Lanner LUNA-D125 User manual

LUNA-D125
User Manual
Version:1.3
Date of Release:2021-01-12
Network Appliance
Platform

2
Icon Descriptions
The icons are used in the manual to serve as an indication of interest topics or important messages. Below
is a description of these icons:
Note: This mark indicates that there is a note of interest and is something that you should pay
special attention to while using the product.
Warning: This mark indicates that there is a caution or warning and it is something that could
damage your property or product.
Online Resources
The listed websites are links to the online product information and technical support.
Copyright and Trademarks
This document is copyrighted © 2020 by Lanner Electronics Inc. All rights are reserved. The original
manufacturer reserves the right to make improvements to the products described in this manual at any time
without notice.
No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means
without the prior written permission of the original manufacturer. Information provided in this manual is
intended to be accurate and reliable. However, the original manufacturer assumes no responsibility for its
use, nor for any infringements upon the rights of third parties that may result from such use.
Acknowledgment
Intel® and Intel® Atom® are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other
countries.
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Resources
URL
Lanner
http://www.lannerinc.com
Product Resource
http://www.lannerinc.com/download-center
RMA
http://eRMA.lannerinc.com

3
Compliances and Certification
FCC Class A Certification
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Notice
(1) A Unshielded-type power cord is required in order to meet FCC emission limits and also to prevent
interference to the nearby radio and television reception. It is essential that only the supplied power cord
be used.
(2) Use only shielded cables to connect I/O devices to this equipment.
(3) Changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
Safety Guidelines
Follow these guidelines to ensure general safety:
Keep the chassis area clear and dust-free during and after installation.
Do not wear loose clothing or jewelry that could get caught in the chassis. Fasten your tie or scarf and
roll up your sleeves.
Wear safety glasses if you are working under any conditions that might be hazardous to your eyes.
Do not perform any action that creates a potential hazard to people or makes the equipment unsafe.
Disconnect all power by turning off the power and unplugging the power cord before installing or
removing a chassis or working near power supplies
Do not work alone if potentially hazardous conditions exist.
Never assume that power is disconnected from a circuit; always check the circuit.

4
Consignes de sécurité
Suivez ces consignes pour assurer la sécurité générale :
Laissez la zone du châssis propre et sans poussière pendant et après l’installation.
Ne portez pas de vêtements amples ou de bijoux qui pourraient être pris dans le châssis. Attachez votre
cravate ou écharpe et remontez vos manches.
Portez des lunettes de sécurité pour protéger vos yeux.
N’effectuez aucune action qui pourrait créer un danger pour d’autres ou rendre l’équipement dangereux.
Coupez complètement l’alimentation en éteignant l’alimentation et en débranchant le cordon
d’alimentation avant d’installer ou de retirer un châssis ou de travailler à proximité de sources
d’alimentation.
Ne travaillez pas seul si des conditions dangereuses sont présentes.
Ne considérez jamais que l’alimentation est coupée d’un circuit, vérifiez toujours le circuit. Cet appareil
génère, utilise et émet une énergie radiofréquence et, s’il n’est pas installé et utilisé conformément aux
instructions des fournisseurs de composants sans fil, il risque de provoquer des interférences dans les
communications radio.
Lithium Battery Caution:
There is risk of Explosion if Battery is replaced by an incorrect type.
Dispose of used batteries according to the instructions.
Installation only by a trained electrician or only by an electrically trained person who knows all Installation
and Device Specifications which are to be applied.
Do not carry the handle of power supplies when moving to another place.
Please conform to your local laws and regulations regarding safe disposal of lithium BATTERY.
Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery can result in
an explosion.
Leaving a battery in an extremely high temperature surrounding environment can result in an explosion
or the leakage of flammable liquid or gas.
A battery subjected to extremely low air pressure that may result in an explosion or the leakage of
flammable liquid or gas.
Electrical equipment generates heat. Ambient air temperature may not be adequate to cool equipment
to acceptable operating temperatures without adequate circulation. Be sure that the room in which you
choose to operate your system has adequate air circulation.
Ensure that the chassis cover is secure. The chassis design allows cooling air to circulate effectively. An
open chassis permits air leaks, which may interrupt and redirect the flow of cooling air from internal
components.
Electrostatic discharge (ESD) can damage equipment and impair electrical circuitry. ESD damage occurs

