change without notice and should not be construed
as a commitment by Kvaser AB.

Kvaser Hybrid CAN/LIN User’s Guide 2 (21)
(This page is intentionally left blank.)
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 3 (21)
Contents
1 About this manual 4
2 Introduction 5
2.1 Welcome to Kvaser Hybrid CAN/LIN . . . . . . . . . . . . . . . . . . 5
2.2 Major features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.3 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.4 Additional software and documentation . . . . . . . . . . . . . . . . 6
3 Kvaser Hybrid CAN/LIN hardware 7
3.1 Hardware installation . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2 USB connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.3 CAN/LIN channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.4 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.5 LED Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.6 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3.7 Limitations in LINlib functionality . . . . . . . . . . . . . . . . . . . . 9
4 Appendices 10
4.1 Definitions of LED states and colors . . . . . . . . . . . . . . . . . . 10
4.2 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.3 CAN/LIN connector . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.4 CAN bus termination . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.5 Updating the firmware . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5 Disposal and Recycling Information 16
6 Legal acknowledgements 17
6.1 Usage warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6.2 EU Regulatory Compliance . . . . . . . . . . . . . . . . . . . . . . . 18
6.3 FCC Regulatory Compliance . . . . . . . . . . . . . . . . . . . . . . 19
6.4 Patents, Copyrights and Trademarks . . . . . . . . . . . . . . . . . . 20
7 Document Revision History 21
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 4 (21)
1 About this manual
This manual is intended for Kvaser Hybrid CAN/LIN users. This document contains
a description of the hardware’s properties and general instructions for connecting
the device to a computer.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 5 (21)
2 Introduction
This section will describe the functions and features of the Kvaser Hybrid CAN/LIN.
2.1 Welcome to Kvaser Hybrid CAN/LIN
Figure 1: Kvaser Hybrid CAN/LIN
Kvaser Hybrid CAN/LIN is a single channel interface where the channel can be
opened either as CAN or LIN. The Kvaser Hybrid CAN/LIN is compatible with
applications that use Kvaser’s CANlib and LINlib.
This guide applies to Kvaser Hybrid CAN/LIN devices using at least firmware and
driver versions listed in Table 1. For minimum compatible firmware and driver
versions of Kvaser Hybrid CAN/LIN see Table 9 on Page 15.
Device Product Number Firmware Driver (Windows/Linux)
Kvaser Hybrid CAN/LIN 73-30130-01284-4 v3.25 v5.36 (kcany/mhydra)
Table 1: Firmware and driver versions needed to support all functionality present in
this guide.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 6 (21)
2.2 Major features
•Hybrid USB CAN/LIN interface.
•Supports both LIN master and LIN slave mode
•Supports LIN 1.3 to 2.2
•LIN reference voltage detection
•Supports CAN FD, up to 5 Mbit/s (with correct physical layer implementation).
•Supports both 11-bit (CAN 2.0A) and 29-bit (CAN 2.0B active) identifiers.
•Powered through the USB connector.
•100% compatible with applications written for other Kvaser CAN hardware
with Kvaser CANlib and Kvaser LINlib.
•Fully compatible with J1939, CANopen, NMEA 2000 R
and DeviceNet.
•Quick and easy plug-and-play installation.
2.3 Interface
Kvaser Hybrid CAN/LIN provides a CAN/LIN bus interface through a standard USB
interface.
2.4 Additional software and documentation
The Kvaser CANlib SDK includes everything you need in order to develop software
applications interacting with Kvaser CAN hardware. The SDK contains full
documentation and many sample programs, written in C, C++, C#, Delphi, Python
and Visual Basic. Kvaser CAN hardware is built around the same common
software API. Applications developed using one device type will run without
modification on other device types.
The latest versions of documentation, software and drivers can be downloaded for
free at www.kvaser.com/download.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 7 (21)
3 Kvaser Hybrid CAN/LIN hardware
In this section you can read more about the CAN/LIN channels, power supply and
LED indicators.
3.1 Hardware installation
For the Kvaser Hybrid CAN/LIN to communicate with the host computer, a
compatible version of the Kvaser driver and firmware must be installed.
After the driver has been installed on the host computer, the firmware may then be
downloaded and installed on the Kvaser Hybrid CAN/LIN.
The latest version of the driver and firmware can be downloaded from
www.kvaser.com/download.
The driver is installed by running the file kvaser_drivers_setup.exe .
The Kvaser Hybrid CAN/LIN may be inserted in any free USB socket on the host
computer. You do not need to switch the power off before inserting or removing the
device.
