Lantronix XPort AR User manual

Part Number 900-405
Revision C December 2006
XPort AR
User Guide

XPort AR User Guide 2
Copyright & Trademark
© 2006 Lantronix. All rights reserved. No part of the contents of this book may be
transmitted or reproduced in any form or by any means without the written permission
of Lantronix. Printed in the United States of America.
Ethernet is a trademark of XEROX Corporation. UNIX is a registered trademark of
The Open Group. Windows 95, Windows 98, Windows 2000, and Windows NT are
trademarks of Microsoft Corp. Netscape is a trademark of Netscape Communications
Corporation.
Contacts
Lantronix Corporate Headquarters
15353 Barranca Parkway
Irvine, CA 92618, USA
Phone: [phone]
Fax: [phone]
Technical Support
Phone: [phone] or 949-453-7198
Fax: [phone]
Online: www.lantronix.com/support
Sales Offices
For a current list of our domestic and international sales offices, go to the Lantronix
web site at www.lantronix.com/about/contact.
Disclaimer & Revisions
Note: This product has been designed to comply with the limits for a Class B digital
device pursuant to Part 15 of FCC and EN55022:1998 Rules when properly enclosed
and grounded. These limits are designed to provide reasonable protection against
radio interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy, and if not installed and used in accordance with
this guide, may cause interference to radio communications.
The information in this guide may change without notice. The manufacturer assumes
no responsibility for any errors that may appear in this guide.
Date Rev. Comments
6/2005 A Initial Document
11/2005 B Added V2.0 software information
12/2006 C Added V3.0 information

XPort AR User Guide 3
Contents
Figures 7
1: Using This Guide 8
Purpose and Audience _______________________________________________ 8
Summary of Chapters ________________________________________________ 8
Additional Documentation _____________________________________________ 9
2: Description and Specifications 10
Features _________________________________________________________ 10
Applications_______________________________________________________ 10
Protocol Support ___________________________________________________ 11
Evolution OS™ ____________________________________________________ 11
Additional Features _________________________________________________ 11
Modem Emulation_______________________________________________________ 11
Power over Ethernet (PoE)________________________________________________ 11
Web-Based Configuration and Troubleshooting________________________________ 12
Command-Line Interface (CLI) _____________________________________________ 12
SNMP Management _____________________________________________________ 12
XML-Based Architecture and Device Control __________________________________ 12
Rich Site Summary (RSS) ________________________________________________ 12
Enterprise-Grade Security ________________________________________________ 12
Troubleshooting Capabilities_______________________________________________ 13
Configuration Methods ______________________________________________ 13
Addresses and Port Numbers _________________________________________ 14
Hardware Address ______________________________________________________ 14
IP Address_____________________________________________________________ 14
Port Numbers __________________________________________________________ 14
Product Information Label ____________________________________________ 14
3: Using DeviceInstaller 16
Accessing XPort AR using DeviceInstaller _______________________________ 16
Viewing the XPort AR’s Current Configuration ____________________________ 16
4: Configuration Using Web Manager 18
Accessing Web Manager through a Web Browser _________________________ 18
Network Settings ___________________________________________________ 19
Network Configuration ___________________________________________________ 19

