L SHAPE MASSAGE CHAIR User manual

L SHAPE
MASSAGE CHAIR
User Manual
Name : L Shape Massage Chair
Rated Voltage: 110-120V 220-240V
Rated Frequency: 50/60hz
Rated Power :260w
Safety Design : Class I
TECHNICAL SPECIFICATIONS
Manufacturer Reserves The Right To Make Changes To Informations Published In This Document,
Including Without Limitation Specifications And Product Descriptions, At Any Time And Without Notice.

CONTENTS SAFETY PRECAUTIONS
MEDICAL WARNINGS
- Patients with serious hyperostosis
- Swollen lump and patient thrombosis
- Patients with serious heart conditions
- Pregnant Women
- People that consume large amounts of alcohol
- People with diabetes
- People suffering from high fever
- Patients with malignant tumors or malignant abscesses
- People with distorted joints
- People with serious skin conditions
- People with spinal injuries
- All people should consult a physian and exercise care when operating this system
- Minors under 16 years or people unable to control his/her behavior, i.e. mental patients,
people with paralysis, etc.
- Should not be allowed to operate the massage chair.
- Thank you for your purchase of this product. Before using, please read this USER MANUAL carefully,
and pay special attention to the safety precaution to ensure proper operation and use.
- Please keep this USER MANUAL properly for further reference.
- Before using, please read this "SAFETY PRECAUTIONS" carefully to ensure proper operation.
- The following "SAFETY PRECAUTIONS" is of great help to your correctly use of this massage chair
- To clearly indicate the degrees of danger and damage, the classes of accidents caused by incorrect
use are classified into WARNING and FORBIDDEN . Instructions marked as followings should
be strictly followed.
Not recommended for the following people.
CAUTION
WARNING
- Use this appliance only for its intended use as described in this manual.
Do not use attachments not recommended by the manufacturer.
- Never operate this appliance if it has a damaged cord or plug.
- Keep the cord away from heated surfaces.
- please empty pockets and remove all your arm Jewellery and watch before
using this chair
- Do not operate where aerosol (spray) products are being used.
- To disconnect, turn all controls to the off position, then remove plug from outlet.
- Connect this appliance to a properly grounded outlet only. See Grounding Instructions.
- Do not remove the back cushion and do not play with roller mechanism.
- Do not remove the bottom seat and do not play with actuators.
- Keep the cord out of heavy traffic area.
- Always unplug the power cord from the electrical outlet 0immediately after use.
- Only people less than 120kgs are acceptable.
- Do not operate any equipment with damaged parts.
CAUTION
SAFETY PRECAUTIONS
NAME AND FUNCTION OF EACH COMPONENT
PREPARATION BEFORE USING
PRODUCE STORAGE AND MAINTENANCE
TROUBLESHOOTING GUIDE
MEDICAL WARNINGS ----------------------------------------------------------------------------------
WARNING -----------------------------------------------------------------------------------------------
FORBIDDEN --------------------------------------------------------------------------------------------
REMOVE PLUG -----------------------------------------------------------------------------------------
EXTERNAL STRUCTURE --------------------------------------------------------------------------------
INTERNAL STRUCTURE --------------------------------------------------------------------------------
CONTROLLER ------------------------------------------------------------------------------------------
REMOTE CONTROLLER INSTRUCTION -------------------------------------------------------
INSTALLATION METHOD ------------------------------------------------------------------------
MUSIC SYSTEM -----------------------------------------------------------------------------------------
INSTALLATION POSITION -----------------------------------------------------------------------------
SURROUNDING ENVIRONMENT --------------------------------------------------------------------
GROUNDING INSTRUCTIONS -----------------------------------------------------------------------
AFTER USING THE CHAIR -----------------------------------------------------------------------------
METHODS OF STORAGE ------------------------------------------------------------------------------
MAINTENANCE -----------------------------------------------------------------------------------------
KIND REMINDING --------------------------------------------------------------------------------------
TROUBLESHOOTING GUIDE -------------------------------------------------------------------------
01
01
02
02
03
04
05
06 - 08
09 - 17
18
19
19
20
20
20
20
21
21

