Larson Electronics EXP-LED-F4W-R2 User manual

EXP-LED-F4W-R2
INSTRUCTION MANUAL

EXP-LED-F4W-R2
Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
1 of 3
Explosion Proof LED Flashlight - C1D1 - 325 Lm/High, 125 Lm/
Low - (3) AA Batteries, Magnetic Base/Clip - IPX7 Waterproof
Instruction Manual
Thank you for your purchase of the EXP-LED-F4W-R2 from Larson Electronics.
WARNING: MAKE SURE POWER ISTURNED OFF BEFORE INSTALLING
BATTERIES OR PERFORMING ANY MAINTENANCE.
RISK OF FIRE/ELECTRIC SHOCK –TURN OFF POWER AT SWITCH BEFORE INSTALLING BATTERIES OR SERVICING.
RISK OF PERSONAL INJURY –FLASHLIGHT MAY BECOME UNSTABLE OR DAMAGED IF NOTUSED PROPERLY.
RISK OF BURN –ALLOW FLASHLIGHT TO COOL BEFORE SERVICING.
Never place spotlight face down when light ison. Doing so could burn/ignite surfaces such as seats, carpeting, etc. and
cause major property damage. Always turn spotlight off when not inuse.
Avoid direct eye exposure the light source when light ison. DO NOTshine light into the face of someone else.
DO NOTtouch lens of light when on or recently on. The lens/cooling fins will be hot after long periods.
DO NOTallow children to handle or operate this light.
DO NOTuse this product for other than its intended use.
DO NOToperate in close proximity of combustible or flammable materials.
DO NOTattempt to operate this light if cord, plug, battery, lens or any part of the light isdamaged or corroded.
MAGNETIC WARNING
WARNING
TO AVOID THE RISK OFFIRE, EXPLOSION OR ELECTRIC SHOCK, THIS PRODUCT SHOULD BE INSTALLED,
INSPECTED AND MAINTAINED BY A QUALIFIED ELECTRICIAN ONLY, IN ACCORDANCE WITH ALL
APPLICABLE ELECTRICAL CODES.
TO AVOID ELECTRIC SHOCK:
•BE CERTAIN ELECTRICAL POWER IS OFF BEFORE AND DURING INSTALLATION AND MAINTENANCE.
•PRODUCT MUST BE CONNECTED TO A WIRING SYSTEM WITH AN EQUIPMENT-GROUNDING
CONDUCTOR.
TO AVOID EXPLOSION:
•MAKE SURE THE SUPPLY VOLTAGE IS WITHIN THE VOLTAGE RATING.
•ENSURE THE MARKED T RATING IS LESS THAN THE IGNITION TEMPERATURE OF THE HAZARDOUS
ATMOSPHERE.
•DO NOT OPERATE IN AMBIENT TEMPERATURES ABOVE THOSE INDICATED ON THE PRODUCT
NAMEPLATE.
•DO NOT OPERATE IF THE LENS, CORD, SEALS, HOUSING, RECEPTACLES, ETC. IS CRACKED OR
DAMAGED. IF SO, DISCONTINUE USE AND CONTACT MANUFACTURER FOR REPLACEMENT PARTS.
•ALL FASTENERS SHOULD BE PROPERLY SEATED.
•PEOPLE WITH PACEMAKERS SHOULD CONSULT THEIR PHYSICIAN(S) BEFORE USE.
ELECTROMAGNETIC FIELDS INCLOSE PROXIMITY TOHEART PACEMAKER COULD CAUSE
PACEMAKER INTERFERENCE OR PACEMAKER FAILURE.
•KEEP FINGERS AWAY FROM MAGNET WHEN MOUNTING ASINJURY COULD OCCUR.

Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
2 of 3
BATTERY INSTALLATION
1. Unscrew the flashlight tail cap.
2. Insert (3) AA alkaline batteries paying attention to
positive/negative markings on interior of battery
chamber.
3. Screw the tail cap back on making sure not to over
tighten.
MOUNTING
The EXP-LED-F4W-R2 can be mounted and carried
in several different ways.
•Handheld - Operators can use the flashlight in
a handheld fashion for many tasks.
•Base Magnet - Operators can mount the
flashlight on flat, magnetic surfaces for
convenient, hands-free operation.
•Belt Clip - Operators can attach the flashlight
to a belt for carrying between uses.
•Belt Clip Magnet - Operators can utilize the
belt clip magnet to attach the flashlight to a
magnetic area on a belt or tool belt for quick
access.
•Lanyard Slot - Operators can attach a lanyard
(not included) to the lanyard slot on the tail cap.
OPERATION
1. Press the light switch once to put the flashlight
into high mode (325 lumens).
a. The flashlight will run for 7 continuous
hours in high mode.
2. Press the light switch again to put the
flashlight into low mode (125 lumens).
a. The flashlight will run for 24
continuous hours in low mode.
3. Press the light switch a third time to turn the
flashlight off.
EXP-LED-F4W-R2

Larson Electronics, LLC
Phone: [phone]
Fax: [phone] www.larsonelectronics.com
3 of 3
MAINTENANCE
Caution: To avoid personal injury, disconnect power to the light and allow the unit to cool down before
performing maintenance.
Warning: No user serviceable parts inside of fixture. Risk of electric shock. Removal of the lens will void
the warranty.
1. Perform visual,mechanical and electrical inspections on a regular basis.We recommend routine
checks to be made on a yearly basis. Frequency of use and environment shoulddetermine this. It is
recommendedto follow an Electrical Preventive Maintenance Program as described in NFPA 70B:
Recommendedpractice for Electrical Equipment.
2. The lens should be cleaned periodically as neededto ensure continued photometric performance.
Clean the lens with a damp, non-abrasive,lint-free cloth. If not sufficient, use mild soapor a liquid
cleaner.
3. Do not operate if the lens is cracked or damaged. All fasteners shouldbe properly seated.
USE AND CARE
Unauthorized modification may impair the function and/or safety of this device and could affect the life of the equipment.
Always check for damaged or worn out parts before using the device. Store it in a secure place out of the reach of
children when not in use.Inspect for good working condition prior to storage and before re-use.
REPLACEMENT PARTS
The EXP-LED-F4W-R2 is designed to provide years of reliable performance. Should the need for replacement parts
arise, please contact Larson Electronics.
EXP-LED-F4W-R2
THESE INSTRUCTIONS MAY NOT COVER ALL DETAILS OR VARIATIONS OF THIS PRODUCT FOR YOUR EQUIPMENT OR INSTALLATION REQUIREMENTS.
SHOULD FURTHER INFORMATION NOT COVERED BY THESE INSTRUCTIONS BE REQUIRED, PLEASE CONTACT LARSON ELECTRONICS BY EMAIL AT
SAL[email protected] OR BY PHONE AT 1-877-348-9680 FOR FURTHER ASSISTANCE.
PLEASE VISIT LARSONELECTRONICS.COM FOR WARRANTY AND RETURN INFORMATION.
