LABTEC ECO static User manual

User Manual Labtec ECO page 1www.labtec.de
User Manual
Labtec ECO static / dynamic
Labtec
No Content Page
1foreword 2
2safety instructions 2
3device description 3
4technical data 4
5component description 5
6operating elements 6
7commissioning 7
8care and maintenance 7

User Manual Labtec ECO page 2www.labtec.de
1. foreword
This operating manual describes the operati-
on of the Labtec ECO series of test instru-
ments.
Labtec test devices are professional tools
that require comprehensive respiratory pro-
tection expertise, e.g. by completing training
as a respirator maintenance technician, to
ensure proper operation and correct measu-
rement.
A prerequisite for proper operation of the de-
vice is that the device is operated and used
exclusively in accordance with these opera-
ting instructions. Labtec is not liable for per-
sonal injury or damage to property or conse-
quential damage of any kind if the device is
used in a manner other than that described
in this manual. The same applies to the ac-
ceptance of any warranty and guarantee
claims.
Otherwise, the terms of sale and delivery as
well as the warranty and guarantee conditi-
ons of Labtec GmbH apply, which are not
extended in any way by these instructions.
2. safety instructions
Each Labtec test device requires device-
specific instruction by an authorized Labtec
employee or training partner.
The device may only be operated by instruc-
ted and authorized personnel.
The device may only be serviced and re-
paired by trained and certified Labtec service
technicians. Only original spare parts and
accessories must be used.
The device may only be opened by a Labtec
service technician or, if expressly requested,
under instruction by a Labtec employee.
To ensure proper functioning of the device
and thus a correct measurement result, the
device must be serviced at least once a year
by a trained and certified Labtec service
technician and tested and calibrated by him
or her using a Labtec calibration device.
The list of current, certified employees, trai-
ning partners and service technicians is up-
dated daily and is available from Labtec or
on the Labtec homepage.
Labtec devices are partly operated with bre-
athing air in the high pressure range of up to
400bar. Operating a device under high pres-
sure requires the greatest care. Before
connecting and disconnecting a test item /
breathing apparatus, the test bench must al-
ways be completely depressurized and air
supply lines, especially the main valve,
closed.
The device connection must always be che-
cked. Devices must always be connected
completely correctly. When connecting to the
high pressure device connection, the device
thread must be completely screwed to the
internal thread of the device connection.
Before switching off the test device electri-
cally, the test bench must first be completely
depressurized and vented and then all
connected devices and any full face masks
must be removed.
Never test dirty demand valves or masks on
the test head. There is a risk of dust particles
getting into the measuring system, which
can impair the function.
When the test stand is started up, the mouth
opening and the instrument connections
must remain open, otherwise self-calibration
will be incorrect and the measurement data
will be incorrect.
The test device must be set up horizontally
and rest well on all support buffers.
Care must be taken to ensure that the mea-
suring nozzle in the mouth opening in the
test head is not clogged. In case of false
measuring values in low pressure, the ope-
ning can be cleaned with a 0.2 - 0.35 mm
needle.
In case of queries or uncertainties
contact the Labtec customer service!

