2 LOCC-Box-Net
2.1 General
LOCC-Box-Net ist eine elektronische Lastüberwachung zum Aufbau einer selektiven Absicherung von
Verbrauchern. Diese können ohmsch, kapazitiv oder induktiv sein. LOCC-Box-Net ist eine busfähige
Variante welche über Gateway’s in verschiedene Feldbussysteme integriert werden kann. Sie ist eine
weitere Variante der Standard LOCC-Box. Eine Parametrierung von Statusausgang, Ferneingang
bzw. dem Einschaltverhalten kann mit der kostenlosen Software LOCC-Pads oder der Steuerung
(SPS) erfolgen.
2.1.1 Propertys
- One channel version
- 10 adjustable current ranges, 1 … 10A in 1A steps
- 5 adjustable characteristics, fast acting … super slow acting
- Optimal protection for wire and devices
- Energy management
- Preventive maintenance
- Analog characteristic with thermic- and magnetic range
- Single or centralized fault indication
- Status display for normal operation, 90%- and 100% load and error.
- Remote input for switch On / Off
- Solid-State-Relays function with integrated overload- and short circuit protection
- Integration in Field bus systems
- …
2.1.2 Versions
Article
Property 716403 716404 716410 716411
Current range
10, adjustable in 1A steps, 1A – 10A
adjustable via rotary switch
adjustable via
Field bus or
LOCC-Pads
Characteristics
fast acting / middle acting / slow_1- / slow_2- / slow_3 acting
adjustable via rotary switch
adjustable via
Field bus or
LOCC-Pads
Status output
default: active Low after overload , short circuit + manual Off
parametrizable with LOCC-Pads
parametrizable
via Field bus or
LOCC-Pads
Remote input
default: On / Off about pulse length
parametrizable with LOCC-Pads
parametrizable
via Field bus or
LOCC-Pads
Device type type 1 type 3

User Manual LOCC-Box-Net, LOCC-Pads
8 LOCC-Box-Net_1.61_HB_EN
2.1.3 Adjustments
Die Einstellungen (Parametrierung) der Module erfolgt je nach Variante über Drehschalter, Software
LOCC-Pads oder das entsprechende Feldbussystem.
2.1.4 Reset of default
Alle Varianten können auf Werkseinstellungen zurück gesetzt werden.
Gilt ab Softwareversion: SW1. 6 – siehe Typenschild. Folgende Eigenschaften werden geändert:
- Knotennummer auf 0
- Kommentare werden gelöscht
- Strombereich auf 10A und Charakteristik auf 5 à nur Typ 716411
- Meldeausgang, Ferneingang und Einschaltverhalten auf Default (Kapitel 3.5.8)
- Charakteristik Nr. 10 wird auf Default wie Nr. 5 zurück gesetzt (Kapitel 3.5.4)
Das Zurücksetzen geschieht wie folgt:
- Die LOCC-Box-Net ist mit dem Gerätetaster in den Zustand AUS zu schalten à rote LED.
- Der Gerätetaster ist mindestens 5s lang zu drücken bis die LED anfängt grün zu blinken.
- Das Modul ist jetzt zurück gesetzt. In der Steuerung bzw. LOCC-Pads wird für das Module die
Information Leitungsbruch, Dahtbruch oder Kommunikationsfehler angezeigt.
2.2 Installation
2.2.1 System Assembly
For assembly mount the products on a top hat rail according to EN
50022. There are two possibilities:
A) Operating with supply set 716425 (Supply terminal and End
block)
ΠSnap on the supply terminal on the left side. The terminal includes
the end stop function. The supply terminal is connected to the PSU
(DC 12/24V, 40A).
• Alongside of the supply terminal (right side) the needed number of
control devices 716410 can be mounted.
Ž Mount the end stop terminal.
• To get an electrical connection between supply terminal and
control device cut the copper rail 716426 to a suitable length.
Calculation: 18mm + 8,1mm x n. The copper rail has to be
snapped into the relevant slots of the supply terminal and end stop terminal.
• To contact the single control modules, move the contact slide on the copper rail by using a screw
driver. The load is connected to termination point (1). The minus potential of the load must be
connected directly to the users power supply. This also applies to the minus potential (5). For all
other functions, see the function plan on the next page.
‘ If required, the copper rail can be covered by a plastic cover 716427 between supply terminal and
end terminal. The pre cut part is based on the calculation: L = 6mm + 8,1mm x n.

