Lane 59909-059-1X User manual

MADE IN VIET NAM
DESCRIPTION QTY
A
PART
Page 1 of 3
B
1
DRAWING
1
ASSEMBLY INSTRUCTIONS
Customer Service Contact Information:
Toll Free Phone Number: 1-844-771-2727
Email: [email protected]
Website: www.lanefurniture.com
NOTES:
1.CHECK CAREFULLY FOR SMALL PARTS WHICH MAY COME LOOSE DURING SHIPMENT.
2.REMOVE ALL COMPONENTS FROM THE PACK AND PLACE ON A CLEAN, SOFT SURFACE TO ASSEMBLE.
3.UNITS SHOULD BE ASSEMBLED BY TWO OR MORE PEOPLE.
4.DO NOT OVER -TIGHTEN SCREW/ BOLTS UNTIL ASSEMBLY IS COMPLETED.
5.WITH USE, SCREW MAY BE COME LOOSE & MUST BE TIGHTENED PERIODICALLY.
SEAT
LEFT BACKREST
PART LIST
DESCRIPTION QTY
E
PART
F
1
DRAWING
1
LEFT WING
C1
MIDDLE BACKREST
COMPLETED SOFA - DUAL POWER - RECLINING ASSEMBLY
RIGHT WING
ITEM # 59909-059-1X/2X/1MX
SOFA - DUAL POWER - RECLINING
G1
PLUG
D1
RIGHT BACKREST H1 TRANSFORMER

MADE IN VIET NAM
Page 2 of 3
ASSEMBLY INSTRUCTIONS
Customer Service Contact Information:
Toll Free Phone Number: 1-844-771-2727
Email: [email protected]
Website: www.lanefurniture.com
NOTES:
1.CHECK CAREFULLY FOR SMALL PARTS WHICH MAY COME LOOSE DURING SHIPMENT.
2.REMOVE ALL COMPONENTS FROM THE PACK AND PLACE ON A CLEAN, SOFT SURFACE TO ASSEMBLE.
3.UNITS SHOULD BE ASSEMBLED BY TWO OR MORE PEOPLE.
4.DO NOT OVER -TIGHTEN SCREW/ BOLTS UNTIL ASSEMBLY IS COMPLETED.
5.WITH USE, SCREW MAY BE COME LOOSE & MUST BE TIGHTENED PERIODICALLY.
THE PARTS ARE LOCATED INSIDE THE BOX AS BELOW:
WINGS ARE STORED
UNDER METAL FRAME
E
F
A
BCD
A
TRANSFORMER & PLUG
STORED IN PAPER BOX
ITEM # 59909-059-1X/2X/1MX
SOFA - DUAL POWER - RECLINING

STEP 1
STEP 2
MADE IN VIET NAM
Page 3 of 3
ASSEMBLY INSTRUCTIONS
Important:
1. Attach the Backrest (B/C/D) to the Seat (A).
2. Attach the Left/Right Wings (E/F) to the Left/Right side of the Backrest (B/D).
Important:
1. Connect the power wire under the Armrest frame to the power source through
out the Transformer (H) and The Plug (G).
2. Open the footrest or move the headrest by pressing the power button on/off.
ASSEMBLY COMPLETED
A
EBC
DF
G
H
ITEM # 59909-059-1X/2X/1MX
SOFA - DUAL POWER - RECLINING