User Manual Labtec ECO page 3www.labtec.de
3. device description
Labtec ECO dynamic and Labtec ECO
static are electronic test devices to be ope-
rated via a PC for the testing of breathing
masks according to DIN EN 136, self-
contained breathing apparatus (SCBA) ac-
cording to DIN EN 137 and chemical protec-
tive suits (CPS) according to DIN EN 943-1.
The tests are performed in the low (-50 to 50
mbar), medium (0 to 20 bar) and high pres-
sure measuring range (0 to 300 bar).
For testing other breathing apparatus or che-
mical protective suits, contact Labtec. Only
breathing air according to DIN EN 12021
may be used.
Model differences
Labtec ECO dynamic are automatic testing
devices incl. artificial lung for dynamic tes-
ting of breathing equipment during respirati-
on.
Compared to Labtec ECO dynamic, Labtec
ECO static test devices have no artificial
lung and are therefore only suitable for static
testing of breathing equipment.
The device has several expansion options
(modules) which are identified by a letter
code:
Modul T (Terminal): Control panel with
OLED display and complete set of control
elements for manual operation of the unit.
Module COM (All-in-One Computer):
Freely positionable touchscreen PC, connec-
ted to test device via swivel arm mounting,
incl. pre-installed LabNet Profi test software.
Module S (safety valve test): System com-
ponent and module for automatic medium
pressure increase for SCBA safety valve
tests.
Connection requirements
A 230-240 V / 50-60 Hz power supply is re-
quired to operate the test stand.
The high pressure supply required for opera-
tion is provided by a 300 or 200 bar brea-
thing air cylinder or by a central air supply
with 300 bar.
As medium pressure connection Euro-
coupling and nipple are available as stan-
dard. If units with other coupling connections
are tested, appropriate intermediate adap-
ters must be used. Please contact the manu-
facturer of the units for this.
Scope of delivery and accessories
The scope of delivery of the device includes
a high-power-connection cable incl. screw
fitting, power supply cable and a USB cable.
Adapters for the connection of CPS, regula-
tors and sealing caps for respirators must be
ordered separately depending on the
connection used (e.g. ESA, PE45, RD40,
manufacturer-specific connections).
Labtec offers a wide range of accessories for
test devices.
The range includes test adapters for adap-
ting all respiratory protection devices on the
market, quick release devices for quick de-
vice adaptation as well as holders for holding
helmet-mask combinations.
Further information and brochures
can be found at www.labtec.de

User Manual Labtec ECO page 4www.labtec.de
component description unit value
high-pressure sensor measuring range
precision bar %0...400 ± 0,5
medium pressure sensor measuring range
precision bar %0…+25 ± 0,5
low pressure sensor measuring range
precision mbar %-50...0...+50 ± 0,05
complete device Max. permissible operating pressure bar 400
power supply V / Hz 230-240 / 50-60
total power electricity Wmax. 450
IP rating IP 54
permissible temperature range °C -10...+55
measuring volume ml 480
dimensions W X L x H mm 500 x 630 x 540
total weight kg 41 (ECO dynamic)
39 (ECO static)
4. technical data

User Manual Labtec ECO page 5www.labtec.de
5. component description
Test stand housing (A)
Thanks to its ergonomic design, the test stand
can be operated fatigue-free even during con-
tinuous operation. Operation in computer mo-
de is via PC keyboard and mouse or manually
via the optionally available front panel
Front cover / Panel (only with Option T) (B)
The front panel contains the control buttons
and an OLED display showing measuring va-
lues and system information..
Multifunction test head (C)
The test head is a fixed head that can be in-
flated by an electric pump so that full face
masks of any brand can be sealed without
problems. A measuring point is installed in the
test head which measures the internal pres-
sure in the mask or demand valve.
The Labtec ECO dynamic model has a se-
cond measuring point in the forehead area of
the head. This can be queried via the soft-
ware.
Air supply / device connection (D)
The air supply can be provided optionally:
1. Through an existing, fixed 300 bar pipe
supply via a 6 mm high-pressure pipe
fitting.
2. Through an available 300 bar high pres-
sure hose for connection to a breathing
air cylinder or pipe supply.
Attention: Never connect or disconnect
lines under pressure !
Device connection (E)
High-pressure device socket for connecting
the pressure regulator of the SCBA to be
tested.
CPS test connection and system vent (F)
Quick coupling for filling CPS. For all other
test procedures, the coupling must be
connected to the supplied plug-in silencer for
system venting.
Medium pressure device connections (G,
H)
Quick coupling for connecting the medium
pressure line of the demand valve to be
tested.
Plug nipple for connecting the medium pres-
sure line of SCBA to be tested.
Power connection (I)
On the left side of the housing there is a C13
power plug coupling for the connection of a
cold appliance cable with C14 plug.
USB-Interface (J)
The USB port for data transfer to a PC is lo-
cated on the left side of the housing.
Artifical Lung
Labtec ECO dynamic devices contain the
artificial lung, which is continuously adjustable
in stroke and breathing frequency. The desi-
red respiration can be infinitely adjusted in the
software in the stroke from 5 to 40 strokes/
min and in the volume from 0.5 to 3.5 litres.
Vacuum pump
With the built-in vacuum pump, the required
air currents are generated and the probe is
inflated or deflated. The desired air flow rate
can be set in the software from 0.5 to 10 l/
min.
A
B
C
F
J
I
D
G, H E

