User & Installation Guide
LAM1741
Ceramic
Touch Control Hob

02_
LAMONA Appliances
Dear Customer,
Congratulations on your choice of hob which has been designed to give you excellent service.
The user manual will help you use your product quickly and safely.

Please read this user manual before installing and using the hob.
Always follow the safety instructions.
Keep this user manual within easy reach for future reference.
Please read any other documents supplied with the product.
Remember that this user manual may also applicable for other models and there maybe some minor
differences between the illustrations and your product.
Explanation of symbols
Throughout this user manual the following symbols are used:
This product’s packaging material is recyclable. Help recycle it and protect the
environment by dropping it off in the municipal receptacles provided for this purpose.
Your product also contains a great amount of recyclable material. It is marked with this
label to indicate the used appliances that should not be mixed with other waste. This
way, the appliance recycling organised by your manufacturer will be done under the
best possible conditions, in compliance with European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment. Contact your town hall or your retailer for the used
appliance collection points closest to your home. We thank you doing your part to protect
the environment.
Important information or useful tips about usage.
Warning for possible hazards to health and property.
Warning possibility of electric shock.

_ 03
User manual LAM1741
Index
Index
01 - Before Using the hob 04
02 - Safety 04
General 05
Fire safety advice 06
Fire Safety 06
If a pan catches Àre 06
Deep fat frying 06
If you have an Electrical Fire 06
03 - Using your hob 08
Touch controls 08
Controls layout 08
Initial setup 08
Functions 09
Timed cooking 10
Safety shut off 10
04 - Cleaning and Maintenance 11
Ceramic hob glass 11
05 - Trouble Shooting 12
06 - Installation 13
General Information 13
Positioning 13
Connect to the electricity supply 16
Technical Data 17
07 - Your guarantee 18

04_
LAMONA Appliances
Before Using the hob
Make sure that you have removed all packaging, wrappings, stickers and from the hob surface.
It is recommended that you clean and wash the hob surface before using for the time.
Apply a thin coat of ceramic hob cleaner to the hob to help maintain and protect it.
01 - Before using the hob
WARNING! - The
appliance and its
accessible parts become
hot during use. Care should
be taken to avoid touching
heating elements. Children
less than 8 years of age
shall be kept away unless
continously supervised.This
appliance can be used by
children aged from 8 years
and above and persons
with reduced physical
sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning the use of the
appliance in a safe way and
understand the hazards
involved. Children shall not
play with the appliance.
Cleaning and user
maintenance shall not be
made by children without
supervision.
WARNING! -
Unattended cooking on a
hob with fat or oil can be
dangerous and may result
NEVER try to extinguish a
off the appliance and then
or damp cloth.
WARNING! - Metallic
objects such as knives,
forks, spoons and lids
02 - Safety

_ 05
User manual LAM1741
should not be placed on
the hob surface since they
can get hot.
WARNING! -Danger
on the cooking surface.
WARNING! -Never
leave any cook zone on
without a pan covering it.
This causes a hazard.
WARNING! -If the
surface is cracked, broken
or shattered, switch off
the appliance to avoid the
possibility of electric shock
and call for a service
engineer’s visit
WARNING! -
Servicing should be
carried out only by
authorised personnel.
WARNING! -
Do not spray aerosols
in the vicinity of this
appliance while it is in
operation.
WARNING! - Do not
liquids or items in the
vicinity of this appliance.
WARNING! -
Do not modify this
appliance.
General
 Always ensure that pan bases are dry, stable
and before using them on the hob.
 Alwa\Vmatch the size of pan to the cook
zone – do not use large pans on small zones
or vice versa.
 Alwa\Vposition pans over the centre of the
cook zone, and turn the handles to a safe posi-
tion so they cannot be knocked or grabbed.
 Always lift pans onto and off the hob, rather
than sliding them across the surface, to avoid
marks and scratches.
This appliance should only be used for normal
domestic cooking of food.
 Never use the hob for any other purpose than
cooking food.
Plastic cooking utensils can melt if they come
into contact with a warm hob. Never leave
them close to, or on top of the hob.
Safety

