INSTRUCTION BOOKLET
Model: 18307

2
Thank you for choosing your Lakeland Juicepresso.
Please take a little time to read this booklet before you use your Juicepresso and then keep
it in a safe place for future reference.
Your Juicepresso will extract juice from fruit and vegetables, from soft fruits to harder
vegetables. The process extracts a high percentage of the juice whilst maintaining the
nutritional qualities and the full flavour of the juices. The simple design makes the machine
quick and easy to clean.
An award winning family-owned business, here at Lakeland we still have the same values
of excellent quality, value for money and exceptional customer care as we did when we first
set up the company in the 1960s. Our products are carefully selected and rigorously tested
to meet our high standards, so you can be assured that any product you purchase will be
easy-to-use and highly durable.

3
CONTENTS
Product features .....................................................................................................................4
Safety cautions .................................................................................................................5 - 6
How to use your Juicepresso ..............................................................................................7
How to assemble the Juicepresso and using for the first time....................................7
Instructions for use ................................................................................................................8
A guide to ingredients ...........................................................................................................9
Adapting your own recipes ..................................................................................................9
Hints and tips ..........................................................................................................................9
Recipes ........................................................................................................................ 10 - 17
Troubleshooting ....................................................................................................................18
Care and cleaning ................................................................................................................19
Electrical connections .........................................................................................................20
Recycling your electricals ..................................................................................................20

4
PRODUCT FEATURES
Hopper and
feed tube
Base unit
Pusher
Pulp outlet
Juice outlet
2 jugs
Cleaning brush
Squeezing screw
Drum
Silicone seal

5
SAFETY CAUTIONS
Carefully read all the instructions before using the appliance and keep in a safe place for future reference.
Always follow these safety cautions when using the appliance to avoid personal injury or damage to the
appliance. This appliance should be used only as described in this instruction book.
• Make sure your electricity supply matches the voltage shown on the appliance
• Ensure all packaging materials and any promotional labels or stickers are removed from the appliance
before the first use
• Always inspect the appliance before use for noticeable signs of damage. Do not use if damaged or
has been dropped. In the event of damage, or if the appliance develops a fault contact the Lakeland
customer care team on 015394 88100
• Do not use this appliance if the lead is damaged. If the lead is damaged it must be replaced with a
special lead contact the Lakeland customer care team on 015394 88100
• Always use the appliance on a dry, level, heat resistant surface
• Unplug from the mains when not in use and before cleaning. Allow to cool before cleaning the
appliance. To disconnect, turn the socket to “off” and remove the plug from the mains socket
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the appliance by a person responsible for
their safety
• Children should always be supervised to ensure they do not play with this product
• Do not use any accessories or attachments with this appliance other than those recommended
by Lakeland
• To protect against fire, electric shock or personal injury, do not immerse cord, plug or base unit in
water or other liquids
• Do not leave the lead hanging over the edge of a kitchen table or worktop. Avoid contact between
the lead and hot surfaces
• For indoor use only
• For domestic use only
• This appliance should be used for preparation of food as described within the instructions for use
that accompany it
• Always ensure that your hands are dry before removing the plug from the mains socket. Never pull
the plug out of the mains socket by its lead
• Please use both hands when lifting and moving this machine
• To avoid injury or possible fire, do not cover the appliance when in use
• Do not connect this appliance to an external timer or remote control system
• An extension cable may be used with care. The electrical rating of the cable should be at least as
great as the appliance. Do not allow the cable to hang over the edge of the worktop or touch any hot
surfaces
• This appliance complies with the basic requirements of Directives 04/108/EC (Electromagnetic
Compatibility) and 06/95/EC (Safety of Domestic Electrical Appliances)

6
• If squeezing screw sticks and does not spin, please turn off the machine and put in reverse for
2-3 seconds
• Please do not disassemble the machine while operating nor put anything into juice or pulp vent while
operating. If the pulp vent becomes blocked, switch off and use the handle of the cleaning brush to
remove any food trapped in it
• Do not use the product longer than 20 minutes, excessive use can cause overheating which can lead
to motor failure
• Use the pusher, not fingers or utensils, to push food into the juicer
• Do not use the appliance if the rotating sieve is damaged
• Do not run the product without fruit or vegetables inside drum, otherwise, main parts may
get damaged
WARNING: A cut off plug inserted into a 13 amp socket is a serious safety (shock) hazard.
Ensure the cut off plug is disposed of safely.
CAUTION: The plastic bags used to wrap this appliance or the packaging may be
dangerous. To avoid risk of suffocation, keep these bags out of reach of babies and children.
These bags are not toys.