User Manual Labtec ECO page 6www.labtec.de
6. operating elements
LCD multi function display
Digital display of status of operation
Display for low pressure (LP)
Display for medium pressure (MP)
Display for high pressure (HP)
Push button for test head inflation
Pressing causes the test head to be inflated out of the test head
Push button for test head deflation
Pressing causes the air to be aspirated out of the test head
Push button to generate positive pressure
Forcing pump +5 l/min is set in motion by pressing this button
Push button to generate negative pressure
Forcing pump –5l/min is set in motion by pressing this button
Push button for low pressure relief
Pressing causes the air to be aspirated out of the test equipment
Switch button for 10 l/m exhalation
Forcing pump +10 l/min is set in motion by pressing this button. LED shows function. Pressing
button again switches it off.
Switch button for 10 l/m inhalation
Forcing pump -10 l/min is set in motion by pressing this button. LED shows function. Pressing
button again switches it off.
Switch button for CPS inflation
Pressing causes the CPS to be inflated.
Switch button for CPS deflation
Pressing causes the CPS to be deflated.
Push button for medium pressure relief
Pressing causes the air to be aspirated out of the test equipment
Switch button for the main valve
When pressed, the high pressure main valve is opened which raises the high pressure. Pressing
button again switches it off.
Push button for high pressure relief
Pressing causes the air to be aspirated out of the test equipment
Push button for Medium pressure increase (Only active with option SI)
When pressing the medium pressure is increased until the safety valve on the device opens.
Switch button for Artifical Lung (only active with ECO dyanmic, main valve has to be open)
When pressed, the artificial lung is switched on and ventilated through the mouth opening of the
test head. Pressing button again switches it off.

User Manual Labtec ECO page 7www.labtec.de
7. commissioning
When setting up the unit, make sure that it is
horizontal and rests well on all support buffers.
Establish high-pressure connection
Connect the high-pressure line to the air supp-
ly connection of the test device.
Establish power supply
Connect the power supply to a 230 V / 50-60
Hz power source using the supplied power
cable. Switch on the unit at the switch.
Establish connection to the PC
Install the LabNet Profi test software accord-
ing to the installation instructions. Establish the
connection between PC and test bench via
USB cable.
> See separate installation and operating
instructions LabNet Profi
Device connection (breathing mask)
The test head must be completely vented. The
breathing connection of the mask is closed
with a suitable sealing cap. Alternatively,
connect the mask to a suitable demand valve
and then make a device connection (SCBA).
The mask is put on the test head. The inner
mask should rest correctly on the nose of the
probe.
Then tighten the fasteners of the head mask
starting from the bottom. The test head can
now be inflated until a tight fit of the mask is
ensured. If necessary, readjust the mask.
Device connection (SCBA)
The regulator of the compressed air breathing
apparatus is screwed directly to the high pres-
sure device connection. When connecting,
make sure that the compressed air breathing
apparatus is screwed completely into the inter-
nal thread of the device connection.
For tests in the medium pressure range, dis-
connect the medium pressure line of the
SCBA at the Euro coupling and connect it to
the plug nipple of the medium pressure device
connection and the line of the demand valve to
the EURO quick coupling of the medium pres-
sure device connection.
If the SCBA to be tested does not have a Euro
coupling, a suitable adapter must be used.
Please contact the compressed air breathing
apparatus manufacturer.
The demand valve is inserted into the mouth
opening of the test head using a suitable
adapter.
8. care and maintenance
The test instrument should be protected from
external harmful influences such as water, mo-
isture in the form of steam and dust.
The test head should be cleaned and maintai-
ned regularly. This can significantly increase
the service life of the search unit.
The test head should always be covered with
the enclosed protective hood after the instru-
ment has been used.
> See separate test head care instructions
The test device must be serviced at least an-
nually by a certified Labtec service technician.
The test device is recalibrated and deviations
in the previous test cycle can be excluded.
The maintenance is carried out with a special
calibration device.
The maintenance is confirmed by a calibration
certificate issued directly by Labtec. The main-
tenance may only be carried out by authorized
and trained service technicians.
In order to ensure a cost-effective and timely
maintenance, it is possible to conclude a main-
tenance contract with Labtec.

