Lamona LAM3675 Guide

Instructions and Installation
LAM3675
Built-In Single Split Cavity Oven
www.howdens.com/appliance-registration

See back page for product serial number

www.howdens.com
Page _ 3
LAMONA Appliances
Dear Customer,
Congratulations on your choice of oven.
The user manual will help you use your product quickly and safely.
Please read this user manual before installing and using the oven.
Always follow the safety instructions.
Keep this user manual within easy reach for future reference.
Please read any other documents supplied with the product.
Explanation of symbols
Throughout this user manual the following symbols are used:
Important information or useful tips about usage.
Warning for possible hazards to health and property.
Warning possibility of electric shock.
This appliance is marked according to the European directive 2012/19/EU on Waste
Electrical and Electronic Equipment (WEEE). WEEE contains both polluting substances
(which can cause negative consequences for the environment) and basic components
(which can be re-used). It is important to have WEEE subjected to specific treatments, in
order to remove and dispose properly all pollutants, and recover and recycle all materials.
Individuals can play an important role in ensuring that WEEE does not become an
environmental issue; it is essential to follow some basic rules:
• WEEE shall not be treated as household waste.
• WEEE shall be handed over to the relevant collection points managed by the municipality or by
registered companies.
• WEEE can be recycled free of charge.
Product information correct at the time of publication in February 2019.
The company has a policy of continuous product development and reserves the right to change
any products and specifications given in this manual.

Exclusive to Howdens Joinery.co Page _ 4
Index
User manual LAM3675
Before using the oven
General
Safety for children
Safety when working with electricity
Safety and cleaning
Shelf positions
General information
Oven layout
Control panel layout
Accessories
Operating modes
Oven functions
Preparation
First cleaning of appliance
Initial heating
Tips for energy saving
How to operate the main oven & grill
Operating a single oven
How to operate the grill
Cooking table
Oven cooking tables
Grill cooking tables
Cooking and baking advice
Telescopic runner system
General
Safety
How to place wire trays
Care and maintenance
Care and maintenance
General information
Cleaning the oven door
Removal of the oven door
Removal of the inner door glass
Replacing the oven lamp
Cleaning the inside of the oven
Installation
Before installation
Electrical connections
Cooling fan
Technical specification
Trouble shooting
Your guarantee
05
05
05
08
08
09
10
10
10
10
11
11
14
14
14
14
15
15
23
25
25
27
27
29
29
29
29
29
30
30
30
30
31
31
32
33
33
34
35
36
37
38

LAMONA Appliances
www.howdens.com
Page _ 5
Safety for children
• Make sure that you have removed all packaging, wrappings, stickers and films from the oven’s
surface.
• It is recommended that you clean and wash the oven’s surface before using for the first time (page 12)
Before using the oven
General
•This appliance is for
domestic cooking purposes
only. It must not be used for
other purposes, e.g room heat-
ing, or drying towels and dish
cloths over the handle. Com-
mercial use will void the guar-
antee (see guarantee page).
• The manufacturer shall not
be liable for any damage
caused by improper use or
handling errors.
• This product is not intended
to be used by persons with
physical, sensory or mental
disorders or unlearned or
inexperienced people (including
children) unless they are super-
vised by a person who will be
responsible for their safety or
who will instruct them accord-
ingly in the use of the product.
• Children must be super-
vised to prevent them from
playing with the product.
• Electrical products can be
dangerous to children. Keep
children away from the product
when it is operating and do not
allow them to play with or near
the product.
• CAUTION: Accessible parts
of the oven may become hot
when the oven or grill is in use.
Children should be kept away
until the product has cooled
down.”
• Do not store any items
above the appliance that chil-
dren may reach for.
• When the door is open, do
not load any heavy object on it
and do not allow children to sit
on it. The door or door hinges
may be damaged.
• The packaging materials
will be dangerous for children.
Keep the packaging materials
away from children. Please
dispose of all parts of the pack-
aging according to environmen-
tal standards.

Exclusive to Howdens Joinery.co Page _ 6
User manual LAM3675
• Accessible parts may
become hot during use. To
avoid burns, children less than
8 years of age should be kept
away unless continuously
supervised.
• This appliance can be used
by children aged 8 years and
above, persons with reduced
physical, sensory or mental
capabilities or lack of experi-
ence and knowledge, if they
have been given supervision or
instruction concerning use of
the appliance in a safe way and
understand the hazards
involved.
• Cleaning and user mainte-
nance must not be made by
children without supervision.
• Connect the product to an
earthed outlet protected by a
fuse of suitable capacity as
stated in the “Technical specifi
cations” table. Our company
shall not be liable for any prob-
lems arising due to the product
not being earthed in accord-
ance with the local regulations.
• Do not operate the product
if the power cable is damaged.
Replace with a suitable cable
by a qualified person.
• Do not operate the product
if it is defective or has any
visible damage.
• Do not carry out any repairs
or modfications to the product.
• Never wash down the
product with excessive water,
as there is the risk of electric
shock!
• Never use the product
when your judgment or coordi-
nation is impaired by the use of
alcohol and/or drugs.
• Product must be discon-
nected from the mains during
installation, maintenance,
cleaning and repair proce-
dures.
• Repair procedures must
always be performed by quali-
fied persons. The manufacturer
shall not be held responsible
for damages arising from
procedures carried out by
unauthorised persons, which
may also void the guarantee.
• Be careful when using
alcoholic drinks in your dishes.
Alcohol evaporates at high
temperatures and may ignite
when it comes into contact with
hot surfaces.