7
For proper operation,
‘close dot’ ( ) on the hopper
should be aligned with ‘dot’( ) on the drum.
HOW TO USE YOUR JUICEPRESSO
Line up the 2 jugs in front of the pulp and juice outlets before switching on or
using the machine.
HOW TO ASSEMBLE THE JUICEPRESSO
AND USING FOR THE FIRST TIME
1. Assemble the drum on
the Base Unit.
Make sure the drum is
fully into the shaft of the
base unit.
2. Place and push the
squeezing screw into
the centre of the drum.
3. Assemble the hopper
onto the Drum.
Make sure ‘open dot’ ( ) on the
hopper points to ‘dot’ ( ) on the
drum. Turn the hopper clockwise
until it clicks into the drum.
Drum
Base unit
Squeezing
screw
Hopper
Reverse the steps
carefully on disassembling.
IMPORTANT
Silicone seal

8
INSTRUCTIONS FOR USE
Operational buttons
• “ON” activates the motor and starts making juice
• “REV” means reverse operation. Use this button when something is stuck. It will remove
the clogged material
• “OFF” stops the operation. Place the button at the centre to turn off the product
• Rinse fruit or vegetables thoroughly before putting them into the machine
• After rinsing, put ingredients into the machine using the pusher.
Remove any hard seeds before making juice
• We recommend not juicing more than 1kg of fruit or vegetables at a time
• Insert juicy ingredients slowly into the drum to ensure as much liquid can be extracted
e.g. soft fruits, pears and melon
If your Juicepresso gets jammed with a piece of fruit or vegetable:
1. Turn “OFF” the machine
2. Run the product in “REV” mode for a few seconds
3. Operate the product again
4. If “REV” mode is inoperable, turn off and disassemble the Juicepresso. Then,
reassemble following the instructions
5. Add a small piece of fruit or vegetable and try operating again
1. ON
2. OFF
3. REVERSE

9
A GUIDE TO INGREDIENTS
• Wash or remove outer skins from fruit or vegetables before juicing
• Remove any large or hard stones before juicing e.g. plums, cherries etc.
• Generally citrus skins should be removed, although some recipes may specify using thin
skinned limes or lemons for instance and leaving the skin on
• Cut ingredients so they pass through the hopper easily without needing to be forced
• Most fruits, vegetables and herbs can be juiced, though onions are rarely used in recipes
ADAPTING YOUR OWN RECIPES
• After you have made some of the recipes supplied you may wish to adapt a few of
your own recipes
• Start by selecting one of the recipes in this booklet, which is similar to your own and use
this as a guide
• Choose combinations of fruit and vegetables that usually work well together
• The pulp generated from the juicing can also be used, see Recipes for some ideas. This is
easiest to do with single types of pulp not mixtures
HINTS AND TIPS
• If you prefer cold drinks, keep your ingredients in the fridge prior to juicing
• Generally it is best to juice, and then consume it as soon as possible to receive the
maximum nutritional benefit. If juice is not to be consumed immediately, it should be
kept refrigerated
• If you are using ingredients with less juice e.g. carrots, kale or spinach it is useful to
combine them with juicier ingredients such as oranges, apples or cucumber
• Try to juice a combination of fruits and vegetables to limit the amount of sugar in the juices

10
RECIPES
Please note all spoon measures given in recipes use standard metric measuring
spoons e.g. 5ml is 1 tsp and 15ml is 1 tbsp, and we recommend you use a set of measuring
spoons to get accurate recipes.
Fruit and vegetables should not be peeled unless specified.
CARROT & GINGER JUICE - makes 1 serving
Carrots 4-5 medium to large
Fresh root ginger 1-2cm slice to taste
• Halve larger carrots lengthwise so they fit easily into the feed tube
• Feed the carrots and the ginger into the Juicepresso feed tube
• Serve the juice in a glass and drink soon after preparation for maximum benefit
Ingredient Quantity
KALE, CELERY AND PINEAPPLE JUICE - makes 1 serving
Kale 20g
Celery 2-3 sticks
Pineapple 175g, cored and peeled, cut into slices
• Cut all the items into pieces that will fit easily into the feed tube
• Combine kale and celery and feed into Juicepresso
• Then process the pineapple and pour into serving glass
Ingredient Quantity
APPLE AND BEETROOT JUICE - makes 1 serving
Apples 2
Beetroots 2 raw, can include stalks and leaves
• Cut all items into pieces that will fit easily into the feed tube
• Process the apples and beetroot and pour into serving glass
Ingredient Quantity

