Landmann Avalon User instructions

Assembly and operating manual
Version: 12791 GB
reVision: #035-2012
edition: 06/11 Ut


Please read before
assembling and using!
Failure to observe these instructions can
affect or damage the device and other
objects and lead to personal injury.
We therefore recommend that you read
the relevant chapter of these instruc-
tions prior to assembly and before each
use. Follow the steps in the order they
are specified and please observe the
safety warnings.
These instructions form part of the prod-
uct. They should therefore always be
stored with the product and passed on
to each subsequent user.

1
2
3
3
4
4
4
5
7
8
9
10
11
12
6
13
14
15
14
16
20
21
22
23
24
19
13
18
19
18
17
BA
BB
C

12791
A x1 26x
B M5x8 2x
C M6x12 12x D M6x65 8x
E AA / 1,5V 1x

DIN EN 498 (Oktober 2009)
18.10.2011

5
12791
Table of contents
Delivery specifications.............................................................................................................................. 6
Operational Elements............................................................................................................................... 6
Gas connection elements ......................................................................................................................... 6
Function..................................................................................................................................................... 7
Utilisation .................................................................................................................................................. 7
Correct usage ........................................................................................................................................................ 7
Incorrect usage...................................................................................................................................................... 7
Guarantee claims and warranty .............................................................................................................. 7
Safety instructions.................................................................................................................................... 7
Definition of instructions used............................................................................................................................. 7
General safety precautions................................................................................................................................... 8
Residual risks ......................................................................................................................................................... 8
Assembly ................................................................................................................................................. 10
Connecting and disconnecting the gas cylinder................................................................................... 10
Parts and tools needed ....................................................................................................................................... 10
Before starting .................................................................................................................................................... 10
Connecting the gas cylinder............................................................................................................................... 11
Disconnecting the gas cylinder .......................................................................................................................... 11
Operation ................................................................................................................................................ 12
Starting up the barbecue ................................................................................................................................... 12
Igniting the burners............................................................................................................................................ 12
Switching off the barbecue................................................................................................................................ 13
Cleaning................................................................................................................................................... 14
Barbecue.............................................................................................................................................................. 14
Gas system ........................................................................................................................................................... 14
Maintenance............................................................................................................................................ 14
Barbecue.............................................................................................................................................................. 14
Gas system ........................................................................................................................................................... 14
Battery ................................................................................................................................................................. 14
Environmental information and disposal measures............................................................................. 14
Troubleshooting...................................................................................................................................... 15
Specifications .......................................................................................................................................... 16
Accessories (optional)............................................................................................................................. 16

612791
Controls
Pos. * Designation Function
A Electronic
pulse igniter
Ignites the gas that
flows into the burner
when the flame regula-
tor (B or C) is open.
B Flame regu-
lator for the
grill unit
Feeds gas into the burner
on the grill unit (press,
set to "large flame"
and keep depressed).
After ignition, adjust
the heat input for each
burner side (turn).
C Flame regu-
lator for the
side burner
Feeds gas into the
side burner (press, set
to "large flame" and
keep depressed).
After ignition, set
heat input (turn).
* see fold-out page
Delivery specifications
Pos. * Qty. Designation
1 1 Warming rack
2 1 Hotplate
3 2 Cooking grill
4 3 Flame tamer
5 1 Grill unit (pre-assembled)
6 1 Side burner adjusting ele-
ment with gas hose (pre-
assembled on grill unit)
7 1 Side burner
8 1 Side burner insert
9 1 Side burner support
10 1 Side burner table with electronic
pulse ignition (pre-assembled)
11 1 Control knob cap
12 1 Control knob for side burn-
er adjusting element
13 2 Upright (rear right, front left)
14 2 Upright (rear left, front right)
15 1 Cross bar
16 1 Front panel
17 1 Gas cylinder retaining bar
18 2 Caster
19 2 Caster with holding brake
20 1 Cart base
21 1 Gas cylinder storage
22 1 Base shelf
23 1 Drip pan holder
24 1 Drip pan
1Screw card with assembly material
* see fold-out page
Gas connection elements
Pos. * Designation Function
G0 Gas cylinder Fuel container
G1 Cylinder
valve
Cut off safety device;
open gas supply (turn
anti-clockwise) and
close (turn clockwise).
G2 Cylinder
valve thread
Gas cylinder - pressure
regulator connection
G3 Coupling
nut pressure
regulator
Connect the pressure regu-
lator to the gas cylinder
(turn anti-clockwise) and
disconnect (turn clockwise).
G4 Pressure
regulator
Reduce gas pressure.
G5 Pressure
regulator
connection
Pressure regulator - gas
hose connection
G6 Hose clip Attach the pressure regula-
tor - gas hose connection
G7 Gas hose Direct gas to burner.
* see fold-out page

