Lamborghini Caloreclima ECO 3 Manual

AZIENDA CERTIFICATA UNI EN ISO 9001
UNI EN ISO 9001 CERTIFIED COMPANY
СЕРТИФИЦИРОВАННАЯ КОМПАНИЯ UNI EN ISO 9001
BRUCIATORE DI GASOLIO
LIGHT OIL BURNERS
BRULEUR FIOUL DOMESTIQUE
ÖLBRENNER
QUEMADORES PARA GASÓLEO
ГОРЕЛКА НА ДИЗЕЛЬНОМ ТОПЛИВЕ
ECO
3 - 3R - 3 ST - 3R ST - 5 N
5R N - 5 R N ST - 7R - 7/2
MANUALE DI INSTALLAZIONE E MANUTENZIONE
INSTALLATION AND MAINTENANCE MANUAL
NOTICED’INSTALLATIONET D’ENTRETIEN
INSTALLATIONS-UNDWARTUNGSANLEITUNG
MANUAL PARA LA INSTALLACIÓN Y EL MENTENIMIENTO
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ И ТЕХНИЧЕСКОМУ
ОБСЛУЖИВАНИЮ
IT
FR
UK
DE
ES RU

25
UK
GENERAL STANDARDS
This manual is an integral and essential part of the product and must be given to the
installer.
Read the warnings given in this manual as they supply important indications regarding
instal-lation, use and maintenance safety.Keep this manual carefully for future referen-
ce. The burner must be installed in compliance with the Standards in force, according
to the manufacturer’s instructions and by qualied staff Incorrect installation can cause
injury/damage to persons, animals or objects, for which the manufacturer cannot be
held responsible.
This appliance must only be destined for the use for which it was expressly declared.
Any other use must be considered improper and therefore dangerous.The manufactu-
rer is not liable for any damage caused by improper, incorrect or unreasonable use.
Before carrying out any cleaning or maintenance, disconnect the appliance from the
mains power supply by acting on the system switch or via the relevant shut-off ele-
ments.
In the case of breakdown and/or bad functioning of the appliance, deactivate it and do
not at-tempt repairs or direct interventions.
Only contact qualied professional staff.Any product repairs must only be performed
by an after-sales centre authorised by the manufacturer, using original spare parts.Fai-
lure to comply with the above can compromise appliance safety.In order to guarantee
the efciency of the appliance and its correct functioning, it is indispen-sable to follow
the manufacturer’s indications.
Have qualied professional staff perform periodic maintenance of the appliance.Whe-
never the appliance is no longer to be used, the parts that may become a potential
source of danger must be made harmless.
Before commissioning the burner, have qualied staff check:a) that the plate data are
those requested by the gas electricity mains supplies;b) that burner calibration is com-
patible with boiler power;c) that the ow of combustion agent air and the evacuation
of ue gases take place correctly according to Standards in force;d) that aeration and
normal maintenance of the burner are guaranteed.
Before performing any intervention that envisions disassembly of the burner or ope-
ning of the inspection access points, disconnect the electric current.
Do not deposit containers of inammable substances in the room where the burner is
situa-ted.