User Manual Labtec ECO page 8www.labtec.de
Konformitätserklärung
Certificate of Conformity
Attestation de Conformité
Bezeichnung der Maschine: Prüfgerät
Type of machine: Test Equipment
Description de la machine: Instrument de vérification
Modell / Model / Modèle: Labtec ECO
Typ / Type / Type:
Geräte Nr. / instrument no. / Instrument numéro: ECO static
ECO dyanmic
Hiermit wird bestätigt, dass das Gerät den Anforderungen der Maschinenrichtlinie
2016/42/EG, sowie der EMV - Richtlinie 2014/30/EU einschließlich allen bis heute
veröffentlichen Änderungen bzw. Nachträgen entspricht. Das Gerät entspricht
folgenden Normen bzw. Richtlinien:
We do hereby certify that the above mentioned product meets the requirements set
forth in EEC-Guideline 2016/42/EG and EMC 2014/30/EU including all changes and
addendums to date thereto. The above mentioned product meets the following
standards and guidelines:
Nous Vous Confirmons que l’appareil cité ci-dessus correspond aux exigences des
directives 2016/42/EG ainsi qu’ à la directive CEM 2014/30/EU ci-inclus toues les
modifications ainsi que tous les suppléments publiés jusqu’à ce jour. L’appareil
mentionné correspond aux nomes cités ci-après :
DIN EN 60950-1, Ausgabe / dates / en date du 2014-08
DIN EN 135 Ausgabe / dates / en date du 1999
DIN EN 136 Ausgabe / dates / en date du 1998
DIN EN 137 Ausgabe / dates / en date du 2006
DIN EN 837 Ausgabe / dates / en date du 1997
Datum / date
01.01.2020
Diese Konformitätsbescheinigung wurde automatisch
erstellt und ist ohne Unterschrift gültig.
This calibration certificate was produced automatically
and is valid without signature.
Labtec
Gesellschaft für Labortechnik mbH

User Manual Labtec ECO page 9www.labtec.de
Step Activity Comment operating
elements
1.1.1 Close breathing connection to mask with sealing
plug. If necessary, moisten the exhalation valve of the mask.
1.1.2 Place the mask on the test head and tighten the mask strap. Fill test head with head inflation
button
The inflation time varies from mask
type to mask type.
1.1.3 Set test vacuum with negative pressure button
to setpoint value - # mbar. Switch on stop watch. Adjust the test pressure with the low pressure relief button if necessary.
1.1.4 Read the pressure difference after # min. on the
display (LP) and compare with setpoint.
1.1.5 Deflate the test head with button for test head
deflation. Remove mask from test head.
1.2.1 Seal the exhalation valve of the mask with the adapter. Close breathing connection to mask
with sealing plug.
Test only possible with tightly fitted
exhalation valve. Use the manufac-
turer's specific adapters.
1.2.2 Place the mask on the test head and tighten the mask strap. Fill test head with head inflation
button
The inflation time varies from mask
type to mask type.
1.2.3 Set test vacuum with negative pressure button
to setpoint value - # mbar. Switch on stop watch. Adjust the test pressure with the low pressure relief button if necessary.
1.2.4 Read the pressure difference after # min. on the
display (LP) and compare with setpoint.
1.2.5 Deflate the test head with button for test head
deflation. Remove mask from test head.
1.3.1 Close breathing connection to mask with sealing
plug.
1.3.2 Place the mask on the test head and tighten the mask strap. Fill test head with head inflation
button
The inflation time varies from mask
type to mask type.
1.3.3 Switch on vacuum pump with switch 10l/min
Exhalation to produce constant flow.
1.3.4 Read the opening pressure on the display (LP)
and compare it with the setpoint.
1.3.5 Switch off the pump by pressing the 10/lmin
Exhalation switch again.
1.3.6 Deflate the test head with button for test head
deflation. Remove mask from test head.
A 1 Testing of full face breathing masks
1. Complete device (full face mask)
1.1 Leak test with open exhalation valve at - # mbar
1.2 Tightness test with closed exhalation valve at + # mbar
1.3 Opening pressure of the exhalation valve