For information on how to upgrade the firmware, see Section 4.5, Updating the
firmware, on Page 15.
3.2 USB connector
The Kvaser Hybrid CAN/LIN has a standard USB type “A” connector.
Figure 2: A standard USB type “A” connector.
Connect the device to your computer using any high quality USB 2.0 certified
cable. The maximum USB cable length is 5 m (∼16 ft). If you need a longer cable,
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 8 (21)
you can use USB hubs or USB extension cables with a built-in hub. By chaining up
to 5 hubs, you can achieve an effective cable length of up to 25 m (∼82 ft).
As USB cables become longer they are more sensitive to EMI,
because they make a longer antenna that can pick up more
noise. These issues can be mitigated by using higher quality
cables with better shielding. Thicker cables tend to be better than
thin ones, and braided shielding tends to be more reliable than
only foil. Furthermore, longer cables may introduce signal
degradation and timing issues that, if necessary, can be mitigated
using shorter cable segments combined with hubs that amplify
the signal and handle delays on a per-cable basis.
3.3 CAN/LIN channel
The Kvaser Hybrid CAN/LIN has one CAN/LIN channel in a 9-pin D-SUB CAN
connector (see Figure 3). See Section 4.3, CAN/LIN connector, on Page 13 for
pinout information.
Figure 3: CAN/LIN connector on Kvaser Hybrid CAN/LIN
3.4 Power supply
The Kvaser Hybrid CAN/LIN is powered from the USB port. You also need to apply
a reference voltage to the LIN reference power pin when running the channel in LIN
mode. See Section 4.3, CAN/LIN connector, on Page 13 for pinout information.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 9 (21)
3.5 LED Indicators
The Kvaser Hybrid CAN/LIN has a single power LED as well as one traffic LED
and one Informational LED for the CAN/LIN channel as shown in Figure 4 on
Page 9. Their functions are described in Section 4.1, Definitions of LED states and
colors, on Page 10.
Figure 4: LEDs on the Kvaser Hybrid CAN/LIN.
3.6 Troubleshooting
Use “Kvaser Device Guide” in the Control Panel to verify that the computer can
communicate with the Kvaser Hybrid CAN/LIN. If the firmware version shown is all
zeros, there are communication problems. If the LEDs are not flashing or do not
light up at all, check the power supply.
3.7 Limitations in LINlib functionality
The following limitations apply to the Kvaser Hybrid CAN/LIN:
•The API call linSetupIllegalMessage() is not supported.
•The fields synchEdgeTime and byteTime in the struct LinMessageInfo is
not used.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 10 (21)
4 Appendices
In this section you will find technical information about the Kvaser Hybrid CAN/LIN
and its connectors.
4.1 Definitions of LED states and colors
The Kvaser Hybrid CAN/LIN has three types of LEDs; Power, Traffic and Info.
These are dual colored as shown in Table 2. A device with multiple channels has
one Traffic LED for each channel. When the device has more than one channel a
space and digit is added on the label, CH 1, CH 2 etc. The red Traffic LEDs are
also used to indicate errors by using all red Traffic LEDs simultaneously.
LED Label Color
Power PWR Green/Yellow
Traffic CH Yellow/Red
Info INFO Green/Yellow
Table 2: The different type of LEDs.
The following definitions is used to describe the state of an LED:
Off The LED is off and no light is emitted.
Flash The LED is lit up for a very short time. A single flash may be hard to see
and a continuous set of flashes will look the same as On.
Slow Blink The LED is repeatedly turned On and Off. The On and Off phase is
equal in time.
Fast Blink The LED is repeatedly turned On and Off but with a higher frequency
than Slow Blink. The On and Off time is still equal.
On The LED is constantly emitting light.
Slow Waver This is a variant of Slow Blink but instead of being Off, a second color
is On. This is only possible with a dual colored LED.
Fast Waver The LED is alternating between two colors as in Slow Waver but
using a higher frequency.
Running This means that all LEDs are lit, one at the time, in sequence with every
color available i.e. “Power green->Power yellow->Traffic 1 yellow->Traffic 1
red->Traffic 2 yellow->Traffic 2 red->. . . ”
As an example, "Slow Waver (Green/Yellow)" means that the LED is slowly blinking
by alternating between green and yellow.
The Kvaser Hybrid CAN/LIN has three LEDs as shown in Figure 4 on Page 9.
Their functions are shown in Table 3 on Page 11.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 11 (21)
LED Function Description
PWR (Green) Power Steady light when unit is powered and working.
