Labconco Purifier Logic+ 30348 User manual

LABCONCO CORPORATION
8811 Prospect Avenue
Kansas City, MO 64132
[phone] I [phone]
[e-mail]
Please read this manual before
operating equipment
Original Instructions
User’s Manual

2
Logic+® Type B2 Biosafety Cabinets
2019—Present (Catalog Numbers Ending in -x1)
30348xxxx 30368xxxx

3
Copyright © 2018 Labconco Corporation. The information contained in this manual and the
accompanying products are copyrighted and all rights reserved by Labconco Corporation.
Labconco Corporation reserves the right to make periodic design changes without obligation to
notify any person or entity of such change.
Returned or Damaged Goods
Do not return goods without the prior authorization from Labconco. Unauthorized returns will not
be accepted. If your shipment was damaged in transit, you must file a claim directly with the freight
carrier. Labconco Corporation and its dealers are not responsible for shipping damages.
The United States Interstate Commerce Commission rules require that claims be filed with the
delivery carrier within fifteen (15) days of delivery.
Limitation of Liability
The disposal and/or emission of substances used in connection with this equipment may be
governed by various federal, state, or local regulations. All users of this equipment are required to
become familiar with any regulations that apply in the user’s area concerning the dumping of waste
materials in or upon water, land, or air and to comply with such regulations. Labconco Corporation
is held harmless with respect to user’s compliance with such regulations.
Contacting Labconco Corporation
If you have questions that are not addressed in this manual, or if you need technical assistance,
contact Labconco’s Customer Service Department or Labconco’s Product Service Department at
(800)-821-5525 or [phone], between the hours of 7:30 a.m. and 5:30 p.m., Central
Standard Time.
Part #3848331 Rev. C
ECO L847
Warranty
Labconco Corporation provides a warranty to the original buyer for the repair or replacement of parts and
reasonable labor as a result of normal and proper use of the equipment with compatible chemicals. Broken
glassware and maintenance items, such as filters, gaskets, light bulbs, finishes and lubrication are not
warranted. Excluded from warranty are products with improper installation, erratic electrical or utility supply,
unauthorized repair and products used with incompatible chemicals.
Purifier®Logic®+ Biological Safety Cabinets and PuriCare®Procedure Stations carry a five-year warranty from
date of installation or six years from date of shipment from Labconco, whichever is sooner. Warranty is non-
transferable and only applies to the owner (organization) of record.
Buyer is exclusively responsible for the set-up, installation, verification, decontamination or calibration of
equipment. This limited warranty covers parts and labor, but not transportation and insurance charges. If the
failure is determined to be covered under this warranty, the dealer or Labconco Corporation will authorize repair
or replacement of all defective parts to restore the unit to operation. Repairs may be completed by 3rd party
service agents approved by Labconco Corporation. Labconco Corporation reserves the rights to limit this
warranty based on a service agent’s travel, working hours, the site’s entry restrictions and unobstructed access
to serviceable components of the product.
Under no circumstances shall Labconco Corporation be liable for indirect, consequential, or special damages of
any kind. This warranty is exclusive and in lieu of all other warranties whether oral, or implied.

4
TABLE OF CONTENTS
1: INTRODUCTION 7
2: PREREQUISITES 8
Clearance Requirements 8
Location Requirements 9
Exhaust Requirements 10
Concurrent Balance Volumes 10
Electrical Requirements 11
Service Line Requirements 12
3: GETTING STARTED 13
Unpacking the Cabinet 14
Preparing the Cabinet for Operation 15
Moving and Lifting the Cabinet 15
Installing the Cabinet on an Existing Work Surface 15
Installing the Cabinet on a Labconco Base Stand 16
Telescoping Base Stands 16
Manual or Electric Hydraulic Lift Base Stands 16
Exhaust System Connections 17-18
Exhaust System Requirements 18
Connecting the Cabinet to Utility Service Lines 18-19
Optional Vacu-PassTM Cord and Cable Portal Use 20
Installing the Drain Valve 21
Initial Certification 22
4: PERFORMANCE FEATURES & SAFETY PRECAUTIONS 23
HEPA Filters 23-24
ULPA Filters 24
Laminar Airflow 25
Directional Airflow 26
Motor/Blower 27
Airflow Sensor 27
Cabinet Grilles, Ductwork & Air Balance Controls 28
Ultraviolet (UV) Lamp 28
Safety Precautions 29-30