User Manual LOCC-Box, LOCC-Pads
LOCC-Box-Net_1.61_HB_EN 9
Der max. Strom einer Einspeiseklemme beträgt 40A. Um einen Strom > 40A in
das System einzuspeisen können, empfehlen wir die zusätzliche Verwendung
einer oder mehrerer Einspeiseklemmen vom Typ 716421. Somit ist ein
Maximalausbau mit 160A möglich (begrenzt durch die 3x10mm Kupferschiene).
B) Direct voltage supply of the control unit
Instead of powering the system via the supply terminal, it is possible to power the system via the
termination point (6). A power supply of DC 12/24 V is needed. All other functionalities correspond
to description A).
2.2.2 Simplified diagram
a) with supply terminal
b) Direct supply

User Manual LOCC-Box-Net, LOCC-Pads
10 LOCC-Box-Net_1.61_HB_EN
2.2.3 Dimension and Pin assignment
LOCC-Box 716410
LOCC-Box 716411
1: + Output
2: Control input (Set / Reset)
3: Status output
4: Communication
5: 0V
6: + Supply (alternative)
7: + Supply

User Manual LOCC-Box, LOCC-Pads
LOCC-Box-Net_1.61_HB_EN 11
2.2.4 Function, Displays and Settings
Functionality
PIN
Description
Output + , Load 1 + potential load
Control input - Set /Reset 2
Binary DC 12/24V input to switch on/ off the control unit.
Parametrizable with software LOCC-Pads - chapter 3.5.8
Default: Off: DC 12/24V (falling edge, pulse > 100ms, < 800ms)
On: DC 12/24V (falling edge, pulse > 1sec)
Single or centralized fault
indication 3
Binary output DC 12/24V for fault indication.
Parametrizable with software LOCC-Pads - chapter 3.5.8
Status 1: Level High: LOCC-Box switched on ; nominal operation
(Default) Level Low: LOCC-Box switched on ; nominal operation
Level Low : LOCC-Box blown ; load circuit open
Status 2: Level High: LOCC-Box switched on ; nominal operation
Level High: LOCC-Box switched on ; nominal operation
Level Low : LOCC-Box blown ; load circuit open
Communication 4 1 wire bus for Gateway
Input - 5 0V LOCC-Box device. Connect it directly to the power supply. On this
pin a minus potential of the load is not allowed.
Input + DC 12/24V
(alternative) 6
DC 12/24V, max. 10A; LOCC-Box
Under consideration of a max. total current DC 6A the jumper comb
716428-716430 (8-pole) or 716438-716440 (16-pole) can be used to
distribute the potential.
Contact slide, + input 7 Voltage supply of the module/ Load DC 12/24V, maximum DC 10A
Status indication
Operation
Description
LED green ON Function ok – output is active. #
LED red OFF The module is switched off or acknowledged via the button or
software.#
LED red with short off OFF The module is switched off or acknowledged via the remote
input.. #
LED green, flashing1Hz Overload Load over 90% of Inom
LED green, flashing 5 Hz Overload Load over 100% of Inom
LED red, flashing 1Hz Over
current Output switched off. Reason: over load. #
LED red, with short on Over
current Output switched off . Reason: short circuit. #
LED red, flashing 5Hz Error Wiring fault, internal device error
Adjustments
Operation
Description
Thumb wheel - I * Current Setting the rated current in 1 amp steps.
Thumb wheel - C * Characteristic 1: quick acting, 2: middle acting, 3: slow acting_1,
4: slow acting_2, 5: slow acting_3 (chapter 2.4)
Push button ** On / Off Nominal operation : On / Off
Fuse tripped : 1. press: Acknowledge / 2. press: On
* Settings are active after a restart of the modules. Use the push button for the restart.
** The push button has a master function. A module which was switched off by the button can only be
restarted by the push button, LOCC-Pads or the field bus.
# If an interruption of the operating voltage occurs the last status is stored (default).
The status output, the remote input and the switch on behavior after interrupt of the
power supply is adjusted of “default”.
Adjustments can be made via LOCC-Pads, see chapter 3.5.8.