26
UK
The burner room must have openings towards the outside in compliance with local
Standards in force. If in doubt relative to the circulation of air, rst of all we recommend
that the CO2 value is measured, with the burner functioning at maximum ow rate and
the room ventilated, only via the apertures destined to feed air to the burner andthen
by measuring the CO2 value again, with the door open.The value of CO2 measured in
both cases must not change in a signicant manner.If there are more than one burner
and fan in the same room, this test must be performed with all appliances functioning
simultaneously.
Never obstruct the air apertures of the burner room, the burner fan intake apertures
and any air duct or ventilation grid and external dissipations, with the purpose of pre-
venting:- the formation of toxic/explosive gas mixtures in the air of the burner room;-
combustion with insufcient air, from which dangerous, costly and polluting functioning
oc-curs.
The burner must always be protected from rain, snow and freezing.
The burner room must always be kept clean and free from volatile substances, which
could be sucked inside the fan and block the interior pipes of the burner and the com-
bustion head. Dust is extremely dangerous, especially if this can deposit on the fan
blades, where it will reduce ventilation and produce pollution during combustion. The-
dust an also accumulate on the rear part of the ame stability disc in the combustion
head and cause a poor air/fuel mixture.
The burner must be fed with the type of fuel for which it has been set-up as indicated
on the data plate and in the technical features supplied in this manual. Moreover, it
must be supplied with all control and safety devices requested by local regulations in
force. Pay great care that no external material enters the line during installation.
Make sure that the electric power supply used for the connection is in compliance with
the features indicated on the data plate and in this manual.Make an electric plant with
an effective connection to an earth plant, in compliance with Standards in force. The
earth cable must be a couple of cm. longer that the phase and neutral wire.
If in doubt regarding efciency, it must be checked and controlled by qualied staff.
Never ex-change the neutral and phase cables.The burner can be connected to the
mains electricity with a plug-socket connection only if this is equipped in a way that the
coupling conguration prevents the inversion of phase and neutral.Install an omnipo-
larswitch with opening between contacts of at least 3mm upstream from the appliance
as reque-sted by the existing legislation.
The entire electric system and in particular all cable sections, must be suitable for the
maxi-mum absorbed power value indicated on the appliance data plate and in this
manual.
If the burner power supply cable is faulty, it must only be replaced by qualied staff.

27
UK
Never touch the burner with wet body parts or without wearing shoes.
Never stretch (force) power supply cables and keep them away from heat sources.The
length of the cables used must allow the burner and any boiler door to be opened.
The electric connections must be made exclusively by qualied staff and the regula-
tions in force on the subject of electricity must be respected.After all packaging ma-
terial has been re moved, control the contents and ensure that these have not been
damaged in any way during transport.
If in doubt, do not use the burner and contact the supplier.
The packaging materials (wooden cages, cardboard, plastic bags, expanded mate-
rials, sta-ples, etc...) represent a form of pollution and potential risk if left everywhere.
Collect them and dispose of them in a suitable manner (in a suitable place).
The entire electric system and in particular all cable sections, must be suitable for the
maxi-mum absorbed power value indicated on the appliance data plate and in this
manual.
If the burner power supply cable is faulty, it must only be replaced by qualied staff.
Never touch the burner with wet body parts or without wearing shoes.
Never stretch (force) power supply cables and keep them away from heat sources.The
length of the cables used must allow the burner and any boiler door to be opened.
The electric connections must be made exclusively by qualied staff and the regula-
tions in force on the subject of electricity must be respected.
After all packaging material has been removed, control the contents and ensure that
these have not been damaged in any way during transport.If in doubt, do not use the
burner and contact the supplier.
The packaging materials (wooden cages, cardboard, plastic bags, expanded mate-
rials, sta-ples, etc...) represent a form of pollution and potential risk if left everywhere.
Collect them and dispose of them in a suitable manner (in a suitable place).
.

28
UK
DIMENSIONS
ABC DE Ø F Ø G
min max
ECO 3
ECO 3R 250 215 320 - 90 160 80 -
ECO 3 - ST
ECO 3R - ST 250 215 335 - 90 160 80 60
ECO 5 N
ECO 5R N 280 247 342 - 90 195 80 -
ECO 5 R N - ST 280 247 342 - 90 195 80 60
ECO 7 R - 7/2 280 247 410 40 140 195 90 -
ECO 3 -3R - 5 N - 5 N R - 7 R - 7/2
ECO 3 ST -3R ST - 5 N ST - 5 N R ST