5
5: USING THE CABINET 31
System Reset Switch 31
Information Center 32
Alarm Screens 33-34
Operating the Sliding Sash 35
Starting the Cabinet 35
Using the Cabinet Keypad 36
Navigating the Cabinet Menu Screens 37
Navigating the Configuration Submenu 38-40
Activating a Startup Tone 38
Selecting a Language 38
Setting the Clock 39
Setting Automatic Operation Options 40
Navigating the Settings Submenu 41-42
Selecting the Units of Measure 41
Activating the Security Lock 41
Setting the USB Output Rate 41
Navigating UV Parameters 42
The Tools Submenu 42
Timer Operation 43
Interval Timer Operation 43
Stopwatch Timer Operation 43
If An Airflow Alert Activates 44
Resetting the Airflow Alert System 44
Working in the Cabinet 44-46
6: MAINTAINING THE CABINET 47
Suggested Maintenance Schedule 48
Service Operations 49-54
Work Surface Removal 49
Front Grille Removal 49
Towel Catch Removal 50
Front Panel Removal & Installation 51
Changing the LED Lamps 52-53
Changing the Optional UV Lamp 53
Resetting a Circuit Breaker 54
Storage 54
7: TROUBLESHOOTING 55-58
APPENDIX A: COMPONENTS 59
APPENDIX B: DIMENSIONS 60

6
APPENDIX C: SPECIFICATIONS 61
Electrical Data 61
Motor Specifications 61
Environmental Conditions 62
APPENDIX D: ACCESSORIES 63
APPENDIX E: QUICK CHART 64
CAUTION –See Manual. When this symbol is on the unit it
indicates a caution that is detailed in this manual.
ATTENTION - Voir manuel. Lorsque ce symbole est allumé
l'appareil, il indique une mise en garde qui est indiqué
dans ce manuel.

7
1: Introduction
Congratulations on the purchase of a Labconco®Purifier© Biosafety Cabinet. The
cabinet is designed to protect you, the product and the laboratory environment
from biohazardous aerosols. It is the result of years of experience in
manufacturing biohazard cabinetry, and users like you suggested many of its
features to us.
This cabinet offers many unique features to enhance safety, performance and
ergonomics. To take full advantage of them, please acquaint yourself with this
manual and keep it handy for future reference. If you are unfamiliar with how
biosafety cabinets operate, please review Section 4: Performance Features and
Safety Precautions before you begin working in the cabinet. Even if you are an
experienced cabinet user, please review Section 5: Using the Cabinet; it describes
the cabinet’s features so that you can use it efficiently.
This manual and other technical documents are available for download at
our website: labconco.com.
If the unit is not operated as specified in this manual it may impair the
protection provided by the unit.
Si l'unité n'est pas utilisée comme spécifié dans ce manuel il peut diminuer
la protection fournie par l'unité.

8
2: Prerequisites
Before you install the cabinet, you need to prepare the site for installation.
Examine the location where you intend to install it. You must be certain that the
area is level and of solid construction. In addition, a dedicated source of electrical
power must be located near the installation site.
This section lists all requirements for:
Clearance
Location
Exhaust
Electrical
Service Lines
Refer to Appendix C: Specifications, for complete cabinet electrical and
environmental conditions and specifications.
Clearance Requirements
A minimum clearance of at least 6 inches (150 mm) is suggested on the top and
both sides of the cabinet for service.
Refer to Appendix B: Dimensions, for complete cabinet model dimensions.

2: Prerequisites
9
Location Requirements
The cabinet should be located away from traffic patterns, doors, fans, ventilation
registers, fume hoods and any other air-handling devices that could disrupt its
airflow patterns. All windows in the room should remain closed. Figure 2-1 shows
the preferred location for the cabinet.
Preferred location Air register blocked or redirected
to prevent cabinet disruption
Alternate location
Main Disconnect Device
(Power cord plug in back
of the electronics
module).
Do not position the unit so that it is difficult to operate the main disconnect
device.
Ne placez pas l'appareil de sorte qu'il est difficile de faire fonctionner le
dispositif principal de déconnexion.
Figure 2-1

