1.0 INTRODUCTION
1.1 General Introduction
1.2 About SOLOnet Digital Thermometers
This publication provides the necessary information required to safely operate
the Land SOLOnet digital thermometer. This manual should be used in
conjunction with the other publications of the Land SOLOnet series
(Thermometer Quick-Start Guide - PP305 / Thermometer Installation Guide -
PP308 / Mountings and Accessories Installation Guide - PP310).
It is important to fully check all equipment with which you have been supplied.
The equipment must only be used, maintained and serviced by suitably trained
personnel, capable of carefully following the procedures and guidelines given in
this User Guide and associated literature.
All Land SOLOnet literature should be read thoroughly before proceeding with
any operations detailed within it. It is also advisable that all supplied literature is
kept readily available, for reference when the equipment is in general use.
Land SOLOnet is a compact, web browser enabled infrared thermometer system
offering the user maximum flexibility and connectivity. There are several different
thermometer types with choice of operating wavelength, optical variants, laser
alignment and measurement ranges to suit applications within the operating
range of 200 to 1750°C/392 to 3182°F.
307001
Fig. 1 - Land SOLOnet Digital Thermometer

User Guide User Guide
Page 2 PP307 Page 2 PP307
1.3 Nomenclature
The Instrument detail label is positioned at the top of the rear face of the SOLOnet
casing, adjacent to the ‘Power/Comms’ LED. The instrument ‘Type’ specifies
the thermometer variant and variant options. The instrument ‘Serial Number’ is
a unique number incorporating the manufacture date code (see Fig. 2)
Upon receipt of the instrument, check and make a note of the Instrument ‘Type’
and ‘Serial Number’ in the spaces provided below.
Instrument Type:
Serial Number:
307002
Fig. 2 - Land SOLOnet Digital Thermometer Nomenclature
SN11 - (550 to 1750°C/1022 to 3182°F, 100:1 optics, 1µm wavelength)
SN21 - (250 to 1300°C/482 to 2372°F, 100:1 optics, 1.6µm wavelength)
SN51 - (200 to 1100°C/392 to 2012°F, 50:1 optics, 5µm wavelength)
SNR1 - (700 to 1750°C/1292 to 3182°F, 100:1 optics, 1µm ratio wavelength)
Y- (Laser Alignment Option)
123456 - (Unique Instrument Serial Number) 01 - (Date Code)

User Guide User Guide
Page 3PP307 Page 3PP307
2.0 SPECIFICATIONS
2.1 SOLOnet Thermometers
Model .. SN11 SN21 SN51 SNR1 Operating range: 550 to 1750°C/ 250 to 1300°C/ 200 to 1100°C/ 700 to 1750°C/
1022 to 3182°F 482 to 2372°F 392 to 2012°F 1292 to 3182°F
Specified range: 600 to 1750°C/ 300 to 1300°C/ 250 to 1100°C/ 750 to 1750°C/
1112 to 3182°F 572 to 2372°F 482 to 2012°F 1382 to 3182°F
Spectral response: 1µm 1.6µm 5µm 1µm ratio Field of view 100:1 100:1 50:1 100:1 (95% energy): Focusing: Fixed, user configurable focus: 250mm/9.8in, 500mm/19.7in, 1000mm/39.4in and infinity Output: 0 or 4 to 20mA user selectable (isolated 50V) Response time 10ms 10ms 50ms 10ms (0 to 90%): Emissivity: 0.10 to 1.00 _ Non greyness: 0.80 to 1.25 Resolution (mid range): <1K Stability: 0.2°/° 0.2°/° 0.02%K/K 0.05K/K Accuracy (absolute): 0.3%K 2K 0.35%K 0.6%K Time functions: Peak picker, track and hold, and averager Alarm outputs: Process high, process low, internal temperature, emissivity/NG signal lost, insufficient signal (SNR1
only); rated to 50V d.c., 0.1A non-inductive, NO or NC – software selectable
Optional sighting: Laser defining optical axis; class 2, 1mW, 650nm, 120s ON duration, automatic switch-off Ambient limits: 5 to 60°C/41 to 140°F specified; 0 to 70°C/32 to 158°F operating EMC: EN 61326:1999 (immunity and emission) Sealing: IP65/NEMA 4X Vibration: 3g (10 to 300Hz) Power supply: 18 to 30V d.c. (24V d.c. nominal) Optional Air cooled/purged jacket, water cooled/air purged jacket, air purge and mounting bracket, 1-axis accessories: and 2-axis adjustable mounting brackets, 3m, 15m, 25m prewired cable assemblies,
Web/Ethernet Interface Unit SN-W/E, d.c. power supply unit, temperature indicator unit LMi