User Manual LOCC-Box-Net, LOCC-Pads
12 LOCC-Box-Net_1.61_HB_EN
2.2.5 Installation
2.3 Technical data
2.3.1 LOCC-Box-Net (Control unit)
Input
Nominal voltage DC 12/24V
Voltage range DC 10 – 32V
Nominal current DC 10A max.
System current DC 40A via copper bar 3x10mm
Polarization protection internal electronic
Terminal screw less contact slide
Remote input (SET/RESET)
Signal level DC 12/24V (EN 61131)
Switch off time (Reset) > 100ms, < 800ms (falling edge) #
Switch on time (Set) ≥ 1sec (falling edge) #
Output
Switching technology MosFET
Output current DC 10A max.
Voltage drop < 170mV (10A)
Status indication green, red (see chapter 2.1.3)
Switch on capacity 10.000 μF
Rated switch off current DC 1A – DC 10 A (via switch, in steps of 1A)
Switch off times 1= fast acting, 2= middle acting, 3=slow acting_1, 4=slow acting_2,
5 - 9= slow acting_3, Curve 10 is via LOCC-Pads programmable!
Status output
Switch technology Solid state, open Collector with pull up resistor
Signal level DC 12/24V no fault; DC 0V fault occurred
General Data
Housing material PA 6.6 (UL 94 V0; NFF I2,F2)
Mounting snap on TS 35 (acc. EN 50022)
Protection level IP 20
Mounting position any
Installation technology spring termination 0.25mm2 – 2.5mm2 all types of wires
until 2.5mm² without end sleeve, until 1.5mm² with end sleeve
Operation temperature -25°C … +50°C
Store temperature -40°C … +85°C
Dimension (WxHxD) 8.1mm x 116mm x 114,5mm
Weight 0.12 kg
Approvals cULus 508, files E135145, vol. 2, sec. 8
Standards EN 60950-1; EN61131-1,2; EN 60898; EN 60947-4-1; EN 50081

User Manual LOCC-Box, LOCC-Pads
LOCC-Box-Net_1.61_HB_EN 13
2.3.2 Supply set (Supply terminal and end block), 716425
Input
Nominal voltage DC 12/24V
Nominal current DC 40A max.
General Data
Housing material PA 6.6 (UL 94 V0; NFF I2,F2)
Mounting snap on TS 35 (acc. EN 50022)
Protection level IP 20
Mounting position any
Installation technology spring termination 0.33mm2 – 10.0mm2
0.33mm² – 6.0mm²
Operation temperature -25°C … +60°C
Store temperature -40°C … +85°C
Dimension (WxHxD) 10.0 mm x 63.7mm x 119.4mm
Weight 0.035 kg
Approvals cULus 508, files E135145, vol.2, sec. 8
# Default-settings, and other operations modes can be set via LOCC-Pads

User Manual LOCC-Box-Net, LOCC-Pads
14 LOCC-Box-Net_1.61_HB_EN
2.4 Characteristic Curves
The LOCC-Box / LOCC-Box-Net offer the possibility to implement 10 characteristics. Up to the product
state E06 the first 3 switch positions (C) are realized as: 1 = fast acting, 2 = middle acting and 3 = slow
acting_1. With the product state E07 (end of August, 2009) and higher we provide additional the
switch position 4 = slow acting_2 and 5 = slow acting_3. All other switching positions are like the last
one.
1. Switch setting, characteristic fast acting 2. Switch setting, characteristic middle acting
3. Switch setting, characteristic slow acting_1 4. Switch setting, characteristic slow acting_2
5. Switch setting, characteristic slow acting_3
1 2 3 4 5 6 7 8 9 10 1 2 3 4 5 6 7 8 9 10
1 2 3 4 5 6 7 8 9 10 1 2 3 4 5 6 7 8 9 10
1 2 3 4 5 6 7 8 9 10