5
when electronic components are improperly handled and can result in complete or intermittent failures.
Be sure to follow ESD-prevention procedures when removing and replacing components to avoid these
problems.
Wear an ESD-preventive wrist strap, ensuring that it makes good skin contact. If no wrist strap is available,
ground yourself by touching the metal part of the chassis.
Periodically check the resistance value of the antistatic strap, which should be between 1 and 10
megohms (Mohms).
Environment:
Do not install and/or operate this unit in any place that flammable objects are stored or used in.
If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack
environment may be greater than room ambient. Therefore, consideration should be given to installing
the equipment in an environment compatible with the maximum ambient temperature (Tma) specified
by the manufacturer.
Installation of the equipment (especially in a rack) should consider the ventilation of the system’s intake
(for taking chilled air) and exhaust (for emitting hot air) openings so that the amount of air flow required
for safe operation of the equipment is not compromised.
To avoid a hazardous load condition, be sure the mechanical loading is even when mounting.
Consideration should be given to the connection of the equipment to the supply circuit and the effect
that overloading of the circuits might have on over-current protection and supply wiring. Appropriate
consideration of equipment nameplate ratings should be used when addressing this concern.
Reliable earthing should be maintained. Particular attention should be given to supply connections other
than direct connections to the branch circuit (e.g., use of power strips).
Installation & Operation:
The installation of this product must be performed by trained specialists; otherwise, a non-specialist
might create the risk of the system’s falling to the ground or other damages.
Lanner Electronics Inc. shall not be held liable for any losses resulting from insufficient strength for
supporting the system or use of inappropriate installation components.
Avertissement concernant la pile au lithium
Risque d’explosion si la pile est remplacée par une autre d’un mauvais type.
Jetez les piles usagées conformément aux instructions.
L’installation doit être effectuée par un électricien formé ou une personne formée à l’électricité
connaissant toutes les spécifications d’installation et d’appareil du produit.
Ne transportez pas l’unité en la tenant par le câble d’alimentation lorsque vous déplacez l’appareil.
La machine ne peut être utilisée qu’à un lieu fixe comme en laboratoire, salle d’ordinateurs ou salle de
classe.

6
Sécurité de fonctionnement
L’équipement électrique génère de la chaleur. La température ambiante peut ne pas être adéquate pour
refroidir l’équipement à une température de fonctionnement acceptable sans circulation adaptée. Vérifiez
que votre site propose une circulation d’air adéquate.
Vérifiez que le couvercle du châssis est bien fixé. La conception du châssis permet à l’air de
refroidissement de bien circuler. Un châssis ouvert laisse l’air s’échapper, ce qui peut interrompre et
rediriger le flux d’air frais destiné aux composants internes.
Les décharges électrostatiques (ESD) peuvent endommager l’équipement et gêner les circuits électriques.
Des dégâts d’ESD surviennent lorsque des composants électroniques sont mal manipulés et peuvent
causer des pannes totales ou intermittentes. Suivez les procédures de prévention d’ESD lors du retrait et
du remplacement de composants.
Portez un bracelet anti-ESD et veillez à ce qu’il soit bien au contact de la peau. Si aucun bracelet n’est
disponible, reliez votre corps àla terre en touchant la partie métallique du châssis.
Vérifiez régulièrement la valeur de résistance du bracelet antistatique, qui doit être comprise entre 1 et
10 mégohms (Mohms).
Grounding Procedure for DC
Power Source
Loosen the screw of the earthing point.
Connect the grounding cable to the ground.
The protection device for the DC power source must
provide 30 A current.
This protection device must be connected to the power
source before DC power
Electrical Safety Instructions
Before turning on the device, ground the grounding cable of the equipment.
Proper grounding (grounding) is very important to protect the equipment against the harmful effects of
external noise and to reduce the risk of electrocution in the event of a lightning strike.
To uninstall the equipment, disconnect the ground wire after turning off the power.
A ground wire is required and the part connecting the conductor must be greater than 4 mm2 or 10
AWG.

7
Procédure de mise à la terre
pour source d’alimentation
CC
Desserrez la vis du terminal de mise àla terre.
Branchez le câble de mise à la terre à la terre.
L’appareil de protection pour la source d’alimentation
CC doit fournir 30 A de courant.
Cet appareil de protection doit être branché àla source
d’alimentation avant l’alimentation CC.
Consignes de sécurité électrique
Avant d’allumer l’appareil, reliez le câble de mise à la terre de l’équipement à la terre.
Une bonne mise à la terre (connexion à la terre) est très importante pour protéger l’équipement contre
les effets néfastes du bruit externe et réduire les risques d’électrocution en cas de foudre.
Pour désinstaller l’équipement, débranchez le câble de mise à la terre après avoir éteint l’appareil.
Un câble de mise à la terre est requis et la zone reliant les sections du conducteur doit faire plus de 4
mm2 ou 10 AWG.
Suitable for installation in Information Technology Rooms in accordance with Article 645 of the National
Electrical Code and NFPA 75.
Peut être installé dans des salles de matériel de traitement de l'information conformément àl'article 645
du
National Electrical Code et à la NFPA 75.
The machine can only be used in a restricted access location, such as labs or computer facilities with the
proper authorization.
Les matériels sont destinés àêtre installés dans des EMPLACEMENTS À ACCÈS RESTREINT.
This equipment must be grounded. The power cord for product should
be connected to a socket-outlet with earthing connection.