SAFETY PRECAUTIONS
- Any other use not recommended by the manufacturer may cause electrical
shock or injury.
- Do not touch or re-wire the wires connected to the master-box.
- Do not attempt to repair or adjust any electrical or mechanical functions on this unit.
Doing so will void the warranty.
- Do not put your hands or head under the chair
- When using the massage chair, ascertain that the footrest is in the lowest position
CAUTION
FORBIDDEN
- Do not allow children to play near the chair especially during operation
- Do not leave mobility impaired or speech impaired people alone in chair
- Do not place or stock this machine near damp places such as swimming pools or
bathrooms
- Do not press by force on the massage rollers
- Do not stand on the chair or store heavy items on the chair
- Do not use in the environment which is dusty, greasy or lacking oxygen
- Do not place near steam oven, open fire, or heat
- Wear suitable clothing, do not massage with bare skin
- Do not place directly in the sun
- Do not use electric blanket while using the massage chair
- Do not use outdoors
- Do not use while smoking
- Do no use immediately after meals
- Do not sit on the back cushions, armrest, or legs
- Don't use the massage chair when your body is wet or moist as it can result in
electrical shock
- Do not operate with more than one person
- Don't use when using head ornamentation as it can result in injury
- Do not stumble over electrical wires or connections
PROHIBITED
- Before maintenance, please pull out power plug. In addition,
please do not insert or unplug the power plug with damp hands, to avoid electric shock.
- When the massage chair is not in use, please switch off power and remove the plug
from socket. When power is off, please cut off power supply immediately
and pull out the power plug from socket.
REMOVE PLUG
NAME AND FUNCTION OF EACH COMPONENT
EXTERNAL STRUCTURE
Pillow
Back cushion
Shoulder Section
Seat cushion
Armrest
Legrest
LED light
Loud Speaker
Back Rest Cover
Moveable pulley
USB Socket
Earphone Socket
Fuse
Power Switch
Power Socket

Massage
Mechanism
NAME AND FUNCTION OF EACH COMPONENT
INTERNAL STRUCTURE
Back Air
Massage Unit
Back Heat
Slide Rail
Foot Air
Massage Unit
Sole Air
Massage Unit
Shoulder Air
Massage Unit
Mobile Phone
Link Line
Armrest Air
Massage Unit
Seat Air
Massage Unit
Foot Roller
Massage Unit
CONTROLLER
NAME AND FUNCTION OF EACH COMPONENT
Display Screen
Shoulder Position
Adjustment
Volume Up
Volume Down
Play/Pause
On/Off
Feet Up
Feet Down
Back UpBack Down
Extend
Retract
Mechanism Speed
Roller Speed
Air Intensity
Mechanism Width
Auto Mode
Manual Mode
Music Forward
Music Sync
Music Backward
Back Heat

NAME AND FUNCTION OF EACH COMPONENTNAME AND FUNCTION OF EACH COMPONENT
On/Off:
This button starts/stops the massage system.
REMOTE CONTROLLER INSTRUCTION
Auto
Auto Massage Modes
When the power is on, press this button, display screen lights-up, then press this
button to choose the auto mode menu : Relax, Extend, Zero(gravity), Neck Shoulder,
Back Waist. Choose one to have a specific massage.
Relax : For early morning or noon leisure massage, to generate muscle energy.
Extend: For office people and drivers who sit for long time, to stretch full body and recover.
Zero: Zero Gravity is a neutral body posture that reclines the body and elevates the
feet above the heart, It was developed by NASA, and has been scientifically proven
to put a person into a heightened state of relaxation and well-being. It can imitate
weightless status of aerospace, thus fully releasing the weight the body, the body will
stay in a most comfortable status without any stress, to enjoy The best massage feeling.
Neck Shoulder: Specific massage on Neck, Shoulder and Back to improve soreness of these
parts.
Back Waist: Specific massage on Back, Waist and Buttock, to improve soreness of these parts.
Manual
When the power is on, press this button, display screen lights-up, then press this
button to choose the manual mode menu: shiatus, knocking, pummel, tapping,
Kneading. Choose any of these to have a specific massage.
Shoulder Up
Shoulder Down
Under auto mode, if you feel the mechanism height does not fit well. Press this 2 buttons
( with 7 different choice), engages mechanism to desired shoulder height. The highest
mechanism is on your head. press shoulder down it goes from head to
your Neck and Shoulder. if the mechanism highest setting goes on your back, press
Shoulder up , it will go up to your Neck, Shoulder and Head. Under manual mode,
press shoulder up or shoulder down ,release it till to the desired part for fixed
partial massage.
REMOTE CONTROLLER INSTRUCTION
Speed
Mechanism Speed:
press this button, to circularly choose 0-6 levels of massage speed and intensity.
Roller Speed:
press this button, to circularly choose 0-6 foot roller speed.
Roller
Music Sync:
Under music, press this button to choose music synchronous massage. The mechanism
intensity and speed would be changed together according to the music rhythm.
Music Sync
Airbag
Air Intensity:
press this button, to circularly choose 0-6 airbags intensity.
Width
Mechanism Width :
under manual mode, press this button, to circularly choose 1-6 massage width.
Heat
Heat :
This button starts/stops the back cushion heat.
MP3 player Control :
with USB , Earphone, Mobile Phone link
press : Play/Pause Control
press or : Volume up /down Control
press or : songs Forward/Backward Control