Contents
XPort AR User Guide 4
Line 1, Line 2, and Line 3 Settings _____________________________________ 21
Line 1 Configuration _____________________________________________________ 21
Line 1 Command Mode___________________________________________________ 23
Tunnel 1 and Tunnel 2 Settings________________________________________ 24
Accept Mode___________________________________________________________ 24
Packing Mode __________________________________________________________ 26
Serial Settings__________________________________________________________ 27
Connect Mode__________________________________________________________ 28
Modem Emulation_______________________________________________________ 30
Start and Stop Characters ________________________________________________ 31
Disconnect Mode _______________________________________________________ 32
AES Keys – Connect Mode _______________________________________________ 33
Protocol Stack Configuration__________________________________________ 35
Configurable Pin Manager____________________________________________ 36
CPM: Configurable Pins __________________________________________________ 36
CPM: Groups __________________________________________________________ 39
DNS Configuration__________________________________________________ 41
PPP _____________________________________________________________ 41
SNMP Configuration ________________________________________________ 43
FTP Configuration __________________________________________________ 44
TFTP Configuration_________________________________________________ 45
IP Address Filter ___________________________________________________ 45
Syslog ___________________________________________________________ 46
HTTP Settings_____________________________________________________ 47
HTTP Configuration _____________________________________________________ 48
HTTP Authentication_____________________________________________________ 50
RSS_____________________________________________________________ 51
Command Line Interface Settings______________________________________ 52
CLI Configuration _______________________________________________________ 52
Email Configuration_________________________________________________ 53
SSH Settings______________________________________________________ 56
SSH Server’s Host Keys__________________________________________________ 56
SSH Server’s Authorized Users ____________________________________________ 57
SSH Client Known Hosts _________________________________________________ 58
SSH Client User Configuration _____________________________________________ 59
SSL Settings ______________________________________________________ 60
XML Configuration__________________________________________________ 61
Import System Configuration ______________________________________________ 61

Contents
XPort AR User Guide 5
Export System Configuration ______________________________________________ 62
Filesystem Configuration_____________________________________________ 64
Query Port________________________________________________________ 66
Diagnostics Configuration ____________________________________________ 67
Hardware______________________________________________________________ 67
MIB-II Statistics_________________________________________________________ 68
IP Sockets_____________________________________________________________ 69
Ping__________________________________________________________________ 70
Traceroute_____________________________________________________________ 71
DNS Lookup ___________________________________________________________ 71
Memory_______________________________________________________________ 72
Buffer Pools____________________________________________________________ 73
Processes _____________________________________________________________ 73
System Configuration _______________________________________________ 74
5: Point-to-Point Protocol (PPP) 76
6: Tunneling 77
Connect Mode_____________________________________________________ 77
Accept Mode ______________________________________________________ 78
Disconnect Mode___________________________________________________ 79
Packing Mode _____________________________________________________ 79
Modem Emulation __________________________________________________ 80
Command Mode ________________________________________________________ 80
Serial Line Settings _________________________________________________ 81
Statistics _________________________________________________________ 82
7: SSH and SSL Security 83
Secure Shell: SSH__________________________________________________ 83
SSH Server Configuration_________________________________________________ 83
SSH Client Configuration _________________________________________________ 84
Secure Sockets Layer: SSL___________________________________________ 84
8: Using Email 86
SMTP Configuration ________________________________________________ 86
Priority Levels _____________________________________________________ 87
DNS Records______________________________________________________ 87
Extended Hello ____________________________________________________ 87
Email Statistics ____________________________________________________ 87
9: Configuration Pin Manager 89
Configurable Pins __________________________________________________ 89

Contents
XPort AR User Guide 6
CP Groups________________________________________________________ 90
10: XML 92
11: Branding the XPort AR 93
Web Manager Customization _________________________________________ 93
Command Mode ___________________________________________________ 93
12: Updating Firmware 94
Obtaining Firmware_________________________________________________ 94
Loading New Firmware ______________________________________________ 94
A: Technical Support 95
B: Binary to Hexadecimal Conversions 96
Converting Binary to Hexadecimal _____________________________________ 96
Conversion Table _______________________________________________________ 96
Scientific Calculator _____________________________________________________ 96
Compliance Information 98
Warranty 99

