Your Palm Powered™wireless solution
Your Smart Start to
Kyocera’s Smartphone Series
Kyocera’s smartphone (model QCP™6035) integrates a
Palm™handheld, a digital phone and a wireless modem into
one compact package. This technology-packed device lets
you think multipurpose—and lets you work that way, too.
quickstart_ms04.10 KWC 4/20/01 2:42 PM Page 2

2
It’s a Palm
handheld
Address Book
2. Tap “New” in the To Do List
screen. 3. Enter the text for the item. 4. To delete the item: Tap the check
box to the left of the item.
Date Book and To Do List
2. Tap a time line and enter the event. 3. To set the length of the event if
the appointment is longer or
shorter than 1 hour, tap the time
of the event to open the
Set Time dialog box.
4. Tap “OK.”
1. Press .
Use the To Do List feature of Kyocera’s smartphone to remember items you need to accomplish.
Use the Date Book feature of Kyocera’s smartphone to schedule events.
1. Press .
It’s a Palm handheld
To Do List
Memo Pad
Date Book
Kyocera’s smartphone runs on Palm
OS®software and includes powerful
tools like an Address Book, Date Book,
Memo Pad and To Do List. Plus,
Kyocera’s smartphone supports the
installation of hundreds of applications
compatible with Palm OS software.
quickstart_ms04.10 KWC 4/20/01 2:42 PM Page 3

3
It’s a Palm handheld
Setting network preferences
The correct network preference must be set before you can use the
Eudora®email application or the EudoraWeb™browser. Check with your
service provider to see if these network preferences are already set.
2. Tap . Tap “New” from the
service options.
3. Enter the following information
that should be provided by your
phone service provider, network
administrator or Internet Service
Provider (ISP):
User Name: Insert user name here.
Password: Tap “Prompt” to
assign a password.
Connection: Select “Wireless
Modem.”
Phone: For commercial ISPs, put in
the 10-digit phone number provided
by the ISP. For data services from
phone service providers, enter the
appropriate code.
4. Tap “Details.” Fill in the following
information if it is not already set
as a default:
Connection type: Check “PPP.”
Idle timeout: Check “Power Off.”
Query DNS: Verify if your ISP
supports DNS querying. Primary
DNS and Secondary DNS will be
provided by the ISP, if required.
IP Address: Check “Automatic.”
1. Tap .
Setting E-Mail and Network Preferences*
5. Consult with your network
administrator or ISP to see if a
login script is necessary. Scripts
are typically required by ISPs
that do not use Password
Authentication Protocol (PAP)
or a similar system.
If a script is necessary, tap
“Script.” Scripts are written
by tapping on the “End” pick
list and selecting the appropriate
action. Continue this process
until the script is complete.
quickstart_ms04.10 KWC 4/20/01 2:43 PM Page 4

4
It’s a Palm handheld
Kyocera’s smartphone provides dial-up access to your company network or your
ISP in much the same way that your laptop does. This setup has to be configured
on Kyocera’s smartphone before you can use your e-mail application.
Setting E-mail and Network Preferences* , continued
1. Tap with the stylus.
2. Tap “Menu/Options/Network
Preferences” to set up your e-mail.
4. Enter your name as you would like
it to appear in the “From” line of
your outgoing messages.
3. Tap “Use step by step wizard”
to create a new Eudora email
account.
5. Enter the e-mail address
assigned to you by your ISP.
6. Enter the name you will use to
log on to this account. 7. Enter the full name of your
incoming (POP3) mail server. 8. Enter the full name of your
outgoing (SMTP) mail server. 9. Enter a descriptive name for
this account.
Setting up a Eudora®email account
Kyocera’s smartphone offers the Eudora®email application to send
and receive e-mail. This application has multiple mailboxes and
extensive filtering.
10. Tap “Done” to save the
newly created account.
quickstart_ms04.10 KWC 4/20/01 2:43 PM Page 5