29
UK
TECHNICAL DATA
Model ECO 3
ECO 3 ST
ECO 3 R
ECO 3 R ST ECO 5 NECO 5 R N ECO 5R N ST
Heat output KW 16,6 - 35,6 14,2 - 35,6 29,6 - 59,3 30,8 - 59,3
Flow rate kg/h 1,4 - 3,0 1,2 - 3,0 2,5 - 5,0 2,6 - 5,0
Motor electric power supply W100 100 100 100
Preheater W- 110 - 110
Max current consumption A2,0 2,5 1,0 2,8
Weight kg 10,5 10,7 11,3 11,5
Functioning type On / Off
Fuel Light oil
Max. viscosity at 20°C 1,5 °E - 6 CSt - 41 sec; R1
Power supply V / Hz 230 / 50-60
Ignition transformer power supply V / A 230-240 / 0,25 (50/60 Hz) 230-240 / 0,15 (50/60 Hz)
Ignition transformer
(voltage / secondary current) kV/mA 15 / 40 26/35
Modello ECO 7 R ECO 7/2
Heat output KW 52,2 - 86,6 47,4 - 86,6
Flow rate kg/h 4,4 - 7,3 4,0 - 7,3
Motor electric power supply W100
Preheater W110 --
Max current consumption A2,8 2,3
Weight kg 12 15,8
Functioning type On / Off Two stages
Fuel Light oil
Max. viscosity at 20°C 1,5 °E - 6 CSt - 41 sec; R1
Power supply V / Hz 230 / 50-60 230 / 50
Ignition transformer power supply V / A 230-240 / 0,15 (50/60 Hz) 230-240 / 1,2 (50 Hz)
Ignition transformer
(voltage / secondary current) kV/mA 26/35 10 / 20

30
UK
WORK CURVES
The curves shown in the diagram were obtained by performing combustion tests in
accordance with the specications and characteristics of re required by law.
-0,2
0,0
0,2
0,4
0,6
0,8
1,0
1,2
1,4
mbar
10 20 30
kW
40
-0,2
0,0
0,2
0,4
0,6
0,8
1,0
1,2
1,4
mbar
10 20 30
kW
40
ECO 3 - ECO 3 ST ECO 3 R - ECO 3 R ST
2
1
3 4 5 16
17
15
6 7 8 9
10
11
14 13
12
MAIN COMPONENTS
LEGENDA
1 Components plate
2 Solenoid valve
3 Mounting ange
4 Photoresistance
5 Reset button
6 Electrodes
7 Nozzle line (with preheater mod. R.)
8 Air damper
9 Control unit
10 Pump
11 Motor
12 Burner body
13 Fan
14 Combustion head
15 Transformer
16 Flow nozzle
17 Air servomotor
(only 7/2)

31
UK
0
0,5
-0,2
1
10 20 30 40 50 9060 70 80
2345678
1
1,5
mbar
kg/h
kW
-0,2
0,0
0,2
0,4
0,6
0,8
1,0
1,2
1,4
mbar
30 40 50
kW
60
-0,2
0,0
0,2
0,4
0,6
0,8
1,0
1,2
1,4
mbar
30 40 50
kW
60
-0,2
0,0
0,2
0,4
0,6
0,8
1,0
1,2
1,4
mbar
30 40 50
kW
60
ECO 5 N ECO 5 R N
ECO 7/2
ECO 5 R N ST
* Working range obtainable in
1st stage.
-0,2
0,0
0,2
0,4
0,6
0,8
1,0
1,5
mbar
50 60 70
kW
80 90
ECO 7 R

32
UK
BOILER ASSEMBLY
3 2 5
14
95 M8
140 180
45˙
Insert screw 1 (M8 x 30) in ange 2 - Fasten
ange 2 onto Boiler with screws 3 (N° 4 screws
M8 x 20) placing the insulation gasket 4.Insert
burner into ange/boiler and fasten to screw 1
with nut 5.
ECO 3 - 3 R - 3 ST - 3 R ST - 5 N - 5N R - 5 N R ST
ECO 7 R - 7/2
Fix the ange 2 to the boiler with 4 screws
3 (M8 x 25), interposing the insulating seal
4 and the insulating cord5 as shown. Fit
the burner to the ange/boiler and tighten
the screw 1 on the ange thus locking the
burner.