Contents
XPort AR User Guide 7
Figures
Figure 2-1. Sample Hardware Address................................................................................................14
Figure 2-2. Product Label....................................................................................................................15
Figure 4-1. Web Manager Home Page ................................................................................................19
Figure 4-2. Network Configuration........................................................................................................20
Figure 4-3. Line 1 Configuration...........................................................................................................22
Figure 4-4. Line 1 Command Mode......................................................................................................23
Figure 4-5. Tunnel 1.............................................................................................................................24
Figure 4-6. Tunnel 1 Accept Mode.......................................................................................................25
Figure 4-7. Tunnel 1 Packing Mode .....................................................................................................27
Figure 4-8. Tunnel 1 Serial Settings.....................................................................................................28
Figure 4-9. Tunnel 1 Connect Mode.....................................................................................................29
Figure 4-10. Tunnel 1 Modem Emulation.............................................................................................31
Figure 4-11. Tunnel 1 Start/Stop Chars ...............................................................................................32
Figure 4-12. Tunnel 1 Disconnect Mode..............................................................................................33
Figure 4-13. AES Keys – Connect........................................................................................................34
Figure 4-14. Protocol Stack..................................................................................................................35
Figure 4-15. CPM: CPs ........................................................................................................................37
Figure 4-16. CPM: Groups ...................................................................................................................39
Figure 4-17. DNS Settings....................................................................................................................41
Figure 4-18. PPP Settings....................................................................................................................42
Figure 4-19. SNMP Configuration ........................................................................................................43
Figure 4-20. FTP Configuration............................................................................................................44
Figure 4-21. TFTP Configuration..........................................................................................................45
Figure 4-22. IP Address Filter Configuration........................................................................................46
Figure 4-23. Syslog ..............................................................................................................................47
Figure 4-24. HTTP Statistics ................................................................................................................48
Figure 4-25. HTTP Configuration .........................................................................................................49
Figure 4-26. HTTP Authentication........................................................................................................50
Figure 4-27. RSS..................................................................................................................................51
Figure 4-28. Command Line Interface Statistics..................................................................................52
Figure 4-29. Command Line Interface Configuration...........................................................................53
Figure 4-30. Email Statistics.................................................................................................................54
Figure 4-31. Email Configuration..........................................................................................................55
Figure 4-32. SSH Server: Host Keys....................................................................................................56
Figure 4-33. SSH Server: Authorized Users ........................................................................................57
Figure 4-34. SSH Client: Known Hosts ................................................................................................58
Figure 4-35. SSH Client: Users............................................................................................................59
Figure 4-36. SSL...................................................................................................................................60
Figure 4-37. Import System Configuration ...........................................................................................62
Figure 4-38. Export System Configuration...........................................................................................63
Figure 4-39. Filesystem........................................................................................................................64
Figure 4-40. Filesystem Browser..........................................................................................................65
Figure 4-41. Query Port Configuration .................................................................................................67
Figure 4-42. Diagnostics: Hardware.....................................................................................................68
Figure 4-43. MIB-II Network Statistics..................................................................................................69
Figure 4-44. IP Sockets........................................................................................................................70
Figure 4-45. Diagnostics: Ping .............................................................................................................70
Figure 4-46. Diagnostics: Traceroute...................................................................................................71
Figure 4-47. Diagnostics: DNS Lookup................................................................................................72
Figure 4-48. Diagnostics: Memory........................................................................................................72
Figure 4-49. Diagnostics: Buffer Pools.................................................................................................73
Figure 4-50. Diagnostics: Processes....................................................................................................74
Figure 4-51. System .............................................................................................................................75