8
Table of Contents
Package Content.........................................................................................................................10
Ordering Information .................................................................................................................11
Optional Accessories ..................................................................................................................11
System Specifications.................................................................................................................12
Front Panel .................................................................................................................................13
Rear Panel...................................................................................................................................14
Block Diagram.............................................................................................................................15
Motherboard Layout ..................................................................................................................16
Opening the Chassis ...................................................................................................................20
Replacing the System Memory...................................................................................................21
Installing LTE Kit (M.2 LTE Card with Antenna)..........................................................................23
Installing Wi-Fi Kit (Mini PCIe Wi-Fi Card with Antenna) ...........................................................27
WiFi/LTE Cable Routing Example ...............................................................................................31
Rackmounting the System (with the Adapter Holder)...............................................................32
Main Setup .................................................................................................................................35
Advanced Setup..........................................................................................................................37
Security Setup.............................................................................................................................91
Save & Exit Setup........................................................................................................................97

9
Warranty Policy ........................................................................................................................100
RMA Service..............................................................................................................................100
RMA Service Request Form......................................................................................................101

Chapter 1: Product Overview
10
LUNA-D125 series is an Intel Rangeley (ATOM) based system desktop platform, based on 2-Core CPU with
4x GbE ports. This system is targeted at low cost desktop with ECC DDR3L Memory support.
Package Content
Your package contains the following items:
1x LUNA-D125 Network Security Platform
1x Power cord
1x 36W power adaptor
1x Nameplate
4x Rubber foot
LUNA-D125
Power Cable
Name Plate
Rubber
Foot
Power Adapter

Chapter 1: Product Overview
11
Ordering Information
SKU No.
Main Features
LUNA-D125A
Intel® Atom® C2316, 4x GbE, Intel® QuickAssist Technology
Note: If any component should be missing or damaged, please contact your dealer immediately
for assistance.
Optional Accessories
Model Name
Description
mini-PCIe Wifi Kit
1x mini-PCIe card + 2x Antennas + Accessories
M.2 3042 (B key) LTE Kit
1x M.2 card + 2x Antennas + Accessories
Rackmount Kit
2x Mounting Ears + Accessories
Adapter holder Kit
1x Adapter Holder Bracket

Chapter 1: Product Overview
12
System Specifications
Form Factor
Desktop
Platform
Processor Options
Intel® Atom® C2316 (Rangeley)
CPU Socket
Onboard
Chipset
SoC
Security Acceleration
Intel® QuickAssist Technology
BIOS
AMI SPI Flash BIOS
System Memory
Technology
DDR3L 1333MHz non-ECC SODIMM
Max. Capacity
16 GB
Socket
1x 204-pin SODIMM
Networking
Ethernet Ports
4x GbE RJ45
Bypass
N/A
NIC Module Slot
N/A
LOM
IO Interface
N/A
OPMA slot
N/A
I/O Interface
Reset Button
1
LED
Power/Status/Storage
2x LED per GbE ports
Power Button
1
Console
1x RJ45
USB
2x USB 2.0
LCD Module
N/A
Display
N/A
Power input
1x DC Jack
Storage
HDD/SSD Support
N/A
Onboard Slots
8GB onboard storage, 1 x M.2 2242 (SATAIII)
Expansion
mini-PCIe
1x mini PCIe Connector
(Support PCIe x1 signal)
M.2
1x M.2 2242 B key socket (SATAIII signal)
1x M.2 3042 B key socket
(PCIE/USB2.0/UIM )
SIM card Slot
1x Nano SIM Card Connector for one of the
3042 M.2 slots
Antenna hole
4x Antenna hole
Miscellaneous
Watchdog
Yes
Internal RTC with Li Battery
Yes
TPM
Infineon SLB9665
Cooling
Processor
Thermal Pad
System
Fanless
Environmental Parameters
Temperature
0~40ºC Operating
-20~70ºC Non-Operating
Humidity (RH)
5~90% Operating
5~ 95% Non-Operating
System Dimensions
(WxDxH)
185 x 44 x 137 mm
Weight
1.0 kg
Package Dimensions
(WxDxH)
290 x 196 x 106 mm
Weight
1.3 kg
Power
Type/Watts
12V 3A 36W Power Adapter
Input
AC 100~240V @47~63 Hz
Approvals and Compliance
RoHS, CE, FCC Class B, UL