33
UK
FUEL FEED PIPES
10
20
30
40
50
60
m
4H-m
ø 12
ø 10
ø 8
0
20
40
60
80
100
m
ø 10
ø 8
ø 6
1
03
24H-m
1
0
3
2
ASPIRATED SYSTEM GRAVITY-DROP SYSTEM
A
-H +H
H
H
G
C
E
B
LF
D
DIAMETER PIPE
Key
A Fuel aspiration line
B Fuel lter
C Fuel aspiration line gate
D Flow-stop solenoid valve
E Return line gate
F Return line
G Bottom valve
H Rapid on-off gate with remote control
L One-way check valve
Diagrams refer to light oil with max viscosity 1.5°E (6 cSt) at 20°C.
The release pushbutton on the equipment is the main component for accessing all the diagno-
stic functions (activation and deactivation) as well as for releasing the control and checking
device.
The release pushbutton has a multicoloured led which indicates the state of the control and
checking device during operation and when the diagnostic function is in use.
LMO EQUIPMENT

34
UK
If the burner is locked out, there will be a steady red light on the lock out pushbutton.
By pressing the transparent pushbutton, the control and checking device will be released.
By pressing it for more than 3 seconds, the diagnosis stage will be activated (red light ashes
rapidly). The table below describes the causes of the lock out or fault in relation to the number
of ashes (always red). The diagnosis function is interrupted by pressing the release button for
at least 3 seconds..
Condition Colour sequence
Standby, other intermediate states No light
Fuel preheating “on”, waiting time 5s.max Yellow
Ignition stage Yellow, ashing
Correct operation Green
Incorrect operation, current level of
ame detector below permitted minimum Green, ashing
Drop in voltage Alternating yellow red
Burner lock out Red
Fault Red, ashing
Stray light before burner ignition Alternating green, red
Rapid ashing for diagnostics Red, rapid ashing
DIAGNOSIS OF LMO EQUIPMENT FAULTS AND LOCK OUT
List operating anomalies
Visual indication Possible causes
2 ashes ¬¬
No ame signal
- Faulty fuel valves
- Faulty ame detector
- Incorrect burner setting, no fuel
- No ignition
3 ashes ¬¬¬ Not used
4 ashes ¬¬¬¬ Stray light on ignition
5 ashes ¬¬¬¬¬ Not used
6 ashes ¬¬¬¬¬¬ Not used
7 ashes ¬¬¬¬¬¬¬
No ame signal during operation
- Faulty fuel valves
- Faulty ame detector
- Incorrect burner setting, no fuel
8 ashes ¬¬¬¬¬¬¬¬ Anomalies in fuel preheating time
9 ashes ¬¬¬¬¬¬¬¬¬ Not used
10 ashes ¬¬¬¬¬¬¬¬¬¬ Incorrect electrical connection or damage to equipment
EQUIPMENT STATE INDICATORS
Description

35
UK
The wiring scheme to be carried out by technician are:
— Power Supply Line
— Thermostats Line
— Eventual blocking lamp and/or hour-meter
WARNING:
- Do not invert the neutral with the phase.
- Make the connection to an ef cient earthing system.
- Bridge 3-8 on base is found only on versions withouth preheater.
1 2 2345678101112 9
TR
M
MB
VE
FR
PR
Tm
2
FA
MA
TC-TA
TS
F
IG
B4 T2 T1 N L1
S3
L
N
LS
N
N
CO
Z
H
PB
SC
Key
CO Hour-meter (possible)
F Fuse
FA Anti-interference lter
FR Photoresistance
IG Main switch
LS Lock-out warning light (possible)
MA Control unit terminal board
MB Burner motor
PB Burner connector
PR Preheater (only mod.R)
SC Plug
TA-TC Boiler environment thermostat
TR Ignition transformer
TS Safety thermostat
Tm Minimum thermostat
VE Solenoid valve
WIRING DIAGRAM
ECO 3 - 3R - 3 ST 3 3 R ST - 5 N - 5 R N - 5 R N ST - 7 R

36
UK
ECO 7/2
Key CM Connector FFuse FA Anti-interference lter FR Photoresistance IG Main switch MA Control unit terminal board MB Burner motor
MS Air motor terminal board TC Boiler environment thermostat TR Ignition transformer TS Safety thermostat Tmf TFlame mudulationthermostat
(possible) VE1 1st stage solenoid valve VE2 2st stage solenoid valve

37
UK
After having installed the nozzle, check the correct position of the electrodes and deector
according to the following levels. It is adviseable to check levels after every intervention on
head.
ELECTRODES - DEFLECTOR SETTING
ECO 7/2
ECO 3 - 3R - 3 ST 3 3 R ST - 5 N - 5 R N - 5 R N ST - 7 R
3 4
2 3
3,5 4
6,5 7
HEAD COMBUSTION ADJUSTMENTS
Head adjustment is made by the screw 1, as for indi-
cations of index 2.