XPort AR User Guide 8
1: Using This Guide
Purpose and Audience
This guide provides the information needed to configure, use, and update the XPort
AR™. It is intended for software developers and system integrators who are
embedding the XPort AR in their designs.
Summary of Chapters
The remaining chapters in this guide include:
Chapter Description
2: Description and
Specifications Main features of the product and the protocols it supports.
Includes technical specifications.
3:Using DeviceInstaller Instructions for viewing the current configuration using
DeviceInstaller.
4:Configuration Using Web
Manager Instructions for accessing Web Manager and using it to
configure settings for the XPort AR.
5:Point-to-Point Protocol (PPP) Overviews PPP on the XPort AR.
6:Tunneling Information on tunneling features available on the serial
lines.
7:SSH and SSL Security Overview and configuration of SSH and SSL security
settings.
8:Using Email Information on the SMTP server and setting email
parameters on the XPort AR.
9:Configuration Pin Manager Information on the Configuration Pin Manager (CPM) and
setting the configurable pins to work with a device.
10:XML Configuring the XPort AR using XML.
11:Branding the XPort AR Instructions for customizing the XPort AR.
12:Updating Firmware Instructions for obtaining the latest firmware and updating
the XPort AR.
A: Technical Support How to contact Lantronix Technical Support.
B: Binary to Hexadecimal Instructions for converting binary values to hexadecimal and
tables listing all configuration options in hexadecimal
notation.

1: Using This Guide
XPort AR User Guide 9
Additional Documentation
The following guides are available on the product CD or the Lantronix Web site
(www.lantronix.com):
XPort AR Getting
Started Provides the steps for getting the XPort AR evaluation
board up and running.
XPort AR Integration
Guide Provides information about the XPort AR hardware,
testing the XPort AR using the evaluation board, and
integrating the XPort AR into your product.
XPort AR Command
Reference Instructions for accessing Command Mode (the
command line interface) using a Telnet connection
through the network or through the serial port. Detailed
information about the commands.

XPort AR User Guide 10
2: Description and Specifications
This chapter summarizes the XPort AR device server’s features and basic
information needed before getting started.
Features
The XPort AR is designed with additional features above and beyond the original
XPort, including:
The Evolution OS operating system
Two full serial ports with all hardware handshaking signals or three serial ports
without handshaking signals
11 configurable pins
Supports fully compliant PoE designs by using PoE compliant magnetics and
passing through both the used and unused pairs
Increased memory: 4MB Flash and 1.25MB RAM
Hardware capability in place to allow future software support for:
−I2C Bus
−SPI Bus
−CAN Bus
−USB
−External interrupts, including one non-maskable
−Timer input
Applications
The XPort AR device server connects serial devices such as those listed below to
Ethernet networks using the IP protocol family.
ATM machines
CNC controllers
Data collection devices
Universal Power Supply (UPS) management units
Telecommunications equipment
Data display devices
Security alarms and access control devices
Handheld instruments
Modems

2: Description and Specifications
XPort AR User Guide 11
Time/attendance clocks and terminals
Protocol Support
The XPort AR device server contains a full-featured TCP/IP stack. Supported
protocols include:
ARP, IP, UDP, TCP, ICMP, BOOTP, DHCP, Auto IP, Telnet, FTP, TFTP, HTTP,
SSH, SSL, SNMP, and SMTP for network communications and management.
TCP, UDP, TCP/AES, UDP/AES, Telnet, and SSH for tunneling to the serial port.
TFTP, FTP, and HTTP for firmware upgrades and uploading files.
Evolution OS™
XPort AR incorporates Lantronix’s Evolution OS™. Key features of the Evolution
OS™ include:
Built-in Web server for configuration and troubleshooting from Web-based
browsers
CLI configurability
SNMP management
XML data transport and configurability
Rich Site Summary (RSS) information feeds
Enterprise-grade security with SSL and SSH
Comprehensive troubleshooting tools
Additional Features
Modem Emulation
In modem emulation mode, the XPort AR can replace dial-up modems. The unit
accepts modem AT commands on the serial port, and then establishes a network
connection to the end device, leveraging network connections and bandwidth to
eliminate dedicated modems and phone lines.
Power over Ethernet (PoE)
The XPort AR supports PoE (also known as the IEEE standard 802.3af).
Conventionally, network devices require a connection to the network and a power
connection. PoE provides power to network devices over an Ethernet connection if
the required hardware is available. The XPort AR passes PoE through the RJ45 to a
connector on the bottom. To enable PoE, take the connections and design a PoE
circuit and regulator to provide power for the device connected to the XPort AR. The
XPort AR passes power not only through unused pairs, but through communications
pairs as well.

