Langer & Laumann Otis 6970 User manual

1
User manual
Otis 6970 door operator
with
TSG door operator

2
document history
no.
ver.
date
worker
1
1.0
30.01.08
CSA
2
1.1
06.02.08
CSA
3
1.2
26.11.15
JE
4
1.3
30.12.19
CSA
Fordern Sie die Umbauanleitung auf Deutsch an,
indem Sie den QR Code einscannen.
Langer & Laumann Ing.-Büro GmbH
Wilmsberger Weg 8
48565 Steinfurt
Germany
Telephone: [phone]
Email: [e-mail]
Web: www.LuL-Ing.de
© 2019 Langer & Laumann Ingenieurbüro GmbH All rights reserved
These operating instructions and the product described therein are copyright protected for Langer & Lau-
mann Ingenieurbüro GmbH or its suppliers, with all rights reserved. In accordance with this copyright these
operating instructions may not be copied either in part or in their entirety without the written authorisation of
Langer & Laumann Ingenieurbüro GmbH unless within the framework of normal use of the product or to
create backup copies. This exceptional provision does not extend to include copies, which are created for
third parties and sold to or in any other way conveyed to same. Nevertheless, the entire, acquired material
(including all backup copies) can be sold to, handed over to or made available on a loan basis to such par-
ties. In accordance with the provisions of the law, the production of a translation similarly falls under the defi-
nition of copying.
Langer & Laumann Ingenieurbüro GmbH does not accept any warranty or guarantee for the content
of these operating instructions, and similarly declines any legal guarantee in respect of marketability
or suitability for a specific purpose. Langer & Laumann Ingenieurbüro GmbH is not liable for errors in
these operating instructions or for consequential or direct damage in conjunction with the delivery, perfor-
mance or use of these operating instructions. Langer & Laumann Ingenieurbüro GmbH reserves the right
to occasionally revise these operating instructions and change their content without prior notification.
file: 1.20.92250_Umbauanleitung_Otis_6970_auf_TSG_V1.3_en.docx
date of print: 12/30/2019 8:55:00 AM

3
table of contents:
1Basic Instructions ___________________________________________________________________ 4
1.1 Status of the Installation Instructions ________________________________________________ 4
1.2 Copyright______________________________________________________________________ 4
1.3 Instructions in the Installation Manual________________________________________________ 4
1.4 Informal Measures by the Fitter ____________________________________________________ 4
1.5 Requirements of Installation Personnel ______________________________________________ 4
1.6 Description of Symbols ___________________________________________________________ 5
2Procedure_________________________________________________________________________ 6
3Advantages________________________________________________________________________ 6
4Required Tools _____________________________________________________________________ 6
5Conversion instructions ______________________________________________________________ 7
6Parts list __________________________________________________________________________ 8
7Figures ___________________________________________________________________________ 9
7.1 Technical figures _______________________________________________________________ 12
8Contact __________________________________________________________________________ 14

4
1 Basic Instructions
1.1 Status of the Installation Instructions
Product installation instructions are enclosed by the manufacturer or supplier in order to provide the custom-
er or fitter with the essential knowledge necessary for correct and safe installation. These brief installation
instructions are intended to clarify basic mechanical installation steps and to illustrate the principal differ-
ences between the door operator versions for telescopic 2-panel and central 2-panel. Electrical connection,
commissioning and adjustment of the door control unit are expressly not components of these instructions.
1.2 Copyright
We reserve all rights pertaining to these technical documents. It is prohibited to reproduce them, make them
available to third parties or to use them in any other unauthorised manner without our prior agreement.
Changes require our express prior and written agreement.
1.3 Instructions in the Installation Manual
All instructions in the installation manual absolutely must be adhered to.
1.4 Informal Measures by the Fitter
The fitter installing the system is him/herself responsible for participating in training. He/she must immediate-
ly inform the manufacturer/supplier of missing or damaged delivered parts.
1.5 Requirements of Installation Personnel
Persons responsible for installation and maintenance should be familiar with the generally applicable safety
and work-hygiene regulations. They should be familiar with Langer & Laumann products. Installation tools
are to be properly functional and measuring instruments must be subject to continuous checks.