CH (Yellow) CAN RxTx Status for the CAN/LIN channel
INFO (Green) LIN Mode In use as LIN
INFO (Yellow) LIN Mode LIN reference voltage is available
Table 3: LEDs on the Kvaser Hybrid CAN/LIN.
4.1.1 Interface mode
The device is in Interface mode when connected to the PC via USB. If the Power
LED is showing a steady green light, the device is in Interface mode and working
correctly. When connected to the computer for the first time, the Power LED will
blink slowly in yellow until the driver is installed and the device has received a USB
configuration.
When in Interface mode, if the Power LED is yellow for an extended period,
something is wrong. Please see Table 4.
The power should never be removed when firmware update is in
progress.
Power LED Traffic LED Description
Slow Blink (Yellow) All off (-) Waiting for USB configuration
Slow Waver (Green/Yellow) Slow Waver (Yellow/Red) Firmware configuration error1
Slow Waver (Green/Yellow) All Slow Blink (Yellow) Power problem2
Table 4: Yellow Power LED shows problems in Interface mode.
4.1.2 CAN and LIN usage
Kvaser Hybrid CAN/LIN is ready to be operated as either a CAN or LIN interface
when connected to the PC without further configuration. You can use the same
CANlib and LINlib API calls as with other Kvaser interfaces, use CANlib for CAN
and LINlib for LIN related usage. Both libraries are included in the Kvaser CANlib
SDK, see Section 2.4, Additional software and documentation, on Page 6.
4.1.3 CAN interface mode
When Kvaser Hybrid CAN/LIN is used as a CAN interface, the traffic LED is used
as described in Table 5 on Page 12.
1This should not normally happen. If it does, please contact Kvaser support.
2This indicates low power supply, such as using an unpowered USB hub.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 12 (21)
Traffic LED Description
Off (-) Idle, no CAN traffic
Flash (Yellow) CAN message received or sent
Flash (Red) Error frame received
All Fast Blink (Yellow) Firmware update is in progress
Fast Blink (Red) CAN channel is error passive
On (Red)3CAN overrun
Table 5: Traffic LED shows CAN bus status in CAN Interface mode.
4.1.4 LIN interface mode
When Kvaser Hybrid CAN/LIN is used as a LIN interface, the traffic LED is used as
described in Table 6.
Traffic LED Description
Off (-) Idle, no CAN traffic
Flash (Yellow) Internal activity or LIN message received or sent
All Fast Blink (Yellow) Firmware update is in progress
Table 6: Traffic LED shows LIN bus status in LIN Interface mode.
4.2 Technical data
In Table 7 on Page 13 you will find the Kvaser Hybrid CAN/LIN’s technical
specifications.
3The red Traffic LED indicating overrun will stay on until the device goes bus off.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 13 (21)
CAN/LIN Channels 1 (Configurable as CAN or LIN)
CAN Transceivers TJA1051T/E (Compliant with ISO 11898-2)
CAN Bit Rate 50 kbit/s to 1 Mbit/s
CAN FD Bit Rate Up to 5 Mbit/s (with correct physical layer implementation)
CAN/LIN Controller Kvaser CAN/LIN IP in FPGA
LIN Transceivers TJA1021T/20
LIN Bit Rate 1 - 20 kbit/s
Time stamp resolution 50 µs
CAN Max message rate 20000 msg/s
Error Frame Detection Yes
Error Frame Generation No
Silent mode No
Kvaser MagiSync No
Kvaser CANtegrity No
PC interface USB 2.0
Power consumption max 195 mA
Hardware configuration Done by software (Plug & Play).
Software requirements Windows (7 or later), Linux.
Dimensions 35 x 165 x 17 mm for body incl. strain relief
Weight 120 g
Operating temperature −40 ◦C to +85 ◦C
Storage temperature −40 ◦C to +85 ◦C
Relative humidity 0 % to 85 % (non-condensing.)
Table 7: Technical Specifications.
4.3 CAN/LIN connector
Kvaser Hybrid CAN/LIN devices that use the 9-pin D-SUB connector (see Figure 5)
have the pinning described in Table 8 on Page 14.
Figure 5: The D-SUB 9 connector pin numbers
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 14 (21)
D-SUB 9 CAN Function LIN Function
1 Not connected Not connected
2 CAN_L channel Not connected
3 GND GND
4 Not connected Not connected
5 Shield Shield
6 Not connected Not connected
7 CAN_H channel LIN_BUS channel
8 Not connected Not connected
9 Not connected Reference Voltage
Table 8: Pin configuration of the 9-pin D-SUB connector.