2: Prerequisites
10
Exhaust Requirements
NOTE: THE EXHAUST BLOWER CANNOT RUN AT ITS NOMINAL FLOW RATE
WITH THE SASH COMPLETELY CLOSED. IF YOU CHOOSE TO CLOSE THE
SASH COMPLETELY TO USE THE UV LIGHT FOR SURFACE DISINFECTION,
THEN THE EXHAUST BLOWER MUST BE SHUT OFF, OR ITS FLOW RATE
REDUCED 90% OR MORE FOR PROPER OPERATION. THE LOGIC+ HAS AN
OPTIONAL EN/CONTACT CIRCUIT BOARD THAT HAS DRY CONTACTS THAT
CAN BE CONFIGURED TO SIGNAL THE EXHAUST BLOWER TO TURN ON
WHEN THE LOGIC+’s BLOWER IS ON. FOR FURTHER INFORMATION,
CONTACT LABCONCO’S PRODUCT SERVICE DEPARTMENT. AS AN
ALTERNATIVE, A REMOTE ELECTRICAL SWITCH FOR THE EXHAUST
BLOWER CAN BE INSTALLED NEAR THE LOGIC+.
Before deciding on a location, examine it carefully to ensure that it accommodates
the cabinet’s exhaust duct. The area directly above the cabinet’s exhaust port
should be clear of structural elements, water and utility lines, or other fixed
obstructions. There should be enough clearance to allow for the passage of a 10"
stainless steel duct. Avoid cabinet locations that require either an elbow directly on
top of the cabinet’s exhaust connection or an excessive number of elbows to clear
other items. For a further discussion of the cabinet’s exhaust system
requirements, please go to Section 3: Getting Started.
Concurrent Balance Volumes (CBV)
NOTE: THE CBV IS ESTABLISHED BY NSF DURING LISTING TESTING. THE
STATIC PRESSURE LISTED IS MEASURED AT THE BSC’S CONNECTION TO
THE EXHAUST SYSTEM. THE VALUES PUBLISHED INCLUDES 0.7 INCHES
OF FILTER LOADING, FROM THE BSC’S ORIGINAL PRESSURE. IN ORDER
TO OBTAIN MAXIMUM EXHAUST HEPA FILTER LOADING, THE SYSTEM
SHOULD BE CAPABLE OF GENERATING A STATIC PRESSURE 1.3 INCHES
HIGHER THAN THOSE NOTED.
Concurrent Balance Values
Traverse Exhaust Volume
(CFM)
734
1191
Differential Pressure (in. H20)
1.7
2.1

2: Prerequisites
11
Electrical Requirements
The cabinet models have the following electrical requirements:
Model Number
Typical Operating
Current (Amps)
Electrical Circuit
Requirements1
3034xxx01
3 A
115 V, 60 Hz, 12 A
3034xxx21
3 A
100 V, 50/60 Hz, 12 A
3034xxx-11, 31, 41, 51, 61, 71
1.5 A
230 V, 50/60 Hz, 6 A
3036xxx01
5 A
115 V, 60 Hz, 12 A
3036xxx21
5 A
100 V, 50/60 Hz, 12 A
3036xxx-11, 31, 41, 51, 61, 71
2.5 A
230 V, 50/60 Hz, 6 A
A dedicated outlet with an appropriate circuit breaker should be located as
close as possible to the right rear side of the cabinet, at a height even with,
or higher than, the top of the bench or stand. Consult your local electrical
codes for properly rated circuit breakers. For safe operation the dedicated
outlet must provide the protective earthing ground connection to the
cabinet.
On 100 and 115 VAC models, both internal electrical outlets are protected by a
ground fault interrupter circuit (GFIC). Labconco does not recommend plugging
the cabinet into a GFIC outlet.
Electrical outlets in the cabinet are restricted to 5 amps (115 Volt
models) or 2 amps (230 Volt models) maximum current.
Les prises électriques dans l'armoire sont limitées à 5 ampères
(modèles 115 volts) ou 2 ampères (modèles 230 volts) courant
maximum.
Do not use any detachable power cord that is not adequately rated for the
unit.
Ne pas utliser un fil électrique amovible qui n’est pas du tension
nominale de l’appareil.
Table 2-1
1 Electrical Requirements, ‘V’ = VAC (Voltage with alternating current), ‘A’ = Amperes

2: Prerequisites
12
Service Line Requirements
All utility service lines should be ¼ inch O.D., brass, copper, or stainless steel, and
equipped with an easily accessible shut-off valve. If the service line pressure
exceeds 40 PSI, it must be equipped with a pressure regulator to reduce the line
pressure.
The use of flammable gases or solvents should be avoided in the cabinet. Open
flame in the cabinet will disrupt the laminar airflow in the cabinet and may damage
the HEPA filters. Flammable gases or solvents may reach explosive
concentrations in the cabinet or ductwork. If you feel that the procedure requires
the use of an open flame or flammable materials, contact the institution’s safety
office.
The use of air or gases under high pressure should be avoided as they may
seriously disrupt the airflow patterns in the cabinet.