06_
LAMONA Appliances
 Never use the hob surface as a chopping
board or food preparation area, as this may
lead to it becoming damaged.
 Never leave aluminium foil on the hob top,
it reÁects heat back into the element which
leads to damage.
 Never heat up a sealed tin of food on the hob,
as it may explode.
 Never leave pans overhanging the edge of the
hob. The surface of the hob is smooth. If pans
are knocked they may move on the hob top.
Fire safety advice
Most kitchen Àres occur when people are distracted
or leave things unattended, so remember:
If you’re called away from the hob - by the phone or
someone at the door, either take pans off the heat,
or switch off your hob.
Don’t let yourself be distracted while cooking.
If you do have a Àre in the kitchen, don’t take any
risks - get everyone out of your home and call the
Fire Service
,IDSDQFDWFKHVÀUH  
Do not move it as it’s likely to be extremely hot.
Turn off the heat if it’s safe to do so, but never
lean over a pan to reach the controls.
Use Àre blanket or a damp tea-towel to cover
the pan.
If you have put the Àre out, leave the pan to
cool completely.
Deep-fat frying presents more
dangers in your kitchen
Never Àll a pan or other deep fat fryermore
than one-third full of oil.
Do not use a Àre extinguisher on a pan of
burning oil - the force of the extinguisher can
spread the Àre and create a Àreball.
,I\RXKDYHDQHOHFWULFDOÀUHLQWKH
NLWFKHQ   
Pull the plug out, or switch off the power at the
fuse box - this may be enough to stop the Àre
immediately
Smother the Àre with a Àre blanket, or use a
dry powder or carbon dioxide extinguisher
Remember: never use water on an electrical or
cooking oil Àre.
Avoiding damage to the appliance
The ceramic glass of the hob can be damaged by
objects falling onto it. Be especially careful with
heavy jars of food being stored in cupboards above
the hob, we recommend storing them away from the
hob area.
The edge of the glass can be damaged by being
knocked by cookware. Cookware made of cast
iron, cast aluminium or with damaged bottoms
can scratch the ceramic glass if pushed across the
surface.
Objects that melt and things that boil over can burn
onto the ceramic glass and should be removed as
soon as possible. To avoid damage to cookware and
the ceramic glass, do not allow sauce pans or frying
pans to boil dry.
Do not use the cooking zones with empty cookware
or without cookware in place.
Safety

_ 07
User manual LAM1741

08_
LAMONA Appliances
Touch Controls
The touch controls for your hob have been designed
to provide you with Ànger tip control of your hob,
providing accurate and repeatable power settings
for cooking and an easy clean surface that can be
easily wiped over. When a cook zone is activated the
power setting is displayed for each zone individually,
Controls layout
a. Referred =one x4
b. Minute Minder / Fault code
c. Upper Left Zone
d. Lower Right Zone
e. Minus ¶-’ Power Level / Time
f. Power On/off
g. Timer
h. Upper Right Zone
i. Lower Right Zone
j. Plus ¶’ Power Level / Time
k. Lock
Initial set up
Before switching on the power supply to the
appliance, switch off any bright lights such as
cooker hoodand ensure the appliance is not in
direct sunlight.
This is to enable the electronic controls to calibrate
its sensitivity against natural ambient lighting
approx 30 seconds.
Failure to observe the above will result in the hob
not functioning correctly, Display showing ´FLµ.
To rectify remove all strong lighting sources and
re-apply power.
The hob should complete the calibration procedure
satisfactorily and lighting such as cooker hoods can
be used normally.
03 - Using the hob - electric ceramic
a
c
d
h
i
g
e j
f k
b
Using the hob

