Lamona LAM3501 Troubleshooting guide

User & Installation Guide
LAM3501
LAM3502
Built in Electric Oven
(Side Opening)

02_
LAMONA Appliances
Dear Customer,
Congratulations on your choice of oven which has been designed to give you excellent service.
The user manual will help you use your product quickly and safely.
 Please read this user manual before installing and using the oven.
 Always follow the safety instructions.
 Keep this user manual within easy reach for future reference.
 Please read any other documents supplied with the product.
Explanation of symbols
Throughout this user manual the following symbols are used:
Important information or useful tips about usage.
Warning for possible hazards to health and property.
Warning possibility of electric shock.
This product’s packaging material is recyclable. Help recycle it and protect the environment
by dropping it off in the municipal receptacles provided for this purpose. Your product also
contains a great amount of recyclable material. It is marked with this label to indicate
the used appliances that should not be mixed with other waste. This way, the appliance
recycling organised by your manufacturer will be done under the best possible conditions,
in compliance with European Directive 2002/96/EC on Waste Electrical and Electronic
Equipment. Contact your town hall or your retailer for the used appliance collection points
closest to your home. We thank you doing your part to protect the environment.

_ 03
User manual LAM3501 / LAM3502
Index
Index
01 - Before using the oven 05
General 06
Safety for children 07
Safety when working with electricity 07
03 - General information 08
Oven layout 08
Control panel layout 08
Accessories 08
04 - Preparation 09
First cleaning of the appliance 09
Initial heating 09
Tips for energy saving 09
05 - Operation modes 10
Operating modes 10
06 - How to operate the main oven 11
Select a temperature and operating mode 11
How to use the oven 11
How to use the grill 11
Shelf positions 11
Switch off the oven 11
07 - How to operate the timer 12
How to operate the oven timer 12
Switch on fully automatic operation 12
Switch on semi-automatic operation 12
Interrupting the cooking process 13
How to activate the program lock 13
Deactivate the program lock 13
How to use the minute minder 13
Switching off the alarm 13
08 - Cooking and baking advice 14
09 - Cooking tables 15
Oven cooking table 15
Grill cooking table 16
10 - Care and maintenance 17
General information 17
Cleaning the control panel 17
Cleaning the door and removing-
the inner glass 17
Replacing the oven Lamp 18
11 - Installation 19
Before installation 19
Installation and connection 20
Connection to the mains supply 20
Cooling Fan 21
22
13 - Troubleshooting 23
14 - Your Guarantee 24
Important safety information 05

04_
LAMONA Appliances

_ 05
User manual LAM3501 / LAM3502
tThis appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capa-bilities or
lack of experience and knowledge if they have been given supervision
or instruction concern-ing use of the appliance in a safe way and
understand the hazards involved.
Children shall not play with the appliance. Cleaning and user mainte -
nance shall not be made by children without supervision.
tThe appliance and its accessible parts become hot during use. Care
should be taken to avoid touching heating elements. Children less
than 8 years of age shall be kept away unless continuously
super-vised.
tDo not use steam cleaners to clean the appliance as this may cause an
electric shock.
-
ons”.
tIf the power connection cable for the product is damaged, it must be
persons in order to avoid a hazard.
tDuring use the appliance becomes hot. Care should be taken to avoid
touching heating elements inside the oven.
tThe appliance must be installed so that it can be completely
discon-nected from the network. The separation must be provided
-
lation, according to construction regulations.
tAccessible parts may become hot during use. Young children should
be kept away.
tDo not use harsh abrasive clean-ers or sharp metal scrapers to clean
the oven door glass since they can scratch the surface, which may
result in shattering of the glass.
tRear surface of the oven gets hot when it is in use. Make sure that the
gas/electrical connection does not contact the rear surface; other -
wise, connections can get damaged.
t&OTVre that the appliance is swit fore replacing the lamp to
avoid the possibility of electric shock.
Important instructions and warnings for safety and environment