38
UK
NOZZLE CHOICE
Inside every PUMP/NOZZLE PRESSURE box there are two values. The ow rate in kg/h is expressed
at the top, in kW at the bottom.
INSTALLING NOZZLE.
Once the nozzle adapt to the boiler power has been chosen proceed with its mounting onto the burner
following the instructions given in the paragraph “MAINTENANCE” (Fig. A, B, C, C1).
Bar
GPH 8 9 10 11 12 13 14 15 16 17 18 19 20
0,40 1,36 1,44 1,52 1,59 1,67 1,73 1,80 1,86 1,92 1,98 2,04 2,10 2,15
16,1 17,1 18,0 18,9 19,8 20,5 21,3 22,1 22,8 23,5 24,2 24,9 25,5
0,50 1,70 1,80 1,90 1,99 2,08 2,17 2,25 2,33 2,40 2,48 2,55 2,62 2,69
20,2 21,3 22,5 23,6 24,7 25,7 26,7 27,6 28,5 29,4 30,2 31,1 31,9
0,60 2,04 2,16 2,28 2,39 2,50 2,60 2,70 2,79 2,88 2,97 3,06 3,14 3,22
24,2 25,6 27,0 28,3 29,7 30,8 32,0 33,1 34,2 35,2 36,3 37,2 38,2
0,65 2,21 2,34 2,47 2,59 2,71 2,82 2,92 3,03 3,12 3,22 3,31 3,41 3,49
26,2 27,8 29,3 30,7 32,1 33,4 34,6 35,9 37,0 38,2 39,3 40,4 41,4
0,75 2,55 2,70 2,85 2,99 3,12 3,25 3,37 3,49 3,61 3,72 3,82 3,93 4,03
30,2 32,0 33,8 35,5 37,0 38,5 40,0 41,4 42,8 44,1 45,3 46,6 47,8
0,85 2,89 3,06 3,23 3,39 3,54 3,68 3,82 3,96 4,09 4,21 4,33 4,45 4,57
34,3 36,3 38,3 40,2 42,0 43,6 45,3 47,0 48,5 49,9 51,4 52,8 54,2
1,00 3,40 3,61 3,80 3,99 4,16 4,33 4,50 4,65 4,81 4,96 5,10 5,24 5,37
40,3 42,8 45,1 47,3 49,3 51,4 53,4 55,2 57,0 58,8 60,5 62,1 63,7
1,10 3,74 3,97 4,18 4,38 4,58 4,77 4,95 5,12 5,29 5,45 5,61 5,76 5,91
44,4 47,1 49,6 51,9 54,3 56,6 58,7 60,7 62,7 64,6 66,5 68,3 70,1
1,20 4,08 4,33 4,56 4,78 5,00 5,20 5,40 5,59 5,77 5,95 6,12 6,29 6,45
48,4 51,4 54,1 56,7 59,3 61,7 64,0 66,3 68,4 70,6 72,6 74,6 76,5
1,25 4,25 4,50 4,75 5,00 5,20 5,40 5,60 5,80 6,00 6,20 6,35 6,55 6,70
50,4 53,4 56,3 59,3 61,7 64,0 66,4 68,8 71,2 73,5 75,3 77,7 79,5
1,35 4,59 4,87 5,13 5,38 5,62 5,85 6,07 6,28 6,49 6,69 6,88 7,07 7,26
54,4 57,8 60,8 63,8 66,7 69,4 72,0 74,5 77,0 79,3 81,6 83,9 86,1
1,50 5,10 5,41 5,70 5,90 6,24 6,50 6,75 6,98 7,21 7,43 7,65 7,86 8,06
60,5 64,2 67,6 70,0 74,0 77,1 80,1 82,8 85,5 88,1 90,7 93,2 95,6
1,65 5,61 5,95 6,27 6,58 6,87 7,15 7,42 7,68 7,93 8,18 8,41 8,64 8,87
66,5 70,6 74,4 78,0 81,5 84,8 88,0 91,1 94,1 97,0 99,7 102,5 105,2
1,75 5,95 6,31 6,65 6,98 7,29 7,58 7,87 8,15 8,41 8,67 8,92 9,17 9,41
70,6 74,8 78,9 82,8 86,5 89,9 93,3 96,7 99,7 102,8 105,8 108,8 111,6
2,00 6,80 7,21 7,60 7,97 8,33 8,67 8,99 9,31 9,61 9,91 10,20 10,48 10,75
80,7 85,5 90,1 94,5 98,8 102,8 106,6 110,4 114,0 117,5 121,0 124,3 127,5
2,25 7,65 8,15 8,55 8,97 9,37 9,75 10,12 10,47 10,85 11,15 11,47 11,79 12,09
90,7 96,7 101,4 106,4 111,1 115,6 120,0 124,2 128,7 132,2 136,0 139,8 143,4
2,50 8,50 9,01 9,50 9,97 10,41 10,83 11,24 11,64 12,02 12,39 12,75 13,10 13,44
100,8 106,9 112,7 118,2 123,5 128,4 133,3 138,1 142,6 147,0 151,2 155,4 159,4
3,00 10,20 10,82 11,40 11,96 12,49 13,00 13,49 13,96 14,42 14,87 15,30 15,72 16,12
121,0 128,3 135,2 141,9 148,1 154,2 160,0 165,6 171,0 176,4 181,5 186,4 191,2
3,50 11,90 12,62 13,30 13,95 14,57 15,17 15,74 16,29 16,83 17,34 17,85 18,34 18,81
141,1 149,7 157,7 165,5 172,8 179,9 186,7 193,2 199,6 205,7 211,7 217,5 223,1
4,00 13,60 14,42 15,20 15,94 16,65 17,33 17,99 18,62 19,23 19,82 20,40 20,95 21,50
161,3 171,0 180,3 189,1 197,5 205,5 213,4 220,8 228,1 235,1 242,0 248,5 255,0