7
12791
Safety instructions
Definition of terms used
The following pictograms and signal words are used
in these instructions to point out hazards and impor-
tant information.
Safety instructions
Pictogram and
signal word Note on ...
Danger
... a possible danger that can
result in severe personal inju-
ry or damage to property if
the stated measures are not
observed.
Caution
... a possible danger that can
result in damage to property if
the specified measures are not
observed.
Operating notes
Pictogram Note on ...
... a useful function or tip.
!
... Danger of confusion; the sym-
bol points to an easily visible
part of the component.
Function
When the cylinder valve (G1) and flame regulators (B
or C) are open, the gas flows through the gas hose
(G7) into the burner assigned to the the flame regu-
lator.
When the electronic pulse igniter (A) is actuated a
spark is emitted from the spark plugs on the burners
(grill unit and side burner) that then ignites the gas.
The gas supply (= heat output) for the respective
burner can be regulated and interrupted by using the
flame regulators (B or C).
Utilisation
Proper use
This is a gas barbecue that is intended for outdoor
use only. Intended use means only using the barbe-
cue to prepare barbecue food, while observing and
complying with all of the instructions in this manual.
This barbecue is only intended for private use.
Improper use
Any other use or application extending beyond the
intended purpose is not permitted. This applies in
particular to the following methods of improper use:
• Do not operate the barbecue with coal or fuel
other than liquid gas (propane/butane).
• Do not use the barbecue as a heating appliance.
• Do not use the barbecue to heat materials and
substances other than food that is suitable for
barbecuing.
• Only use the side burner as a stove for pots and
pans.
Guarantee claims and warranty
Your Landmann barbecue left the factory in a techni-
cally flawless condition.
In addition to your statutory warranty claims, Land-
mann therefore also provides an extended 5 year
quality and durability warranty against rusting
through of the cover and rusting through or burning
through of the cooking grills and hotplate.
Any warranty and guarantee claims shall become
void in the event of improper use of the barbecue or
the use of non-approved fuels. Discolouration, rust-
ing or slight deformation of parts exposed directly
to the flames (cooking grill, hotplate, burner, burner
cover etc.) do not impair the function of the barbe-
cue and, as such, do not form a basis for any claims.
Please retain your receipt in case you need to make a
warranty claim.