User Guide User Guide
Page 4 PP307 Page 4 PP307
2.2 SN-W/E Interface Unit
Specifications
Mounting: DIN Rail
Power Requirements: 24V d.c. nominal
Ambient Operating range: 0 to 70°C/32 to 158°F
Sealing: To IP20/NEMA1
EMC: EN 61326:1999
Wiring Details (Customer and Thermometer connections)
Pin No. Function
1 Power In (+)
2 Power In (-)
3 mA Out (+)
4 mA Out (-)
5 Emissivity In (+)
6 Emissivity In (-)
7 Laser Switch Input
8 Common (laser and command)
9 Command Switch Input
10 Relay 1a
11 Relay 1b
12 Relay 2a
13 Relay 2b
14 Comms from IRT (+) [Y]
15 Comms from IRT (-) [Z]
16 Comms to IRT (-) [B]
17 Comms to IRT (+) [A]

User Guide User Guide
Page 5PP307 Page 5PP307
3.2 Introduction to Configuration
3.0 HARDWARE CONFIGURATION REQUIREMENTS
This section of the User Guide contains additional information to that found in
the SOLOnet Installation Guide (PP308), therefore it is recommended that the
two publications be cross-referenced when installation of the system is
implemented. Associated User, Assembly and Installation Guides provided with
any system accessories should also be refered to.
The following diagrams are only intended to give a range of examples illustrating
the flexibility of SOLOnet connectivity. Should the intended application differ
from those illustrated, please contact Land Instruments for information on how
SOLOnet can be configured to suit the specific requirement.
3.2.1 Web Browser Configuration - Via Network
307003
SOLOnet Thermometer
Thermometer Cable
‘Straight’ Patch
Cable
SN-W/E Interface Unit
Network Switch
Switch set to ‘Ethernet’
Laptop/PC with ‘Java Runtime’ Installed and ‘Proxy Server’ Enabled
Fig. 3 - SOLOnet Thermometer in Web Browser Configuration - Via Network
Most users may want to configure the thermometer to suit their own particular
requirements. Land SOLOnet thermometers provide various options for
instrument configuration. This section briefly describes the schemes available,
together with the minimum hardware requirements for ‘off-line’ configuration.
Any of these schemes may also be incorporated into full installations for
‘on-line’ configuration.
At the heart of a Land SOLOnet thermometer is a powerful digital core, capable
of handling internal signal conversions, controlling and monitoring I/O and
performing various temperature time functions. Built around this core are high
quality optical and mechanical parts, accessories and robust interface electronics,
which ensure trouble-free installation and reliable operation.
3.1 General Introduction
‘Straight’ Patch Cable
External 24V d.c. Power Supply