User Manual Labtec ECO page 10 www.labtec.de
A 2 Testing of demand valves
2. Complete device (Demand Valve)
2.1 Tightness: Pressure increase after # min at - # mbar negative pressure / + # mbar positive pressure
2.2 Tightness: Pressure change when medium pressure is applied after # min at # mbar
Step Activity Comment operating
elements
2.1.1 Insert the test adapter into the mouth opening of the test head and connect it to the demand val-
ve.
Select suitable adapter according to
function and connection type
2.1.2 Seal the medium pressure hose of the demand
valve with a sealing cap.
2.1.3 Set test negative pressure with button to gener- ate negative pressure to setpoint + # mbar.
Switch on stop watch.
Adjust the test pressure with the low
pressure relief button if necessary.
opt. Set test overpressure with button to generate positive pressure to setpoint + # mbar. Switch on
stop watch.
Adjust the test pressure with the low
pressure relief button if necessary.
2.1.4 After a preset time # min, read the pressure change on the display (LP) and compare with
the setpoint.
2.1.5 Completely vent the test device.
All further tests require high pressure! Check correct device connection!
The Labtec test bench + connected test device parts must be completely vented before
connecting or removing test devices.
Connect demand valve in combination with a
SCBA base unit to the test device. Check correct device connection!
2.2.1 Open high pressure main valve with main valve
switch. High pressure flows into the unit.
2.2.2 Close high pressure main valve with main valve
switch. Test instrument/test specimen are under pressure.
2.2.3 Set test negative pressure with button to gener- ate negative pressure to setpoint + # mbar.
Switch on stop watch.
Adjust the test pressure with the low
pressure relief button if necessary.
opt. Set test overpressure with button to generate positive pressure to setpoint + # mbar. Switch on
stop watch.
Adjust the test pressure with the low
pressure relief button if necessary.
2.2.4 After a preset time # min, read the pressure change on the display (LP) and compare with
the setpoint.
2.2.5 Completely vent the test device.

User Manual Labtec ECO page 11 www.labtec.de
A 2 Testing of demand valves
2. Complete device (Demand Valve)
2.3 Opening pressure / cut-in pressure at # l/min suction
2.4 Static overpressure
2.5 Inhalation resistance at 40 x 2.5 l/min breathing (only with ECO dynamic)
Step Activity Comment operating
elements
2.3.1 Connect demand valve in combination with a
SCBA base unit to the test device. Check correct device connection!
2.3.2 Open high pressure main valve with main valve
switch. High pressure flows into the unit and is present in the unit.
2.3.3 Switch on vacuum pump with switch 10l/min
Inhalation to produce constant flow.
until the regulator opens and the
maximum negative pressure point is
reached
2.3.4 Read the opening / closing pressure of the de-
mand valve on the display (LP).
2.3.5 Switch off the pump by pressing the 10/lmin In-
halation switch again.
2.3.6 Close high pressure main valve with main valve
switch.
2.2.7 Completely vent the test device.
2.4.1 Connect demand valve in combination with a
SCBA base unit to the test device. Check correct device connection!
2.4.2 Open high pressure main valve with main valve
switch. High pressure flows into the unit and is present in the unit.
2.4.3 Read the static overpressure of the opened de- mand valve on the display (LP) and compare it
with the setpoint.
Test only for positive pressure lung
valves
2.4.4 Close high pressure main valve with main valve
switch.
2.4.5 Completely vent the test device.
2.5.1 Connect demand valve in combination with a
SCBA base unit to the test device. Check correct device connection!
2.5.2 Open high pressure main valve with main valve
switch. High pressure flows into the unit and is present in the unit.
2.5.3 Start breathing with switch for artificial lung
2.5.4 Read the low pressure on the display (LP). Read the minimum low pressure
during the inhalation
2.5.5 Stop breathing with switch for artificial lung
2.5.6 Close high pressure main valve with main valve
switch.
2.5.7 Completely vent the test device.