5
1.6 Description of Symbols
WARNING:
This sign is to indicate a possible impeding danger of serious physical damage or death.
CAUTION:
This sign is to indicate a possible impending danger of light physical damage. This sign is also
to warn you of material damage.
NOTE:
You will be informed of various possible applications and will receive further useful sugges-
tions.

6
2 Procedure
Replacement of an Otis 6970 door operator with a Langer & Laumann Ing. Büro GmbH TSG door
operator (TSG).
3 Advantages
-A very competitively priced package.
-Simple and quick replacement of a defective control unit and motor with a Langer & Laumann
Ing. Büro GmbH door operator (TSG).
-Few mechanised parts required.
-All required parts are included in the delivery
-The conversion can be carried out very quickly and simply.
-The electrical wiring can be carried out even by fitters with little experience
-No hand-held terminal is required for programming. All parameters can simply be set on the de-
vice.
-Easy calibration.
-The conversion kit is stored in the Langer & Laumann Ing. Büro GmbH as astock item.
4 Required Tools
Drilling machine
Metal drills 9, 11mm
Open ended spanners SW10, 13, 17, 19, 24
Screw driver
Wire cutting pliers
Spirit level

7
5 Conversion instructions
1. Please remove all parts from the packaging and check you have all the required parts according to
the parts list.
2. Remove old drive motor and selector of old door operator (Caution: do not remove the old buffers,
you will need them).
3. Remove long lever with attached counterweight up to pivot point.
4. Mount TSG drive on the combi-bracket.
5. Mount the TSG roller on the second combi-bracket.
6. Mount the TSG coupler on the fast panel. Caution: do not drill into the trailer wheel track!
7. Mount combi-bracket with TSG drive under the door bar. Caution: the combi-bracket has to be
mounted as far outside as possible. So the panel can open completely and the clamp for the toothed
belt does not touch the toothed wheel on the TSG drive.
8. Mount combi-bracket with TSG roller. Caution: the panels have to be opened and closed completely.
Ensure the clamp for the toothed belt does not touch the toothed wheel on the TSG drive. The
alignment of the motor pulley and divertor pulley is important; please make sure that the alignment is
correct and in line!
9. Mount TSG end stoppers on the combi-brackets and adjust to approximate position.
10. Test the movement of the panels. If necessary correct the position of the mechanical components.
11. Fit the toothed belt, connect to the belt clamp and tighten with the tension device on the combi-
bracket carrying the idler pulley.
12. Mount the big plate on door operator using the old holes and buffers. Mount the plate horizontal and
in good order!
13. Connect new lever with axis and screw on big plate. Mount the lever horizontal and in good order!
14. The length of the lever has to fit on the clearance of the door. Close the door and close the coupler
(perhaps with a lace or something else). Hold the new lever on the existing lever and make a mark,
then drill a hole. After that connect both levers so that they can pivot. If the big lever is too long cut it.
15. Carry out final adjustment of the buffers.
16. Please refer to the TSG instruction manual enclosed for information regarding the set-up of the elec-
trics.

8
6 Parts list
Tabelle 1: parts list
pos.
Item number
Description
Quantity
1
1.20.92200
Mechanical parts Otis 6970
1
2
Accessories
3
Miscellaneous bolts /washers / nuts
4
8.20.00100
TSG circuit board in TSG casing (waterproof IP54)
1
5
8.20.40000
Motor large left version gearbox
24V/2,8A/1:15
1
6
1.20.92250
User manual Otis 6970 Umbau
1
7
1.20.91000
TSG manual
1

9
7 Figures
Abb. 1: Otis 6970 pre-conversion

10
Abb. 2: Otis 6970 post-conversion
Abb. 3: Otis 6970 post-conversion: Idler pulley side

11
Abb. 4: Otis 6970 post-conversion: drive side

12
7.1 Technical figures
Abb. 5: View from above
Abb. 6: View from side

13
Abb. 7: View from the front

14
8 Contact
You can reach us at the following address with any questions or queries:
Langer & Laumann Ing.-Büro GmbH
Wilmsberger Weg 8
48565 Steinfurt
Germany
Telephone: [phone]
Email: [e-mail]
Web: www.LuL-Ing.de