13
3: Getting Started
Now that the installation is properly prepared, you are ready to inspect, install, and
certify the Logic+ Biosafety Cabinet. This Section covers how to:
Unpack and move the cabinet
Install the cabinet
Connect the electrical supply source
Connect the service lines
Connect to an exhaust system (optional)
Arrange certification of the cabinet
Tools required for installation of the cabinet include two 1/2" wrenches, a flat-blade
screwdriver, a #2 Phillips screwdriver, and a carpenter’s level.
Note: The cabinet models weigh between 400–700 lbs. (182-318 kg). The
shipping pallet allows for lifting with a mechanical lift truck or floor jack. If you must
lift the product manually, use at least six (6) persons and follow safe-lifting
guidelines.

3: Getting Started
14
Unpacking the Cabinet
1. Carefully remove the outer carton and inspect the cabinet for damage that
may have occurred in transit. If the cabinet is damaged, notify the delivery
carrier immediately and retain the entire shipment intact for inspection by
the carrier.
Note: United States Interstate Commerce Commission rules require that claims be filed
with the delivery carrier within fifteen (15) days of delivery.
Do not return goods without the prior authorization of Labconco. Unauthorized returns will
not be accepted.
If the cabinet was damaged in transit, you must file a claim directly with the freight carrier.
Labconco Corporation and its dealers are not responsible for shipping damages.
Do not discard the carton or packing material for the cabinet until all of the components
have been checked, installed and tested.
2. The cabinet is secured to the pallet in two places on each side. To access
the nuts and bolts, remove the side panels by removing and keeping the
two Phillips screws from both panels. Swing the front of each panel away
from the cabinet, and lift it straight up to remove the panel from the cabinet.
3. While the side panels are off, the sash weight support pins must be
removed. Follow the two yellow strings to the support pin and its clevis pin.
Remove the clevis pins, and pull the support pins straight back. Discard the
pins and yellow string. See Fig. 3-1 below.
Note: The side panels must be removed
to access the fasteners that secure the
cabinet to the pallet. DO NOT ATTEMPT
TO LIFT THE CABINET BY THE SIDE
PANELS; DAMAGE WILL OCCUR.
Clevis Pin
Support
Pin
Yellow
String
Same on opposite end!
Yellow String (to
Left End Pins)
Shipping Bolts (2 per end)
Figure 3-1
Parts Box
(ref Fig. 3-2)
Product illustration
may not accurately
represent all models

3: Getting Started
15
Preparing the Cabinet for Operation
Installation instructions (Labconco P/N 1056801) are attached to the sash of the
cabinet. If these instructions are missing or unclear, contact Product Service at
[phone] or [phone]. The following are located in a box (see Fig.
3-1 on previous page and Fig. 3-2 below) underneath the work surface:
User’s Manual Thumb Drive
Drain Valve Assembly and fasteners
Power Cord
Vacu-PassTM Accessories (optional)
If you did not receive one or more of the components listed for the cabinet, or if
any of the components are damaged, contact Labconco Corporation immediately
for further instructions.
Moving and Lifting the Cabinet
Move the cabinet, attached to its pallet, by using a floor jack, or a furniture dolly
underneath the unit. DO NOT move the cabinet by tilting it onto a hand truck.
When lifting the cabinet DO NOT lift the cabinet in the middle front area of the hull.
Lifting here may bend or distort the bottom of the cabinet, causing damage to the
unit.
Installing the Cabinet on an Existing Work Surface
Note: The cabinet is very top heavy. Use caution when lifting or moving it.
When installing the cabinet onto an existing work surface or benchtop, ensure that
the structure can safely support the combined weight of the cabinet and any related
equipment. The work surface should be at least as wide as the cabinet and 31
inches (787 mm) deep to properly support the unit. A hole or notch may be cut in the
supporting surface in the right front corner to accommodate the optional drain valve.
Parts Box
Underneath the work surface
Figure 3-2