_ 09
User manual LAM1741
Using the hob
Functions
Lock
A Red Led indicates when the key lock is
active, to deactivate/activate, touch the Key
Lock key for 1 second.
The key lock is deactivated when the Red LED
switches off.
If any of the cook zones are ON, the key lock
function locks all the keys except the ON/OFF
key.
If the cook zones are OFF, the key lock function
locks all the keys, including the ON/OFF key.
The Key Lock is automatically activated every
time the electricity supply is switched off and back
on to the hob.
To avoid unintentional switching on of the
appliance, e.g. by small children and pets, we
recommend activation of the key lock feature.
Switching on the hob
Touch and hold the on/off symbol for 1
sec. The hob will beep and all energy level
indicators will display “0”.
If no other symbol is selected within 10 secs
the hob will turn off.
Operating a zone
Ensure the Key lock is deactivated.
Touch the On/Off Key for 1 second a beep
sounds and the cook zone displays become
illuminated.
Touch the required cook zone key, it will start
to
Whilst adjust the cook zone power
level as required by using the Up+/down- keys.
Then either touch the cook zone key again to
the setting or after 5-10 seconds the
hob will auto set the hob power and will beep
and stop
To adjust the power setting follow steps 3-5.
Repeat as necessary for the other zones.
Switching a zone off
Touch the required cook zone key until the
zone display now either return the
power level to 0 by pressing the down(-) key or
simultaneously press the down(-) and up (+)
simultaneously and it will jump straight to the
0 setting.
Notes on use
The power settings on the hob do not indicate
any set temperature and cannot be used to
judge one element against another.
During cooking, the elements will cycle on and
off. This is normal.
Auto heat-up
Select appropriate cook zone and increase to
power level 9.
Now press the up (+) key again and until the
Red LED is illuminated next to the cook zone.
The power level will still be so now
select the power level you would like (use the
heat up time table for guidance).
Once set the Red LED is illuminated.
Once the heat up time as elapsed a beep will
sound and the Red Led disappears and the
heater remains at the reduced level.
Power Level Time (Min/Sec)
Heat up Time (Approx)
101:11
2 02:44
3 04:47
4 05:28
5 06:29
601:11
7 02:44
8 02:44

10_
LAMONA Appliances
Timed cooking
R
e
f
ere
d
zone
LED’s
Timer
Timer adjust indicator
All 4 cooking zones can be operated under the
timer independently and at the same time for
up to 99 minutes. When the set time expires the
timer will beep and the cook zone will switch off
automatically.
To set the timed cooking to a zone:
Set the desired zone power level as described
previously.
Whilst the cook zone power level is
touch the timer key and the timer will
illuminate “00” and two Red LEDs will
illuminate the one will be on
the
timer to indicate the activated timed cook
zone and the second one “00.” Indicates that
the time can be adjusted.
Using the “+” or “-” symbols, set the time
required in minutes.
To check remaining time:
Touch the symbol for the desired zone followed
by the timer symbol.
To adjust the set time:
Touch the symbol for the desired zone followed
by the timer symbol.
Using the “+” or “-” symbols, reduce or
increase the time required (in minutes).
To deactivate timed Cooking:
Touch the symbol for the desired zone followed by
the timer symbol.
Adjust the “-” symbol down to “0”. At the end of the
cooking time
At the end of the cooking time the buzzer will
activate and the zone’s LED will Touch the
zone key to deactivate.
Residual heat indicator
If the glass surface is hot an “H” will be displayed in
the cook zone display until the glass has
cooled.
“ H” and “0” will alternatively if the cook
zone is hot and another cook zone is in use.
lock:
When the system is in child lock the controls
are deactivated. To lock and unlock the hob
touch and hold the key symbol.
Safety shut off
If the power level of a zone is not changed
for a long period of time the cook zone will
automatically switch off. The maximum time a
cook zone can stay on depends on the power
level.
Power Level Max. time on (hrs)
110
25
35
44
53
62
72
82
91
Using the hob