Chapter 1: Product Overview
13
Front Panel
No.
Description
F1
SIM Slot
For 1x Nano SIM card
F2
Data Connection
LED Indicators
F3
System LED
Indicators
Note: Please refer to Appendix A: LED Indicator Explanations for descriptions of the LED
Indicators
F1
6
F2
6
F3
6
System Power
System Status
HDD Activity
Data Speed
Data Link
LAN Port
4 3 2 1

Chapter 1: Product Overview
14
Rear Panel
No.
Description
R1
Antenna Port
4x Antennas (from left to right LTEWi-fiWi-fiLTE)
R2
Power Button
Push to power on/off the system
R3
DC-in Jack
For power supply
R4
Reset Button
Press to perform a system reset
R5
Console Port
1x RJ45 console port
R6
USB Ports
2x USB 2.0 port
R7
GbE Ports
4x RJ45 port with LED (LAN1 for PXE Boot)
R2
R1
R7
R3
R5
R6
R4

Chapter 2: Motherboard Information
15
Block Diagram
The block diagram indicates how data flows among components on the motherboard. Please refer to the
following figure for your motherboard’s layout design.

Chapter 2: Motherboard Information
16
Motherboard Layout
The motherboard layout shows the connectors and jumpers on the board. Refer to the following picture as
a reference of the pin assignments and the internal connectors.

Chapter 2: Motherboard Information
17
Jumper/Connector
Description
LAN1~LAN4
RJ45 GbE ports
USB1
Standard USB2.0 Type-A Connector
COM1
RJ45 Console Debug Port
DC_IN1
DC2.5V power supply
DIMM1
DDR3L 204-pin SO-DIMM Slot
BZ1
Buzzer
MPCIE1
Mini-PCIe Slot
SIM1
Nano SIM Slot
M.2_SSD
M.2 2242 B-Key Socket, supporting SATA III signal for SSD module.
M.2_WWAN
M.2 3042 B-Key Socket, supporting PCIe x 1 and USB2.0 signal with a
SIM card for the 4G module.
BT1
3.3V RTC battery holder
CPU_FAN1
Reserved 4-pin system fan connector
LED1
System LED indicator
LED11,14,15,16
LAN_LED RJ45 Port data transmission status
SW2
Power button
SW1
Reset button
SPIROM1
Reserved BIOS Debug port
LPC1
Reserved LPC Debug port
CSAE_OPEN
Case-open pin header
JBAT1
Clear CMOS Jumper
Setting
Mode
1-2
Normal (Default)
2-3
Clear CMOS
AT_ATX
Configures the automatic power-on function
Setting
Mode
1-2
Auto power-on (AT)
2-3
Normal (ATX_default)
J2
Hardware/Software Reset Jumper
Setting
Mode
1-2
SW Reset (Default)
2-3
HW Reset
J4
Flash BIOS ROM selection jumper
Pin
Mode
1-2
Normal mode (Default)
2-3
Flash. Bios mode

Chapter 2: Motherboard Information
18
JP/CN
pin#
Signal
Remark
SPIROM1
1
SPI_
HOL
D0_L
SPI_HOLD0_L
2
Dum
my
net
Dummy net
3
SPI_A
VN_C
S0_J_
N
SPI_AVN_CS0_J_N
4
V_3P
3_SPI
V_3P3_SPI
5
PMU
_AVN
_SPI_
MISO
PMU_AVN_SPI_MIS
O
6
Dum
my
net
Dummy net
7
Dum
my
net
Dummy net
8
PMU
_AVN
_SPI_
R_CL
K
PMU_AVN_SPI_R_C
LK
9
GND
GND
10
PMU
_AVN
_SPI_
R_M
OSI
PMU_AVN_SPI_R_M
OSI
JP/CN
pin#
Signal
Remark
J4
1-2
Normal mode
default jumper 1-2
2-3
Flash bios mode
JP/CN
pin#
Signal
Remark
AT_ATX
1-2
AT mode
default jumper 2-3
2-3
ATX mode
JP/CN
pin#
Signal
Remark
J2
1
RST_FP_BTN#_SIO
1-2: SW reset(default)
2-3: HW reset
2
RST_FP_BTN#
3
RST_FP_BTN#_R_SO
C
JP/CN
pin#
Signal
Remark
JBAT1
1
1-2: Normal (Default)
2-3: Clear CMOS
2
AVN_RTEST_N
3
GND

Chapter 3: Hardware Setup
19
To reduce the risk of personal injury, electric shock, or damage to the equipment, please remove all power
connections to completely shut down the device. Also, please wear ESD protection gloves when conducting
the steps described hereafter.

Chapter 3: Hardware Setup
20
Opening the Chassis
1. Loosen the four screws (indicated in the photos) that fix this unit’s side panels.
2. Loosen the screw that fixes the SIM Slot cover, and then pull open the bottom panel.