39
UK
KEY
1 I ntake
2 Return
3 Nozzle
4 Pressure Adjustment
PUMP PRESSURE ADJUSTMENT
The pump pressure is pre-set during production at 12 bar.For controlling pressure use an oil
bathed manometer.
The pressure can be adjusted from 11 to 14 bar. From 7 to 14 bar for model R.
The pump is preadjusted at the factory to 10 bar for the 1st stage and 18 bar for the
2nd stage.Use an oil-bath pressure gauge to check the pressure.The recommended
operating pressure is between 10 and 20 bar.
KEY
1 Intake
2 Return
3 Nozzle
4 Low-pressure regulator (1st stage)
5 High-pressure regulator (2nd stage)
6 1st stage solenoid valve
7 2nd stage solenoid valve
8 Vacuometer attachment
Pressure gaugeattach-
ment for1st and 2nd stage
Pressure gauge-
attachment for2nd
stage only
ECO 7/2
ECO 3 - 3R - 3 ST 3 3 R ST - 5 N - 5 R N - 5 R N ST - 7 R

40
UK
Orientative positions of deector and air ap according to various Boiler power levels (kW)
and nozzle size (GPH).
It is necessary to make combustion tests and to turn the air shaft regulating screw for adju-
sting the air quantity.
3
4
5
2
1
MAX
MIN
35
30
21
19
11
kW
...
GpH
0.35
0.50
0.65
0.75
0.85
...
...
...
...
2
1
3
3 3
4 4
5 5
2 2
1 1
MAX MAX
MIN MIN
35 35
11 11
kW kW
30 30
21 21
19 19
... ...
0.65 0.65
0.85 0.85
0.75 0.75
GpH GpH
0.35 0.35
0.50 0.50
... ...
... ...
... ...
... ...
2 2
1 1
3 3
ECO 3 - 3R - 3 ST 3 3 R ST
ECO 5 N - 5 R N - 5 R N ST
3
4
5
2
1
MAX
MIN
59
45
32
kW
GpH
0.65
1.00
1.35
...
...
...
2
1
3
3 3
4 4
5 5
2 2
1 1
MAX MAX
MIN MIN
59
45
32
kW
GpH
0.65
1.00
1.35
...
...
...
2
1
359
45
32
kW
GpH
0.65
1.00
1.35
...
...
...
2
1
3
AIR DAMPER ADJUSTMENT
After having untightened the screw C, whith the screwAit obtains the air combustion adjustment,
according tothe indications of index B. Block the screw C when the calibration is effected.
ECO 3 - 3R - 3 ST 3 3 R ST - 5 N - 5 R N - 5 R N ST - 7 R
ECO 7 R