User Manual LOCC-Box, LOCC-Pads
LOCC-Box-Net_1.61_HB_EN 15
3 LOCC-Pads (Software) 2)
3.1 Introduction
This section describes the installation and the functionality of the LOCC-Pads software. It also
describes the connection between LOCC-Pads (716410) and the Gateway (716459). The software
and all components are suitable to the LOCC-Box-Net modules. The software is compatible with
following operating systems:
§ Windows 2000 1)
§ Windows XP 1), 32 Bit
§ Windows Vista 1), 32 Bit
§ Windows 7 1), 32 Bit, 64Bit
The software is designed to parameterize, to analyze and to diagnose the LOCC-Box-Net and all
connecting loads. Connect the module via the USB interface to the computer, see chapter 3.3Fehler!
Verweisquelle konnte nicht gefunden werden.. For the communication between LOCC-Box-Net
and LOCC-Pads a Gateway is required.
Connect the Gateway after installing the software LOCC-Pads, otherwise an
installation of the device driver is not possible. The LOCC-Pads software is also
needed for the communication via RS232 and CANopen in order to set the
required parameters such as parity or baud rate. You can find detailed
information in chapter 3.4.3.
3.2 Installation
The Software package LOCC-Pads is needed for installation. The software can be downloaded free of
charge on the Lütze website:
www.luetze.de - Deutschland - Downloads - Eplan/Macros/Software
To install the software proceed as follows:
1. Download the file LOCC-Pads_x.x.x.x.zip and save it in any
directory. The directory can be deleted after the installation.
2. Extract the Zip-Files in the same directory.
3. Start the installation by double clicking on the file
LOCC-Pads_setup_xxxx.exe. Choose a setup language
(German / English). Confirm by clicking OK.
4. Windows1) starts the setup assistant. The
Assistant guides through the installation.
Follow the instructions and confirm with Next
to continue or Cancel to abort.

User Manual LOCC-Box-Net, LOCC-Pads
16 LOCC-Box-Net_1.61_HB_EN
5. Licensing Agreement
Please read the licensing agreement
carefully and choose I accept the Agreement
or I reject the agreement. In case of a
rejection it is not possible to proceed with the
installation. Confirm with Next.
6. Choose a Target Folder
The setup chooses automatically the
presettled folder where LOCC-Pads have to
be installed. Click Next to continue or
Browse, if you wish to choose another folder.
Note the necessary disc space.
7. Choose the Start Menu Folder
The setup will create automatically the
program linkage in the presettled start menu
folder. Click Next to continue or Browse…, if
you wish to choose another folder.
8. Additional functions
Mark the checkbox Create a desktop icon to
create a shortcut on the desktop. To confirm
click Next.

User Manual LOCC-Box, LOCC-Pads
LOCC-Box-Net_1.61_HB_EN 17
9. Installation
All adjustments are displayed. Click Install to
start the installation. Click Back if you wish to
modify your adjustments.
10. Device driver installation
11. End
Mark the checkbox Launch LOCC Pads to
start LOCC Pads after installation. Click
Finish to complete the installation.
3.3 USB connection
The picture shows the connection between LOCC-Box-Net and a computer via the USB connection.
The follow example show the gateway 716459 (CANopen). The connection to other gateway is similar
– see the relevant the relevant user manual. The USB cable is in the gateway scope of delivery.
Please make sure that the software LOCC-Pads is already installed!

