Lanta Nebula Blizzard v3 User guide

Owner Handbook
Nebula Blizzard v3™
Snow Machine
L69500 Nebula Blizzard v3.indd 1 14/07/2016 09:47

© Lanta Lighting™ 2016. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
July 2016 - Version 1
Nebula Blizzard v3™ Owner Handbook
For your Safety
• Follow all instructions to maintain Manufacturer Warranty and for your own safety.
• There are no user replacement parts inside the product. Do not open the product for
any reason. This will invalidate your Manufacturer Warranty and may impair the safety
features of the product.
• All Lanta products designed for indoor use. Under no circumstances must these
products be used outdoors unless the product specification specifically defines the
product as being water resistant.
• Do not expose this product to moisture, rain or other fluids.
• Do not use if the product if you suspect it has been damaged in any way, including
being dropped, is malfunctioning, or has been exposed to liquids or moisture. The unit must
be repaired by an authorised service centre only. Manufacturer Warranty is void if the unit is
opened or adapted in any way. Operator safety may be compromised if this product is not
operated and maintained in accordance with the details contained in this Owner Handbook.
• This appliance must be earthed. Do not remove the earth connection in the plug or any
other location- it is essential for user safety.
• Be aware that products are mains powered and may be capable of producing high
voltages from its outputs and has mains voltages inside the cabinet.
Product Installation, Use & Maintenance
• Keep this Owner Handbook safe for future reference.
• Clean the product with a clean and dry, non-abrasive cloth. Do not use solvents or
liquids to clean the product.
• To prevent overheating, do not obstruct any ventilation opening, fan cover or vent. Do
not install near any sources of heat such as radiators, heaters or other heat producing
items such as amplifiers, power units etc.
• Never lift, move or carry the product by any other means other than the case as a
whole or handle if provided.
• Power connection to the product is via a UK 240 Volt AC three-pin mains plug. Do not
remove or adapt this plug. If necessary, only replace the plug top fuse with one of the
same type, size and value.
• The mains lead must not be crushed or damaged. If any damage occurs, disconnect
from the mains immediately. Replace the damaged cable, or if the mains lead is
captive, return the product to an authorised repair centre for cable replacement. Do
not attempt to repair the cable - it must be discarded and destroyed.
• To maintain the Manufacturer Warranty, only attach authorised accessories and external
devices. This includes cables, connectors and other electrical and/or mechanical devices.
• Unplug the product from the mains during lightning storms or periods of mains
fluctuations. If the product is going to be unused for long periods, unplug from the mains.
L69500 Nebula Blizzard v3.indd 2 14/07/2016 09:47

© Lanta Lighting™ 2016. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
July 2016 - Version 1
Nebula Blizzard v3™ Owner Handbook
Product Quality & Compliance
Products from Lanta Lighting meet all required safety standards in force at the time of
manufacture and are fully compliant with them.
Unpacking & Inspection
• Inspect the packaging before opening. If the packaging appears to have sustained
significant damage, please take extra care before using the product. If you are in any
doubt, consult a suitably qualified professional.
• If you suspect the product has been damaged, do not use it. Return it to your original
supplier without delay.
• Keep all packaging in a safe place for storage or transportation in future.
Manufacturer Warranty
• This Manufacturer Warranty is valid in the UK only.
• Lanta Lighting warrants that this product is free from workmanship defects and material
failure during normal use and operation for a 12 month period from original date of
sale, providing all of the terms indicated in the warranty section have been fully
complied with. Please refer to your suppliers T&C’s for warranty details.
• Expressly excluded is our liability for any directly connected or indirectly connected item
or items or any consequential loss associated with the failure of the product however
caused.
• If the product has been opened, modified, tampered with, incorrectly connected,
used inappropriately or in conflict with the instructions herein, or the product model
or serial number has been damaged, removed, tampered with, obliterated or made
partly unreadable by any person or persons, the Manufacturer Warranty is irrevocably
null and void.
• No extension, adaption, alteration or modification to the terms of this Manufacturer
Warranty will be permitted, unless expressly authorised in writing (excluding email and
fax) by a Director of Lanta Lighting. Warranty is transferrable during the Warranty period.
For Further Information about Lanta Lighting
Our website can be found at www.lantalighting.com and is available for the benefit
of customers worldwide. Please consult for information, advice and support on this and
other high quality products from Lanta.
L69500 Nebula Blizzard v3.indd 3 14/07/2016 09:47