The Reference Voltage (pin 9) is only used as voltage reference and power to the
LIN transceiver. The Kvaser Hybrid CAN/LIN itself (including CAN transceiver) is
powered through the USB connector. The Reference Voltage (pin 9) must be
connected to a voltage supply in the range of 6 V to 27 V (absolute maximum rating
is 40V) to ensure proper behaviour of the transceiver. The Kvaser Hybrid CAN/LIN
will automatically switch the internal pull-up resistor from (typical) 160 kΩto 1 kΩ
when going from slave mode to master mode.
4.4 CAN bus termination
Every CAN bus must be terminated with a 120 Ωresistor at each end of the bus.
The Kvaser Hybrid CAN/LIN does not contain any CAN bus termination, because
their inclusion could cause severe disturbance in a system which is already
correctly terminated.
For laboratory or testing use, the exact value of the termination resistors is not
critical. Sometimes a single terminator is sufficient. For production, proper
termination is essential. If you see error frames on the bus, you should check the
termination.
To save yourself a lot of trouble, always terminate the CAN
bus properly.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 15 (21)
4.5 Updating the firmware
For the Kvaser Hybrid CAN/LIN to communicate with the host computer, compatible
versions of the Kvaser CANlib (including driver) and firmware must be installed.
The latest versions of firmware and drivers can be downloaded for free at
www.kvaser.com/download.
Connect the Kvaser Hybrid CAN/LIN to your PC with the USB cable and start the
update.exe application. A window opens showing the Firmware Update
Instructions, read and follow those carefully.
To check the current firmware version, open “Kvaser Device Guide” which can be
found in the Control Panel. Select “Kvaser Hybrid CAN/LIN” in the tree view to the
left, and click on the channel. The firmware revision information now appears in the
right half of the window.
The absolute minimum firmware and driver versions needed in order to use Kvaser
Hybrid CAN/LIN are listed in Table 9
Device Firmware Driver (Windows/Linux)
Kvaser Hybrid CAN/LIN v3.25 v5.36
Table 9: Minimum compatible driver and firmware versions of Kvaser Hybrid
CAN/LIN.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 16 (21)
5 Disposal and Recycling Information
When this product reaches its end of life, please dispose of it
according to your local environmental laws and guidelines.
For information about Kvaser’s recycling programs, visit:
https://www.kvaser.com/en/kvaser/recycling-policy.html
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 17 (21)
6 Legal acknowledgements
6.1 Usage warning
WARNING FOR ALL USERS
WARNING! - YOUR USE OF THIS DEVICE MUST BE DONE WITH CAUTION AND A FULL
UNDERSTANDING OF THE RISKS!
THIS WARNING IS PRESENTED TO INFORM YOU THAT THE OPERATION OF THIS DEVICE
MAY BE DANGEROUS. YOUR ACTIONS CAN INFLUENCE THE BEHAVIOR OF A CAN-BASED
DISTRIBUTED EMBEDDED SYSTEM, AND DEPENDING ON THE APPLICATION, THE
CONSEQUENCES OF YOUR IMPROPER ACTIONS COULD CAUSE SERIOUS OPERATIONAL
MALFUNCTION, LOSS OF INFORMATION, DAMAGE TO EQUIPMENT, AND PHYSICAL
INJURY TO YOURSELF AND OTHERS. A POTENTIALLY HAZARDOUS OPERATING
CONDITION IS PRESENT WHEN THE FOLLOWING TWO CONDITIONS ARE
CONCURRENTLY TRUE: THE PRODUCT IS PHYSICALLY INTERCONNECTED TO A REAL
DISTRIBUTED EMBEDDED SYSTEM; AND THE FUNCTIONS AND OPERATIONS OF THE
REAL DISTRIBUTED EMBEDDED SYSTEM ARE CONTROLLABLE OR INFLUENCED BY THE
USE OF THE CAN NETWORK. A POTENTIALLY HAZARDOUS OPERATING CONDITION MAY
RESULT FROM THE ACTIVITY OR NON-ACTIVITY OF SOME DISTRIBUTED EMBEDDED
SYSTEM FUNCTIONS AND OPERATIONS, WHICH MAY RESULT IN SERIOUS PHYSICAL
HARM OR DEATH OR CAUSE DAMAGE TO EQUIPMENT, DEVICES, OR THE SURROUNDING
ENVIRONMENT.
WITH THIS DEVICE, YOU MAY POTENTIALLY:
•CAUSE A CHANGE IN THE OPERATION OF THE SYSTEM, MODULE, DEVICE,
CIRCUIT, OR OUTPUT.