_ 11
User manual LAM1741
04 - Cleaning & maintenance
Ceramic glass hobs
It is recommended that you clean and wash
the hob surface before using for the time.
Apply a thin coat of ceramic hob cleaner to the
hob to help maintain and protect it.
The ceramic hob top can be cleaned using a
clean, damp cloth or kitchen paper. Do not
use a used dishcloth or sponge as they can
leave a of detergent on the surface which
can lead to discoloration. Please ensure that
the elements are cooled fully to avoid steam
burns.
You can use a specialist ceramic cleaner to
restore the surface, but use sparingly to avoid
coating the hob top too thickly. Too much
cream cleaner will lead to discolouration. Use
a dry, clean cloth to polish the surface.
For stubborn marks, a specialist hob scraper
or cleaner can be used.
Do not use steam cleaners or high-pressure
cleaning equipment.
Regular cleaning will prevent any salts or
minerals from accumulating on your hob and
discolouring the glass.
Wipe any spillage as soon as possible.
Clean the hob top as regularly as possible, this
will prevent any build up of grease which may
be a hazard.
Foods with high sugar content (toffee, fruit
juice, jam, etc.) that boil over while cooking, or
spattered sugar stains must be immediately
removed using a scraper even if hot.
Notes:
The edge of the ceramic glass will always
appear to be a different colour than the top
surface due to the ground safety edge.
Scratches or dark stains on the ceramic
glass that cannot be removed do not affect the
function of the appliance.
Safety when Cleaning
For cleaning, the appliance must be switched
off and cooled down.
Risk of burns from residual heat.
Cleaning and maintenance

12_
LAMONA Appliances
05 - Trouble shooting
If you encounter a problem, it is often something minor, please read some of the suggested tips below.
The hob is not working Check the fuse/circuit breakers to see if you are experiencing a power
failure
The hob has turned itself off Check that the main on/off switch has not been touched or covered
accidentally, remove any objects on the hob and try turning it back
on again.
Repairs Repairs are to be carried out by trained service technicians.
Display F and letters If “F” and letters appear on the display, your unit has detected a
fault, the following table lists actions you should take to correct the
problems
Error codes
Hob Status
Codes Fault Description Action
H Residual Heat “ H” will switch off when
glass surface drops below 60oC
Hob Status
Codes Fault Description Action
F0 Touch Control Error Switch the power off and on, The system will reset and the hob should
now be working correctly
FA Touch Control Error Switch the power off and on,The system will reset and the hob should
now be working correctly
FU Touch Control Error Switch the power off and on, The system will reset and the hob should
now be working correctly
FJ Touch Control Error Switch the power off and on, The system will reset and the hob should
now be working correctly
FC Touch Control Error Switch the power off and on, The system will reset and the hob should
now be working correctly
Fr Touch Control Error Switch the power off and on, The system will reset and the hob should
now be working correctly
Fc or F Overheat / Temperature Problem Allow hob to cool then Switch the power off and on, The system will
reset and the hob should now be working correctly
FE Overheat / Temperature Problem Allow hob to cool then Switch the power off and on, The system will
reset and the hob should now be working correctly
Ft Overheat / Temperature Problem Allow hob to cool then Switch the power off and on, The system will
reset and the hob should now be working correctly
FL Poor Ambient Light Conditions Switch off lighting in area, Clean hob surface, Switch the power off and
on, The system will reset and the hob should now be working correctly
If any of the above problems persist please contact the customer service line for further assistance,
Trouble shooting