5
It’s a Palm handheld
Sending an e-mail*
1. Tap .
2. Tap . Tap “New Message.”
3. Fill in the destination and subject,
and write the contents of the
e-mail.
4. Tap “Send.” This will put the
e-mail in the Out Box, ready
to transmit.
5. Tap . Tap “Send Mail.”
1. Using the stylus, tap .
2. Tap on a bookmark, or tap
“Menu/Options/Visit Location”
to enter any URL.
3. Enter a valid URL and tap “OK.”
4. Kyocera’s smartphone will then
make a connection to access
the URL.
Using the Internet*
Kyocera’s smartphone offers the EudoraWeb™browser, an HTML Web
browser that converts a Web site into text-only data for a faster download.
Note: The EudoraWeb browser is not a Secure Sockets Layer
(SSL) enabled browser. To view Internet sites with SSL encryption,
you must download either the WebClient™or Browse-it™software
program to Kyocera’s smartphone. These two SSL-enabled browsers
are on the CD-ROM that is included with Kyocera’s smartphone.
quickstart_ms04.10 KWC 4/20/01 2:43 PM Page 6

6
3. Once the application has been downloaded, double
click on the application you want to install.
4. The application you clicked will appear in the
Install Tool box. Click “Done.”
It’s a Palm handheld
Customize Kyocera’s smartphone by downloading third-party applications such as language-translation software.
Note: We recommend that you use only applications certified to work with Palm™or Palm OS®products.
2. You will be prompted to save the application to the hard
drive of your computer before the download.
1. Visit a Web site that offers third-party applications to
download. Double click on the application you want
to download.
5. Click “OK.” Synchronize Kyocera’s smartphone with your
computer to install the application you downloaded.
Installing Third-Party Applications
quickstart_ms04.10 KWC 4/20/01 2:43 PM Page 7

7
It’s a Palm handheld
Deleting Third-Party Applications
1. Tap .
2. From the pull-down menu,
tap “Delete.”
3. Tap the application you want to
delete. Tap “Delete.” 4. Tap “Yes”to delete the selected application.
quickstart_ms04.10 KWC 4/20/01 2:43 PM Page 8

It’s a Palm handheld
Exchange business cards, schedules and memos quickly by beaming
information to and from business associates with IR-enabled devices.
To beam memo information
1. Select the memo you want
to beam. 2. Point the IR port of Kyocera’s
smartphone at the port of
the receiving device, keeping
approximately 6 to 8 inches
between the two devices.
3. Tap . Tap “Beam Memo”
from the drop-down menu.
(This command may vary
depending on the application.)
4. Wait for the “Beam Status”
dialog box to indicate the
transfer is complete before
continuing to work.
Infrared (IR) Beaming
1. Enter the fields in the Address
Book to set up the information
you would like to beam as your
business card.
3. A box will appear asking if this
is the contact you want to set as
your business card. Tap “Yes.”
To beam business-card information
4. A contact-card icon will appear
indicating that the contact you
selected will be set as your
business card. To quickly beam
your business card, press
for a few seconds.
2. Tap . Tap “Select Business Card.”
8
quickstart_ms04.10 KWC 4/20/01 2:43 PM Page 9

9
To start Data/Fax mode
You can use Data/Fax mode with the flip open or closed, but you cannot make or
receive voice calls or use any other applications while the phone modem is in use.
1. Slide the phone into the cradle
and open the flip. If the cradle is
attached to the port you use for
HotSync®operations, turn off the
HotSync function on your computer.
It’s a Palm handheld
2. Tap to open Data/Fax mode.
You will see status information
beginning with “Initializing
Modem” and continuing to
“Ready to Send Data or Faxes.”
3. From the computer, make the
connection you want to initiate.
Kyocera’s smartphone has a built-in 14.4 Kbps wireless modem.
1. Tap to open Data/Fax mode.
2. Tap to open the Data/Fax menu.
Data/Fax Setup
3. To preset the phone to receive
specific types of data calls, tap
the tab beside Incoming Calls
to select.
quickstart_ms04.10 KWC 4/20/01 2:43 PM Page 10

It’s a wireless phone
1. Turn on the phone by pressing
down for approximately
3 seconds.
2. Using the keypad, enter the
phone number.
3. Press .
Making a phone call with the flip closed
Making a phone call from the Address Book
The Address Book in Kyocera’s smartphone holds thousands of names
and is seamlessly integrated with the phone for direct dialing.
1. With the phone turned on, open
the keypad. Tap with the stylus. 2. Tap the phone number of the
person you want to call.
3. Tap to place the call.
Making a Phone Call
1. With the phone turned on, open
the keypad. Tap .
Making a phone call using
the Dialer
3. Tap to place the call.
2. With the stylus, tap the phone number
you want to call on the screen.
10