812791
Residual risks
Danger: Hot surfaces and parts
During operation some parts of the barbecue can
get very hot, particularly those near the burner.
Possible consequences:
• Severe burns from touching parts near the
burners.
• Fire or smoldering fire if flammable materials
or substances are near the barbecue.
Safety measures prior to using the barbecue:
• When setting up the barbecue, make sure that
• there are not, and will not be, any flammable
materials or substances nearby. Minimum dis-
tance to flammable materials or substances: 2
m above and 1 m to the side. Distance to less
flammable materials or substances, e.g. walls:
min. 0.25 m.
–the barbecue is positioned firmly on a suf-
ficiently large surface area. Secure the bar-
becue against rolling away by applying the
parking brakes on the two right rollers. The
barbecue must not be moved during opera-
tion.
Safety measures while barbecuing:
• Wear protective barbecue gloves.
• Never leave the barbecue unattended. Take
particular care to ensure that children and
pets are kept away from the barbecue.
General Safety Precautions
Failure to observe the following basic safety meas-
ures can cause severe injury to persons and substan-
tial damage to property:
• Use the barbecue exclusively for the intended pur-
pose .
• Never use the barbecue despite obvious damage.
• Never modify the barbecue's technology. Use only
original spare parts from LANDMANN.
• Use only accessories that are expressly authorised
for this barbecue (see the "Accessories" chapter;
if in doubt please contact our customer service
department).
• Only use the barbecue outdoors in a well venti-
lated area and above ground (i.e. not in areas that
are below ground level).
• Never leave the barbecue unattended when in
use. Take particular care to ensure that children
and persons with physical or mental disabilities
keep well away from the barbecue. They may not
be able to identify the dangers correctly.
• Always wear barbecue mittens when using the
barbecue.
• Small parts may be lethal if swallowed. Note that
there is a danger of suffocation if the respiratory
tract is covered by packing foil.
• Do not place heavy loads on the barbecue. In par-
ticular, observe the maximum weight loads in the
Technical Specifications.
• The electronic pulse ignition system is powered by
a battery. Observe the following during assembly:
–Old batteries can leak. Acid escaping from the
battery can damage the barbecue and cause
acid burns in case of skin contact. For this rea-
son, make sure that you wear acid-resistant
gloves when removing a leaky battery.
–Never recharge batteries and never expose bat-
teries to high temperatures as this causes a risk
of explosion.

9
12791
Danger: Gas is highly flammable
Liquid gas is highly flammable and explosive.
Possible consequences:
• Serious injury to persons or damage to prop-
erty if escaping or accumulated gas ignites in
an uncontrolled manner.
Safety measures:
• Only use the barbecue outdoors and ensure
that the area is well-ventilated.
• Protect the gas cylinder and the gas hose from
direct sunlight and other sources of heat (max.
50°C). Take particular care to ensure that the
gas hose does not touch any part of the hot
barbecue.
• Close the valve on the gas cylinder immediate-
ly when you finish using the barbecue.
• When connecting the gas cylinder make sure
that there are no sources of ignition within a
5 m radius.
• Take special care not to light any naked flames,
do not smoke or switch on electric appliances
(devices, lights, door bells), etc. (spark-over
possible).
• Before each use, make sure that all gas con-
nections are sealed and intact.
• If necessary, ensure that you replace the gas
hose if required to do so to comply local leg-
islation.
The barbecue must not be used if the connec-
tions for the gas supply are porous or faulty.
This also applies, for example, to hoses or fit-
tings that are blocked with insects, as this can
result in a dangerous flashback.
• When igniting the gas flame do not bend over
the cooking area or the side burner, as defla-
gration can occur if gas has accumulated in the
fire bowl.
For the same reason, never re-ignite immedi-
ately if the flame goes out, instead:
–Turn the flame regulators (3 x B and C) to
"Off" to interrupt the supply of gas.
–Wait for 3 minutes to ensure that any accu-
mulated gas has dissipated.
–Then re-ignite the burners (see the chapter
"Operations").
Danger: Gas displaces oxygen
Liquid gas is heavier than oxygen. Therefore it
settles on the ground and displaces the oxygen
at that level.
Possible consequences:
• Suffocation resulting from a lack of oxygen if
the concentration of gas is allowed to rise suf-
ficiently.
Safety measures:
• Only use the barbecue outdoors in a well ven-
tilated area and above ground (i.e. not in are-
as that are below ground level).
• Close the valve on the gas cylinder immediate-
ly when you finish using the barbecue.
• If the barbecue is not being used for a pro-
longed period, cut off the supply from the gas
cylinder and store properly:
–Fit the gas cylinder valve with a cap nut and
safety cap.
–Do not store the gas cylinder in rooms
below ground level, in or near stairways,
hallways or passages and thoroughfares
between buildings.
–Always store gas cylinders upright, even if
they are empty!