3: Getting Started
16
Installing the Cabinet on a Labconco Base Stand
Labconco offers accessory base stands in a variety of configurations to suit your
particular needs. If assembly of the base stand is required, the assembly
instructions are packaged with the base stand.
Telescoping Base Stands
These stands are included with some cabinet models, or available separately. The
base stands are listed in Table 3-1 below. An optional caster wheel kit is available
(catalog number 3730500).
Cabinet Width
(Feet)
Base Stand Catalog
Number
4'
3401004
6'
3401006
Manual or Electric Hydraulic Lift Base Stands
These base stands offer infinitely adjustable height between 25.5 and 33.5 inches
(648 to 851 mm), giving a cabinet work surface height of 28.0 to 36.0 inches. The
height is adjusted either manually (hand crank) or electric pump that drives the
hydraulic legs of the stands. All of the hydraulic stands are equipped with fixed
feet, but can be converted to caster wheels with the Caster Kit (catalog number
3784000). The base stands for each cabinet size are listed in Table 3-2 below.
Cabinet
Width
(Feet)
Manual Lift Stand
Catalog Number
Electric (100-115V) Lift
Stand Catalog Number
Electric (230V) Lift
Stand Catalog Number
4'
3780201
3780101
3780104
6'
3780202
3780102
3780105
Note: When installing the cabinet on the hydraulic lift base stand, ensure that the
hydraulic lines and the electrical cord are clear of any obstructions before installing
the cabinet on the stand or operating the lift system.
Table 3-1
Table 3-2
Note: B2 biosafety cabinets MUST be connected to an exhaust system, if ordering
the caster wheel kit, the duct connection MUST be of flexible construction.
Note: B2 biosafety cabinets MUST be connected to an exhaust system, if ordering
an adjustable height stand, the duct connection MUST be of flexible construction.

3: Getting Started
17
Exhaust System Connections
The Purifier Logic Series Total Exhaust Biosafety Cabinets are a “Type B2
biosafety cabinet,” meaning they direct their HEPA filtered exhaust air out of the
laboratory.
WARNING: The Logic Total Exhaust Biosafety Cabinet is designed to
be connected to an appropriate exhaust system. Without verified inflow
velocity, the cabinet may NOT contain hazardous particulate or gasses. Do
not attempt to operate it when it is not connected to an appropriate exhaust
system that has been inspected by a qualified certifier.
WARNING: Type B2 Biosafety Cabinets rely on external blowers
(usually on the roof of a building) to exhaust 100% of the air entering the
cabinet. If the building exhaust blower fails or is mistakenly turned OFF, the
cabinet will become pressurized, resulting in a flow from the work area into
the laboratory. It is imperative that the following be considered in a risk
assessment:
Justify the type of work is appropriate for the cabinet Type B2.
Exhaust system must be reliable, maintained, frequently inspected
and preferably redundant.
Exhaust termination must be distant from other building air intake
systems to prevent the reintrainment of volatile chemicals.
NOTE: THE EXHAUST BLOWER CANNOT RUN AT ITS NOMINAL FLOW RATE
WITH THE SASH COMPLETELY CLOSED. IF YOU CHOOSE TO CLOSE THE
SASH COMPLETELY TO USE THE UV LIGHT FOR SURFACE DISINFECTION,
THEN THE EXHAUST BLOWER MUST BE SHUT OFF, OR ITS FLOW RATE
REDUCED 90% OR MORE FOR PROPER OPERATION. THE LOGIC CONTROL
BOARD HAS DRY CONTACTS THAT CAN BE CONFIGURED TO SIGNAL THE
EXHAUST BLOWER TO TURN ON WHEN THE LOGIC BLOWER IS ON. FOR
FURTHER INFORMATION, CONTACT LABCONCO’S PRODUCT SERVICE
DEPARTMENT. AS AN ALTERNATIVE, A REMOTE ELECTRICAL SWITCH FOR
THE EXHAUST BLOWER CAN BE INSTALLED NEAR THE LOGIC.
THE EXHAUST CONNECTION IS A SEALED EXHAUST SYSTEM FROM THE
TOP OF THE CABINET TO THE REMOTE BLOWER. THE EXHAUST
SYSTEMS SHOULD BE DEDICATED TO A SINGLE CABINET. THE CABINET IS
EQUIPPED WITH AN EXHAUST FLOW ALARM, SUCH THAT AN ALARM
SOUNDS, AND THE CABINET BLOWER SHUTS OFF IN THE EVENT OF
INSUFFICIENT EXHAUST FLOW.

