Lantronix EDS3000PS User manual

1. HARDWARE OVERVIEW
2. INSTALLATION
EDS3000PS Device Server Quick Start Guide
1. RTS (Out)
2. DTR (Out)
3. TX (Out)
4. GND
5. GND
6. RX (In)
7. DSR (In)
8. CTS (In)
RS-232 Pin Assignment
!Thank you for choosing Lantronix. Please register the EDS3000PS in order to receive nocaons for
rmware and documentaon updates at www.lantronix.com/product-registraon.
EDS3000PSQuick Start Accessories Part Number
Power Cord, 125 V
AC/10 A - 6  cord length 500-215-R
Networking cable, RJ45- DB9
Female Cable to DTE Device,
6  length 500-103-R
START
WHAT’S IN THE BOX
1. Power o the serial device that will be connected to the EDS3000PS.
2. Aach a RJ 45 serial cable between the EDS3000PS and your serial
device.
3. Connect an CAT5E Ethernet cable between the EDS3000PS Ethernet
port and your Ethernet network.
4. Connect the power cord and apply power.
5. Power up the serial device.
EDS3008PS, EDS3016PS Other adapters are available and are sold
separately.
LEDs Descripon
Transmit (Green) Blinking = EDS is transming data on the
serial port.
Receive (Orange) Blinking = EDS is receiving data on the
serial port.
Diagnosc (Green)
Fast blink= Inial startup, loading OS.
Slow blink (once per second) = Operang
system startup.
ON = Unit has nished boong.
Power (Blue) ON = EDS is receiving power.
Ethernet LEDs
Le LED Right LED Descripon
OFF OFF No Link
ON OFF Link 10Mbps or 100Mbps
Blinking OFF Acvity 10Mbps or 100Mbps
ON ON Link 1000Mbps
Blinking ON Acvity 1000Mbps
EDS3016PS Back View
RJ45 Serial Port
Power Connector
Reset Switch
RJ45 Ethernet Port
EDS3016PS Front View
Power LED
Transmit LED
Receive LED
Diagnosc LED
Console Port
Ethernet LEDs

4. IP ADDRESS CONFIGURATION
EDS3000PS Device Server Quick Start Guide
If the EDS3000PS was not assigned an IP address
automacally through DHCP, you must assign one via
CLI. If it was successfully assigned an IP address
through DHCP, you can change the conguraon via
the Web Manager or CLI.
The device’s factory default username is “admin” and
factory default password is the last eight characters of
the Device ID.
To congure the IP address manually, you need the
following informaon:
IP address: ______ . ______ . ______ ._______
Subnet mask: ______ . ______ . ______ ._______
Gateway: ______ . ______ . ______ ._______
DNS: ______ . ______ . ______ ._______
The EDS3000PS must have a unique IP address on
your network. This IP address can be assigned
automacally with DHCP, or you can assign it
manually. The EDS3000PS looks for a DHCP server
when it rst powers up to assign an IP address. You
can use Lantronix Provisioning Manager to locate the
automacally assigned IP address.
1. Download the latest version of Lantronix
Provisioning Manager from
hps://www.lantronix.com/products/
lantronix-provisioning-manager/.
2. Install Lantronix Provisioning Manager.
To congure via Web Manager:
1. Enter the device IP address in the address
bar of a browser.
2. Log in to the EDS3000PS.
3. Change network sengs, if needed, in
Network > Wired Network > Interface >
Conguraon, or perform other
conguraon.
To congure via Command Line:
1. Connect via a terminal emulator over serial or
via Telnet (if the EDS3000PS already has an
IP address).
2. Log in to the EDS3000PS.
3. Change network sengs, if needed, in enable
> cong > if 1, or perform other conguraon.
Contact Technical Support
For technical support queries, visit hps://www.lantronix.com/support or call [phone]
Monday – Friday from 6:00 a.m. – 5:00 p.m., Pacic Time, excluding holidays.
Latest Firmware For the latest rmware downloads, visit hps://www.lantronix.com/support/downloads
© 2021 Lantronix, Inc. Lantronix is a registered trademark of Lantronix, Inc. All other trademarks are the property of respective
owners. Specifications subject to change without notice. 895-0042-00 Rev. B
3. Run Lantronix Provisioning Manager.
4. If this is your rst me running Lantronix
Provisioning Manager, proceed through the
inial setup.
5. Locate your device in the device list and note
the IP address.
For detailed instrucons, see the Lantronix
Provisioning Manager online help at
hps://docs.lantronix.com/products/lpm/.
3. DEVICE DISCOVERY
Lantronix ConsoleFlow™ — Soware plaorm to centrally access and remotely manage your Lantronix
device assets. Visit hps://www.lantronix.com/consoleow to request a free trial.