© Lanta Lighting™ 2016. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
July 2016 - Version 1
Nebula Blizzard v3™ Owner Handbook
IMPORTANT!
Battery Operated Products
Some Lanta products include an internal battery for portable use. These batteries are
high energy rechargeable devices and for safety and product performance purposes
these batteries have a permanent connection between the appliance and the battery.
The batteries are constructed from Lithium Ion materials, a much safer product than
older generation primary Lithium batteries. Great care must be exercised when handling
and disposing of these batteries and they must only be accessed and/or serviced by an
authorised Lanta service centre.
DO NOT ATTEMPT TO ACCESS, MODIFY OR DISPOSE OF THE BATTERY!
End of life disposal of the product and/or the battery must not be disposed
in domestic rubbish or other non-specific recycling centre.
Only disposal sites that fully conform to the requirements of the EU Battery
Directive are permitted to recycle these products and batteries.
Please visit www.gov.uk for further information.
About Lanta Lighting™
Based in the UK, Lanta are committed to providing high quality products at cost-effective
prices to the professional lighting market. Since the first product was launched in 2006,
Lanta has established a reputation for reliability, common sense design and customer
support that has become the envy of others. All Lanta products are specifically designed
for UK operation and are optimized for 240VAC 50Hz UK mains power.
The Lanta Lighting range includes:-
Professional Lighting
Focussing on the use of LED technology, Lanta offer distinctive lighting effects for install
and mobile applications. From washes to floods, spots to projectors, LED technology now
outperforms traditional lights while at the same time requiring significantly lower power
and generating far less unwanted heat.
Atmospheric Effects
When you need special atmospheric effects, Lanta have everything from bubble
machines to fake snow, hazers and foggers. There’s also a range of fluids and consumables
specially designed to get the best from the range.
Control Gear
Lightweight and portable, Lanta Control Gear is robust enough to survive life on the road
and smart enough to control DMX kit whatever the venue.
Visit us at www.lantalighting.com for more details.
L69500 Nebula Blizzard v3.indd 4 14/07/2016 09:47

© Lanta Lighting™ 2016. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
July 2016 - Version 1
Nebula Blizzard v3™ Owner Handbook
INSIDE THE BOX
• 1 x Nebula Blizzard v3™
• IEC Power Cable
• Wireless Remote Control
• Wired Remote Receiver
SPECIFICATIONS
Model Number L69500
Power
Fuse Rating
800w
F5A
Control Wireless Remote
Output 30m²
Construction Plastic
Power Requirement 240V AC 50/60Hz
Tank Capacity 1 Litre
Dimensions (mm) 240 x 360 x 225
Getting to know your Lanta Product
The portable and compact Nebula Blizzard™; is the ideal companion for anyone who
needs to launch an avalanche of foamy snow at a moment’s notice. Mount at floor level
and you have a blanket of ground cover. Fix to truss or a lighting bar and create your own
foam party with foam falling over the audience. A screw-top 1 litre tank holds Lanta Snow
Fluid (available separately) securely enough to prevent accidental spills from knocks and
bangs.
360mm
225mm
240mm
L69500 Nebula Blizzard v3.indd 5 14/07/2016 09:47

© Lanta Lighting™ 2016. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
July 2016 - Version 1
Nebula Blizzard v3™ Owner Handbook
Nebula Blizzard V3™
The LANTA Nebula Blizzard v3 must be mounted on a firm, level surface or suspended
from a stable truss using the supplied bracket and suitable truss coupler. It must not be
used on an unstable, unlevel surface. Ensure there is adequate ventilation around the
product. It must only be used horizontally, do not tilt or operate on an incline when using
fluid, as this may spill out and damage the product and invalidate the warranty. Ensure
that the snow is not directed at someone’s face. NB. This is an indoor rated product. Do
NOT use outdoors.
L69500 Nebula Blizzard v3.indd 6 14/07/2016 09:47

© Lanta Lighting™ 2016. Terms Apply. All trademarks are the property of their
respective owners. E&OE. All specifications and details are correct at time of print.
July 2016 - Version 1
Nebula Blizzard v3™ Owner Handbook
Nebula Blizzard V3™
HOW TO OPERATE
1. Remove the tank bottle cap and fill with Lanta Snow Fluid (sold separately).
1. Do NOT overfill.
2. Replace the tank cap securely.
3. Plug in the Wireless Receiver unit.
4. Plug in IEC Power Cable.
5. Plug into Mains and switch on.
6. Operate the machine using the Wireless Remote Control.
IMPORTANT: Do not run the machine without fluid as it will damage the unit.
REMOTE CONTROL
The wireless remote has 4 button controls:
BUTTON A: Stops the machine
BUTTON B: Starts the Machine
BUTTON C: Stops the machine
BUTTON D: Starts the Machine
TROUBLESHOOTING
If you experience low output, pump noise, or no output at all, unplug immediately and
do the following:
1. Check the fluid level, the external fuse, the remote connection and main power supply.
If all appear OK, plug the unit in again.
2. If the machine operates, but snow does not come out after 5 seconds, switch off and
check the hose going into the tank to make sure there is fluid going into the hose.
3. If you are unable to determine the cause of the problem, do not continue to operate
as this may damage the unit. Contact your supplier for support.
PRODUCT MAINTENANCE
Warning: If your Snow Machine is to be stored for an extended period, it must be flushed
before being stored otherwise fluid may thicken in the tank and block the pump. Failure
to do so will void your warranty.
After 20 hours of use, or if your machine is to be stored, purge your machine as follows:
1. Drain the unit of all fluid.
2. Fill the tank with 500ml of distilled water.
3. Run the unit until all the distilled water is consumed.
(Do not allow the pump to run dry).
4. Switch off, disconnect from the main supply and allow the sock to dry before storing.
5. For maximum life, it is highly recommended that you only use Lanta®Snow Fluid and
purge the system AT LEAST every 30 days.
Keep this User Manual for future consultation.
If you sell the product to another user, be sure that they also receive this document.
L69500 Nebula Blizzard v3.indd 7 14/07/2016 09:47