3: Getting Started
18
If your research involves the use of toxic compounds or volatile materials, contact
your facility’s safety officer or Labconco to ensure that your Purifier and its exhaust
system are compatible with the materials you will be working with.
Exhaust System Requirements
The cabinet exhaust stack is sized to accept 10-inch (254 mm) stainless steel
ductwork. The exhaust system’s blower should be sized to handle the exhaust
volume of each cabinet, as shown in the QuickChart (Appendix E). The exhaust
system must maintain a static pressure equal to or greater than the system
pressure, plus a pressure of 1.5 inches (38 mm) water for the Logic cabinet. In
order to get the maximum life out of the cabinet’s exhaust filter, the system needs
to be able to operate at an additional 2.0 inches (51 mm) of vacuum, compared to
the initial total system pressure.
NOTE: The exhaust system should be fitted with a backdraft damper
(Catalog Number 3858800) to prevent the reversing of airflow in the system.
LABCONCO MANUFACTURES EXHAUST BLOWERS AND A BACKDRAFT
DAMPER, WHICH ARE SUITABLE FOR MOST SINGLE CABINET
INSTALLATIONS. SEE APPENDIX D.
Connecting the Cabinet to Utility Service Lines
Note: Some models have a solenoid valve connected to the service valve on the
right side, rear position. The solenoid prevents gas from flowing to the service
valve when the unit blower is off, or there is a loss of electrical power. It is the only
service valve position that can be fitted with a solenoid valve. Connect the gas
service to the solenoid valve.
The service lines (if any) should be connected to the tube fitting(s) on the outside
of the liner wall as shown in Figure 3-1. To install the tubing, follow these steps:
1. Ensure that the tubing is ¼ inch O.D., soft metal, and that the end has been
completely deburred.
2. Route the tubing from the rear of the cabinet, ensuring that it will line up with
the slot in the back of the side panel. The slot is located from 8 ¾ to 11 ¼
inches (222 to 288 mm) from the bottom of the cabinet.
Note: Make sure that the tube routing will not contact any electrical wires. DO
NOT loop service line tubing within the side panels of the cabinet.
3. Make sure that the nut on the tube fitting is loose, but do not remove it. Make
sure the tube ferrule is in the fitting.

3: Getting Started
19
4. Push the tube into the fitting until it is properly seated. The tube will go
approximately ¾ inch (19 mm) into the fitting.
5. Tighten the tube fitting nut hand tight and then, using a 7/16-inch wrench,
tighten it at least ¾ turn more.
6. Close the service valve in the cabinet and then slowly open the shutoff valve
on the service valve. Test all fittings for leakage. Tighten the tube nut slightly if
needed.
Tube fitting nut
Tube fitting
Figure 3-1

3: Getting Started
20
Using the Optional Vacu-PassTM Cord & Cable Portal
There must be enough clearance to pass the cord or cable between the cabinet’s
exterior dress panel and any obstruction.
Note: Some Vacu-Pass components and the cord or cable passing through it may
become contaminated during use of the cabinet. Ensure all potentially
contaminated components are surface decontaminated before handling or removal
from the cabinet.
1. Remove the grommet from the liner sidewall. Remove the solid sealing plug
from the body of the portal by either pressing it through from the outside, or by
carefully inserting a spatula or similar device between the sealing plug and the
body of the portal, and prying the plug out.
2. Locate the pass-thru universal sealing plug, which is included in the parts box
located underneath the work surface during shipment.
3. Pass the cord or cable through the body of the portal, and then through one of
the holes in the pass-thru universal sealing plug, then through the grommet, as
shown in Figure 3-2.
Note: select a hole in the sealing plug that is slightly smaller than the cord or
cable, to create a proper seal. This will also help minimize movement of the cord
or cable if it is accidentally pulled during use.
4. Position the cord or cable as it will be used in the cabinet, and then push the
plug back into the body of the portal until it seats in the portal. Reinstall the
grommet.
Figure 3-2