06_
LAMONA Appliances
Before Using the oven
01 - Before using the Oven
 Make sure that you have removed all packaging, wrappings, stickers and from the oven’s
surface.
 It is recommended that you clean and wash the oven’s surface before using for the time.
This appliance is for domestic cooking
purposes only. It must not be used for other
purposes, for example room heating, or drying
towels and dish cloths. Commercial use will void
the guarantee.
The manufacturer shall not be liable for any damage
caused by improper use or handling errors.
General
This product is not intended to be used by persons
with physical, sensory or mental disorders or
unlearned or inexperienced people (including
children) unless they are supervised by a person
who will be responsible for their safety or who will
instruct them accordingly in the use of the product.
Children must be supervised to prevent them from
tampering with the product.
 Connect the product to an earthed outlet
protected by a fuse of suitable capacity
as stated in the “Technical
table. Our company shall not be liable for
any problems arising due to the product not
being earthed in accordance with the local
regulations.
 Do not operate the product if the power cable
is damaged. Call service agent.
 Do not operate the product if it is defective or
has any visible damage.
 Do not carry out any repairs or
on the product. However, you may remedy
issues that do not require any repairs or
See Troubleshooting, later in
this booklet
 Never wash down the product with excessive
water, as there is the risk of electric shock!
 Never use the product when your judgment or
coordination is impaired by the use of alcohol
and/or drugs.
 Product must be disconnected from the mains
during installation, maintenance, cleaning and
repair procedures.
 Repair procedures must always be performed
by service agents. The manufacturer
shall not be held responsible for damages
arising from procedures carried out by
unauthorised persons, which may also void
the guarantee.
 Be careful when using alcoholic drinks in
your dishes. Alcohol evaporates at high
temperatures and may cause since it can
ignite when it comes into contact with hot
surfaces.
 Do not heat closed tins and glass jars in the
oven. The pressure that would build-up in the
tin/jar may cause it to burst.
 Do not place any materials close
to the product as the sides may become hot
during use.
 Do not place baking trays, dishes or aluminium
foil directly onto the bottom of the oven. The
heat accumulation might damage the oven
and it’s enamel surfaces.
 Keep all ventilation slots clear of obstructions,
as this may cause premature failure of the
oven element.
 Parts of the appliance may become hot during
or immediately after use. Care should be
taken to avoid touching the heating elements,
and components inside the oven which maybe
hot. Always allow time for the oven
to cool.
 WARNING FIRE RISK -
Do not place aluminium foil, baking trays
or cook on the base of this oven, doing so
will cause permanent damage to your
appliance and cabinetry with the potential

_ 07
User manual LAM3501 / LAM3502
Safety
 Do not allow the oven to cool with the door
open. Even if the oven door is only open a
little, front panels of adjacent units could
become damaged over time.
 If the door seal is very dirty this can prevent
the door from closing properly during use,
resulting in possible damage to adjacent

the door seal is clean.
 Product may become hot when it is in use.
Please be careful not to touch these hot
surfaces.
 Always use heat resistant oven gloves when
putting dishes in or removing dishes from the
hot oven.
 Do not use the product if any door glass is
removed or damaged.
 Rear surface of the oven may get hot when
it is in use. Make sure that the electrical
connections do not contact the rear surface;
otherwise, connections may be damaged.
 Do not trap the mains cable and do not route
it over hot surfaces. The cable insulation may

circuit.
 Make sure that the product function knobs are
switched off after every use.
 When hot and cold air meet, condensation
can form. The outer door is air cooled and the
inner glass will become hot during cooking,
therefore some condensation might form.
This is perfectly normal. All condensation
will disappear as the oven reaches cooking
temperature.
 
in accordance with the regulations in force.
Otherwise, the guarantee may become void.
Safety for children
Electrical products can be dangerous to children.
Keep children away from the product when it is
operating and do not allow them to play with or near
the product.
“CAUTION: accessible parts of the oven may
become hot when the oven or grill is in use. Children
should be kept away until the product has cooled

Do not store any items above the appliance that
children may reach for.
When the door is open, do not load any heavy object
on it and do not allow children to sit on it. The door
or door hinges may be damaged.
The packaging materials will be dangerous for
children. Keep the packaging materials away
from children. Please dispose of all parts of the
packaging according to environmental standards.
Safety when working with
electricity
Any work on electrical equipment and systems
should only be carried out by authorised and

In case of any damage, switch off the product and
disconnect it from the mains. To do this, turn off the
fuse at the fuse box.
Make sure that fuse rating is compatible with the
product.
Do not switch the oven off at the mains
isolation switch immediately after cooking.
Cooling fan continues to run for up to 20-30
minutes (approx) even after the oven control is
turned off.

08_
LAMONA Appliances
a. Control panel
b. Handle
c. Oven Door
03 - General Information
d. Grill heating element
e. Light
f. Oven shelf positions
g. Heating element and fan