2: Description and Specifications
XPort AR User Guide 12
Web-Based Configuration and Troubleshooting
Built upon popular Internet-based standards, the XPort AR enables users to
configure, manage, and troubleshoot efficiently through a simplified browser-based
interface that can be accessed anytime from anywhere. All configuration and
troubleshooting options are launched from a well-organized, multi-page interface.
Users can access all functionality via a Web browser, allowing them flexibility and
remote access. As a result, users can enjoy the advantages of decreased downtime
(based on the troubleshooting tools) and the ability to implement configuration
changes easily (based on the configuration tools).
Command-Line Interface (CLI)
Making the edge-to-enterprise vision a reality, the XPort AR with the Evolution OS™
uses industry-standard tools for configuration, communication, and control. For
example, the Evolution OS™ uses a Command Line Interface (CLI) whose syntax is
very similar to that used by data center equipment such as routers and hubs.
SNMP Management
The XPort AR supports full SNMP management, making it ideal for applications
where device management and monitoring are critical. These features allow networks
with SNMP capabilities to correctly diagnose and monitor XPort AR.
XML-Based Architecture and Device Control
XML is a fundamental building block for the future growth of M2M networks. The
XPort AR supports XML-based configuration setup records that makes device
configuration transparent to users and administrators. The XML is easily editable with
a standard text or XML editor.
Rich Site Summary (RSS)
The XPort AR supports Rich Site Summary (RSS), a rapidly emerging technology for
streaming and managing on-line content. RSS feeds all the configuration changes
that occur on the device. The feed is then read (polled) by an RSS aggregator. More
powerful than simple email alerts, RSS uses XML as an underlying Web page
transport and adds intelligence to the networked device while not taxing already
overloaded email systems.
Enterprise-Grade Security
Without the need to disable any features or functionality, the Evolution OS™ provides
the XPort AR the highest level of security possible. This ‘data center grade’ protection
ensures that each device on the M2M network carries the same level of security as
traditional IT networking equipment in the corporate data center.
By protecting the privacy of serial data being transmitted across public networks,
users can maintain their existing investment in serial technology, while taking
advantage of the highest data-protection levels possible.
SSH and SSL can:
Verify the data received came from the proper source

2: Description and Specifications
XPort AR User Guide 13
Validate that the data transferred from the source over the network has not
changed when it arrives at its destination (shared secret and hashing)
Encrypt data to protect it from prying eyes and nefarious individuals
Provide the ability to run popular M2M protocols over a secure SSH
connection
In addition to keeping data safe and accessible, the XPort AR has robust defenses to
hostile Internet attacks such as denial of service (DoS), which can be used to take
down the network. Moreover, the XPort AR can not be used to bring down other
devices on the network.
The XPort AR can be used with Lantronix’s Secure Com Port Redirector (SCPR) to
encrypt COM port-based communications between PCs and virtually any electronic
device. SCPR is a Windows application that creates a secure communications path
over a network between the computer and serial-based devices that are traditionally
controlled via a COM port. With SCPR installed at each computer, computers that
were formerly “hard-wired” by serial cabling for security purposes or to accommodate
applications that only understood serial data can instead communicate over an
Ethernet network or the Internet.
Troubleshooting Capabilities
The XPort AR offers a comprehensive diagnostic toolset that lets you troubleshoot
problems quickly and easily. Available from the Web Manager, CLI, and XML
interfaces, the diagnostic tools let you:
View critical hardware, memory, MIB-II, buffer pool, and IP socket
information.
Perform ping and traceroute operations.
Conduct forward or backup DNS lookup operations.
View all processes currently running on the XPort AR, including CPU
utilization and total stack space available.
Configuration Methods
After installation, the XPort AR requires configuration. For the unit to operate
correctly on a network, it must have a unique IP address on the network. There are
three basic methods for logging into the XPort AR and assigning IP addresses and
other configurable settings:
DeviceInstaller: Configure the IP address and view network settings on the XPort
AR using a Graphical User Interface (GUI) on a PC attached to a network. (See
3:Using DeviceInstaller.)
Web Manager: Through a web browser, configure the XPort AR’s settings using the
Lantronix Web Manager. (See 4:Configuration Using Web Manager.)
Command Mode: There are two methods to accessing Command Mode: making a
Telnet connection or connecting a terminal (or a PC running a terminal emulation
program) to the unit’s serial port. (See the XPort AR Command Reference Guide for
Command Mode input and available commands.)

