l-com DVI to VGA Conversion Box User manual

6265 Variel Avenue Woodland Hills, CA 91367
voice: 818 884-6294 fax: [phone]
email: [email protected] website: http://www.gefen.com
Distributed by:
L-com
®
CONNECTIVITY
PRODUCTS
45 Beechwood Drive
North Andover, MA 01845
www.L-com.com
E-mail: [email protected]
Fax: [phone]
Toll Free: 800-343-1455
User Manual
DVI toVGA
Conversion Box
ex•tend•it

Congratulations
on your purchase of the ex•tend•it DVI to VGA Conversion
Box. Your complete satisfaction is very important to us.
Gefen’s line of KVM (Keyboard Video & Mouse), DVI, ADC, USB, switches,
extenders, converters and hubs is designed to make computer use more
comfortable, more productive and less expensive.
KVM switches allow access to multiple computers from a single keyboard,
while the extenders give the user control over a computer up to 330 feet
away from the work area.
The ex•tend•it line offers solutions for noise, space and security concerns,
data center control, information distribution, conference room presentation,
and school and corporate training environments.
Our Committment
Gefen will always offer the finest quality product at the best possible
price. Included in that price is a lifetime of free support from a team of out-
standing engineers.
Introduction
The ex•tend•it DVI to VGA Conversion Box connects analog CRT or LCD
monitors to DVI compliant video graphic cards. Analog monitors
can also be used instead of digital monitors in applications requiring two
monitor displays side by side.
•Connects computers with DVI-D connectors to analog SVGA
monitors or projectors
•Maintains up to 1920 x 1200 x 60 resolution
•Supports DDWG standard for DVI compliant monitors
•Installs in seconds
•DVI cables are used to connect the computer to the DVI input

How to connect the
DVI to VGA Conversion Box
1- Connect your analog monitor to the HD-15 female connector at the
output side of the DVI to VGA Conversion Box.
2- Connect the DVI (m-m) cable between the DVI connector on the graphic
card and the DVI input of the DVI to VGA Conversion Box.
3- Connect the power supply.
The convertor generates all the compatible digital to analog conversion signals
to make the connection between the digital input and the analog output work.
What’s included
• 6 foot DVI-D cable (m-m)
• 5V external power supply
• DVI to VGA Conversion Box
.
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.

.front view
back view

Wiring Diagram
Technical Support:
phone: [phone]
fax: [phone]
email: [email protected]
web: www.gefen.com
Technical Support Hours:
9:00 am – 5:00 pm PST
Monday -– Friday
Write to:
Gefen, Inc.
c/o Customer Service
6265 Variel Avenue
Woodland Hills
CA 91367-9897
USA
Asking for Assistance
Trademarks:
Macintosh is a trademark of Apple Computer Inc.
ex•tend•it is a trademark of Gefen Inc.
The DVI to VGA Conversion Box is a trademark of Gefen Inc.
© Copyright 2002 Gefen Inc. All Rights Reserved

,
-
Warranty
Gefen Inc. warrants the equipment it manufactures to be free from defects
in material and workmanship. If equipment fails because of such defects
and Gefen Inc. is notified within one (1) year from the date of shipment,
Gefen Inc. will, at its option, repair or replace the equipment, provided
that the equipment has not been subjected to mechanical, electrical, or
other abuse or modifications. Equipment that fails under conditions other
than those covered will be repaired at the current price of parts and
labor in effect at the time of the repair. Such repairs are warranted for
ninety (90) days from the day of re-shipment to the Buyer.
This warranty is in lieu of all other warranties expressed or implied,
including without limitation, any implied warranty or merchantability or
fitness for any particular purpose, all of which are expressly disclaimed.
The information in this manual has been carefully checked and is
believed to be accurate. However, Gefen Inc. assumes no responsibility for
any inaccuracies that may be contained in this manual. In no event will
Gefen Inc. be liable for direct, indirect, special incidental, or consequential
damages resulting from any defect or omission in this manual, even if
advised of the possibility of such damages. The technical information
contained herein regarding DVI to VGA Conversion Box features
and specifications is subject to change without notice.
All Rights Reserved © Copyright 2002Gefen Inc.