User Guide User Guide
Page 6 PP307 Page 6 PP307
307004
SOLOnet Thermometer
Thermometer Cable
Cross-over
Ethernet Cable
SN-W/E Interface Unit
Switch set to ‘Ethernet’
Laptop/PC with ‘Java Runtime’ Installed, ‘Proxy’ Disabled and ‘Peer to Peer’ Enabled
3.2.2 Web Browser Configuration - Via Direct Connection
Fig. 4 - SOLOnet Thermometer in Web Browser Configuration
- Via Direct Connection
This scheme (‘Peer to Peer’) may be used where a network is not available.
A cross-over Ethernet cable will be required and the PC/laptop will need to be
configured for ‘Peer to Peer’ operation, as described in Appendix A and B.
The SN-W/E Interface Unit manages and converts the RS485 messaging from
the thermometer, allowing the user to configure the thermometer using standard
web browser software. Additionally, the user may modify the SN-W/E IP address
to integrate it within an organisational network.
The SN-W/E is supplied with: the ‘IP Address’ set to 10.1.10.200
the ‘Subnet Mask’ set to 255.255.0.0
It may be connected directly to a company network, providing this IP address is
not already in use. Alternatively, it may be connected to an Ethernet switch as
shown in Fig. 3. Using this method, the IP address may be changed or set to be
dynamically assigned if the intended network requires this.
External 24V d.c. Power Supply
Note
If the company network operates a ‘MAC address’ filtering system,
the MAC address must first be added to the network configuration.
Contact local network manager for details.

User Guide User Guide
Page 7PP307 Page 7PP307
307006
SOLOnet Thermometer
Thermometer Cable
4-Core Cable RS232 to RS485
Converter
SN-W/E Interface Unit
RS232 Serial Cable
4-Core Cable to
‘Customer Connections’
Pins 14 to 17
Switch set to ‘RS485’
Laptop/PC with ‘Windows Configurator Software’ Installed
3.2.4 Windows Configurator Software (SN-WCS) - Via SN-W/E
This scheme allows the user to connect a laptop or PC by RS485, to configure
a SOLOnet thermometer, via a SN-W/E interface unit. An RS232 to
4-wire RS485 converter is required and the laptop/PC requires Land Windows
Configurator software (SN-WCS) installed. An external 24V d.c. power supply
is required to power the thermometer and this is wired direct through the
thermometer cable.
Fig. 6 - SOLOnet Thermometer in Direct RS485 Configuration
3.2.3 Windows Configurator Software (SN-WCS) - Direct RS485
307005
SOLOnet Thermometer
Thermometer Cable
RS232 Serial Cable
RS232 to RS485
Converter
Laptop/PC
Laptop/PC with ‘Windows Configurator Software’ Installed
This scheme allows the user to connect a laptop or PC direct to a SOLOnet
thermometer. An RS232 to 4-wire RS485 converter is required and the
laptop/PC requires Land Windows Configurator Software (SN-WCS) installed
to allow thermometer configuration. An external 24V d.c. power supply is required
to power the thermometer and this is wired direct through the thermometer cable.
Fig. 5 - SOLOnet Thermometer Configuration by Direct RS485 using WCS
External 24V d.c. Power Supply
External 24V d.c. Power Supply
Intentionally left blank

User Guide User Guide
Page 8 PP307 Page 8 PP307
307007
SOLOnet Thermometer
Thermometer Cable
RS232 Serial Cable
RS232 to RS485
Converter
Laptop/PC Running ‘Windows XP’ O.S. with ‘Hyperterminal’ Open
3.2.5 Windows XP Hyperterminal - Direct 4-Wire RS485
This scheme is for advanced users only and allows the user to connect a laptop
or PC by RS485, to configure a SOLOnet thermometer. An RS232 to
4-wire RS485 converter is required and the laptop/PC requires Windows 98/
2000/XP operating system, with the ‘Hyperterminal’ utility opened. An external
24V d.c. power supply is required to power the thermometer and this is wired
direct through the thermometer cable.
With this method of configuration, only addresses 1 to 127 are accessible. The
addresses above 127 are available, but the relevant characters are hidden and
require the use of a utilities programme (such as ‘Procomm Plus’) to allow them
to become visible and therefore useable.
Fig. 7 - SOLOnet Thermometer Configuration Via Windows XP Hyperterminal
External 24V d.c. Power Supply