User Manual LOCC-Box-Net, LOCC-Pads
18 LOCC-Box-Net_1.61_HB_EN
1. Supply the module, the LOCC-
Box-Net and the Gateway with
an operating voltage of DC
12/24V.
2. Connect all the COM
connectors of the LOCC-Box-
Net module to the Gateway.
The jumper combs (see
chapter 4, Accessories) are
suitable for this purpose.
3. Connect the USB cable to the
Gateway or rather to the
computer. The computer will
recognize the Gateway as new
hardware and, if necessary, the assistant to search a new hardware will start.
3.4 Adjustments
After connecting the modules as described in
chapter 3.3, start the software by double
clicking on the LOCC-Pads symbol on the
desktop or by Start >Programs>LOCC-
Pads>LOCC-Pads.
LOCC-Pads starts in an inactive mode. With
LOCC-Pads it is possible to make adjustments
in the COM settings, to download the firmware
and to select a language.
3.4.1 Language
Click Extra > Language to choose a language (English or German).
3.4.2 COM Config
To create a communication between computer and the Gateway, it is
necessary to define the connection USB-Comport. The adjustment has to
be made by clicking Extra > COM Config.
-> The active state is indicated in the status line (COM-state) on the
right bottom of the window.
3.4.3 LOCC-Box Gateway
In order to use the Gateway for CANopen (RS232) and EtherCAT, it is necessary to make some basic
setting. Click Extra > LOCC-Box Gateway. The first line display the currently firmware from the
connected module.

User Manual LOCC-Box, LOCC-Pads
LOCC-Box-Net_1.61_HB_EN 19
Ø General
- Cycle time (ms): Time for the cyclic inquiry of the
Connected LOCC-Box-Net modules
Ø CAN
- Node number: Assignment of the node number in
the CANopen Network, maximal 254
- Baud rate (Kbit/s): Adjustment of the data rates,
min. 10 / max. 1000
Ø COM
- Baud rate (bit/s): Adjustment of the data rates,
min. 600 / max. 115200
All the values in gray can be read after the call of the window and show the present adjustments of the
Gateway. With the button „Refresh“ it is possible to update the values and to save them with „Set“.
“OK“ is used to close the window - new adjustments are not saved. At the top the currently firmware is
additionally indicated.
3.4.4 Firmware Download
The Firmware Download is for updating the gateway software. It is only for service purposes
(updates). This function is password protected.
3.5 Function via USB
The software LOCC-Pads is subdivided in
following windows:
“LOCC-Box Nodes“,
“All Nodes“,
“LOCC-Box Status“,
“LOCC-Box Characteristic“,
“LOCC-Box Counter“ and
“LOCC-Box Current/Voltage“.
Further options and adjustments can be found
in the menu item Extra. The options are
described below.

User Manual LOCC-Box-Net, LOCC-Pads
20 LOCC-Box-Net_1.61_HB_EN
3.5.1 Window - LOCC-Box Nodes (Node Number Assignment)
This window offers the possibility to search modules, to adjust the start/stop record of the module data
and the scan time. Also the node number, the device status, the type, the serial number and an
editable comment are displayed.
Searching new modules with node number 0 (delivery status)
Modules with default settings always have the node number 0. To
use the modules they have to be assigned by a node number
between 1 and 254.
After clicking Search, the internal bus is checked for
connected modules. After the check the message Found
new nodes... appears.
To configure those nodes click Yes, to cancel click No.
If choosing Yes all found modules are in the configuration
mode.
The modules are flashing green. As a standard number 1 is
suggested.
The number can be changed to any other number. To assign
any module to that number press the push button of that
module for 1 sec. The displayed number increments by 1 and
the next module can be assigned. This process has to be
repeated till all modules are assigned to a node number.
Assigned modules can be reset by choosing Extra > LOCC-Box Reset. See
chapter 3.5.11.
An additional Reset of the default status is possible over the push button. See
chapter 2.1.4.
Searching modules with a node number > 0
After clicking Search, the internal bus is checked for
connected modules. All modules with a node number
between 1 and 254 will be displayed in the LOCC-
Box Node window.
Modules with the node number 0 or the same node
number are also recognized. These modules have to
be configured.
The window Search Node appears.
In the following example two modules with the node number 6 were
found.
After configuring node number 7 the search restarts.
This process will be repeated till all modules are
assigned to a valid node number (accept 0).