11
BLUEBERRY BANANA SMOOTHIE - makes 1 serving
Milk 75ml
Natural yogurt 3 tbsp
Small Banana 1, peeled
Blueberries 75g
• Place the milk and yogurt into the juice collection jug
• Feed the banana and the blueberries through the Juicepresso
• Stir to mix all the ingredients and pour into serving glass
Ingredient Quantity
VIRGIN MARY - makes 1 serving
Tomatoes 4 medium
Lemon ½ peeled
Celery 1 stick plus one to serve
Small rounded red chilli ½ seeds removed
Tabasco sauce few drops
Worcestershire Sauce 1 tsp
Freshly ground black pepper
• Cut tomatoes and celery into pieces that fit the feed tube
• Process tomatoes, 1 celery stick and chilli through the Juicepresso
• Add Tabasco and Worcestershire sauce
• Stir, pour into serving glass, add black pepper and a celery stick to serve
Ingredient Quantity
GREEN JUICE - makes 1 serving
Kale 100g washed
Small head broccoli 250g including stalk
Watercress 50g
Medium apples 2
• Cut all items into pieces that will fit easily into the feed tube
• Process all the ingredients through Juicepresso and pour into serving glass
Ingredient Quantity

12
GRAPEFRUIT AND PINEAPPLE JUICE - makes 1 serving
This is a good base juice to which other ingredients such as beetroot, celery, parsley and cabbage can
be added.
Grapefruit 1 peeled
Pineapple ¼ small, cored and peeled
• Cut all items into pieces that will fit easily into the feed tube
• Process the ingredients through Juicepresso and pour into serving glass
Ingredient Quantity
LIME MOJITO COCKTAIL - makes 1 serving
You can make variations on your mojito by adding other fruits too e.g. raspberries.
Mint leaves 4-5
Lemon peeled ½
Limes 1 small, peeled
Demerara sugar 25g
White rum 25ml
Limes skin on, small cut into wedges, ½ to serve
Sparkling mineral water / soda water 150ml
Some ice for glass
• In a tall glass, place mint leaves and then process cut up lemon and lime through Juicepresso and
add these to glass
• Add sugar and white rum then use a spoon to stir this all together
• Place ice in glass, add lime wedges, and then fill to top with sparkling water, serve
Ingredient Quantity
GREYHOUND COCKTAIL - makes 1 serving
For best results chill the grapefruit and the vodka before making this.
Vodka 25ml
Slice of lemon or lime to garnish
• Cut grapefruit into pieces that will fit easily into the feed tube
• Process the grapefruit in Juicepresso and pour into serving glass, add vodka and garnish with slice
of lemon or lime
Ingredient Quantity

13
CHERRY LEMON COOLER - makes 1 serving
Cherries 100g, stones removed
Lemon ½, peeled
Ice 2-3 cubes
Sparkling mineral water or soda water
• Process cherries and cut up lemon in Juicepresso
• Pour into a tall glass, add ice and fill to top with sparkling water or soda water
Tip: If you add lemon vodka, you can enjoy it as cherry martini.
Ingredient Quantity
NON-FAT FRUIT SMOOTHIE - makes 1 serving
Strawberries 250g
Pear ½
Small banana 1, peeled
Skimmed milk 75ml
Fat free natural yoghurt 3 tbsp
• Remove the green leaves and stalks from strawberries, cut pear into 2-3 pieces and process these
through Juicepresso along with banana
• Add milk and yoghurt to the juice and stir well then pour into a serving glass
Tip: You can use non dairy milk and yoghurt such as soya milk too.
Ingredient Quantity
SOYBEAN MILK - makes 1 serving
This 100% pure soybean milk contains no additives.
Using the boiling water from cooking the beans in the milk adds to the flavour.
Dried soya beans 200g
Water 1 litre
Honey to taste if required
• Rinse soya beans and soak overnight in a large bowl covered in water. Drain out this water,
rinse again
• Put soya beans in a large pan and add 1 litre of water, bring to boil and allow to boil for 45 minutes.
Remove from pan, drain but reserve the cooking liquor, cool down
• Make the cooking liquor up to 1 litre with cold water and then juice the soya beans and mix with the
water. You may want to add a little honey to sweeten this depending on how you plan to use it
Ingredient Quantity