2: Description and Specifications
XPort AR User Guide 14
Addresses and Port Numbers
Hardware Address
The hardware address is also referred to as the Ethernet address or MAC address.
The first three bytes of the Ethernet address are fixed and read 00-20-4A, identifying
the unit as a Lantronix product. The fourth, fifth, and sixth bytes are unique numbers
assigned to each unit.
Figure 2-1. Sample Hardware Address
00-20-4A-14-01-18 or 00:20:4A:14:01:18
IP Address
Every device connected to an IP network must have a unique IP address. This
address references the specific unit.
Port Numbers
Every TCP connection and every UDP datagram is defined by a destination and
source IP address, and a destination and source port number. For example, a Telnet
server commonly uses port number 23.
The following is a list of the default server port numbers running on the XPort AR:
TCP Port 22: SSH Server (Command Mode configuration)
TCP Port 23: Telnet Server (Command Mode configuration)
TCP Port 80: HTTP (Web Manager configuration)
TCP Port 443: HTTPS (Web Manager configuration)
UDP Port 161: SNMP
TCP Port 21: FTP
UDP Port 69: TFTP
UDP Port 30718: 0x77FE Query port
TCP/UDP Port 1001: Tunnel 1
TCP/UDP Port 1002: Tunnel 2
Product Information Label
The product information label on the underside of the unit contains the following
information about the specific unit:
Bar code
Serial number
Product ID (name)
Part number

2: Description and Specifications
XPort AR User Guide 15
Hardware address (MAC address)
Figure 2-2. Product Label
Revision
Part Number
MAC Address

XPort AR User Guide 16
3: Using DeviceInstaller
This chapter covers the steps for viewing the XPort AR device server’s properties
and device details.
Accessing XPort AR using DeviceInstaller
Note: Make note of the MAC address. It is needed to locate the XPort AR
using DeviceInstaller.
Follow the instructions on the product CD to install and run DeviceInstaller.
1. Click StartÆPrograms ÆLantronixÆDeviceInstallerÆDeviceInstaller.
2. Click on the XPort AR folder. The list of Lantronix XPort AR devices available
displays.
3. Expand the list of XPorts by clicking the +symbol next to the XPort AR icon.
Select the XPort AR unit by clicking on its IP address to view its configuration.
Viewing the XPort AR’s Current Configuration
1. In the right window, click the Device Details tab. The current XPort AR
configuration displays:
Name Configurable field. Enter a name to identify the XPort AR.
Double-click on the field, type in the value, and press Enter to
complete. This name is not visible on other PCs or laptops
using DeviceInstaller.
Group Configurable field. Enter a group to categorize the XPort AR.
Double-click on the field, type in the value, and press Enter to
complete. This group name is not visible on other PCs or
laptops using DeviceInstaller.
Comments Configurable field. Enter comments for the XPort AR.
Double-click on the field, type in the value, and press Enter to
complete. This description or comment is not visible on other
PCs or laptops using DeviceInstaller.
Device Family Non-configurable field. Displays the XPort AR’s device family
type as XPort AR.
Type Non-configurable field. Displays the device type as XPort AR.
ID Non-configurable field. Displays the XPort AR’s ID embedded
within the box.
Hardware Address Non-configurable field. Displays the XPort AR’s hardware (or
MAC) address.
Firmware Version Non-configurable field. Displays the firmware currently
installed on the XPort AR.