•TURN ON OR ACTIVATE A MODULE, DEVICE, CIRCUIT, OUTPUT, OR FUNCTION.
•TURN OFF OR DEACTIVATE A MODULE, DEVICE, CIRCUIT, OUTPUT, OR
FUNCTION.
•INHIBIT, TURN OFF, OR DEACTIVATE NORMAL OPERATION.
•MODIFY THE BEHAVIOR OF A DISTRIBUTED PRODUCT.
•ACTIVATE AN UNINTENDED OPERATION.
•PLACE THE SYSTEM, MODULE, DEVICE, CIRCUIT, OR OUTPUT INTO AN
UNINTENDED MODE.
ONLY THOSE PERSONS WHO:
(A) ARE PROPERLY TRAINED AND QUALIFIED WITH RESPECT TO THE USE OF THE
DEVICE,
(B) UNDERSTAND THE WARNINGS ABOVE, AND
(C) UNDERSTAND HOW THIS DEVICE INTERACTS WITH AND IMPACTS THE FUNCTION
AND SAFETY OF OTHER PRODUCTS IN A DISTRIBUTED SYSTEM AND THE APPLICATION
FOR WHICH THIS DEVICE WILL BE APPLIED, MAY USE THE DEVICE.
PLEASE NOTE THAT YOU CAN INTEGRATE THIS PRODUCT AS A SUBSYSTEM INTO
HIGHER-LEVEL SYSTEMS. IN CASE YOU DO SO, KVASER AB HEREBY DECLARES THAT
KVASER AB’S WARRANTY SHALL BE LIMITED TO THE CORRECTION OF DEFECTS, AND
KVASER AB HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY OVER AND ABOVE THE
REFUNDING OF THE PRICE PAID FOR THIS DEVICE, SINCE KVASER AB DOES NOT HAVE
ANY INFLUENCE ON THE IMPLEMENTATIONS OF THE HIGHER-LEVEL SYSTEM, WHICH
MAY BE DEFECTIVE.
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 18 (21)
6.2 EU Regulatory Compliance
Company Name:
Postal address:
Postcode:
City:
Telephone number:
E-mail address:
Product:
EU Declaration of Conformity (DoC)
We
Kvaser AB
Aminogatan 25
431 53
M¨olndal
[phone]
[e-mail]
declare that the DoC is issued under our sole responsibility and belongs to the following product:
Kvaser Hybrid CAN/LIN
Object of the declaration (identification of apparatus allowing traceability):
Product: Kvaser Hybrid CAN/LIN
Type: 73-30130-01284-4
The object of the declaration described above is in conformity with the relevant Union harmonisation
legislation:
Electromagnetic Compatibility (EMC) Directive 2014/30/EU (Art. 6)
RoHS recast Directive 2011/65/EU (Art. 4.1)
The following harmonised standards and technical specifications have been applied
(title, date of standard/specification):
EN 55032 (2015 + A11:2020) EN 55035 (2017 + A11:2020)
EN 61000-6-3 (2007 + A1:2011) EN 50581 (2012)
Signed for and on behalf of:
M¨olndal
Place of issue
2021-09-27
Date of issue Claes Haglund, Supply Chain and Quality director
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 19 (21)
6.3 FCC Regulatory Compliance
Federal Communications Commission (FCC) Compliance Information Statement
IDENTIFICATION OBJECT:
Product: Kvaser Hybrid CAN/LIN
Type: 73-30130-01284-4
APPLICABLE COMPLIANCE STATEMENTS:
CFR Title 47 Part 15 §15.107, §15.109
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
RESPONSIBLE PARTY (IN USA) NAME:
Kvaser Inc.
23881 Via Fabricante, Suite 503
Mission Viejo, CA 92691
Internet contact: suppo[email protected]
Kvaser AB, Mölndal, Sweden — www.kvaser.com

Kvaser Hybrid CAN/LIN User’s Guide 20 (21)
6.4 Patents, Copyrights and Trademarks
All trademarks are the property of their respective owner. Windows is a registered
trademark of Microsoft Corporation in the United States and other countries.
Adobe, the Adobe logo, and Reader are either registered trademarks or trademarks
of Adobe Systems Incorporated in the United States and/or other countries.
DeviceNet is a trademark of Open DeviceNet Vendor Association, Inc.
NMEA 2000 is the registered trademark of the National Marine Electronics
Association, Inc.
For information about Kvaser related CAN patents, see www.kvaser.com/patent.
Kvaser AB, Mölndal, Sweden — www.kvaser.com
