Kyocera Mita Ecosys FS-1010 User manual

Page Printer
Installation Guide

Caution
NO LIABILITY IS ASSUMED FOR ANY DAMAGE CAUSED BY IMPROPER INSTALLATION.
Notice on Software
SOFTWARE USED WITH THIS PRINTER MUST SUPPORT THE PRINTER'S EMULATION
MODE. The printer is factory-set to emulate the HP PCL 6. The emulation mode can be changed by
following the procedures described in the Operation Guide contained as an electronic file in the
Kyocera Mita Digital Library CD-ROM supplied with the printer.
Notice
The information in this manual is subject to change without notification. Additional pages may be
inserted in future editions. The user is asked to excuse any technical inaccuracies or typographical
errors in the present edition.
No responsibility is assumed if accidents occur while the user is following the instructions in this
manual. No responsibility is assumed for defects in the printer's firmware (contents of its read-only
memory).
This manual, any copyrightable subject matter sold or provided with or in connection with the sale
of the page printer, are protected by copyright. All rights are reserved. Copying or other reproduc-
tion of all or part of this manual, any copyrightable subject matter without the prior written consent
of Kyocera Corporation is prohibited. Any copies made of all or part of this manual, any copyright-
able subject must contain the same copyright notice as the material from which the copying is done.
Table of Contents
STEP 1 Unpacking .......................................................................1
STEP 2 Positioning the Printer....................................................2
STEP 3 Installing the Toner Container........................................3
STEP 4 Connecting the Printer to the Computer .......................6
STEP 5 Connecting the Power Cord...........................................8
STEP 6 Adding Paper to the Paper Cassette and MP Tray........9
STEP 7 Using the Face-Up Output Tray....................................14
STEP 8 Printing a Status Page..................................................15
©2001 by KYOCERA CORPORATION. All rights reserved, Revision 1.1., October 2001

1
Unpacking
Carefully remove the printer and other items from the box. Check that nothing is miss-
ing against the list of shipped components below.
Shipped Components
Removing Shipping Material
Remove the tape on the rear side of the printer, and remove the two spacers and
printed notice from the paper cassette.
STEP
1
Printer
Power Cord
Toner Container (TK-17)
Installation Guide (this booklet) Kyocera Mita Digital Library CD-ROM
Cleaning Cloth
Ta p e Spacers
Printed Notice

2
Positioning the Printer
Make sure that the place of installation meets the following requirements:
Clearance
Be sure to secure enough space
around the printer. Prolonged
use without sufficient clearance
may cause heat to build up
within the printer, resulting in
fire.
Environment
Do not install the printer where temperature or humidity is outside the rec-
ommended range. Print quality may suffer and there will be an increased
chance of paper jams.
Places to Avoid
Avoid installing the printer in locations subject to:
• Direct drafts of hot or cold air
• Direct drafts from outside (Avoid locations near building entrances.)
• Sudden temperature or humidity changes
• Sources of high temperature, for example, near stoves or radiators
•Excessivedust
•Vibration
• Unstable surfaces and surfaces that are not level
• Ammonia or other harmful fumes (If you are planning to fumigate the room, or
make liberal use of insecticide, remove the printer first!)
• Excessive sunlight or humidity
• Lack of ventilation
• Lowairpressure,e.g.,elevationsgreaterthan2000meters(6500 feet)abovesea
level
Te m p e r a tu r e 10 to 32.5 °C (50 to 90.5 °F), ideally about 23 °C (73.4 °F)
Humidity 20 to 80 %, ideally 60 %
STEP
2
30 cm (11-13/16 inches)
40 cm
(15-3/4
inches)
25 cm
(9-7/8
inches)
50 cm
(19-11/16
inches)
25 cm (9-7/8
inches)

3
Installing the Toner Container
Before you can use the printer for the first time, you must set up the printer by installing
the toner container and interfacing with the computer.
1Open the printer top cover all the way.
2Confirm that the lock lever is in the
release (UNLOCK) position. If not, pull
it forward until it is in the release posi-
tion.
3Take the toner container from the bag.
Hold it with the protective seal (orange-
colored) facing up. Shake the toner con-
tainerhorizontallyatleast5times.This
ensures that the toner is evenly distrib-
uted inside.
STEP
3

4
4Carefully remove the protective seal.
5Install the toner container into the
printer.
6Push firmly on the top of the toner con-
tainer at the positions marked PUSH
HERE.

5
7Push the lock lever to the lock (LOCK)
position.
8Close the top cover.
To remove the toner container
Pull the lock lever #1 to the release
(UNLOCK) position, pull the lock lever
#2, then gently remove the toner con-
tainer.
LOCK
UNLOCK
LOCK
UNLOCK
Lock Lever #2
Lock Lever #1

6
Connecting the Printer to the Computer
There are variousways of connecting the printer to the computer, suchas through the
parallel interface connector, through the USB (Universal Serial Bus) interface connec-
tor, through the optional serial interface board kit (IB-10E)or through the optional net-
work interface board.
Printer Connections
Before performing this step, be sure to turn off both the printer and the com-
puter’s power switches and unplug the printer’s power plug from the power
outlet. Failure to do so may result in electrical shock.
The standard Centronics parallel interface connector and USB interface connec-
tor are located on the rear of the printer.
STEP
4
Printer (Rear)
Optional Serial Interface
Board kit (IB-10E)
Parallel Interface
Network
Optional Network
Interface Board
(DC 3.3V)
Serial Interface
Power Supply
USB
Interface

7
Parallel Interface Connection
1Plug one end of the printer cable (not
included) into the parallel interface con-
nector on the rear of the printer.
• Use a parallel printer cable
that complies with the
IEEE1284 standards.
• The printer will work best if it
is installed near the computer.
The connecting cable should
be shielded and not be longer
than 3 meters (10 feet).
2Close the clips on both sides to fix the
connector in place.
Plug the other end of the printer cable
into the computer’s Centronics parallel
interface connector.
USB (Universal Serial Bus) Interface Connection
1Plug one end of the USB cable on the
rear of the printer.
•Useacablethatcomplies
with Revision 1.1 of USB stan-
dard (a rectangular Type A
plug and a square Type B
plug).
• The connecting cable should
be shielded and not be longer
than 5 meters (16 feet).
2Plug the other end of the USB cableinto
the computer's USB interface connec-
tor.
To p r i n t e r
Clips
Printer Cable
To p r i n t e r
USB Cable

8
Connecting the Power Cord
This section describes the procedure for connecting the power cable and various
cautions.
Notes on Power Supply
• Install the printer near an AC wall outlet, preferably one that can be used for
the printer alone.
• Only use this printer with the supply voltage indicated on the serial number
label attached to the printer’s rear panel.
• If an extension cord is used, the total length of the power cord plus extension
should be 5 meters (16 feet) or less.
Power Requirements
To Connect the Power Cord
• Be sure the printer’s power switch is turned off.
• Only use the power cord supplied with the printer.
1Plug the power cord into the power cord
connector on the rear of the printer.
2Connect the other end of the power cord
into a power outlet.
Be sure to connect to a 3-wire
grounded power strip.
Voltage 120 V (U.S.A. and Canada), 220 to 240 V (European countries, and the
Asia-Pacific region), ±10 % at each voltage
Frequency 60 Hz (120 V) ±2 %, 50/60 Hz (220 to 240 V) ±2 %
Current capacity Max. 7.1 A at 120 V, or max. 3.8 A at 220 to 240 V
STEPSTEP
5
Power Cord
Connector
Power Cord