3: Using DeviceInstaller
XPort AR User Guide 17
Extended Firmware
Version Provides additional information on the firmware version.
Online Status Non-configurable field. Displays the XPort AR’s status as
online, offline, unreachable (the XPort AR is on a different
subnet), or busy (the XPort AR is currently performing a task).
Telnet Enabled Displays whether Telnet is enabled on this XPort AR.
Telnet Port Non-configurable field. Displays the XPort AR’s port for telnet
sessions.
Web Enabled Displays whether Web Manager access is enabled on this
XPort AR.
WebPort Non-configurable field. Displays the XPort AR’s port for Web
Manager configuration.
Maximum Baud Rate
Supported Non-configurable field. Displays the XPort AR’s maximum
baud rate.
Note: the XPort AR may not currently be running at this rate.
Firmware Upgradeable Non-configurable field. Displays True, indicating the XPort
AR’s firmware is upgradeable as newer version become
available.
IP Address Displays the XPort AR’s current IP address. To change the IP
address, click on the Assign IP button on the DeviceInstaller
menu bar.
Supports Configurable
Pins Non-configurable field. Displays True, indicating configurable
pins are available on the XPort AR.
Supports Email Triggers Non-configurable field. Displays True, indicating email
triggers are available on the XPort AR.

XPort AR User Guide 18
4: Configuration Using Web Manager
This chapter describes how to configure the XPort AR using Web Manager,
Lantronix’s browser-based configuration tool. The unit’s configuration is stored in
nonvolatile memory and is retained without power. All changes take effect
immediately, unless otherwise noted.
Accessing Web Manager through a Web Browser
Log into the XPort AR using a standard Web browser.
Note: Alternatively, access the Web Manager by selecting the Web
Configuration tab from DeviceInstaller.
To access Web Manager:
1. Open a standard web browser (such as Netscape Navigator 6.x and above,
Internet Explorer 5.5. and above, Mozilla Suite, Mozilla Firefox, or Opera).
2. Enter the IP address of the XPort AR in the address bar. The XPort AR’s built-in
security requires you to log in with your user name and password.
Note: The factory-default user name is admin and the factory-default password is
PASS.
3. The Web Manager home page displays.
Note: The XPort AR Status page (the home page) displays the common
XPort AR configuration and product information.

4: Configuration Using Web Manager
XPort AR User Guide 19
Figure 4-1. Web Manager Home Page
Network Settings
Click the Network link on the left navigation bar to display the Network menu. The
sub-menus displayed allow for the configuration of the general network settings,
protocol stack, DNS, SNMP, FTP, TFTP, IP address filter, and the query port.
Network Configuration
To configure the network’s general configuration:
1. Click Network ÆConfiguration from the navigation menu. The Network
Configuration window displays.

4: Configuration Using Web Manager
XPort AR User Guide 20
Figure 4-2. Network Configuration
2. Enter or modify the following fields:
BOOTP Client Select On or Off. Overrides the configured IP address,
network mask, gateway, hostname, and domain.
Note: When DHCP is set to On, the system automatically uses
DHCP, regardless if BOOTP Client is set to On.
DHCP Client Select On, Off, or Renew. Overrides the configured IP
address, network mask, gateway, hostname, and domain.
IP Address Enter the XPort AR’s static IP address. The static address is
used when BOOTP and DHCP are both set to Off.
Network Mask Enter the XPort AR’s network mask.
Gateway Enter the XPort AR’s gateway address.
MAC Address Enter the XPort AR’s new MAC address.
Hostname Enter the unit’s hostname.
Domain Enter the unit’s domain name.