14
TOMATO SALSA - makes 1 small bowl
This makes a smooth authentic Mexican salsa, ideal for dipping tortilla chips.
Tomatoes 3-4
Lemon ½, peeled
Green pepper ¼ core and seeds removed
Red pepper ¼ core and seeds removed
Small red onion ¼, peeled
Garlic 2 cloves, peeled
Freshly corriander leaves and stalks small handful
Salt and freshly ground black pepper to taste
• Cut tomatoes into wedges and process using Juicepresso to get both juice and pulp
• Juice the lemon, peppers, garlic and coriander, add the tomato juice and pulp, stir and season with
salt and pepper to taste
Ingredient Quantity
MANGO COULIS - makes enough to serve 4 as an accompaniment
This makes a smooth authentic Mexican salsa, ideal for dipping tortilla chips.
Large mango 1 peeled and stone removed
• Squeeze the juice from the mango
• Take the pulp left when the juice was made and pass it through a sieve
• Mix the juice and the sieved pulp together to create the coulis
Ingredient Quantity

15
BEETROOT BREAD
Fresh yeast 10g or equivalent weight of dried yeast
Strong bread flour 500g
Salt 2 tsp
Water 350ml, at body temperature
Beetroot pulp 125g (about 3 beetroots)
• In a large bowl rub the yeast into the flour, then add the salt and the water, mix all the ingredients with
1 hand for 2-3 minutes until the mix begins to come together, and then add the beetroot
• Empty dough out onto an unfloured work surface, it will be very sticky but if you work with it,
incorporating air onto it, the dough will dry and become smooth within about 10 minutes (you can
also use a food mixer and dough hook for this stage).
• Place in a clean bowl and allow to rise in a warm area, until doubled in size. Shape it into a round loaf
or place in a greased loaf tin of your choice. Sprinkle the top with a little extra flour. Allow to double
in size again. When it is nearly ready, preheat oven to 250°C/Gas 9. Cut a slash in the top of the
loaf with a sharp knife and place in the oven for around 30 minutes, until base of loaf makes a hollow
sound when tapped (cooking times will vary depending on shape you make and tin chosen etc.).
Allow to cool and then slice and use
Ingredient Quantity
RECIPES USING THE PULP FROM THE JUICER
VEGETABLE BURGERS - makes 4 burgers
Olive oil 2 tbsp
Yellow onion 1, peeled and finely chopped
Garlic clove 1, peeled and finely chopped
Smoked paprika 1 tsp
Green vegetable pulp 250g
Can kidney beans 400g rinsed, drained
Parmesan cheese 50g grated
Salt and pepper
• Heat 1 tbsp oil, add onion, garlic and paprika and cook until the onion and garlic are soft and
translucent. Add the green vegetable pulp and kidney beans and cook for 5 minutes, remove
from heat
• Add parmesan, mix well. Taste and season with salt and pepper. Shape using cooking rings and press
down firmly
• Place remaining spoon of oil into pan, add the burgers and cook for 3-4 minutes on each side,
until browned and warmed through. Serve in buns with salad and your favourite relish or salsa
Ingredient Quantity

16
RAW FOOD CRACKERS - makes 24 crackers
These are ‘cooked’ at a low temperature to bind them together whilst preserving the nutritional values,
colours and flavours. If you have a dehydrator you can use this, otherwise use the oven. You can also
change the seeds you use in the mix.
Linseeds 60g
Pumpkin seeds 60g
Chia seeds 120g
Flax seeds 110g
Black mustard seeds ½ tsp
Lemon Juice of 1
Salt 3g
Water 100ml
Beetroot or other vegetable pulp 50g
• Preheat oven to 120°C/Gas½. Combine all the ingredients in a bowl, mix well and then place on
a large 24 x 30cm baking tin lined with cling film or Magic Non-Stick Liner and spread out with a
spatula. Mark in to cracker shapes with a sharp knife
• Bake for 2 hours 30 minutes until firm to touch and bound together, recut the crackers if markings
have disappeared while cooking, allow to cool completely and then remove from tin. Store for up to 1
week in an airtight container
Ingredient Quantity

17
CARROT CAKE
FOR THE CAKE
Butter 350g
Soft light brown sugar 350g
Eggs 6
Self Raising Flour 400g
Ground cinnamon ½ tsp
Carrot pulp 300g
Walnuts (optional) 50g
FOR THE FROSTING
Butter 150g
Full fat soft cream cheese 150g
Icing sugar 400g
Vanilla Extract ½ tsp
(This makes enough frosting to sandwich between 2 cakes and to frost the top, if you prefer to frost
sides too, double the frosting quantities.)
• For the cake, cream together the butter and sugar, gradually add eggs and then flour. Add cinnamon,
carrot pulp and walnuts (if using) and mix well
• Preheat oven to 180ºC/Gas 4. Grease 2 x 20cm round sandwich tins or line them with cake tin liners.
Divide cake mixture evenly between tins and smooth tops with a spatula. Bake for 55 minutes or
until a skewer inserted into centre of cake comes out clean. Allow to cool in tins for 5 minutes, then
transfer to a wire cooling rack until completely cold
• Meanwhile cream together the butter and cheese for the frosting, and gradually add the icing sugar
and the vanilla extract, beat till smooth. Sandwich the 2 cakes together with half the frosting and
spread the remainder on top of the cake
Ingredient Quantity
Ingredient Quantity