_ 13
User manual LAM1741
06 - Installation
Installation
General information
Installation should only be carried out by a qualiÀed
installer or engineer.
Please keep to the following points most carefully;
Although every care has been taken to ensure
this appliance has no burrs, or sharp edges, we
recommend that you wear protective gloves when
installing and moving this appliance. This will
prevent injury.
The minimum distances to other appliances and
units are to be observed.
Wall surfaces above the work surface and
in the immediate vicinity of the cooking
hob must be heat resistant.
Laminated surfaces and the adhesive used for
Àxing them must be heat resistant in order to avoid
any damage.
The space for air circulation, located
underneath and at the back of the hob
improves its reliability by ensuring that it
will cool down, efÀciently.
Installations should be carried out in line
with the National Regulations applicable
with this product type.
Note: Avoid installing the appliance next to doors
and under windows. This will avoid the potential
for hot cookware being knocked off the hob when
doors and windows are opened (Risk of burns).
Built-in appliances may only be used after they have
been built-into suitable built-in units and surfaces
that meet the required standards.
Positioning
Choosing your installation
We recommend that you install this appliance in a
work top which is a minimum 38mm deep.
The hob can be Àtted into a work top less than
38mm deep, but the 25mm gap between hob base
and appliance must be maintained.
Installing the hob over a unit with a drawer or
door
The base of the appliance must be protected
from damage e.g. draws may only be installed
providing a partition panel is Àtted maintaining
the 25mm gap underneath the appliance.
Installation above an oven
Refer to the manufacturer’s instructions for
clearances above the oven. We recommend a
minimum 25mm gap between the bottom of
the hob and appliance
Worktop
25mm
oven or partition
Hob
Clearances and dimensions – requirements
No shelf or overhang of combustible material
should be closer than 650mm above the hob.
There must be a minimum clearance of 50mm
between the edges of the hob and any side
walls; this clearance must be maintained up to
420mm above the worktop.

14_
LAMONA Appliances
Installation
When installing an extractor hood above the
hob, refer to its manufacturer’s instructions
Clearances and dimensions – requirements
There must be a minimum clearance of 50mm
between the rear edge of the hob and the rear
wall. This clearance must be maintained up to
650mm above the worktop (unless otherwise
stated in your extractor manual)
560mm
50mm Min
50mm min
420mm min
490mm
Minimum distance
between carcasses must
be equal to width of hob
*
Minimum height to extractor
as recommend in extractor
instruction manual
*
50mm min between hob and rear wall
(>60mm to cut out aperture)
Fitting into worktop
Cut a hole in the work surface to the required size.
(560mm x 490mm) as illustrated above.
A clearance of at least 50mm should be maintained
between the cutout and any rear or side wall.
The worktop must be of heat-resistant material or
covered with heat-resistant material.
Protecting the cut-out
The types of chipboard used for work
surfaces swell relatively quickly in contact with
humidity.
Apply a suitable sealant to the cut edge to protect it
from moisture ingress.
Self Adhesive Seal
Apply the self adhesive seal to the underside edges
of the hob glass. For best results, the seal should
be adhered along each side in turn, as close to
the edge as possible, and trimmed at each corner,
taking care to ensure a neat join.
This hob can be installed conventionally
(glass above the work top) or recessed into the work
top for a
Conventional Installation
Install the 4 spire clips shown in
Place the hob in the aperture, checking the hob
glass is covering the work top along all four sides.
Set the front edge of the appliance parallel with the
front of the work top.
Locate and attach the securing clamps as required,
Tighten the screws so that the hob is pulled down
against the worktop, thus ensuring a good
seal.
Recessed method
Recess the work top to the appropriate depth
(Approx 5mm) and shape to the hob (add 1mm to
overall glass size.
Install the 4 spire clips shown in
Insert the hob into the recess, ensuring that the
foam seal is sitting correctly.
Locate and attach the securing clamps to the
front and rear underside of the hob, using the
screws provided. Tighten the screws so that the
hob is pulled down against the worktop, thus
ensuring a good seal.
You may want to any gap between the hob top
glass and the work top surface with silicone sealant.
DO NOT silicone sealant under the glass hob
instead of foam seal.