User Manual Labtec ECO page 12 www.labtec.de
A 3 Testing of SCBA
3Pressure indicator (pressure gauge comparison measurement)
3.1 Pressure comparison at # bar (e.g. 300, 200 ...bar)
4Acoustic warning device
4.1 Response pressure
Step Activity Comment operating
elements
3.1.1 Connect demand valve in combination with a
SCBA base unit to the test device. Check correct device connection!
3.1.2 Open high pressure main valve with main valve
switch. High pressure flows into the unit.
3.1.3 Close high pressure main valve with main valve
switch. Test instrument/test specimen are under pressure.
3.1.4
Vent high pressure with button for high pressure
relief (fast) or medium pressure relief (slower) to
test pressure until PA pressure gauge shows the
set point.
Read off the SCBA manometer
3.1.5 Read the high pressure on the display (HP) and
compare it with instrument pressure.
opt. Repeat test steps 3.1.4 and 3.1.5 with other
test values required by manufacturer
3.1.6 Completely vent the test device.
4.1.1 Connect demand valve in combination with a
SCBA base unit to the test device. Check correct device connection!
4.1.2 Open high pressure main valve with main valve
switch. High pressure flows into the unit.
4.1.3 Close high pressure main valve with main valve
switch. Test instrument/test specimen are under pressure.
4.1.4
Vent high pressure with button for high pressure
relief (fast) or medium pressure relief (slower)
until an acoustic signal (warning whistle) beco-
mes audible.
4.1.5 Read the response pressure on the display (HP)
and compare with setpoint.
4.1.6 Completely vent the test device.

User Manual Labtec ECO page 13 www.labtec.de
A 3 Testing of SCBA
Step Activity Comment operating
elements
5.1.1 Connect demand valve in combination with a
SCBA base unit to the test device. Check correct device connection!
5.1.2 Open high pressure main valve with main valve
switch. High pressure flows into the unit.
5.1.3 Close high pressure main valve with main valve
switch. Test instrument/test specimen are under pressure.
5.1.4 Vent high pressure with button for high pressure relief (fast) or medium pressure relief (slower) to
to setpoint + # bar inlet pressure
5.1.5 Read the medium pressure on the display (MP)
and compare with setpoint.
5.1.6 Completely vent the test device
5.3.1 Connect demand valve in combination with a
SCBA base unit to the test device. Check correct device connection!
5.2.1 Open high pressure main valve with main valve
switch. High pressure flows into the unit.
5.2.2 Close high pressure main valve with main valve
switch. Test instrument/test specimen are under pressure.
5.2.3 Vent high pressure with button for high pressure relief (fast) or medium pressure relief (slower) to
to setpoint + # bar inlet pressure
5.2.4 Read the medium pressure on the display (MP),
start the stopwatch.
5.2.5 After a preset time of # min, read the medium pressure again and compare it with the previous-
ly measured value.
Compare difference value with per-
missible deviation.
5.2.6 Completely vent the test device.
5Pressure Regulator (base unit)
5.1 Static Medium pressure at # bar inlet pressure
5.2 Medium pressure increase after # min