41
UK
AIR SEVOMOTOR ADJUSTMENT
ECO 7/2
The geared motor limit switch and auxiliary contacts are triggered by easily accessible
adju-stable cams, which can be set against o graduated scale
SETTING THE CONTACT TRIGGERING POINT
General information:
CAM V (2 Stage) - Cam controlling air valve fully open position (maz. ring rate with
both stages in operation).
CAM IV (1 Stage) - Cam controlling minimum air ow condition (min. ring rate 1st
stage only in operation).
CAM II-III (MV1-MV2) - Auxiliari cam activating the 2nd stage valve.
RECOMMENDATIONS TO PROPERLY SET THE GEARED MOTOR
The geared motor is set upon testing as follows:
CAM V (2 Stage) : is set on approx 90°-120°
CAM IV (1 Stage) : is set on approx 25°÷50°.
CAM II-III (MV1-MV2): is set in such a way that the 2nd stage valve opens when the air
shut-off valve is at 60°÷80°.
Changes to this calibration during installation are legible even when the burner is in
operation by acting on the adjusting screws of the cams.
Tightening the screws increases the angle and positioning of the cams.
CAMMA V (2st Stage)
CAM IV (1st Stage)
CAM II-III (MV1-MV2)
Adjusting screws
ECO 7 R

42
UK
Most components can be checked by removing the cover. For head inspection, the compo-
nent plate must be dismounted which can be hung on the burner body in 2 positions to allow
intervention in the most rationable way. The motor, transformer and electromagnetic valve
are electronically connected to plug/socket, thephotoresistance is inserted under pressure.
ATTENTION:ensure unit is unplugged before removing cover.
Fig. A
By removing the cover, access is gained
to:condensor-motor, control box, transfor-
mer photoresistance, pump, electroma-
gnetic valve.
Fig. B
By unscrewing the plate xing pin the burner
can be opened allowing
access to the fan, nozzle, electrodes and
preheater..
In order to obtain the best combustion performance and efciency, and for respect of the envi-
ronment, checksand adjustment of the combustion must be carried out, and with appropriate
tools.Basic values to be considered are:
—CO2 indicates the amount of excess air during combustion; if air is increased, CO2 % value-
sdecrease, and if combustion air is decreased, CO2 % values increase.
—SMOKE SCALE (Bacharach) indicates that solid un-burnt particles are present in the smo-
ke. If N°2 on the BH scale is exceeded the nozzle must be checked for faults and that it is
adapt to the burnerand boiler (trade, type, pulverization angle).Usually the BH scale number
tends to decrease, increasing pump pressure, in this case keep theincreasing combustion
levels under control.
—SMOKE TEMPERATURE is a level which indicates heat loss through the chimney; higher
thetemperature, greater is the loss and lower combustion efciency. If the temperature is too
high thequantity of burned light oil needs to be lowered.
IMPORTANT: existing laws in some countries can require a different adjustment to that given
here and may alsohave different parameters. ECO burners are designed to meet the toughest
international laws on energy savingand respect of the environment.
COMBUSTION CONTROL
MAINTENANCE

43
UK
Fig. C - C1
To dismount the nozzle:
a)Loosen screw 1 and extract deector/electrode set.
b)Unscrew the nozzle with spanner/counter-spanner.
IMPORTANT:x the deector/electrodes set on the-
nozzle holder tube in position as per g. D.
Fig. D
Centering tongue for vertical position or
lightly to the right position (max 10°)