_ 15
User manual LAM1741
Installation
1
1. Self adhesive seal
Worktop Hob
CONVENTIONAL INSTALLATION
1
Worktop Hob
RECESSED METHOD
1. Self adhesive seal
2. Silicone sealant
21
Fixing brackets
Installation advice :
Depending on the cabinets, the worktop thickness
and the hob positioning, it is possible for the hob
base and/or the clamp brackets to interfere with
parts of the cabinet.
If necessary cut away cabinetry and use appropriate
brackets for your installation
Typical Installation positions
Typical Installation positions
Seal
Underside of hob
Secure the hob to the worktop by means
of the brackets provided, taking the thickness
of the worktop into account.
.
30mm
40mm
50mm
4
Spire Clip
Hob
Hob
Hob
Worktop
Worktop
Worktop

16_
LAMONA Appliances
Connect to the electricity Supply
This appliance must be earthed. Only connect
to the electrical mains terminal with the power
switched off. The electrical mains terminal is live.
Follow the terminal block connection schematic.
Loose and inappropriate connections can make the
terminal overheat.
Ensure the cable clamp is correctly and
securely.
A device must be provided in the electrical
installation which allows the appliance to be
disconnected from the mains at all poles with a
contact opening of at least 3mm.
We recommend that the appliance is connected
by a competent person who is a member of a
“Competent Person Scheme” who will comply with
the required local regulations.
Connection should be made with a suitable cable.
Ensure that you route all mains electrical
cables well away from any adjacent heat source,
such as an oven or grill.
Firstly open the terminal block cover using a small
bladed screwdriver in the door release tabs
shown.
Strip the wires & connect to the terminal block as
shown in the terminal block schematic.
Fit the cable clamp & secure with the screw
provided.
Close the terminal box, ensuring that the cover is
closed and all screws are tight and in place.
Note; The cable clamp has a ratchet type
mechanism on the right hand side of the retaining
arm.
Installation
Door release tab
Cable clamp screw
Cable clamp ratchet
1
2
3
1
2
3
4
5
Live
Neutral
Earth
4
5
BROWN / L1
BLUE / N
GREEN/YELLOW / PE
230V.....240V
Terminal Block Connection
Schematic

_ 17
User manual LAM1741
Technical data
Technical Data
Electrical Supply 220~240V 50Hz
Total Power Rating @ 220 - 240V
~ 50Hz (kW) 5.8 kW
Hob Details
Cook Zone Normal Power
Rating kW
LH Front 2.1
LH Rear 1.2
RH Rear 1.8
RH Front 1.2
Hob Dimensions (W X D X H) mm 590 x 520
Cut Out Required (W x D) mm 560 x 490
Cable Type HORR-F5 4.0mm ², 3 core or equivalent
Installation
This appliance conforms to European Directive 2009/125/EC regarding Eco design
requirements for energy-related products

18_
LAMONA Appliances
07 - Your guarantee
Product Guarantee Details (UK only)
<RXUDSSOLDQFHKDVWKHEHQHÀWRIDFRPSUHKHQVLYHPDQXIDFWXUHU·VJXDUDQWHHZKLFKFRYHUVWKHFRVWRI
breakdown repairs. (Details of which are shown on your Proof of Purchase Document).
Any claim during the period of the guarantee (MUST BE ACCOMPANIED BY THE PROOF OF PURCHASE)
The product must be correctly installed and operated in accordance with the manufacturer’s
instructions and used for normal domestic purposes.
This guarantee does not cover accidental damage, misuse or alternations which are likely to affect the
product.
The guarantee is invalid if the product is tampered with, or repaired by any unauthorised person.
(The guarantee in no way affects your statutory or legal rights)
What to do if you need to report a problem-
Please ensure you have ready:
 7KHSURGXFW·VPRGHOVHULDOQXPEHUV
 Howdens Proof of Purchase document
 Your full contact details
Call the Service Line on 0845 00 60 006
Your guarantee

_ 19
User manual LAM1741
Model LAM1741
Type of hob Ceramic
Noof cookingzones 4
HeaƟngtechnology Ceramic
ႇ
FL - 220mm
RL - 150mm
FR - 150mm
RR - 190mm
EC
electriccooking
FL -158Wh/kg
RL - 184Wh/kg
FR -215.5Wh/kg
RR -216.5Wh/kg
EC
electrichob
193.5Wh/kg
CommissionRegulaƟon (EU) No 66/2014
Product InformaƟon

20_
LAMONA Appliances
Notes