User Manual Labtec ECO page 14 www.labtec.de
A 3 Testing of SCBA
5Pressure Regulator (base unit)
5.3 Dynamic Medium pressure at 40 x 2.5 l/min breathing (only with ECO dynamic)
5.4 Opening pressure of the pressure regulator safety valve (only with module option SI)
6Complete Device
6.1 High pressure tightness test
Step Activity Comment operating
elements
5.3.1 Connect demand valve in combination with a
SCBA base unit to the test device. Check correct device connection!
5.3.2 Open high pressure main valve with main valve
switch. High pressure flows into the unit and is present in the unit.
5.3.3 Start breathing with switch for artificial lung
5.3.4 Read the medium pressure on the display (MP). Read the minimum medium pressure
during the inhalation process
5.3.5 Stop breathing with switch for artificial lung
5.3.6 Close high pressure main valve with main valve
switch.
5.3.7 Completely vent the test device.
5.4.1 Connect demand valve in combination with a
SCBA base unit to the test device. Check correct device connection!
5.4.2 Open high pressure main valve with main valve
switch. High pressure flows into the unit.
5.4.3 Close high pressure main valve with main valve
switch. Test instrument/test specimen are under pressure.
5.4.4 Increase medium pressure with specific button
until thepressure regulator safety valve opens.
Only carry out testing if prescribed by
the manufacturer, otherwise the de-
vice may be damaged.
5.4.5 Read the medium pressure on the display (MP).
5.4.6 Completely vent the test device.
6.1.1 Connect demand valve in combination with a
SCBA base unit to the test device. Check correct device connection!
6.1.1 Open high pressure main valve with main valve
switch. High pressure flows into the unit.
6.1.2 Close high pressure main valve with main valve
switch. Test instrument/test specimen are under pressure.
6.1.3 Read high pressure on the display (HP), start
stop watch.
6.1.4 After a preset time of # min, read the high pres- sure again and compare it with the previously
measured value.
Compare difference value with per-
missible deviation.
6.1.5 Completely vent the test device.

User Manual Labtec ECO page 15 www.labtec.de
A 4 Testing of gas-tight chemical protective suits (CPS)
7Tightness
7.1 Tightness of the suit
8Valves
8.1 Tightness of the suit valves after # min. at - # mbar
(repeat the test depending on the number of valves)
Step Activity Comment operating
elements
7.1.1 Close the high-pressure device connection with
a plug. Device connection must be closed during tightness test.
7.1.2 Connect one tightening valve with test adapter,
seal all other tightening valves with plugs. CPS test adapter CGA 200 and brand -specific adapters
7.1.3 Couple the filling hose of the test adapter with
plug nipple of CPS test connector. CPS test adapter CGA 200
7.1.4 Insert the measuring hose of the test adapter
into the mouth of the test head. CPS test adapter CGA 200
7.1.5 Open high pressure main valve with main valve
switch. High pressure flows into the unit and is present in the unit.
7.1.6 Fill CPS by pressing the CPS inflation switch CPS is filled to +# mbar
7.1.7 Durch erneutes Drücken des Schalters CSA
füllen das Befüllen des Anzugs stoppen. when the required tightening internal pressure is reached.
7.1.8 Press the CPS inflation switch again to stop fil-
ling the suit. Setting the required settling time.
7.1.9 When time has elapsed, set the required test pressure with the CPS inflation or CPS deflation
switches and start the stopwatch.
7.1.10 After a preset time of # min, read the low pres- sure on the display (LP) and compare with the
previously set test pressure.
Compare difference value with per-
missible deviation.
7.1.11 Close high pressure main valve with main valve
switch.
7.1.12 Completely vent the test device. Open the suit
8.1.1 Insert the measuring hose of the test adapter
into the mouth of the test head. CPS test adapter CGA 200
8.1.2 Connect tightening valve with valve test adapter
from inside
manufacturer-dependent adapter,
depending on the number of
existing valves.
8.1.3 Set test vacuum with negative pressure button to
setpoint value - # mbar. Switch on stop watch. Adjust the test pressure with the low pressure relief button if necessary.
8.1.4 After a preset time of # min. pressure change read off the display (LP) and compare with set-
point.
8.1.5 Completely vent the test device.