18
TROUBLESHOOTING
Following are some common problems that can occur when using the Juicepresso. Please
review the problems, their possible cause and any corrective action that should be taken to
ensure successful juicing.
Problem Possible cause Solution
The machine will not start. Lack of power or machine not
correctly put together.
Check power cable is plugged
into socket and switched on.
Check machine is correctly
assembled and that the white
dots on the lid and drum match
up.
There is no juice coming out of
the machine.
The fruit or vegetable being
used is not being fed through
the machine properly.
Switch the machine to ‘reverse’
and allow the squeezing screw
section to rotate a few times,
then switch to ‘forward’ and
see if that dislodges the item
and begins to juice. If not,
disassemble the drum and
squeezing screw section and
then reassemble.
There is no juice coming out of
the machine.
The pulp outlet is blocked with
compacted vegetables.
Switch off at wall socket and
use the handle of the cleaning
brush to unblock any pulp
compacted in the outlet.
Switch on and try again.
Fruit or vegetables will not feed
into the hopper easily.
Piece sizes are too large. Cut the food you are juicing
into smaller pieces so it will
pass through the hopper more
easily.
The pulp is spilling from the jug A large amount of pulp is piling
up in the middle of the jug.
Push pulp down in jug or empty
jug and continue.

19
CARE AND CLEANING
• Unplug the Juicepresso and allow to cool completely before cleaning
• Before the first use and after every use, clean each part thoroughly
• Periodically check all parts to ensure there is no damage or wear and tear before reassembly
• Always use plastic, nylon or silicone spatulas etc. and the cleaning brush supplied to avoid scratching
• Never immerse the base unit in water or any other liquid
• To clean the base unit and control panel, wipe with a clean, damp cloth and dry before storing
• Do not use abrasive cleaners, steel wool or abrasive materials or cleansers
• Wash the hopper, pusher, drum, squeezing screw and jugs in hot, soapy water, rinse and dry
thoroughly. Use the cleaning brush to remove all food residues from the drum, and particularly the
pulp and juice outlets plus the squeezing screw. Remove the rubber pad from base of squeezing
screw, clean around this and replace.
• The drum, jugs, hopper, pusher and squeezing screw are top shelf dishwasher safe
• Store the Juicepresso with the power cable loosely coiled. Never wrap it tightly around the machine

20
ELECTRICAL CONNECTIONS
THIS APPLIANCE MUST BE EARTHED
This appliance is fitted with a fused three-pin plug to BS1363 which is suitable for use in all
homes fitted with sockets to current specifications. If the fitted plug is not suitable for your
socket outlets, it should be cut off and carefully disposed of. To avoid an electric shock, do
not insert the discarded plug into a socket.
FITTINg A NEw PLUg
If for any reason you need to fit a new plug, the flexible mains lead must be connected as
shown here. The wires in the mains lead fitted to this appliance are coloured in accordance
with the following code:
Connect BLUE to Neutral (N)
Connect GREEN & YELLOW to Earth (E)
Connect BROWN to Live (L)
13 amp fuse to be used
If the colours of the wires in the mains lead of this appliance do not correspond with the
coloured markings identifying the terminals in your plug, proceed as follows. The wire which
is coloured green and yellow MUST be connected to the terminal which is marked with the
letter E (Earth) or coloured green. The wire which is coloured blue MUST be connected to
the terminal which is marked with the letter N (Neutral) or coloured black. The wire which is
coloured brown MUST be connected to the terminal which is marked with the letter L (Live)
or coloured red.
Before refitting the plug cover, check that there are no cut or stray strands of wire inside the
plug. Use a 13 amp BS1362 fuse. Only BSI or ASTA approved fuses should be used. If you
are at all unsure which plug or fuse to use, always refer to a qualified electrician.
Note: after replacing or changing a fuse on a moulded plug which has a fuse cover, the cover
must be refitted to the plug; the appliance must not be used without a fuse cover. If lost,
replacement fuse covers can be obtained from an electrical shop. This appliance complies
with the following EEC Directives: 73/23 EEC (Low Voltage Directive) and 89/336 EEC
(EMC Directive).
RECYCLING YOUR ELECTRICALS
Along with many other high street retailers, Lakeland has joined a scheme whereby
customers can take their unwanted electricals to recycling points set up around
the country.
Visit www.recycle-more.co.uk to find your nearest recycling point.