www.howdens.com
Page _ 7
LAMONA Appliances
• Do not heat closed tins and
glass jars in the oven. The
pressure that would build-up in
the tin/jar may cause it to
burst.
• Do not place any materials
close to the product as the
sides may become hot during
use.
• WARNING FIRE RISK -
Do not place aluminium foil,
baking trays or cook on the
base of this oven, doing so will
cause permanent damage to
your appliance and cabinetry
with the potential risk of fire.
• Parts of the oven may
become hot during or immedi-
ately after use. Care should be
taken to avoid touching the
heating elements, and compo-
nents inside the oven which
maybe hot. Always allow oven
to cool.
• If the door seal is very dirty
this can prevent the door from
closing properly during use,
resulting in possible damage to
adjacent furniture and poor
efficiency. Always ensure the
door seal is clean.
• Product may become hot
when it is in use. Please be
careful not to touch these hot
surfaces.
• Always use heat resistant
oven gloves when putting
dishes in or removing dishes
from the hot oven.
• Do not use the product if
any door glass is removed or
damaged.
• Rear surface of the oven
may get hot when it is in use.
Make sure that the electrical
connections do not contact the
rear surface; otherwise, con-
nections may be damaged.
• Do not trap the mains cable
and do not route it over hot
surfaces. The cable insulation
may melt and cause a short
circuit.
• Product must be installed
by a qualified person in accord-
ance with the regulations in
force. Otherwise, the guarantee
may become void.
• When hot and cold air
meet, condensation can form.
The outer door is air cooled and
the inner glass will become hot
during cooking, therefore some
condensation might form. This
is perfectly normal. All conden-
sation will disappear as the
oven reaches cooking tempera-
ture.

• Do not use harsh abra-
sive cleaners or sharp metal
scrapers to clean the oven door
since they can scratch the
surface, which may result in the
shattering of the glass.
•WARNING Ensure that
the appliance is switched off
before replacing the lamp to
avoid the possibility of an
electric shock.
• Do not use oven light for
household room illumination.
• Do not use steam clean-
ers for cleaning.
• The appliance must not be
installed behind a decorative
door.
User manual LAM3675
Exclusive to Howdens Joinery.co Page _ 8
Safety when working with
electricity
Safety and cleaning
• Make sure that the product
control knobs are switched off
after every use.
• Any work on electrical
equipment and systems should
only be carried out by author-
ised or qualified persons.
• In case of any damage,
switch off the product and
disconnect it from the mains.
To do this, turn off at the fuse
box.
• The appliance must be
installed so that it can be
completely disconnected from
the mains easily after installa-
tion by the isolation switch.
• Do not bend or trap cable
against hot surfaces during
install.
• Make sure that fuse rating
is compatible with the product.
• Do not switch the oven
off at the mains isolation
switch immediately after
cooking. Cooling fan contin-
ues to run for up to 20-30
minutes (approx) even after
the oven control is turned off.
• Keep all ventilation slots
clear of obstructions, as this
may cause premature failure of
the oven element.
• Do not allow the oven to
cool with the door open. Even if
the appliances door is only
open a little, front panels of
adjacent units could become
damaged over time.
i
i

Placing the wire shelf and tray
onto the wire racks properly
It is important to place the wire
shelf and/or tray onto the rack
properly. Slide the wire shelf or
tray between 2 rails and make
sure that it is balanced before
placing food on it (Please see
the following figure).
www.howdens.com
Page _ 9
LAMONA Appliances
Shelf positions
The oven has 6 shelf positions,
3 of which are in the the upper
section, and 3 in the lower
section. There is also a rack
gap in the centre for the middle
section plate to be installed.
Do not use centre rack (A) for
placing other shelves or trays
during cooking. It is important
to position the wire shelf
runners correctly before placing
items on the shelf. Do not
insert them forcefully.

Exclusive to Howdens Joinery.co Page _ 10
User manual LAM3675
General information
Control panel layout
Oven layout
Accessories
1. Control panel
2. Handle
3. Front door
4. Shelf positions
5. Middle section plate
6. Lamp
7. Top heating element
8. Top section fan
9. Bottom section fan
1. Function display
2. Current time indicator
3. Temperature indicator
4. Start/stop
5. Time and setting
6. Confirmation
7. Up/down
8. Temperature/booster
9. Function selection
10. Oven section selection
11. On/off
1
11 10 9 8 7 7 6 5 4
2 3
Standard tray / grill pan Grill pan wire rack / trivet Wire grill / (x2 included)
